USER
GUIDE
IMPACT 24
801.100B
USG/024/AE-B
14.06.95
Not actual front page
USER GUIDE
IMPACT 24
USER GUIDE LCD PANEL
2
USER GUIDE LCD PANEL
3
TABLE OF CONTENTS
INTRODUCTION .....................................................................................5
MAIN FEATURES....................................................................................5
SUPPLIED MATERIAL.............................................................................6
OPTIONAL MATERIAL............................................................................6
SETTING UP THE LCD PANEL ...............................................................7
COMPUTER...............................................................................8
MOUSE......................................................................................9
AUDIO AND VIDEO.................................................................. 10
USING THE LCD PANEL....................................................................... 11
REMOTE CONTROL................................................................ 11
FRONT PANEL ........................................................................ 13
CONNECTORS........................................................................ 13
FEATURES............................................................................................ 14
MENU SYSTEM..................................................................................... 19
PRACTICAL HINTS AND TIPS............................................................... 24
MAINTENANCE..................................................................................... 26
SERVICE............................................................................................... 26
TECHNICAL DATA ................................................................................ 27
CONNECTORS ..................................................................................... 30
FCC STATEMENT................................................................................. 32
ENVIRONMENTAL STATEMENT........................................................... 33
SERVICE INFORMATION...................................................................... 34
CONNECTION LAYOUT........................................................................ 35
(Rear Foldout)
USER GUIDE LCD PANEL
4
This publication is printed on recycled paper.
The information contained in this user guide is preliminary, and the products described
herein are subject to change without prior notice..
USER GUIDE LCD PANEL
5
1INTRODUCTION
The LCD panel is a state of the art projection device that can be connected
to most computer and video sources.
The ability to display a multitude of colors simultaneously, makes it the
ideal choice for presenting computer generated text and graphics, as well
as displaying live video.
Applications include presentations, software training, educational use,
advertising, information boards and other situations where a small or
large audience shares information.
2MAIN FEATURES
-PC, MAC and SVGA compatible
-Built in Video
-Multistandard NTSC/PAL/SECAM
-Correct PAL/SECAM aspect ratio
-16.7 million colors
-BatMouse™, infrared remote mouse
-On Screen Display (OSD)
-On Screen Pointer
-Menu control
-User settings memorized
-Correct VGA text
-Infrared remote control
- Housing footprint fits OHP glass exactly
-Low weight
-Intelligent Safecool system
-False light blocking
-4 meters Y-cable
USER GUIDE LCD PANEL
6
3SUPPLIED MATERIAL
A complete set includes the following components :
1. LCD Panel 8. Mouse Adapter Mac
2. AV Cable 9. Power -5, 12, 5 V
3. VGA Cable 10. Power Cable
4. Cable-Adapt. MACII mon 11. BatMouse Remote Control
5. Cable-Adapt. MACII comp. 12. Batteries
6. Mouse Cable 13. Attachè Case
7. Mouse Adapter seriell 14. User Guide
4OPTIONAL MATERIAL
Optional cables and adapters are available for special computer sources.
USER GUIDE LCD PANEL
7
5SETTING UP THE LCD PANEL
Switch off all equipment before connecting the components. Be aware of
static electricity that may build up, especially in the dry season and when
operating on synthetic carpets. Discharge any static electricity by touching
a metallic surface before you start.
Place the LCD panel on top of a transmissive overhead projector (OHP).
Select a high intensity type projector, for instance 400 W halogen or metal-
halide. Best results are obtained in a dimmed room with no direct sunlight
shining in.
The following are guidelines for first time set-up:
Connect the cables and power supply as described below (see rear
foldout).
Attach power to the LCD panel, turn the overhead projector and computer
on. If you are going to use a mouse, make sure to power the LCD panel
first. For more information on set-up see the following sections on
Computer/Mouse/Audio and Video.
USER GUIDE LCD PANEL
8
5.1 COMPUTER
Connect the LCD panel, computer, monitor and power supply as shown in
the rear foldout.
Connect cable (4) between the LCD panel and the computer. Use the Y-
split on the computer end to connect the monitor.
If you have a Macintosh, EGA, CGA or NEC computer, insert applicable
adapters (7) and (8) as described in the table below.
Connect the power supply to the LCD panel (6).
APPLICABLE ADAPTERS:
COMPUTER ADAPTER
VGA None
EGA/CGA EGA/CGA (option)
MACII c../v../LC/ Quadra/Powerbook/ Duo etc. MACII (640 x 480)
(included)
NEC 9801 NEC 9801(option)
TO SET UP FROM THE REMOTE CONTROL:
STEP OPERATION
1Press RESET for default settings
2Press MENU, then select TUNE and adjust with cursor keys
3In the menu, select POSITION, press the LEFT key, then
adjust with cursor keys
4Press MENU again to close the menu
5Adjust CONTRAST and BRIGHTNESS as desired
USER GUIDE LCD PANEL
9
5.2 MOUSE
See the rear foldout when setting up.
Connect the mouse to the LCD panel using the appropriate adapter (9) as
described in the table below. Then connect the adapter (9) to the mouse
cable at the computer end. Finally, connect the mouse cable to the LCD
panel (5).
For the computer to recognise the mouse, connect the mouse before
power is applied.
A Y-split is provided with the PC and MAC adapters that enables parallel
use of the local computer mouse and the remote mouse. The local and
remote mice should however not be operated simultaneously, as this may
lead to unpredictable positioning of the mouse pointer.
If you have a Macintosh, make sure to connect your Mac mouse adapter
via the keyboard.
The PS/2 adapter does not have a Y-split.
APPLICABLE ADAPTERS :
MOUSE ADAPTER
Microsoft 2 key compatible (9 pin serial port) PC
PS/2 compatible mouse PS/2
Macintosh ADB-bus mouse MAC
USING THE REMOTE CONTROL BATMOUSE:
STEP OPERATION
1Control mouse pointer directly with the cursor keys
2Press LEFT to activate (emulates the left mouse key)
3Press DRAG to tag an object, move it using the cursor keys,
then press DRAG again (or wait 5 seconds) to release the
object.
4Press RIGHT if your application requires emulation of the
right mouse key.
The centre key of three-key mice is not emulated.
If double-click does not work properly, try to adjust the double-click rate
within the computer application in use.
