APC-3X98(A) User Manual

APC-3098/3298A/3598A

Panel PC User Manual

Release Date _ Revision

Jun. 2011 V1.0

Aplex Technology, Inc.

15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan

Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: [email protected] URL: www.aplex.com.tw

APC-3X98(A) User Manual

Warning!____________________________________

Safety & Warranty

1. Read these safety instructions carefully.

2. Keep this user's manual for later reference.

3. Disconnect this equipment from any outlet before cleaning. Do not use liquid or spray

detergents for cleaning. Use a damp cloth.

4. For pluggable equipment, the power outlet must be installed near the equipment and must be

easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall could

cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment from overheating.

DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the equipment to the

power outlet.

9. All cautions and warnings on the equipment should be noted.

10. If the equipment is not used for a long time, disconnect it from the power source to avoid

damage by transient over-voltage.

11. Never pour any liquid into an opening. This could cause fire or electrical shock.

12. NEVER OPEN THE EQUIPMENT. FOR SAFETY REASONS, ONLY QUALIFIED SERVICE

PERSONNEL SHOULD OPEN THE EQUIPMENT.

13. If any of the following situations arises, get the equipment checked by service personnel:

�The power cord or plug is damaged.

�Liquid has penetrated into the equipment.

�The equipment has been exposed to moisture.

�The equipment does not work well, or you cannot get it to work according to the users manual.

�The equipment has been dropped and damaged.

APC-3X98(A) User Manual

�The equipment has obvious signs of breakage.

14. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE STORAGE

TEMPERATURE IS BELOW -20°C OR ABOVE 70°C. IT MAY DAMAGE THE EQUIPMENT.

This equipment generates uses and can radiate radio frequency energy and if not installed and

used in accordance with the instructions manual, it may cause interference to radio

communications.

It has been tested and found to comply with the limits for a Class A computing device pursuant to

FCC Rules, which are designed to provide reasonable protection against such interference when

operated in a commercial environment. Operation of this equipment in a residential area is likely

to cause interference in which case the user at his own expense will be required to take whatever

measures may be required to correct the interference.

Disclaimer

This information in this document is subject to change without notice. In no event shall Aplex

Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising

from either the use or misuse of information in this document or in any related materials.

Electric Shock Hazard –Do not operate the machine with its back cover removed. There are

dangerous high voltages inside.

APC-3X98(A) User Manual

Table of Contents______________________

Warning!…………………………………………………………………………….……..….2

Disclaimer………………………………………………………………….…………………2

Chapter 1 Getting Started

1.1 Specifications……………………………………….……………………..6

1.2 Dimensions………………………………...………………………….......8

1.3 Brief Description…………………………………………………….……11

Chapter 2 Hardware

2.1 Mainboard………………..…….……………………………………..…..12

2.2 Jumpers and Connectors Location……………………………………...13

2.3 Jumpers Setting and Connectors……………...………………………13

Chapter 3 BIOS Setup

3.1 Operations after POST Screen..........................................................24

3.2 BIOS SETUP UTILITY..........................................................................25

3.3 System Overview..................................................................................26

3.4 Advanced Settings............................................................................... 27

3.5 Advanced PCI/PnP Settings................................................................ 33

3.6 Boot Settings....................................................................................... 36

3.7 Security Settings.................................................................................. 37

3.8 Advanced Chipset Settings.................................................................. 39

3.9 Exit Options…………………………………...…………………………….44

Chapter 4 Installation of Drivers

4.1 Intel Chipset Driver.…………………………...…………………………47

4.2 Intel Graphics MediaAccelerator Driver...…………………..…………..50

4.3 Intel 8257L Gbe LAN Device Driver………………………………….….53

4.4 Realtek HD Audio Driver Installation…….…………..…………………56

Chapter 5 Touch Screen Installation

5.1 Introduction to Controller Board..…………………………….……………58

5.2 Windows 2000/XP USB Driver Installation………………….………..….58

Figures

Figure 1.1: APC-3098 Dimensions………………………………………..…....8

APC-3X98(A) User Manual

Figure 1.2: APC-3298A Dimensions……………………..……………………..9

Figure 1.3: APC-3598A Dimensions…………………….…………………….10

Figure 1.4: Front View ………………………………………………………….11

Figure 1.5: Rear View…………………………………………………………...11

Figure 2.1: Mainboard Overview………………………………………….....12

Figure 5.1 Birdeye’s View of Control Board………………..…………………58

APC-3X98(A) User Manual

Chapter 1 System

1.1 Specifications

Specs

APC-3098

APC-3298A

APC-3598A

CPU

Intel Atom Z510p 1.1 GHz FSB 400 MHz, Z530p 1.6 GHz FSB 533 MHz for option

Chipset

Intel US15WP

System Memory

On board 1 GB DDR2 400 MHz

Graphic

Intel integrated Graphics GMA500

External I/O Port

2 x USB 2.0 ports

2 x RJ-45 LAN ports

1XDB-15, RS-232 COM2

And RS-232/422/485

COM1(default:RS-232)

1 x DC power input

2 x USB 2.0 ports

1 x RJ-45 LAN port

1XDB-9 RS-232 COM2

1XDB-9 232/422/485

COM1 (Selectable,

default:RS-232)

1 x DC power input

Standard I/O：

2 x USB 2.0 ports

1 x RJ-45 LAN port

1XDB-9 RS-232 COM2

1XDB-9 232/422/485

COM1 (Selectable,

default:RS-232)

1 x DC power input

Option：

1 x VGA DB-15 port

1 x Audio Line-out port

Display Type

8” TFT-LCD

12” TFT-LCD

15” TFT-LCD

Max. Resolution

800 x 600

1024 x 768

Maximum Colors

262K

16.2M

Viewing Angle (Degree)

H:130/ V:110

H:140/V:110

H:160/V:130

Luminance (cd/m²)

350

Backlight Lifetime

50,000 hrs

Rating

IP65

Touch Screen Type

Resistive (optional)

Storage

1 x 2.5” SATA HDD

1 x CF slot (internal)

Wireless LAN

Wireless LAN Module via mini-PCIe (Optional)

Antennas are built-in on the Rear Panel

Power Supply

DC 9-32V

Construction and Color

Stainless steel

Dimensions (WxHxD)

250 x 209 x 65 mm

335 x 269 x 65 mm

399 x 328 x 65 mm

Operating Temperature

0~50℃

Storage Temperature

-20~60℃

Relative Humidity

10%~90%@ 40 ﾟC, (non-condensing)

APC-3X98(A) User Manual

Certificate

CE/FCC Class A

APC-3X98(A) User Manual

1.2 Dimensions

Figure 1.1: Dimensions of the APC-3098

APC-3X98(A) User Manual

Figure 1.2: Dimensions of the APC-3298A

APC-3X98(A) User Manual

Figure 1.3: Dimensions of the APC-3598A
