APC-3x82/83 User Manual
1
APC-3x82/83
User Manual
Release Date Revision
Jan 2013 V1.0
® 2013 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
APC-3x82/83 User Manual
2
Warning!_______________________________
This equipment generates, uses and can radiate radio frequency energy and if not installed and
used in accordance with the instructions manual, it may cause interference to radio
communications.
It has been tested and found to comply with the limits for a Class A computing device pursuant to
FCC Rules, which are designed to provide reasonable protection against such interference when
operated in a commercial environment. Operation of this equipment in a residential area is likely to
cause interference in which case the user at his own expense will be required to take whatever
measures may be required to correct the interference.
Disclaimer
This information in this document is subject to change without notice. In no event shall Aplex
Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising
from either the use or misuse of information in this document or in any related materials.
Electric Shock Hazard –Do not operate the machine with its back cover removed. There are
dangerous high voltages inside.
APC-3x82/83 User Manual
3
Packing List
Accessories (as ticked) included in this package are:
□AC power cable
□Driver & manual CD disc
□Other.___________________(please specify)
Safety Precautions
Follow the messages below to avoid your systems from damage:
◆Avoid your system from static electricity on all occasions.
◆Prevent electric shock. Don„t touch any components of this card when the card is
power-on. Always disconnect power when the system is not in use.
◆Disconnect power when you change any hardware devices. For instance, when you
connect a jumper or install any cards, a surge of power may damage the electronic
components or the whole system.
APC-3x82/83 User Manual
4
Table of Contents______________________
Warning!…………………………………………………………………………….……..….2
Disclaimer………………………………………………………………….…………………2
Packing List...................................................................................................................3
Safety Precautions........................................................................................................3
Chapter 1 Getting Started
1.1 Specifications………………………………………….………….……...…..6
1.2 Dimensions…………………………………...……………….…………......8
1.3 Brief Description of APC-3X82/3X83.………………….………………12
Chapter 2 Hardware Installation
2.1 Mainboard Specifications………………………..…………….…………13
2.2 Jumpers Setting and Connectors………………………….……………17
Chapter 3 BIOS Setup
3.1 Operations after POST Screen.............................................................26
3.2 BIOS SETUP UTILITY................................................................27
3.3 System Overview.......................................................................28
3.4 Advanced Settings................................................................... 29
3.5 Advanced PCI/PnP Settings................................................................ 37
3.6 Boot Settings....................................................................................... 40
3.7 Security Settings.................................................................................. 42
3.8 Advanced Chipset Settings.................................................................. 43
3.9 Exit Options..........................................................................................49
3.10 Examples of GPIO Programming.......................................................50
APC-3x82/83 User Manual
5
Chapter 4 Installation of Drivers
4.1 Intel Chipset Driver.…………………………...……………………………59
4.2 Intel GMA 3150 VGA Chipset Driver..…....…......……………….......…..62
4.3 Intel 82574L Network adapter Driver……..................................……….66
4.4 Realtek HD Audio Driver Installation………………….…………………69
Chapter 5 Touch Screen Installation
5.1 Introduction to Touch Screen Controller Board………………………....72
5.2 Windows 2000/XP USB Driver Installation………………….………..….72
Figures
Figure 1.1: Dimensions of APC-3282/APC-3283……………………………...8
Figure 1.2: Dimensions of APC-3582/APC-3583.....……………………...9
Figure 1.3: Dimensions of APC-3782/APC-3783……...………………..10
Figure 1.4: Dimensions of APC-3982/APC-3983…………...………………..11
Figure 1.5: Overview of APC-3X82 ……..…………………………...12
Figure 1.6: Overview of APC-3X83.........................................12
Figure 2.1: Mainboard Overview……………………………………..……..…13
Figure 2.2: Mainboard Dimensions……………………………………………13
Figure 2.3: Jumpers and Connectors Location-TOP…………………...……14
Figure 2.4: Jumpers and Connectors Location- Bottom………………….…14
Figure 5.1: Bird‟s Eye View of Control Board…………………………….......72
APC-3x82/83 User Manual
6
Chapter 1________________Getting Started
1.1 Specifications
Model No.
Specs
APC-3282/3283
APC-3582/3583
APC-3782/3783
APC-3982/3983
System
Processor
Intel Atom D525 1.8GHz processor FSB 800MHz
System Chipset
Intel ICH8M Chipset
System Memory
1 x 204 Pin SO-DIMM DDR3 800GHz, up to 2GB SDRAM
Storage
1 x 2 .5" SATA HDD Space
1 x CF Internal Slot
1 x CF External Slot for option (except APC-3282/3283)
External I/O Port
4XUSB 2.0
2XGbE RJ-45 LAN port
1XDB-15 VGA (disable for use)
1XDB-9 RS422/485(default RS-485)
1XDB-9 RS-232
1XDC Power input T/B connector
7 Pin T/B for 2in/out/1Ground/Switch±
Expansion Slots
None
OSD
OSD control
Brightness/ Screen and Touch on/off /Power on/off
(APC-3782/3783/3982/3983 add auto tune function key)
OS support
Windows XP Pro, XP Embedded, Windows Embedded Standard 7
LCD
Display Type
12.1”TFT-LCD
15”TFT-LCD
17”TFT-LCD
19”TFT-LCD
Max. Resolution
800x600
1024x768
1280x1024
1280x1024
Max. Color
262K
Luminance (cd/m2)
350
400
350
350
View Angle
H:130°/ V:110°
H:160°/ V:140°
(APC-3582)
H:140°/ V:110°
(APC-3583)
H:170°/ V:160°
H:160°/ V:160°
Backlight Lifetime
50,000 hrs
Touch Screen
Type
Resistive Touch
Light Transmission
80%
Power Supply
Power Input
DC 11~32V
APC-3x82/83 User Manual
7
Mechanical
Construction
Stainless Steel Housing (APC-3X82) / Steel Housing (APC-3X83)
IP Rating
Front Panel IP65 / 6 sides IP42 with waterproof kit
Mounting
VESA 75x75
Mount
VESA 75x75
Mount
VESA 75x75
Mount
VESA 100x100
Mount
Dimensions (WxHxD)
335(W)x265(H)
x67(D) mm
399(W)x324(H)x
67(D) mm
432(W)x358(H)x
66.8(D)mm
470(W)x388.6(H)x
67(D)mm
Environmental
Operating Temperature
0~50 ﾟC
Storage Temperature
-20~60 ﾟC
Storage Humidity
10~90% @40 ﾟC non-condensing
Certificate
CE/FCC Class A
APC-3x82/83 User Manual
8
1.2 Dimensions
Figure 1.1: Dimensions of APC3282/ APC-3283
APC-3x82/83 User Manual
9
Figure 1.2: Dimensions of APC-3582/APC-3583
APC-3x82/83 User Manual
10
Figure 1.3: Dimensions of APC-3782/APC-3783
