ANTAIRA EVC-3001 Manuel utilisateur

ANTAIRA TECHNOLOGIES

Ethernet Extender over VDSL2

Media Converter

EVC-3001 & EVC-3010

User’s Manual

Trademarks

Contents subject to revision without prior notice.

Antaira is a registered trademark of Antaira Technologies. The

information in this manual is subject to change without notice.

All other trademarks belong to their respective owners.

Disclaimer

Antaira Technologies does not warrant that the hardware will

work properly in all environments and/or applications, and makes

no warranty and representation, either implied or expressed,

with respect to the quality, performance, merchantability, or

tness for a particular purpose.

Antaira has made every effort to ensure that this User’s Manual

is accurate; Antaira disclaims liability for any inaccuracies or

omissions that may have occurred.

Information in this User’s Manual is subject to change without

notice and does not represent a commitment on the part of

Antaira. Antaira assumes no responsibility for any inaccuracies

that may be contained in this User’s Manual. Antaira makes no

commitment to update or keep current the information in this

User’s Manual, and reserves the right to make improvements to

this User’s Manual and/or to the products described in this User’s

Manual, at any time without notice. If you nd information in

this manual that is incorrect, misleading, or incomplete, we

would appreciate your comments and suggestions.

FCC Warning

This equipment has been tested and found to comply with the

regulations for a Class A digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment

is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with this user’s guide, may

cause harmful interference to radio communications. Operation

of this equipment in a residential area is likely to cause harmful

interference, in which case the user will be required to correct

the interference at his own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this

product may cause radio interference, in which case the user

may be required to take adequate measures.

Energy Saving Note of the Device

This power required device does not support Standby mode

operation.

For energy saving, please remove the DC-plug to disconnect the

device from the power circuit.

Without removing the DC-plug, the device will still consume

power from the power source. In the view of Saving the Energy

and reduce the unnecessary power consuming, it is strongly

suggested to remove the DC-plug for the device if this device is

not intended to be active.

WEEE Warning

To avoid the potential effects on the environment and

human health as a result of the presence of hazardous

substances in electrical and electronic equipment, end

users of electrical and electronic equipment should

understand the meaning of the crossed-out wheeled bin symbol.

Do not dispose of WEEE as unsorted municipal waste and have

to collect such WEEE separately.

Revision

Antaira Ethernet over VDSL2 Converter User’s Manual

For Models: EVC-3001 & EVC-3010

Rev 1.1 (Dec 2013)

Table of Contents

1. Introduction ..................................................................... 6

1.1 Checklist ................................................................... 6

1.2 Ethernet over VDSL2 Bridge Description....................... 6

1.3 Key Features............................................................ 10

1.4 Specications........................................................... 11

2. Hardware Description ...................................................... 14

2.1 Front Panel .............................................................. 14

2.2 The Rear Panel ........................................................ 16

3. Installation..................................................................... 19

3.1 Install Ethernet over VDSL2 Converter ....................... 19

3.1 EVC-3001 / EVC-3010 LAN to LAN Connection............ 20

3.2 Connecting EVC-3001 / EVC-3010 ............................. 21

3.3 Connecting EVC-3010 ............................................... 23

4. Power Information .......................................................... 25

5. Troubleshooting SYMPTOM:.............................................. 26

6. FAQ............................................................................... 27

1.Introduction

1.1 Checklist

Check the contents of the package for following parts:

EVC-3001 x 1; or EVC-3010 x 1l

5V DC/ 2A AC-to-DC Power Adapter x 1l

RJ-11 Telephone Line x 1l

User’s Manual x 1l

If any of these items are missing or damaged, please contact

Antaira Sales Representative or authorized dealer immediately.

Please retain the carton including the original packing material,

and use them against to repack the product in case there is a

need to return it us for repair.

1.2 Ethernet over VDSL2 Bridge Description

Antaira’s state-of-the-art Ethernet-over-VDSL2 products are

based on two core networking technologies: Ethernet and

VDSL2 (Very-high-data-rate Digital Subscriber Line 2). This

technology offers the absolute fastest possible data transmission

speeds over existing copper telephone lines or coaxial cables

without the need for rewiring.

The EVC-3001 / EVC-3010 Converter has a switching architecture

with RJ-45 10/100Mbps Ethernet port and one asymmetric

or symmetric Ethernet over VDSL port (Asymmetric means

upstream and downstream rate are not the same and Symmetric

means upstream and downstream rate are similar) – the VDSL

port can be RJ-11 connector (EVC-3001) or BNC Connector

(EVC-3010). The EVC-3001 / EVC-3010 can be set to Central

Ofce (CO) or Customer Premises Equipment (CPE) mode via

a DIP switch. The performance of EVC-3001 (RJ11) will up to

100/55Mbps for asymmetric data rate within 200m and up to

25/4Mbps for asymmetric data rate at 1.6km. The performance

of EVC-3010 (BNC) is up to 100/65Mbps for asymmetric data

rate within 200m and up to 25/5Mbps for asymmetric data rate

at 3.0km. This capability is ideal for use as an Ethernet extender

for the existing Ethernet network.

Antaira VDSL2 Converter provides a much cost effective

replacement and smooth migration for existing Long Reach

Ethernet (LRE) networks.

The cable specications of the connection are listed as following:

10Base-T, Category 3, 4 or 5 UTPl

100Base-TX, Category 5, 5e or 6 UTPl

Ethernet over VDSL2, Twisted-pair telephone wiresl

Ethernet over VDSL2, Coaxial cablel

The two drawings pictures are typical application for the Ethernet

over VDSL2 Converter.

Note

Slave device (CPE) must connect to Master device

(CO) through the telephone wire or coaxial cable.

It is not allow connecting like Master to Master

or Slave to Slave. To define the EVC-3001 /

EVC-3010 to CO or CPE, please refer to section

2.2.1 for more detail.

Telephone wire

100Base-TX UTP

VDSL2 Coaxial Cable

VDSL2

Main office/PBX,

Telco CO,

wire closet

Existing Telephone Network

IP Camera

Ethernet

Switch

CAM Viewer

Coaxial

ECV-3011 CPE+

EVC-3011 CO

VDSL2

LAN1

EVC-3001

CPE

Ethernet over VDSL and Telephone Network

Main office/PBX,

Telco CO,

wire closet

LAN2

Router

Internet

Multi-LAN Connection

Telephone wire

100Base-TX UTP

VDSL2 Coaxial Cable

VDSL2

Main office/PBX,

Telco CO,

wire closet

Existing Telephone Network

Ethernet over VDSL and Telephone Network

LAN2LAN1

Up to 1.6km

Up to 3.0km

Coaxial Cable

EVC-3001

CPE

EVC-3001

Main office/PBX,

Telco CO,

wire closet

EVC-3001

CPE

EVC-3001

Ethernet over VDSL and Telephone Network

LAN2LAN1

Up to 1.6km

Main office/PBX,

Telco CO,

wire closet

IP Camera

CAM Viewer

EVC-3001 CO

VDSL2

EVC-3001 CPE

LAN to LAN Connection

1.3 Key Features

The Ethernet over VDSL2 Converter provides the following key

features:

Cost-effective VDSL2 CO / CPE bridge solutionl

One box design, CO / CPE selectable via DIP Switchl

Denes Asymmetric (Band Plan 998) and Symmetric band l

plans for the transmission of Upstream and Downstream

signals

Complies with IEEE 802.3, IEEE 802.3u and IEEE 802.3x l

standards

DMT (Discrete Multi-Tone) line codingl

Half Duplex Back Pressure and IEEE 802.3x Full Duplex Pause l

Frame Flow Control

Built-in POTS splitter to share voice and data - (EVC-3001)l

Voice and data communication can be shared on the existingl

telephone wire simultaneously - (EVC-3001)

Support up to 1536 bytes packet size, 802.1Q VLAN tag l

transparent

VDSL2 Stand-Alone transceiver for simple bridge modeml

application

Selectable Target Band Plan and Target SNR Marginl

Support extensive LED indicators for network diagnosticsl
