Antec SOLO II Manuel utilisateur

S O L O

I I

SER

ANUAL

ILENCE

ENEWED

SOLO

SER

’

ANUAL

Congratulations on your purchase of the Antec SOLO II.

he SOLO II emphasizes Quiet Computing™ and reinvents Antec’s renowned Sonata line with a new

set of attractive, practical features. Externally, the SOLO II’s dual-layer 1.0 mm SECC / polycarbonate

top & side panels absorb noise for exceptional sound dampening. o reduce vibration-related noise,

the dual hard drive mounting system gives you the option of mounting your hard drives using tray

mounts with silicone grommets or the tool-less suspension mount system. SOLO II features an

anodized aluminum front bezel and piano black exterior for an elegant, professional appearance.

With washable fan filters and two front panel USB 3.0 ports, the SOLO II is the rebirth of Quiet

Computing™.

he SOLO II does not include a power supply. Make sure you choose a power supply that is

compatible with your computer components and has a long enough power harness to reach your

motherboard and peripheral devices. We recommend our High Current Gamer, High Current Pro or

Earthwatts power supplies for the latest A X specification compliance, broad compatibility, and

power savings capability.

At Antec, we continually refine and improve our products to ensure the highest quality. As such,

your new chassis may differ slightly from the description in this manual due to improvements

applied for the optimal building experience. As of the date of publication, all features, descriptions,

and illustrations in this manual are correct.

Disclaimer

his manual is intended only as a guide for Antec’s computer enclosures. For more

comprehensive instructions on installing the motherboard and peripherals, please refer to the

manuals that come with those components.

ABLE OF

ONTENTS

ECTION

NTRODUCTION

1.1 Getting to Know your Chassis ..................................................................5

1.2 Chassis Specifications...............................................................................6

1.3 Included Screws .......................................................................................6

1.4 Before you Begin ......................................................................................7

ECTION

ARDWARE INSTALLATION

2.1 Setting up .................................................................................................9

2.2 Motherboard Installation ........................................................................10

2.3 Installing the KUHLER H

O .......................................................................11

2.4 Power Supply Installation ........................................................................12

2.5 Cable Management ..................................................................................14

2.6 External 5.25” Device Installation ............................................................14

2.7 Internal 3.5”/2.5” Device Installation using tray mounts ........................16

Suspension mounting ..............................................................................17

2.8 Internal 2.5” Device Installation ..............................................................18

ECTION

RONT

I O

ORTS

3.1 USB 2.0 .....................................................................................................20

3.2 USB 3.0 .....................................................................................................20

3.3 AC’97 / HD audio ports ............................................................................21

3.4 Power Switch / Reset Switch / Hard Disk Drive LED Connectors.............21

3.5 Rewiring Motherboard Header Connections ...........................................22

ECTION

OOLING SYSTEM

4.1 Included 120 mm rueQuiet™ rear fan ...................................................24

4.3 Washable Air Filters .................................................................................24

4.2 Optional Fans ...........................................................................................25

N RODUC ION

EC ION

1.1 G

E ING O KNOW YOUR CHASSIS

1. Internal: 3 x 3.5” / 2.5”using tray mount OR 2 x 3.5” with suspension mount cables

2. Internal: 1 x 2.5” SSD (dedicated)

3. External: 2 x 5.25”

4. 1 x rear 120 mm rueQuiet™ fan with 2-speed switch

5. 2 x front 120 mm fans (optional) and removable, washable air filters

6. Anodized aluminum front bezel

7. Front ports

8. Power supply mount

9. 7 expansion slots

1.2 C

HASSIS

PECIFICA IONS

Chassis

ype

Mid ower

Chassis

Color

Piano Black

Dimensions

17.3” (H) x 8.1” (W) x 18.5” (D)

440 mm (H) x 205 mm (W) x 470 mm (D)

Weight

20.2 lbs / 9.1 kg

Cooling

-Rear 120 mm rueQuiet™ fan with preinstalled silicone grommets

and 2-speed switch

-2 front 120 mm fan mounts (optional)

Drive Bays

-3 x 3.5”/2.5” using tray mounts with preinstalled silicone grommets

OR 2 x 3.5” with suspension mounting system

-2 x external 5.25”

-1 x 2.5” (dedicated)

Expansion Slots

Motherboard Size

Standard A X, microA X, Mini-I X

Front I/O Panel

-2 x USB 3.0

-2 x USB 2.0

-AC’97 / HD Audio In and Out

-On/Off Button

-Reset

1.3

NCLUDED

CREWS

An inventory of all screws and intended usage and quantity is provided here:

A. Motherboard standoffs (9; 4 preinstalled)

B. Motherboard / PSU / mounting screws (15)

C. 5.25” external drive mounting screws / dedicated 2.5” drive bay (12)

D. 3.5” tray mount screws – coarse threading (14)

E. 2.5” drive mounting screws (tray mount) – fine threading (8)

1.4 B

EFORE

EGIN

In order to ensure that your building experience with the SOLO II will be a positive one, please take

note of the following:

•While working inside your SOLO II, keep your chassis on a flat, stable surface. Make sure your

build environment is clean, well-lit, and free of dust.

•Antec chassis feature rounded edges that minimize the occurrence of hand injuries. Nonetheless,

exercise caution and control when handling chassis interiors. We strongly recommend taking the

appropriate time and care when working inside the chassis. Avoid hurried or careless motions.

•Handle components and cards with care. Do not touch the unshielded components or contacts

on a card. Hold a card by its edges. Hold a component such as a processor by its edges, never by

its pins.

•o avoid electrostatic discharge, ground yourself periodically by touching an unpainted metal

surface (such as a connector or screw on the back of this computer) or by using a wrist

grounding strap.

•Before you connect a cable, ensure that both connectors are correctly aligned and oriented.

Bent pins can be difficult to fix and may require replacement of the entire connector.

•his manual is not designed to cover CPU, RAM, or expansion card installation. Please consult

your motherboard manual for specific mounting instructions and troubleshooting. Before

proceeding, check the manual for your CPU cooler to find out if there are steps you must take

before installing the motherboard.

•Do not sit on your chassis. Although it is constructed of heavy-duty steel and internally

reinforced, it is not designed to support the weight of an adult, and may buckle.

•Remember to use the right tools for each task. Do not use improvised screwdrivers like coins,

nails or knife blades as they may result in damage to screw threads or even injury. Do not use

your fingernails to separate edges or lift the sides of the chassis, as paint chipping or injury may

occur.

ARDWARE

INS ALLA ION

EC ION

2.1 S

E ING

Begin by removing the left side panel by loosening the thumbscrews and swinging the panel outward,

pulling it back towards you; this will completely remove it. Cut the ties on the 5.25” drive cage with a

wire cutter and remove the plastic bag of screws.

he SOLO II should now look like this.

2.2 M

O HERBOARD

NS ALLA ION

Before proceeding:

Check the manual for your CPU cooler to find out if there are steps you must do before installing the

motherboard.

Make sure you have the correct I/O panel for your motherboard. If the panel provided with the

chassis isn’t suitable, please contact your motherboard manufacturer for the correct I/O panel.

he SOLO II comes with four preinstalled motherboard standoffs. hese are positioned for Standard

A X motherboards but can be relocated to accommodate other form factors.

1. Align the motherboard with the standoff holes on the motherboard tray and remember or mark

which holes are lined up

2. Install standoffs as needed and put the motherboard in. he motherboard tray has indicators

pertaining to specific form factors. Use the holes marked “A” for Standard A X and the holes

marked “M” for microA X.

Caution: Make sure to remove any unused motherboard standoffs. hey may come into contact with

the back of the motherboard and may electrify your chassis exterior if left connected.

Make sure you have the correct I/O panel.
