Aplex APC-3X19 Manuel utilisateur
APC-3X19 User Manual
1
APC-3X19
User Manual
Release Date Revision
Jan 2013 V1.0
® 2013 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
APC-3X19 User Manual
2
Warning!_______________________________
This equipment generates, uses and can radiate radio frequency energy and if not installed and
used in accordance with the instructions manual, it may cause interference to radio
communications.
It has been tested and found to comply with the limits for a Class A computing device pursuant to
FCC Rules, which are designed to provide reasonable protection against such interference when
operated in a commercial environment. Operation of this equipment in a residential area is likely to
cause interference in which case the user at his own expense will be required to take whatever
measures may be required to correct the interference.
Disclaimer
This information in this document is subject to change without notice. In no event shall Aplex
Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising
from either the use or misuse of information in this document or in any related materials.
Electric Shock Hazard –Do not operate the machine with its back cover removed. There are
dangerous high voltages inside.
APC-3X19 User Manual
3
Packing List
Accessories (as ticked) included in this package are:
□AC power cable
□Driver & manual CD disc
□Other.___________________(please specify)
Safety Precautions
Follow the messages below to avoid your systems from damage:
◆Avoid your system from static electricity on all occasions.
◆Prevent electric shock. Don‘t touch any components of this card when the card is
power-on. Always disconnect power when the system is not in use.
◆Disconnect power when you change any hardware devices. For instance, when you
connect a jumper or install any cards, a surge of power may damage the electronic
components or the whole system.
APC-3X19 User Manual
4
Table of Contents______________________
Warning!…………………………………………………………………………….……..….2
Disclaimer………………………………………………………………….…………………2
Packing List...................................................................................................................3
Safety Precautions........................................................................................................3
Chapter 1 Getting Started
1.1 Specifications………………………………………….………….……...…..6
1.2 Dimensions…………………………………...……………….…………......8
1.3 Brief Description of APC-3X19………...………………….………………10
Chapter 2 Hardware Installation
2.1 Mainboard Specifications………………………..…………….…………16
2.2 Jumpers Setting and Connectors………………………….……………19
Chapter 3 BIOS Setup
3.1 Operations after POST Screen.............................................................35
3.2 BIOS SETUP UTILITY................................................................35
3.3 System Overview.......................................................................36
3.4 Advanced Settings................................................................... 37
3.5 Chipset Settings................................................................................... 44
3.6 Boot Settings....................................................................................... 53
3.7 Security Settings.................................................................................. 54
3.8 Save & Exit Settings............................................................................ 55
Chapter 4 Installation of Drivers
4.1 Intel Chipset Driver.…………………………...……………………………59
APC-3X19 User Manual
5
4.2 Intel (R) VGA Chipset Driver..…................…......……………….......…..62
4.3 Intel(R) Network adapter Driver…........…..................................……….67
4.4 Realtek HD Audio Driver Installation………………….…………………71
4.5 Microsoft .NET Framework 3.5 Service.................................................73
Chapter 5 Touch Screen Installation
5.1 Introduction to Touch Screen Controller Board………………………....75
5.2 Windows 2000/XP USB Driver Installation………………….………..….75
Figures
Figure 1.1: Dimensions of APC-3519………...……………………………...8
Figure 1.2: Dimensions of APC-3719………...……………………………...8
Figure 1.3: Dimensions of APC-3919………...……………………………...9
Figure 1.2: Overview of APC-3X19 ……….……..…………………………...10
Figure 2.1: Mainboard Overview……………………………………..……..…16
Figure 2.2: Mainboard Dimensions……………………………………………17
Figure 2.3: Jumpers and Connectors Location-TOP…………………...……19
Figure 2.4: Jumpers and Connectors Location- Bottom………………….…20
Figure 5.1: Bird’s Eye View of Control Board…………………………….......75
APC-3X19 User Manual
6
Chapter 1________________Getting Started
1.1 Specifications
Model No.
Specs
APC-3519
APC-3719
APC-3919
System
Processor
Support Socket G2, 2nd Generation Intel Core i7/i5/i3,
up to i7 Quad core 2710QE
System Chipset
Intel QM67 PCH
System Memory
2 x SO-DIMM(204pins) up to 16GB DDRIII 1066/1333MHz FSB
Storage
2 x 2.5" SATA HDD space
External I/O Port
Onboard
2 x DB9 RS-232 (COM1.2)
1 x DVI-I
1 x HDMI
2 x RJ45 GbE LAN
4 x USB 2.0
1 x Mic-in, Line-Out
1 x DC Power 3 Pin terminal block connector
1 x 2 Pin remote power switch connector
2 x LED indication
--------------------------------------------------------------------------------------------------------
By cable
1 x RS-232 COM4
1 x RS-422/485 default RS-485 COM3
1 x CF slot
2 x USB 2.0 Ports (APC-3919 only)
1 x Rocker switch for power on/off
1 x 8 Pin terminal block 3 in/out/VCC/Ground for option
Expansion Slots
1 x PCIe x16 or 1 x PCI slot, default 1 x PCIe x16
OS support
Windows XP embedded, Windows embedded standard 7, Windows 7 Pro for
embedded
LCD
Display Type
15”
17”
19”
Max. Resolution
1024X768
1280X1024
1280X1024
Max. Color
262K
16.7M
16.7M
Luminance (cd/m2)
400
350
350
APC-3X19 User Manual
7
View Angle
160:145
170:160
170:165
Backlight Lifetime
50,000 hrs
Touch Screen
Type
Resistive Touch
Light Transmission
80%
Power Supply
Power Input
DC 9~32V
Mechanical
Construction
Steel black
IP Rating
Front Panel IP65
Mounting
Panel mount/VESA 75 x 75/VESA 100 x 100
Dimensions (WxHxD)
(mm)
410x310x116
439x348x119
484x400x119
Environmental
Operating Temperature
0~50 ﾟC
Storage Temperature
-20~60 ﾟC
Storage Humidity
10~90% @40 ﾟC non-condensing
Certificate
CE/FCC Class A
APC-3X19 User Manual
8
1.2 Dimensions
Figure 1.1: Dimensions of APC-3519
Figure 1.2: Dimensions of APC-3719
APC-3X19 User Manual
9
Figure 1.3: Dimensions of APC-3919
APC-3X19 User Manual
10
1.3 Brief Description of APC-3X19
The APC-3x19 is the fanless and high performance panel-mount industrial panel PC with 15”/17/19”
TFT LCD. It powered by QM67 chipset and support Core i3/i5/i7 Processor up to i7 Quad core
2710QE. The panel PC has a rich variety of functions and peripherals. It comes with 2 x 2.5-inch hard
disk drive and 1 x CF space for data storage , support DDR3 memory up to 16G, support rich i/O, wide
range 9~32V DC input, and also provide 1 x PCIe x 16 slot, it can ensure simplified connectivity to a
variety of external peripheral devices. The OS supports windows XP embedded, Windows embedded
standard 7. The unit deal for a wide range of applications including digital surveillance, data/image
acquisition, factory automation and industrial applications.
Figure 1.5: Overview of APC-3X19
