FABS-1XXP/G(H) User Manual

FABS-1XX Series

7”, 10.1”, 12.1”, 15”, 17”, 19”and 21.5”Flat Front Panel IP66 / IP69K(option)

Stainless Steel Chassis Display

User Manual

Release Date Revision

Aug. 2019 V1.0

Aplex Technology, Inc.

15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan

Tel: 886-2-82262881 Fax: 886-2-82262883 URL: http://www.aplextec.com/zh/home.php

FABS-1XXP/G(H) User Manual

Revision History

Reversion

Date

Description

1.0

2019/08/28

Official Version

FABS-1XXP/G(H) User Manual

Warning!___________________________

This equipment generates, uses and can radiate radio frequency energy and if

not installed and used in accordance with the instructions manual, it may

cause interference to radio communications. It has been tested and found to

comply with the limits for a Class A computing device pursuant to FCC Rules,

which are designed to provide reasonable protection against such interference

when operated in a commercial environment. Operation of this equipment in

a residential area is likely to cause interference in which case the user at his

own expense will be required to take whatever measures may be required to

correct the interference.

Disclaimer

This information in this document is subject to change without notice. In no event

shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or

consequential, arising from either the use or misuse of information in this

document or in any related materials.

Electric Shock Hazard –Do not operate the machine with its back cover

removed. There are dangerous high voltages inside.

FABS-1XXP/G(H) User Manual

Table of Contents

Revision History………………………………………………………………………………….1

Warning!……………………..………………………………………………………….……..….2

Chapter 1 Getting Started

1.1 Features…………………………………….……………..…….........……………………….5

1.2 Specifications…………………………….………………………………….…………………5

1.3 Dimensions…………………...………………...…..……………………………..……..…9

1.4 Brief Description of FABS-1XXPG(H) Series.………..………………………...12

Chapter 2 AD BOARD INFORMATION

2.1 AD Board Specifications..………….…...………..….…..……………………….….20

2.2 Board Dimensions.……………………..…………….………………………..…...……21

2.3 Jumpers and Connectors Location…..…….………………………..…...……22

2.4 Jumper Settings and Connectors.…………..……………………......……...33

Chapter 3 OSD

3.1 AD Board OSD Functions………….…...………..….…..……………………….….32

3.2 OSD Controls……………………………..…………….………………………..…...……33

3.3 Main Menu…..…………………………………………..……………………......……...34

Appendix A: Panel Mounting and VESA Mounting

Panel mounting and VESA mounting……………………………………………………37

Figures

Figure 1.1: Dimensions of FABS-107PG(H).…………………………………………….………..…….9

Figure 1.2: Dimensions of FABS-110PG(H).………………………….…………………………………9

Figure 1.3: Dimensions of FABS-112PG(H).………………………..………………………….…….10

Figure 1.4: Dimensions of FABS-115PG(H)…..…………..………………………………………….10

Figure 1.5: Dimensions of FABS-117PG(H)...............................................................11

Figure 1.6: Dimensions of FABS-119PG(H)...............................................................11

FABS-1XXP/G(H) User Manual

Figure 1.7: Dimensions of FABS-121PG(H)..................................................................12

Figure 1.8: Front View of FABS-107PG(H)….............................................................….13

Figure 1.9: Rear View of FABS-107PG(H)........…………………………………..…..………………..13

Figure 1.10: Front View of FABS-110PG(H)…........................................…………………….14

Figure 1.11: Rear View of FABS-110PG(H)………………………………………………….........…..14

Figure 1.12: Front View of FABS-112PG(H)……………………...…………………………………….15

Figure 1.13: Rear View of FABS-112PG(H)..........................................................……..15

Figure 1.14: Front View of FABS-115PG(H)…………………….……………………..……………….16

Figure 1.15: Rear View of FABS-115PG(H)…………………….………….……………….……………16

Figure 1.16: Front View of FABS-117PG(H).................................................................17

Figure 1.17: Rear View of FABS-117PG(H)...................................................................17

Figure 1.18: Front View of FABS-119PG(H).................................................................18

Figure 1.19: Rear View of FABS-119PG(H)...................................................................18

Figure 1.20: Front View of FABS-121PG(H).................................................................19

Figure 1.21: Rear View of FABS-121PG(H)..................................................................19

Figure 2.1: Dimensions of TB-6802(Top)……………………………..………………..………………..21

Figure 2.2: Dimensions of TB-6802(Bottom)……………………………………….…………………..21

Figure A: Panel mounting and VESA mounting……………………………………………………….37

FABS-1XXP/G(H) User Manual

Chapter 1 Getting Started

1.1 Features

Stainless Steel front bezel display

Flat front panel touch screen

IP66 / IP69K(option) compliant front panel

VGA, DVI-D/HDMI, and DP input

Wide range DC 9~36V power input

High Brightness LCD and Auto dimming for option

Projected Capacitive Touch or AR Glass for option

OSD at rear side

System power LED light

1.2 Specifications

FABS-1XX Series

Outside I/O Port

VGA

DVI-D

1 x DVI-D input (share with HDMI)

HDMI

1 x HDMI input (share with DVI-D)

Audio

1 x audio line-in phone jack

OSD control

OSD on the rear side

LED Light

1 x system power LED light

Speaker

1 x 2W speaker for option

Power

1 x 3-pins terminal block for DC 9~36V power input

Others

1 x USB type B for touch control

1 x RS-232 DB-9 for touch control for option

Power

Power Input

DC 9~36V

Touch Screen

Type

Projected capacitive touch screen (for P model)

Protective AR glass with non-touch version(for G model)

Light Transmission

Over 90%

Mechanical

FABS-1XXP/G(H) User Manual

Construction

304 Stainless Steel chassis(default); 316 Stainless Steel chassis(option)

Mounting

Panel mount / VESA mount 100 x 100

IP Rating

IP66/IP69K(option) compliant front panel

Environmental

Operating temperature

0~50°C

Storage temperature

-30~70°C

Storage humidity

10 to 90% @ 40°C, non- condensing

Vibration

1G / 5~500Hz (Random) / Operation

Shock

15G peak acceleration (11 msec. duration) / Operation

Certification

CE / FCC Class A, design ready to meet EN1672-2 standard

Power Consumption

Model Name

FABS-107P/G(H)

FABS-110P/G(H)

FABS-112P/G(H)

FABS-115P/G(H)

FABS-117P/G(H)

FABS-119P/G(H)

FABS-121P/G(H)

Power

Consumption

5.63W (STD LCD)

9.55W (STD LCD)

12.48W (HB LCD)

16.40W (HB LCD)

29.22W (HB LCD)

Mechanical Specification

Model Name

FABS-107P/G(H)

FABS-110P/G(H)

FABS-112P/G(H)

FABS-115P/G(H)

FABS-117P/G(H)

FABS-119P/G(H)

FABS-121P/G(H)

Dimensions(mm)

217 x 163 x 40

296.03 x 200.02

x 46.9

330.8 x 256.9 x

52.2

422.1 x 322 x

54.1

449.4 x 358.4 x

63.8

485 x 361 x

63.8

573.8 x 378.8 x

59.8

Net Weight(kg)

2.38

3.3

4.95

7.3

FABS-1XXP/G(H) User Manual

Standard LCD

FABS-107P

FABS-110P

FABS-112P

Display Type

7” color TFT LCD

10.1” color TFT LCD

12.1” color TFT LCD

Max. Resolution

800 x 480

1280 x 800

800 x 600

1024 x 768

Max. Colors

262K

16.7M

16.2M

Contrast Ratio

400:1

800/1300:1

1500:1

700:1

Luminance (cd/m2)

350

350/300

450

500

Viewing Angle(H/V)

110/140

170/170

178/178

160/140

Backlight Lifetime(Hrs)

40,000

25,000

50,000

30,000

FABS-115P

FABS-117P

FABS-119P

FABS-121P

Display Type

15” color TFT LCD

17” color TFT LCD

19” color TFT LCD

21.5” color TFT LCD

Max. Resolution

1024 x 768

1280 x 1024

1920 x 1080

Max. Colors

16.2M

16.7M

Contrast Ratio

2000:1

800:1

1000:1

3000:1

Luminance (cd/m2)

300

350

250

Viewing Angle(H/V)

176/176

160/140

170/160

178/178

Backlight Lifetime(Hrs)

50,000

30,000

FABS-1XXP/G(H) User Manual

High Brightness LCD (Option)

FABS-107PH

FABS-110PH

FABS-112PH

Display Type

7” color TFT LCD

10.1” color TFT LCD

12.1” color TFT LCD

Max. Resolution

800 x 480

1280 x 800

800 x 600

1024 x 768

Max. Colors

262K

16.7M

262K/16.2M

Contrast Ratio

400:1

1000:1

700:1

Luminance (cd/m2)

1000

Viewing Angle(H/V)

130/140

170/170

178/178

160/140

Backlight Lifetime(Hrs)

50,000

FABS-115PH

FABS-117PH

FABS-119PH

FABS-121PH

Display Type

15” color TFT LCD

17” color TFT LCD

19” color TFT LCD

21.5” color TFT LCD

Max. Resolution

1024 x 768

1280 x 1024

1920 x 1080

Max. Colors

16.7M

Contrast Ratio

800:1

1000:1

3000:1

Luminance (cd/m2)

1000

900

1000

Viewing Angle(H/V)

145/160

170/160

178/178

Backlight Lifetime(Hrs)

30,000

50,000

30,000
