Aplex ADP-1153 Manuel utilisateur

ADP-1XX3 User Manual

ADP-1153/1193 Display Monitor

User Manual

Release Date Revision

Feb. 2013 V1.0

Aplex Technology, Inc.

15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan

Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: [email protected] URL: www.aplex.com.tw

ADP-1XX3 User Manual

Warning!___________________________________

This equipment generates, uses and can radiate radio frequency energy and if not installed and

used in accordance with the instructions manual, it may cause interference to radio communications.

It has been tested and found to comply with the limits for a ClassA computing device pursuant to

FCC Rules, which are designed to provide reasonable protection against such interference when

operated in a commercial environment. Operation of this equipment in a residential area is likely

to cause interference in which case the user at his own expense will be required to take whatever

measures may be required to correct the interference.

Disclaimer

This information in this document is subject to change without notice. In no event shall Aplex Technology

Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or

misuse of information in this document or in any related materials.

Electric Shock Hazard –Do not operate the machine with its back cover removed. There are

dangerous high voltages inside.

ADP-1XX3 User Manual

Table of Contents______________________

Warning!…………………………………………………………………………….……..….2

Disclaimer………………………………………………………………….…………………2

Chapter 1 Getting Started

1.1 Specifications…………………………………………....……………...….5

1.2 Dimensions…………………………………...………………………….…6

1.3 Brief Description...................................................................................8

1.4 Display Mode……………………………………………………………….9

Chapter 2 OSD

2.1 Front Panel Controls……………………………………………….……….10

2.2 OSD Controls…………………..………………………………………….11

2.3 Main Menu…..………..……………………………………………………..12

2.4 AD Board OSD Functions…….………………...………………….………14

Chapter 3 Installation

3.1 Windows 2000/XP Driver Installation…………………………………….15

3.2 Configuring PenMount Windows 2000/XP Driver………………………19

3.3 Uninstall PenMount Windows 2000/XP Driver………………………….29

Chapter 4 Software

4.1 Software Functions………………………………………………………..30

4.2 Software Function Descriptions……………………………………….…31

Appendix A: Board Description & Specifications………………….41

Figures

Figure 1.1: Dimensions of ADP-1153….………………………………………..6

Figure 1.2: Dimensions of ADP-1193………………………………………….7

Figure 1.3: Front View of the ADP-1XX3…………….……………………….8

ADP-1XX3 User Manual

Figure 1.4: Rear View of the ADP-1XX3…………….………………………….8

Figure A: VESA-mounting………………………….……………………….….40

Appendix

VESA-mounting…………………………………………………………..40

ADP-1XX3 User Manual

Chapter 1 Getting Started

1.1 Specifications

Model No.

Specs

ADP-1153

ADP-1193

Display Type

15” TFT LCD

19” TFT LCD

Max. Resolution

1024x768

1280x1024

Max. Color

16.7M

Luminance (cd/m²)

300

350

Viewing Angle (H/V)

150/140

170/160

Backlight Lifetime

50,000 Hours

On Screen Display

Control

On the rear side

External I/O Port

Default:

1 x VGA Input

1 x DC

Optional:

Touch I/O

Power Input

DC 11~32V

Touch Screen Type

Resistive Touch

Construction

Stainless Steel Enclosure

IP Rating

IP 65

Mounting

VESA 75x75 Mount

VESA 100x100 Mount

Dimensions (WxHxD)

399x324x53 mm

470x388.6x60 mm

Net Weight

6.8kgs

9.9kgs

Operating Temperature

0~50℃

Storage Temperature

-20~60℃

Storage Humidity

10~90% @40℃(non-condensing)

Certificate

CE / FCC Class A

ADP-1XX3 User Manual

1.2 Dimensions

Figure 1.1: Dimensions of ADP-1153

ADP-1XX3 User Manual

Figure 1.2: Dimensions of ADP-1193

ADP-1XX3 User Manual

1.3 Brief Description of the ADP-1XX3

The ADP-1153/1193 is a total IP65 Stainless Steel Enclosure LCD Display, which comes with a 15 inch

(luminance of 300 cd/m²) / 19 inch (luminance of 350 cd/m²) TFT LCD. ADP-1153 comes with viewing

angle of 150 (H) degrees and 140 (V) degrees, ADP-1193 comes with viewing angle of 170 (H)

degrees and 160 (V) degrees, and more outstanding features, thus giving you the best in monitoring

and control applications

The front panel of the display monitor is sealed with gasket for NEMA 4/IP 65 rating when it is

panel-mounted in a NEMA rated cabinet or enclosure. It can also be VESA 100-mounted. It is optional

to be equipped with a resistive touch screen.

Figure 1.3: Front View of ADP-1XX3

Figure 1.4: Rear View of ADP-1XX3

ADP-1XX3 User Manual

1.4 Display Mode

Display Mode

Hori. Sync (KHz)

Vert. Sync. (Hz)

VGA 640 x 480

SVGA 800 x 600

XGA 1024 x 768

SXGA

1152 x 864

1280 x 1024

ADP-1XX3 User Manual

Chapter 2_____________________________

2.1 Front Panel OSD Functions

Auto Adjust Up/Left Down/Right Power

Menu/Entry Power Indicator

Power switch: To turn ON or OFF the power

Shift the icon to the right side or shift it up

Shift the icon to the left side or shift it down

Menu: To enter OSD menu for related icon and item.

Auto Button: One-touch auto adjustment

1.) Getting into Burn-in Mode

Before setting into a burn-in mode, first disconnect the AC power cord. Then press (don‟t let them go)

the buttons until the AC power cord is connected and the “RGB” appears on the top left corner

of your screen. Now it can be put into the burn-in mode for changing colors.

2.) Getting Out of Burn-in Mode

Before getting out of the burn-in mode, please first disconnect the AC power cord. Then press the

button (If not workable, press the button and don‟t let them go) until the AC power cord is

connected. Please don‟t let your fingers go until the AC power cord is connected again and the

wording of “RGB”appears on the top left corner of your screen, and wait for 3 seconds. Under the

non-signal entry situation, if is seen, exit is thus successfully made.

Cable Not Connected
