AOpen MX4GVR Fiche technique

Chassis Intrusion Connecto

CD-IN Connecto

Front Audio Connecto

IrDA Connecto

Front Panel Connecto

FDD Connecto

USB2.0 Connecto

JP14 CMOS Clear Jumpe

-IN Connecto

Resetable Fuse

478-pin CPU socket

(Willamette/Northwood) with Voltage and

Frequency Auto-detection that supports

Intel®Pentium®4 1.4~2.4GHz+ CPU

DD Slot

(For ADD card only)

32-bit PCI Expansion Slot x3

184-pin DIMMx2 supports DDR266/200

DDR SDRAM maximum u

to 2GB

Intel 845GV Chi

set

Low ESR Ca

acitors

TX Power Connecto

ATA 33/66/100 IDE Connecto

4-pin 12V. ATX Power Connecto

RealTek RTL8100BL

PS/2 Mouse

Connector SPP/EPP/ECP Parallel Port

USB2.0

Ports

RJ45 10/100

LAN Jack

PS/2 Keyboard

Connector USB2.0 Port

COM 1 Port VGA Port

C’97 CODEC

SYSFAN3 Connecto

CPUFAN1 Connecto

S/PDIF Connecto

SYSFAN2 Connecto

4Mb Flash ROM BIOS

WOL Connecto

COM2 Connecto

JP28 USB/Keyboard/Mouse Wakeup Jumpe

JP27 USBLAN Wakeu

Jum

CNR Connecto

Line-In

Speaker

Out

MIC-In

BOOT LED

STBY LED

Open reserves the right to revise all the specifications and information contained in this documentation, which are subject to change without notice.

2nd USB Channel 1st USB Channel

1. JP14 Clear CMOS

Everything you need to boot this

motherboard is included in this

Easy Installation Guide. For more

information, a complete Online

User's Manual can be found in the

Bonus Pack CD. Thanks for the

help of saving our earth.

PART NO: 49.8B411.E01 DOC. NO: MX4GVR-EG-E0208A

This motherboard provides USB and PS2 keyboard / mouse wake-up function. You can use JP27 / JP28 to

enable or disable this function, which could resume your system from suspend mode with keyboard o

mouse installed. JP28 controls 1st USB channel, and JP27 controls 2nd USB channel. The factory defaul

setting is set to “Disable”(1-2), and you may enable this function by setting the jumper to 2-3.

You can clear CMOS to restore system default setting. To

clear the CMOS, follow the procedure below.

1. Turn off the system and unplug the AC power.

2. Remove ATX power cable from connector PWR2.

3. Locate JP14 and short pins 2-3 for a few seconds.

4. Return JP14 to its normal setting by shorting pin 1 & pin 2.

5. Connect ATX power cable back to connector PWR2.

Tip: When should I Clear CMOS?

1. Boot fail because of overclocking…

2. Forget password…

3. Troubleshooting…

This Easy Installation Guide x1

80-wire IDE Cable x1

Floppy Disk Drive Cable x1

Registration Card x1

Bonus Pack CD x1

S/PDIF Cable x 1 (User Upgrade Optional)

Retention Module x1

I/O Shield x1

Pin 1

2. JP27/28 Keyboard/Mouse Wakeup Jumper

Normal

(

default

)

Clear CMOS

JP27

Enable

Disable

(Default)

1JP28

EnableDisable

(Default)

Pin 1

Plug in the CPU fan cable to the 3-pin CPUFAN1 connector. If you have chassis fan, you

can also plug it in SYSFAN2 or SYSFAN3 connector.

This motherboard comes with a 20-pin and 4-pin ATX power connector as shown below.

Make sure you plug in the right direction. We strongly recommend you to insert the 4-pin

connector before connecting the 20-pin connector.

CPU Ratio 8x, 10x… 21x, 22x, 23x, 24x

CPU FSB (By BIOS table) 100 and 133MHz.

Northwood CPU CPU Core Frequency FSB Clock System Bus Ratio

Pentium 4 1.6G 1600MHz 100MHz 400MHz 16x

Pentium 4 1.6G 1600MHz 133MHz 533MHz 12x

Pentium 4 1.7G 1700MHz 133MHz 533MHz 13x

Pentium 4 1.8G 1800MHz 100MHz 400MHz 18x

Pentium 4 2.0G 2000MHz 100MHz 400MHz 20x

Pentium 4 2.2G 2200MHz 100MHz 400MHz 22x

Pentium 4 2.26G 2260MHz 133MHz 533MHz 17x

Pentium 4 2.4G 2400MHz 100MHz 400MHz 24x

Pentium 4 2.4G 2400MHz 133MHz 533MHz 18x

Pentium 4 2.53G 2530MHz 133MHz 533MHz 19x

Pentium 4 2.66G 2660MHz 133MHz 533MHz 20x

Pentium 4 2.80G 2800MHz 133MHz 533MHz 21x

Willamette CPU CPU Core Frequency FSB Clock System Bus Ratio

Pentium 4 1.8G 1800MHz 100MHz 400MHz 18x

Pentium 4 1.9G 1900MHz 100MHz 400MHz 19x

Pentium 4 2.0G 2000MHz 100MHz 400MHz 20x

Celeron CPU CPU Core Frequency FSB Clock System Bus Ratio

1.7G 1700MHz 100MHz 400MHz 17x

1.8G 1800MHz 100MHz 400MHz 18x

5. Setting CPU Voltage & Frequency

Setting CPU Core Voltage

This motherboard supports CPU VID function. The CPU core voltage will be automaticall

detected.

Setting CPU Frequency

This motherboard is CPU jumper-less design, you can set CPU frequency through the

BIOS setup, and no jumpers or switches are needed. The default setting is "table select

mode". You can adjust the FSB from "CPU Host/SDRAM/PCI Clock" for overclocking.

BIOS Setup > Frequency / Voltage Control > CPU Speed Setup

3. ATX Power Connectors

Note: Some CPU fans

do not have sensor pin

so they cannot support

fan monitoring.

CPUFAN1 Connector

Warning: Intel 845GV supports

maximum 533MHz system bus and

66MHz AGP clock; higher clock

setting may cause serious system

damage.

4. Installing CPU & System Fan

SYSFAN3 Connector

SYSFAN2 Connector

GND

+12V

SENSOR

Note: Since the latest processor,

Northwood, would detect the clock

ratio automatically, you may not

be able to adjust the clock ratio in

BIOS manuall

GND

+12V

SENSOR

USB2.0 Connector

Front Audio Connector

9. Connecting Front Panel Cable

6. 2nd USB2.0 Connectors

This motherboard provides six USB connectors to link USB devices, such as mouse,

keyboard, modem, printer, etc. There are four ports on the PC99 back panel. You can use

proper cable to connect other USB connectors to the back panel or front panel of chassis.

Pin1

7. Front Audio Connector

If the housing has been designed with an audio port on the front panel, you’ll be able to

connect onboard audio to front panel through this connector. By the way, please remove

5-6 and 9-10 jumper caps from the Front Audio Connector before connecting the cable.

Please do not remove these 5-6 and 9-10 yellow jumper caps if there’s no audio port on

the front panel.

Pin 1

UD_FPOUT_L

HP_ON

UD_RET_

UD_VCC

UD_GND2

110

UD_MIC

UD_MIC_BIAS

UD_FPOUT_

AUD_RET_L

The IrDA connector can be configured to support wireless infrared module, with this module

and application software such as Laplink or Windows 95 Direct Cable Connection, the use

can transfer files to or from laptops, notebooks, PDA devices and printers. This connecto

supports HPSIR (115.2Kbps, 2 meters) and ASK-IR (56Kbps).

Install the infrared module onto the IrDA connector and enable the infrared function from

BIOS Setup, UART Mode, make sure to have the correct orientation when you plug in the

IrDA connector.

8. IrDA Connector

KEY

GND

IR_RX

+5V

IR_TX

IrDA Connector

USBPWR0

USB_FP_P0-

USB_FP_P0+

GND

USBPWR0

USB_FP_P1-

USB_FP_P1+

GND

USB_FP_OC0

1 2

ttach the power LED, speaker, and reset switch connectors to

the corresponding pins. If you enable “Suspend Mode” item in

BIOS Setup, the ACPI & Power LED will keep flashing while the

system is in suspend mode.

Locate the power switch cable from your ATX housing. It is

2-pin female connector from the housing front panel. Plug this

connector to the soft-power switch connector marked SPWR.

Speaker

IDE LED

SPWR

CPI & PWR

LED

Reset

CPI LED (BLUE)

SPWR

GND

ACPI LED-

GND

ACPILED

ACPI_B

GND

RESET

GND

IDE LED

GND

SPEAKE

On the strength of RealTek RTL8100BL LAN controller on board, which is a highly-integrated

Platform LAN Connect device, it provides 10/100M bps Ethernet for office and home use, the

Ethernet RJ45 connector is located on top of USB connectors. The green LED indicates the

link mode, it lights when linking to network and blinking when transferring data. The orange

LED indicates the transfer mode, and it lights when data is transferring in 100Mbps mode. To

enable or disable this function, you may simply adjust it through BIOS.

12. COM2 Connector

This motherboard provides two serial ports. One of them is on back panel connector, and the

other is on the upper middle of board. With proper cable, you can connect it to the back panel o

chassis.

13. Support 10/100 Mbps LAN Onboard

Pin 1

Orange/Speed

Green/ACT

10. S/PDIF (Sony/Philips Digital Interface) Connector

S/PDIF (Sony/Philips Digital Interface) is a newest audio transfer file format, which provides

impressive audio quality through optical fiber and allows you to enjoy digital audio instead

of analog audio. Through a specific audio cable, you can connect the S/PDIF connector to

other end of the S/PDIF audio module, which bears S/PDIF digital output. Normally there

are two S/PDIF outputs as shown, one for RCA connector, the most common one used fo

consumer audio products, and the other for optical connector with better audio quality.

Same as outputs, you can also connect RCA or optical audio products to input connectors

on the module and have the voice or music come out from your computer. However, you

must have a S/PDIF supported speaker/amplifier/decoder with S/PDIF digital input/output to

connect to the S/PDIF digital input/output to make the most out of this function.

Pin 1

S/PDIF Module

(User Upgrade Optional)

S/PDIF

Cable

S/PDIF OUT

S/PDIF IN

(RCA)

S/PDIF IN

(Optical)

S/PDIF OUT

11. Super 5.1 Channel Audio Effects

+5V

S/PDIFOUT

GND

S/PDIFIN

This motherboard comes with an ALC650 CODEC, which supports high quality of 5.1

Channel audio effects, bringing you a brand new audio experience. On the strength of the

innovative design of ALC650, you're able to use standard line-jacks for surround audio outpu

without connecting any external module. To apply this function, you have to install the audio

driver in the Bonus Pack CD as well as an audio application supporting 5.1 Channel. Picture

bellow represents the standard location of all speakers in 5.1Channel sound track. Please

connect the plug of your front speakers to the green “Speaker out” port, rear speakers’ plug

to the blue “Line in” port and both of the center and subwoofer speakers to the red “MIC in”

port.

GND

SOUT

DOD#

RI#

RTS#

SIN

DTR#

DSR#

CTS#

COM2

onnecto

After you finish jumper settings and connect correct cables, power on and

enter the BIOS Setup. Press <Del> during POST (Power On Self Test).

Choose "Load Setup Defaults" for recommended optimal performance.

14. Power-on and Load BIOS Setup

15. AOpen Bonus Pack CD 17. BIOS Upgrade under Windows Environment

You may accomplish BIOS upgrade procedure with EzWinFlash by the following steps, and

it’s STRONGLY RECOMMENDED to close all the applications before you start the

upgrading.

1. Download the new version of BIOS package zip file from our official web site. Unzip the

download BIOS package (ex: WMX4GVR102.ZIP) with WinZip (http://www.winzip.com)

in Windows environment.

2. Save the unzipped files into a folder, for example, WMX4GVR102.EXE

WMX4GVR102.BIN.

3. Double click on WMX4GVR102.EXE, EzWinFlash will detect the model name and BIOS

version of your motherboard. If you had got the wrong BIOS, you will not be allowed to

proceed with the flash steps.

4. You may select preferred language in the main menu, then click [Start Flash] to start the

BIOS upgrade procedure.

5. EzWinFlash will complete all the process automatically, and a dialogue box will pop up

to ask you to restart Windows. You may click [YES] to reboot Windows.

6. Press <Del> at POST to enter BIOS setup, choose "Load Setup Defaults", then “Save

Exit Setup”. Done!

It is strongly recommended NOT to turn off the power or run any application during

FLASH PROCESS.

16. Installing Onboard Sound Driver

You can use the autorun menu of Bonus CD. Choose the utility and driver and selec

model name. After selecting the model name, you can install its AGP, IAA, Audio, LAN

and USB2.0 drivers from this CD.

Del

Warning: Please avoid of using "Load

Turbo Defaults", unless you are sure

our system components (CPU, DRAM,

HDD, etc.) are good enough for turbo

settin

This motherboard comes with AC97 CODEC. This audio driver supports Windows 98SE

and upper Windows OS; you can find the audio driver from the Bonus Pack CD auto-run

menu.

Warning: The upgrade of new BIOS will permanently replace your original BIOS

content after flashing. The original BIOS setting and Win95/Win98 PnP information

will be refreshed and you probably need to re-configure your system.

MX4GVR R1.02 Aug. 01. 2002 AOpen Inc.

Award Plug and Play BIOS Extension v1.0A

If you encounter any trouble while booting your system, follow the

procedures accordingly to resolve the problem.

Part Number and Serial Number

The Part Number and Serial number are printed on bar code label. You can find the bar

code label on the outside packing or on the component side of PCB. For example:

Model name and BIOS version

Model name and BIOS version can be found on upper left corner of first boot screen

(POST screen). For example:

MX4GVR is model name of motherboard; R1.02 is BIOS version

Make sure if the jumper settings for CPU and DRAMs are correct.

Clear CMOS.

Install the VGA card. Then connect your monitor and keyboard.

The problem was probably caused

by power supply or motherboard

failure. Please contact your reselle

or local distributor for repairing.

Perhaps your VGA card or monito

is defective.

Yes

It is very possible that your keyboard

is defective.

During system rebooting, press Del to enter BIOS Setup. Choose

“Load Setup Default".

The problem should be caused by the

IDE cables or HDD itself.

Re-install Windows 95, Windows 98 or Windows NT.

Yes

Turn off the power and unplug the AC power cable, then remove all

of the addon cards and cables, including VGA, IDE, FDD, COM1,

COM2 and Printer.

Turn on the power, and check if

the power supply and CPU fan

work properly.

Start

Check if there is display.

Press Ctrl, and Alt key at the

same time, hold them and then

press Del to see if the

stem reboots.

Turn off the system and

re-connect the IDE cable.

Check if the system can

reboot successfully.

End

P/N: 91.88110.201 is part number, S/N: 91949378KN73 is serial number.

Part No. Serial No.

Dear Customer,

Thanks for choosing AOpen products. To provide the best and fastest service to

our customer is our first priority. However, we receive numerous emails and

hone-calls worldwide everyday, it is very hard for us to serve everyone on time.

We recommend you follow the procedures below and seek help before contact

us. With your help, we can then continue to provide the best quality service to

more customers.

Thanks very much for your understanding!

Open Technical Supporting Team

Web Site: http://www.aopen.com

E-mail: Send us email by going through the contact form below.

English http://english.aopen.com.tw/tech/default.htm

Japanese http://www.aopen.co.jp/tech/default.htm

Chinese http://www.aopen.com.tw/tech/default.htm

German http://www.aopencom.de/tech/default.htm

Simplified Chinese http://www.aopen.com.cn/tech/default.htm

Pacific Rim

AOpen Inc.

Tel: 886-2-3789-5888

Fax: 886-2-3789-5899

America

AOpen America Inc.

Tel: 1-510-489-8928

Fax: 1-510-489-1998

Europe

AOpen Computer b.v.

Tel: 31-73-645-9516

Fax: 31-73-645-9604

Germany

AOpen Computer GmbH.

Tel: 49-1805-559191

Fax: 49-2102-157799

China

艾爾鵬國際貿易(上海)有限公司

Tel: 86-21-6225-8622

Fax: 86-21-6225-7926

Japan

AOpen Japan Inc.

Tel: 81-048-290-1800

Fax: 81-048-290-1820

Online Manual: Please check the manual carefully and make sure the

jumper settings and installation procedure are correct.

http://english.aopen.com.tw/tech/download/manual/default.htm

Test Report: We recommend to choose board/card/device from the

compatibility test reports for assembling your PC.

http://english.aopen.com.tw/tech/report/default.htm

FAQ: The latest FAQ (Frequently Asked Questions) may contain a

solution to your problem.

http://english.aopen.com.tw/tech/faq/default.htm

Download Software: Check out this table to get the latest updated

BIOS/utility and drivers.

http://english.aopen.com.tw/tech/download/default.htm

News Group: News posted by computer experts. You are welcome to join

any discussion there.

http://english.aopen.com.tw/tech/newsgrp/default.htm

Contact Distributors/Resellers: We sell our products through resellers

and integrators. They should know your system configuration very well and

should be able to solve your problem efficiently and provide important

reference for you if next time you want to buy something else from them.

before contacting us. The part number, serial number and BIOS version

are also very helpful.

Autres manuels pour MX4GVR

Table des matières

Autres manuels AOpen Carte mère

AOpen

AOpen DX2G Plus Manuel utilisateur

AOpen

AOpen AX6BC Pro II Millennium Edition Manuel utilisateur

AOpen

AOpen AX3S Pro-U Fiche technique

AOpen

AOpen AK77-600 Max Manuel utilisateur

AOpen

AOpen i855GMEm-LFS Manuel utilisateur

AOpen

AOpen AK73 Series Guide de configuration

AOpen

AOpen Fortress 7000 Manuel utilisateur

AOpen

AOpen AK77-333 Guide de configuration

AOpen

AOpen AX4S-U Manuel utilisateur

AOpen

AOpen AK77-8X Fiche technique

AOpen

AOpen MX3S-U Guide de configuration

AOpen

AOpen S661FXm-FSN Manuel utilisateur

AOpen

AOpen MX3W Pro Guide de configuration

AOpen

AOpen AX4SG WLAN Fiche technique

AOpen

AOpen MX46LS-V Guide de configuration

AOpen

AOpen MX46U2-VN Guide de configuration

AOpen

AOpen i945GTm-VHL Manuel utilisateur

AOpen

AOpen AX3SP-U Guide de configuration

AOpen

AOpen MX4BS Guide de configuration

AOpen

AOpen i945Ga-PLF Fiche technique

AOpen

AOpen AX6L Manuel utilisateur

AOpen

AOpen AX3S Pro Guide de configuration

AOpen

AOpen MX46-800N Fiche technique

AOpen

AOpen AX59PRO Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
