APC-3X97Auser manual

APC-3X97A Panel PC

User Manual

Release Date Revision

Apr 2012 V1.0

Aplex Technology, Inc.

15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan

Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: [email protected] URL: www.aplex.com.tw

APC-3X97Auser manual

Warning!___________________________________

Safety & Warranty

1. Read these safety instructions carefully.

2. Keep this user's manual for later reference.

3. Disconnect this equipment from any outlet before cleaning. Do not use liquid or spray

detergents for cleaning. Use a damp cloth.

4. For pluggable equipment, the power outlet must be installed near the equipment and must be

easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall could

cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment from overheating.

DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the equipment to the

power outlet.

9. All cautions and warnings on the equipment should be noted.

10. If the equipment is not used for a long time, disconnect it from the power source to avoid

damage by transient over-voltage.

11. Never pour any liquid into an opening. This could cause fire or electrical shock.

12. NEVER OPEN THE EQUIPMENT. FOR SAFETY REASONS, ONLY QUALIFIED SERVICE

PERSONNEL SHOULD OPEN THE EQUIPMENT.

13. If any of the following situations arises, get the equipment checked by service personnel:

�The power cord or plug is damaged.

�Liquid has penetrated into the equipment.

�The equipment has been exposed to moisture.

�The equipment does not work well, or you cannot get it to work according to the users manual.

�The equipment has been dropped and damaged.

�The equipment has obvious signs of breakage.

14. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE STORAGE

TEMPERATURE IS BELOW -20°C OR ABOVE 70°C. IT MAY DAMAGE THE EQUIPMENT.

APC-3X97Auser manual

This equipment generates uses and can radiate radio frequency energy and if not installed and

used in accordance with the instructions manual, it may cause interference to radio

communications.

It has been tested and found to comply with the limits for a Class A computing device pursuant to

FCC Rules, which are designed to provide reasonable protection against such interference when

operated in a commercial environment. Operation of this equipment in a residential area is likely

to cause interference in which case the user at his own expense will be required to take whatever

measures may be required to correct the interference.

Disclaimer

This information in this document is subject to change without notice. In no event shall Aplex Technology

Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or

misuse of information in this document or in any related materials.

Electric Shock Hazard –Do not operate the machine with its back cover removed. There are

dangerous high voltages inside.

APC-3X97Auser manual

Table of Contents______________________

Warning!…………………………………………………………………………….……..….2

Disclaimer………………………………………………………………….…………………2

Chapter 1 Getting Started

1.1 Features…......…………….……………………………………..…..…...…6

1.2 Specifications………………………………………….………………...…..6

1.3 Brief Description ……………………………...……………………………8

1.4 Chassis Dimensions..…………………………………………………..…..9

Chapter 2 Mainboard

2.1 Mainboard Specifications….……………………….………………...........12

2.2 Onboard Jumpers and Port Pinouts……….……………….…….…….......18

Chapter 3 AMI BIOS Setup

3.1 Operations after POST Screen................................................27

3.2 Standard CMOS Features..............................................28

3.3 Advanced BIOS Features.....................................................31

3.4 Advanced Chipset Features Setup............................... 34

3.5 Integrated Peripherals................................................................... 37

3.6 Power Managements Setup................................................. 42

3.7 PnP/PCI Configurations Setup...................................................... 45

3.8 PC Health Status…................................................................ 47

3.9 Load Fail-Safe/Optimized Defaults.............................................. 48

3.10 Set Administrator/User Password....................................... 50

3.11 Save & Exit Setup……………............................................. 50

3.12 Exit Without Saving…………………………………….……………………. 51

Chapter 4

4.1 SuperIO Model.................................................................................................52

APC-3X97Auser manual

4.2 W83627UHG Access index port...................................................52

4.3 Configure GPIO register sequence................................................................52

4.4 Read/write GPIO sequence………………………………………………….......52

4.5 Software programming example....................................................................52

Chapter 5

5 Watchdog Source Code...................................................................................59

Chapter 6 Installation of Drivers

6.1 Intel Chipset Drivers .....……………….……………………………….63

6.2 Intel Graphics Media Accelerator Driver……..……………………….66

6.3 RealTek Gigabit LAN Driver………………………………………….70

6.4 Realtek HD Driver Installations…………………………………… 73

Chapter 7 Touch Driver Installation

7.1 Windows 2000/XP Driver Installation for Controller Board.……….….76

7.2 Configuring PenMount Windows 2000/XP Driver……………………..76

Figures

Figure 1.1: Front View ………………….……………………………..…………8

Figure 1.2: Rear View…………...…………………………………………………8

Figure 1.3: Dimensions of the APC-3597A ...........…………………………………9

Figure 1.4: Dimensions of the APC-3797A ………………………… ………..…10

Figure 1.5: Dimensions of the APC-3997A.........................................................11

Figure 2.1: Mainboard Overview….………………..….……………………..……..12

Figure 2.2: Mainboard Dimensions…………………………………………………13

Figure 2.3: Connector and Jumper Locations……………………………………15

Figure 7.1: Bird’s Eye View of Control Board....................................................76

APC-3X97Auser manual

Chapter 1_____________________________

1.1 Features

Fanless Design

Intel Atom N270 1.6GHz Processor, FSB 533MHz

One 200 Pin SO-DIMM socket, up to 2GB DDR2 533MHz SDRAM

11~32V DC wide range power input

Total NEMA4/IP65 compliant

Sealed 5-Wire Resistive Touch Screen, Optional for GFG Resistive Touch Screen

1.2 Specifications

System

Processor

Intel Atom Processor N270 1.6GHz built-in, FSB533MHz

System Memory

1 x 200-pin SO-DIMM socket, support 533MHz up to 2GB SDRAM

System Chipset

Intel 945GSE + Intel ICH7M

External I/O Port

Standard I/O:

2 x USB 2.0 connectors

1 x RJ-45 LAN connector

1 x DB-9 RS-232 (COM 1) connector

1 x DB-9 RS-232/422/485 connector (COM 2), Default RS-232

1 x DC Power input

Full Function I/O:

1 x VGA DB-15 port

1 x Audio Line-out port

Solid Storage Disk

1 x CF Slot (internal)

1 x 2.5” HDD bay for SATA HDD

OS Support

Windows XP Professional, XP Embedded

LCD

Display Type

TFT-LCD

Max. Resolution

15”1024x768 (APC-3597A)

17”/19”1280x1024 (APC-3797A/3997A)

Max. Color

262K

Luminance (cd/m2)

350 (cd/m2)(APC-3597A)

300 (cd/m2)(APC-3797A/3997A)

ViewAngle

H:120°/ V:100°(APC-3597A)

H:160°/ V:170°(APC-3797A)

APC-3X97Auser manual

H:160°/ V:160°(APC-3997A)

Backlight Lifetime

50,000hrs

Touch Screen

Type

Resistive Type

Light Transmission

80%

Power Supply

Power Input

DC 11~32V

Mechanical

Construction

Stainless Steel

IP Rating

Total IP65

Mounting

VESA 75x75 (APC-3597A/3797A)

VESA 100x100 (APC-3997A)

Dimension

399 (W) x324(H) x 53 (D) mm (APC-3597A)

432 (W) x358(H) x 57 (D) mm (APC-3797A)

470 (W) x389(H) x 60 (D) mm (APC-3997A)

Environmental

Operating Temperature

0~50 ﾟC

Storage Temperature

-20~60 ﾟC

Storage Humidity

10~90% @40℃non-condensing

Certificate

Meet CE/FCC Class A

APC-3X97Auser manual

1.3 Brief Description of the APC-3X97A

The chassis of theAPC-3X97A is made of stainless steel with an ultra slim profile. It is built in the Intel

Atom N270 1.6GHz, FSB 533MHz, it is fanless. The model comes with a 15”~19”inch TFT LCD

display, total NEMA 4/IP65 compliant, space for one 2.5-inch HDD, resistive touch screen, a DC

11~32V wide range power input. This industrial panel PC also features 2 COM ports, 2 USB ports and

1 x Gigabit LAN port. It is ideal for use as a PC-based controller for Automotive, Logistic Process,

Materials Handling, and Kiosk applications.

Figure 1.1: Front View of APC-3997A

Figure 1.2: Rear View of APC-3997A

APC-3X97Auser manual

1.4 Chassis Dimensions

Figure 1.3: Dimensions of the APC-3597A

APC-3X97Auser manual

Figure 1.4 Dimensions of the APC-3797A
