Aplex ARCDIS-1 (P/G) Series Manuel utilisateur

ARCDIS-1XX(P/G)(H) (TB-6028) User Manual

ARCDIS-1XX(P/G)(H)

(TB-6028)

7”, 8”, and 10.1”front panel IP66/IP69K(option)

aluminum die-casting chassis Display

User Manual

Release Date Revision

Jan. 2019 V1.6

Aplex Technology, Inc.

15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan

Tel: 886-2-82262881 Fax: 886-2-82262883 URL: http://www.aplextec.com/zh/home.php

ARCDIS-1XX(P/G)(H) (TB-6028) User Manual

Revision History

Reversion

Date

Description

1.0

2014/10/03

Official Version

1.1

2015/06/10

Add 15.6”, 17”, and 18.5”

1.2

2015/07/29

Delete description of die-casting,

Modify Power Consumption

1.3

2017/04/18

Remove 15.6”,17”,18.5”,21.5”

Modify figure of Dimensions

and Product images

Modify Specifications:

Add High Brightness

External I/O Port

Construction of Mechanical

Enviroment Temperature

1.4

2017/07/25

Modify IP65 to IP66/IP69K

1.5

2017/10/23

Modify IP69K for option

Remove RCA function

Modify DVI to DVI-D

Add AR glass non-touch

Add Auto dimming images

1.6

2019/01/09

Add G model series information

ARCDIS-1XX(P/G)(H) (TB-6028) User Manual

Warning!___________________________

This equipment generates, uses and can radiate radio frequency energy and if

not installed and used in accordance with the instructions manual, it may

cause interference to radio communications. It has been tested and found to

comply with the limits for a Class A computing device pursuant to FCC Rules,

which are designed to provide reasonable protection against such interference

when operated in a commercial environment. Operation of this equipment in

a residential area is likely to cause interference in which case the user at his

own expense will be required to take whatever measures may be required to

correct the interference.

Disclaimer

This information in this document is subject to change without notice. In no event

shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or

consequential, arising from either the use or misuse of information in this

document or in any related materials.

Electric Shock Hazard –Do not operate the machine with its back cover

removed. There are dangerous high voltages inside.

ARCDIS-1XX(P/G)(H) (TB-6028) User Manual

Table of Contents

Revision History………………………………………………………………………………….1

Warning!………………………………………………………………………………….……..….2

Disclaimer……………………….……………………………………………….…………………2

Chapter 1 Getting Started

1.1 Features…………………………………………………..…………………………….5

1.2 Specifications…………………………………………………………………………5

1.3 Dimensions……………………...……………...…..…………………………….…7

1.4 System Diagram(Full Function)................................................8

1.5 Brief Description of ARCDIS-1XX(P)(H)…….………..………………….9

1.6 Display Mode…………………………………………..…………………………..10

Chapter 2 OSD

2.1 AD Board OSD Functions………….…...………..….…..……………….….11

2.2 OSD Controls……………………………..…………….…………………….……12

2.3 OSD Functions…………………………………………..………………………...13

2.4 Main Menu………………………………..…………….……………………......13

Chapter 3 Installation

3.1 Windows 7 Universal Driver Installation for PenMount 6000

Series……………………….………..………………..………………………...…19

3.2 Software Functions…………………………………………………………….27

Appendix A: Board Descriptions & Specifications 45

Descriptions…………………………………….………………………………………...45

Specifications…………………………..…………….………………………………....45

Board Dimensions………………….…………………….……………………………46

Appendix B: Panel Mounting and VESA Mounting 47

ARCDIS-1XX(P/G)(H) (TB-6028) User Manual

Figures

Figure 1.1: Dimensions of ARCDIS-107(P/G)(H)….…….…………..…..7

Figure 1.2: Dimensions of ARCDIS-108(P/G)(H)…..………………………7

Figure 1.3: Dimensions of ARCDIS-110(P/G)(H)….……………………...8

Figure 1.4: System Diagram of TB-6028……………………………………...8

Figure 1.5: Front View of ARCDIS-1xx(P/G)(H)….…….………………...9

Figure 1.6: Rear View of ARCDIS-1xx(P/G)(H)……….…………………..9

Figure A: Dimensions of TB-6028……………………………………………..46

Figure B: Panel mounting and VESA mounting………………………….47

ARCDIS-1XX(P/G)(H) (TB-6028) User Manual

Chapter 1 Getting Started

1.1 Features

Solid Aluminum chassis

Variety of LCD panel size selections

IP66 / IP69K(option) compliant front bezel

VGA and DVI-D input

Wide range DC 9~36V power input

Auto dimming for option ( not available for 7”display)

Support protective AR glass for option (non-touch version)

1.2 Specifications

ARCDIS-107

(P/G)

ARCDIS-107

(P/G)H

ARCDIS-108

(P/G)

ARCDIS-108

(P/G)H

ARCDIS-110

(P/G)

ARCDIS-110

(P/G)H

Hardware

Display Type

7” color TFT LCD

8”color TFT LCD

10.1”color TFT LCD

External I/O Port

Default I/O:

1 x 3 pins terminal block for DC 9~36V power input

1 x DVI-D

1 x VGA

1 x USB type A for Touch control

Option I/O:

1 x line in by phone jack

1 x RS-232 DB-9 for Touch control

LED Light

1 x system power LED light

OSD Control

On board controller, extendable key pad from connector

Transfer Board OSD Membrane Keypad

Speaker

1 x 2W speaker for option

LCD

Max. Resolution

800x480

800x600

1280x800

Max. Color

262K

16.2M

16.7M

16.2M

Luminance(cd/m²)

350

1000

350

1000

350

1000

Contrast Ratio

400 : 1

500 : 1

800 : 1

1000:1

Viewing Angle

(H/V)

140(H)/130(V)

140(H)/125(V)

170(H)/170(V)

Backlight Lifetime

40,000 hrs

50,000 hrs(H)

40,000 hrs

30,000 hrs(H)

25,000 hrs

50,000 hrs(H)

ARCDIS-1XX(P/G)(H) (TB-6028) User Manual

Power Input

DC 9~36V on board

Power

Consumption

MAX: 4.2W

MAX: 4.1W(P)

MAX:4.7W

MAX:3.6W(P)

MAX:6.2W

MAX:5.9W(P)

Touch Screen ARCDIS-1XX (H)

Type

Resistive Touch Window

Interface

Default USB / RS-232 for option

Light Transmission

Over 80%

Touch Screen ARCDIS-1XXP(H)

Type

Projected Capacitive

Interface

USB

Light Transmission

Over 90%

Touch Screen ARCDIS-1XXG(H)

Type

Glass-AR

Interface

NA(Glass)

Light Transmission

Over 93%

Mechanical

Construction

Aluminum die-casting chassis

Dimensions

202x149x40 mm

231.1x176.1x50 mm

285x189x48.9 mm

Net Weight

1 kg

1.8 kg

1.7 kg

Mounting

Panel mount / VESA 75x75

Panel mount / VESA 100x100

Environment Specifications

Operating

Temperature

0 ~ 50 ℃

20 ~ 60 ℃for option

Storage

Temperature

-30 ~ 70 ℃

Storage Humidity

10 ~ 90% @40℃Non-condensing, without touch screen

IP Rating

Front Panel IP66 / IP69K(option)

Certificate

CE/FCC Class A

ARCDIS-1XX(P/G)(H) (TB-6028) User Manual

1.3 Dimensions

Figure 1.1: Dimensions of ARCDIS-107 (P/G) (H)

Figure 1.2: Dimensions of ARCDIS-108 (P/G) (H)

ARCDIS-1XX(P/G)(H) (TB-6028) User Manual

Figure 1.3: Dimensions of ARCDIS-110 (P/G) (H)

1.4 System Diagram (Full Function)

Figure 1.4: System diagram of TB-6028

ARCDIS-1XX(P/G)(H) (TB-6028) User Manual

1.5 Brief Description of ARCDIS-1XX (P/G)(H)

ARCDIS-1XX(P/G)(H) series with TB-6028 AD Board is an IP66 / IP69K(option)

compliant front panel designed aluminum die-casting chassis LCD display, which

comes with 7, 8, and 10.1 inch color TFT LCD. It can be panel mounted in front bezel

and VESA 75 x 75 or VESA 100 x 100 mounted in rear bezel. There are multiple

external I/O ports come with VGA, DVI-D, USB, and RS-232…etc. The power supports

wide range DC 9~36V power input. Furthermore, High brightness 1,000 nits LCD is

ideal for sunlight readable semi-outdoors applications, and LCD can be optical

bonding designed for option. ARCDIS-1XX (P/G)(H)series model has more outstanding

features, thus giving the best in monitoring and control application.

Figure 1.5: Front View of ARCDIS-1xx (P/G) (H)

Figure 1.6: Rear View of ARCDIS-1xx (P/G) (H)
