Anywave ATSC 1KW Manuel utilisateur

ANYWAVE

ATSC 1KW DTV Transmitter

User Manual

Version 1.11

September 12, 2014

ATSC 1KW DTV TX User Manual

ACT-1000-USR-DOC-V1.11, 09/12/2014 Page 2 of 73

No part of this publication may be reproduced, translated, transcribed, stored in a

retrieval system, or transmitted into any form or by any means, without the express

written permission of Anywave Communication Technologies, Inc.

FCC Compliance

This equipment complies with relevant portions of Parts 2, 73, & 74 of the FCC rules

governing LPTV operation.

Disclaimer

Information provided by Anywave Communication Technologies is believed to be

accurate and complete; however, no liability can be assumed for its use.

The manufacturer makes no representations or warranties, either expressed or implied,

by or with respect to anything in this manual, and shall not be liable for any implied

warranties of fitness for a particular purpose or for any indirect, special, or

consequential damages. Information in this document is subject to change without

notice and does not represent a commitment on the part of the manufacturer.

USE OF THIS PRODUCT IN A MANNER OTHER THAN DESCRIBED IN THIS

MANUAL MAY RESULT IN DAMAGE TO THE EQUIPMENT AND/OR

PERSONAL INJURY.

PLEASE READ THIS MANUAL IN ITS ENTIRETY BEFORE ATTEMPTING TO

OPERATE THE EQUIPMENT. CONTACT ANYWAVE WITH ANY QUESTIONS

OR CONCERNS YOU MAY HAVE.

Anywave Communication Technologies Inc.

300 Knightsbridge Parkway, Suite 150, Lincolnshire, IL 60069

Tel: (847) 415-2258

Fax: (847) 415-2112

http://www.anywavecom.com/en/

ATSC 1KW DTV TX User Manual

ACT-1000-USR-DOC-V1.11, 09/12/2014 Page 3 of 73

Unpacking

Carefully unpack the equipment and perform a visual inspection to determine if any

apparent damage has occurred during shipment. Please notify the delivery carrier and

Anywave immediately if shipment damage has occurred. Retain all original shipping

materials.

Please locate and reference the Packing Check List to verify you have received all

components of your system. Retain the Packing Check List for future reference.

Also, please identify and remove all packing materials and supports (foam pads, etc.)

prior to initial turn on of the equipment.

Returns and Exchanges

Written approval and a Return Authorization Number (RAN) are required from

Anywave for all equipment returns. Please direct all return inquiries to the Anywave

Service Department at [email protected], providing the Sales Order

number and Serial Number(s) of the equipment. Complete details regarding the nature

and circumstances of your return must be included in your RAN request. Proper

handling and return shipping instructions will be provided with an approved RAN

number.

Technical Support

Technical support and troubleshooting assistance for Anywave Transmitters is

available through theAnywave Service Department during normal business hours (8:00

AM - 5:00 PM CST) at (847) 415-2258.Email questions to

[email protected].

Note: For all service and support requests, you will need to provide the Serial Number

of the equipment with your Sales Order number. For future reference, please record that

information here:________________________________________

ATSC 1KW DTV TX User Manual

ACT-1000-USR-DOC-V1.11, 09/12/2014 Page 4 of 73

WARNING

THE VOLTAGES, CURRENTS, AND RF ENERGY IN THIS EQUIPMENT

ARE DANGEROUS. PERSONNEL MUST AT ALL TIMES OBSERVE ALL

SAFETY WARNINGS, INSTRUCTIONS, AND REGULATIONS.

IN THE CASE OF EMERGENCY, ENSURE THAT ALL POWER HAS BEEN

DISCONNECTED.

ALWAYS DISCONNECT POWER BEFORE REMOVING COVERS,

ENCLOSURES, OR SHIELDS. DO NOT PERFROM SERVICE ON THE

EQUIPMENT WHEN ALONE OR FATIGUED. KNOW YOUR EQUIPMENT

AND DO NOT TAKE RISKS.

This manual is provided as a general guide for trained and qualified personnel well

aware of the dangers inherent in handling potentially hazardous electrical transmission

equipment.

The installation, operation, maintenance and service of this equipment involves risks

both to personnel and equipment, and must ONLY be performed by qualified personnel

exercising due care. Anywave Communication Technologies, Inc. shall not be

responsible for injury or damage resulting from improper handling or from the use of

improperly trained or inexperienced personnel performing such tasks.

All local building and electrical codes as well as fire protection standards must be

observed in the installation and operation of the equipment.

ATSC 1KW DTV TX User Manual

ACT-1000-USR-DOC-V1.11, 09/12/2014 Page 5 of 73

Contents

1 Introduction............................................................................................7

2 TX System Overview .............................................................................8

3 TX Specifications .................................................................................10

4 Control Unit..........................................................................................11

5 Digital Exciter ......................................................................................14

6 PowerAmplifier –600W.....................................................................16

7 TX System Interconnect Diagram......................................................19

8 Theory of Operation............................................................................20

9 Quick Start Guide................................................................................21

10 RF System Connections.....................................................................22

11 AC Mains Connections......................................................................24

12 Operational Basics.............................................................................26

12.1 TX ON/OFF................................................................................................................26

12.2 RAISE/LOWER POWER...........................................................................................27

12.3 RUNNING CORRECTIONS......................................................................................28

12.4 CALIBRATE EXCITER FWD POWER METER......................................................33

12.5 CALIBRATE TX SYSTEM POWER METERS........................................................34

13 Local (Touch Screen) User Interface................................................42

13.1 HOME SCREEN.........................................................................................................42

13.2A/B EXCITER ICON SCREEN .................................................................................43

13.3AMPLIFIER ICON SCREEN.....................................................................................47

13.4 CONFIG SCREEN .....................................................................................................50

ATSC 1KW DTV TX User Manual

ACT-1000-USR-DOC-V1.11, 09/12/2014 Page 6 of 73

13.5 LOG SCREEN............................................................................................................59

13.6 CONTROL SCREEN..................................................................................................59

13.7 HELP SCREEN ..........................................................................................................60

13.8 EMERGENCY MODE...............................................................................................61

14 Remote (Web) User Interface ...........................................................62

ATSC 1KW DTV TX User Manual

ACT-1000-USR-DOC-V1.11, 09/12/2014 Page 7 of 73

1 Introduction

This User Manual contains operational instructions for the Anywave 1KW DTV

Transmitter. Please note that trained and qualified personnel are required to operate

install, maintain, and service this transmission equipment.

ATSC 1KW DTV TX User Manual

ACT-1000-USR-DOC-V1.11, 09/12/2014 Page 8 of 73

2 TX System Overview

The Anywave ATSC 1KW DTV Transmitter comes in single and dual exciter

configurations. Photos of a single exciter system are shown below (with side panels and

rear door removed). The main subsystems (as seen from the front) include the Exciter,

Controller unit (with a touchscreen LCD, built-in preamp and 2-way splitter), two

600W power amplifiers, an AC Mains Breaker, and a channel mask Band Pass Filter

(BPF) - optional.

Controller

Exciter

PA 1

PA 2

BPF

AC Mains

Breaker

ATSC 1KW DTV TX User Manual

ACT-1000-USR-DOC-V1.11, 09/12/2014 Page 9 of 73

From the rearview of the TX cabinet, several other main components can be seen which

include an AC Distribution System, 2-way Combiner, 2-port Directional coupler and

Reject Load.

AC Distribution

System

2-Way

Combiner

2-Port

Directional

Coupler

Combiner

Reject Load

ATSC 1KW DTV TX User Manual

ACT-1000-USR-DOC-V1.11, 09/12/2014 Page 10 of 73

3 TX Specifications

RF Output

Connector: 1 5/8”, 50 Ω

Frequency: 470~860 MHz, in steps of 1 Hz

Rated Power: 1kW (rms)

Level Stability: < ±0.2 dB

MER: > 35 dB

Amplitude Flatness: < ±0.5 dB

Shoulder Level: < - 50 dB (after correction)

Return Loss: > 16 dB

Environment

Operation Temperature: 0 ℃~ +40 ℃

Operation Humidity: < 95 % (non-condensing)

Atmospheric Pressure: 86 kPa ~ 106 kPa

Power Supply

Voltage: 220 VAC, single phase 3-wire (30A)

Frequency: 50/60 Hz

Power Consumption: 5940 W @ 1170 W output (27 A / 220 V)

Other

Cooling System：Forced air cooling

Control Interface: Front panel, Ethernet and RS232

Size (HxWxD): 1270 mm x 600 mm x 900 mm

Note

1. The electrical interface characteristics are measured under normal conditions. Values may

vary.

2. Operating in abnormal conditions may result in damage to the equipment. Long operating

hours in severe environments may reduce the reliability of the entire system, which may

cause permanent damage to equipment. Make sure all electrical interface characteristics

and environmental parameters are within the defined range listed above before operating

this equipment.
