MX64 is a slot 1 based motherboard that utilizes VIA 694X AGPset on Micro

ATX form factor. It implements an onboard audio CODEC and supports new

architectures such as AGP 4x, SDRAM, Ultra DMA 33/66, Bus master IDE

and USB ports. It supports three Dual in-line memory module (DIMM) slots

that allow the installation of SDRAM memory and expansion up to a maximum

of 768MB.

In addition to the above features, MX64 also implements plenty of fabulous

features.

Jumper-less Design Pentium II / Pentium III / Celeron VID signal and SMbus

clock generator provide CPU voltage auto-detection and allows the user to set

the CPU frequency through the CMOS setup, therefore no jumpers or switches

are used. The correct CPU information is saved into the EEPROM. With these

technologies, the disadvantages of the Pentium based jumper-less designs

are eliminated. There will be no worry of wrong CPU voltage detection and no

need to re-open the housing in case of CMOS battery loss. The only jumper

left is to clear the CMOS, which is a safety hook if you forget the password.

Full-range CPU core voltage This motherboard supports the CPU core

voltage from 1.3V to 3.5V, that can be applied to various CPU type in future.

Zero Voltage Wake on Modem In conjunction with ATX soft power On/Off, it

is possible to have system totally power off and wakeup to automatically

answer a phone call such as answering machine or to send/receive fax. The

most important break through is not only external box modem but also internal

modem card can be used to support 0V Wake On Modem. The MX64 and

FM56-P internal modem card implement special circuit (patent applied) to

make sure the modem card work properly without any power.

Wake on LAN This feature is very similar as 0V Wake On Modem, but it is

through local area network. To use Wake on LAN function, you must have a

network card that supports this feature and also need to install a network

management software.

Overview

1-2

Wake on RTC Timer The Wake Up Timer is more like an alarm, which wakes

up and power on your system at a pre-defined time for specific application. It

can be set to wake up everyday or on specific date within a month. The

date/time accuracy is second.

CPU Thermal Protection MX64 has a special thermal detection circuit to have

warning through application software when the temperature is higher than a

predefined value.

CPU and Housing Fan Monitoring MX64 has one more "fan monitoring"

function to prevent system overheat. The system will report and alarm fan

malfunction though utility software such as Hardware Monitoring Utility (named

AOhw140, where 140 means version number).

System Voltage Monitoring Furthermore, MX64 implements a voltage

monitoring system, As you turn on your system, this smart design will continue

to monitor your system working voltage. If any of the system voltage is over

the component's standard. There will be alarm though software such as

Hardware Monitoring Utility for a warning to user.

ACPI Suspend to DRAM You can resume your original work directly from

DRAM without going through the Win98 booting process and run your

application again. Suspend to DRAM saves your current work into the system

memory.

Resetable Fuse MX64 implements resetable fuses to prevent any accidental

short circuit caused by keyboard or USB devices hot plug.

FCC DoC Certificate MX64 has passed FCC DoC test. The radiation is very

low, you can use any kind of housing.

PC99 Ready For user’s convenience in installing the PC system, AOpen

adopts the recommended PC99 color scheme in all connectors that mount on

this motherboard.

Powerful Utility Software AOpen Bonus Pack CD disc contains many useful

utilities, such as Norton Antivirus, AOchip, Hardware Monitoring Utility, and

Suspend to Hard Drive utility.

Overview

1-3

1.1 Specifications

Form Factor Micro ATX

Board Size 220 mm x 245 mm

CPU Intel Pentium II / Pentium III / Celeron

System Memory DIMM 168-pin x3, maximum 768MB.

Second-level Cache Built-in CPU depends on processor

Chipset VIA 694X AGPset

Expansion Slots PCI x 3 and AGP x 1

Audio CODEC AD1881

Serial Port Two serial ports UART 16C550 compatible

Parallel Port One parallel port supports standard parallel port (SPP),

enhanced parallel port (EPP) or extended capabilities

port (ECP).

Floppy Interface Floppy interface supports 3.5 inches drives with

720KB, 1.44MB or 2.88MB format or 5.25 inches

drives with 360KB, 1.2MB format

IDE Interface Dual-channel IDE interface support maximum 4 IDE

hard disks or CDROM, mode 4, bus master hard disk

drives and Ultra DMA 33/66 mode hard drives are also

supported.

USB Interface Two USB ports supported by USB bracket, the BIOS

also supports USB driver to simulate legacy keyboard.

PS/2 Mouse Mini-Din PS/2 mouse connector onboard.

Keyboard Mini-Din PS/2 keyboard connector onboard.

RTC and Battery RTC build in chipset, Lithium (CR-2032) battery.

BIOS AWARD Plug-and-Play, 2M bit Flash ROM BIOS.

Overview

1-4

1.2 Zero Voltage Wake on Modem

The Wake on Modem discussed here is to wakeup from true power off

(identified by fan of power supply is off), This motherboard still supports

traditional green PC suspend mode but it is not discussed here.

With the help ATX soft power On/Off, it is possible to have system totally

power off (The traditional suspend mode of power management function does

not really turn off the system power supply), and wakeup to automatically

answer a phone call such as answering machine or to send/receive fax. You

may identify the true power off by checking fan of your power supply. Both

external box modem and internal modem card can be used to support 0V

Wake On Modem, but if you use external modem, you have to keep the box

modem always power-on. AOpen MX64 and internal modem card implement

special circuit (patent applied) and make sure the modem card works properly

without any power. We recommend you choose AOpen modem card (For

example, FM56-P, FM56-H, etc.) for 0V Wake On Modem applications.

Internal Modem Card Wake Up

(

suchas FM56

)

ExternalB

oxModem

External ModemWakeUp

COM port

TEL Line

-P

Overview

1-5

For Internal Modem Card (AOpen FM56-P):

1. Go into BIOS setup, Power Management Æ0V Wake On Modem, select

Enabled.

2. Setup your application, put into Windows 95.

3. Turn system power off by soft power switch.

4. Connect 4-pin Modem Ring-On cable from FM56-P RING connector to

MX64 connector WKUP.

5. Connect telephone line to FM56-P. You are now ready to use Wake On

Modem.

For External Box Modem:

1. Go into BIOS setup, Power Management Æ0V Wake On Modem, select

Enabled.

2. Setup your application, put into Windows 95 Start Up.

3. Turn system power off by soft power switch.

4. Connect RS232 cable of external box Modem to COM1 or COM2.

5. Connect telephone line to external box Modem. Turn on Modem power

(you must keep Modem power always on). You are now ready to use Wake

On Modem.

Tip: External 0V Wake On Modem signal is detected

through COM1 or COM2. Internal modem card wake up

signal is detected through cable from connector RING

(on modem card) to WKUP (on mainboard).

Note: If you use external modem, the power of external

modem must be kept on to receive signal from telephone

line. Internal modem card has no such limitation.

Overview

1-6

1.3 System Voltage Monitoring

This motherboard implements a voltage monitoring system. As you turn on

your system, this smart design will continue to monitor your system working

voltage. If any of the system voltage is over the component's standard. There

will be alarm through application software such as Hardware Monitor utility for

a warning to user. System voltage monitoring function monitors CPU core

voltage. It is automatically implemented by BIOS and Hardware Monitor utility

(the file name is like aohw100.exe, where 100 means the version number, no

hardware installation is needed.

1.4 Fan Monitoring

There are three fan connectors, two is for CPU, the other can be a housing fan.

The fan monitoring function is implemented by connecting fan to 3-pin fan

connector CPUFAN1 and FAN,and installing Hardware Monitoring Utility.

Note: You need 3-pin fan that supports SENSE

signal for fan monitoring function to work

properly.

Overview

1-7

1.5 CPU Thermal Protection

This motherboard implements special thermal protection circuit below the CPU.

When temperature is higher than a predefined value, the CPU speed will

automatically slow down and there will be warning from BIOS and also

Hardware Monitoring Utility software.

CPU Thermal Protection is automatically implemented by BIOS and utility

software, no extra hardware installation is needed.

2-1

Chapter 2

Hardware Installation

This chapter gives you a step-by-step procedure on how to install your system.

Follow each section accordingly.

Caution: Electrostatic discharge (ESD) can

damage your processor, disk drives, expansion

boards, and other components. Always

observe the following precautions before you

install a system component.

1. Do not remove a component from its

protective packaging until you are ready

to install it.

2. Wear a wrist ground strap and attach it to

a metal part of the system unit before

handling a component. If a wrist strap is

not available, maintain contact with the

system unit throughout any procedure

requiring ESD protection.

Hardware Installation

2-2

2.1 Jumper and Connector Locations

The following figure shows the locations of the jumpers and connectors on the

system board:

FDC

IDE2

IDE1

USB KB2

BIOS

PANEL

IrDA DIMM1

DIMM2

CPU FAN1

PWR2

COM1

PRINTER

PS/2 MS

CPUFAN2

JP14

JP23

COM2

WOM

FAN1

WOL

JP12

DIMM3

PWLED1

JP29

MODEM-CN

CD-IN

JP27

SMB

AOL2

INSPK

CD-IN2

USB2

Hardware Installation

2-3

Jumpers:

JP12: Sound

JP14: Clear CMOS

JP27: PC Beep

JP23, JP29: Host CLK

Connectors:

PS2: PS/2 mouse connector

KB: PS/2 keyboard connector

COM1: COM1 connector

COM2: COM2 connector

PRINTER: Printer connector

PWR2: ATX power connector

USB: USB connector (port 1, 2)

USB2: USB second connector (port 3, 4)

FDC: Floppy drive connector

IDE1: IDE1 primary channel

IDE2: IDE2 secondary channel

CPUFAN1: 3-pin CPU fan connector

CDUFAN2: 2-pin CPU fan connector

FAN1: Fan connector

IrDA: IrDA (Infrared) connector

PANEL: Front panel (Multifunction) connector

CD-IN: CD-audio connector

MODEM-CN: Mono in (Pin 1-2) and Mic out (Pin 3-4)

WOM: 0V Wake On Modem connector

WOL: Wake On LAN connector

Table des matières

Autres manuels AOpen Carte mère

AOpen

AOpen AX4GE Tube-G Manuel utilisateur

AOpen

AOpen MX46L Guide de configuration

AOpen

AOpen AK77-8X Fiche technique

AOpen

AOpen MX4SG-4DL Guide de configuration

AOpen

AOpen AX45H-8X Max Fiche technique

AOpen

AOpen MX4SGI-L Fiche technique

AOpen

AOpen AP53 Manuel utilisateur

AOpen

AOpen i945GTm-VHL Fiche technique

AOpen

AOpen MX46L Fiche technique

AOpen

AOpen AX45 PRO-533 Fiche technique

AOpen

AOpen AX6BC PROII Manuel utilisateur

AOpen

AOpen AX4GE Tube-G Fiche technique

AOpen

AOpen AX4PER Guide de configuration

AOpen

AOpen AX4T-533 Pro Guide de configuration

AOpen

AOpen AK73 Series Guide de configuration

AOpen

AOpen AX4B PRO Guide de configuration

AOpen

AOpen AK73-1394 Guide de configuration

AOpen

AOpen Fortress 9000 Guide de configuration

AOpen

AOpen MX4LR-GN Fiche technique

AOpen

AOpen MX4GVR Guide de configuration

AOpen

AOpen AX4B-533 Tube Fiche technique

AOpen

AOpen AX4PE Tube-G Manuel utilisateur

AOpen

AOpen AX45S-533 Guide de configuration

AOpen

AOpen AX4SG WLAN Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
