Anritsu MT8801C Manuel utilisateur

MT8801C

Radio Communication Analyzer

Option 07: Spectrum Analyzer

Operation Manual

(Panel Operation)

ii .

Table of Contents

Section 1 General ......................................... 1-1

1.1 General ........................................................................... 1-2

1.2 Manual Composition ....................................................... 1-3

1.3 Specifications ................................................................. 1-4

Section 2 Panel Layout ................................ 2-1

Section 3 Operation ..................................... 3-1

3.1 Basic Operation .............................................................. 3-3

3.2 Position of Operation Keys ............................................. 3-9

3.3 Setting Observation of Frequency .................................. 3-10

3.4 Level Range Setting ....................................................... 3-15

3.5 Marker Function .............................................................. 3-17

3.6 Marker Search Function ................................................. 3-25

3.7 Coupled Function ........................................................... 3-30

3.8 Selecting the Display Mode ............................................ 3-35

3.9 Selecting the Sweep Method.......................................... 3-50

3.10 Measurement .................................................................. 3-58

Section 4 Peformance Tests ....................... 4-1

4.1 Requirement for Performance Tests .............................. 4-2

4.2 Instruments Required for Performance Test .................. 4-3

4.3 Performance Tests ......................................................... 4-4

Appendixes.................................................... App-1

Appendix A Soft-Key Menu .................................................... A-1

Appendix B Keywords Index .................................................. B-1

1-1

Section 1 General

1.1 General ...................................................................... 1-2

1.2 Manual Composition .................................................. 1-3

1.3 Specifications ............................................................ 1-4

Section 1 General

1-2

1.1 General

The MT8801C Digital Mobile Radio Transmitter Tester is a test platform having all

the hardware needed to test digital mobile communication terminals. The perfor-

mance of radio equipment can be efficiently evaluated by using it with optional test

software.

The frequency usage of radio equipment is becoming more efficient, and the equip-

ment is becoming faster and more digitalized. The MT8801C Spectrum Analyzer

function (option 07) is suitable for signal analysis of such equipment.

Its C/N, distortion, frequency and level accuracy, and other basic performances are

excellent. Operation can be performed easily using software menu screens.

Because frequency domain and time domain waveforms can be switched and dis-

played with one touch, signal analysis of radio equipment can be carried out effi-

ciently.

A MEASURE function allows measurements corresponding to various applications.

Noise measurements, C/N ratio measurements, occupied frequency bandwidth mea-

surements, adjacent channel leakage power measurements, mean power measure-

ments, and evaluation of other radio equipment performances can be easily per-

formed.

Because the Spectrum Analyzer function (option 07) uses high-speed digital signal

processing technology, its main transmitting and measurements can be performed

quickly and accurately.

1-3

1.2 Manual Composition

This manual is made up of the following sections.

Section 1 General

Describes the introduction, function specifications and performance of this instru-

ment.

Section 2 Panel Layout

Explains the basic items for operating this equipment.

Section 3 Operation

Explains basic operation and how to operate for each measurement item.

Section 4 Performance Test

Explains the performance test method for this instrument.

Appendix A Soft-Key Menu

Appendix B Keywords Index

Section 1 General

1-4

1.3 Specifications

The MT8801C Digital Mobile Radio Transmitter Tester option 07 specifications are

listed in Table 1-1 below.

Table 1-1 Option 07: Spectrum Analyzer (1/2)

Frequency setting range

Frequency display accuracy

Marker frequency display accuracy

Frequency span

Resolution bandwidth

Video bandwidth

Sideband noise

HPF

Level measurement

Overall level accuracy

Reference level

Frequency response

Maximum input level

Average noise level

Residual response

0 Hz to 3 GHz (Band 0)/10 MHz to 3 GHz (Band 1)

Setting resolution: 1 Hz

±(display frequency ×reference frequency accuracy + span x span accuracy)

Normal marker: Same as display frequency accuracy,

Digital marker: Same as span accuracy

Span setting range: 0 Hz and 10 kHz to 3 GHz (Band 0)

0 Hz and 10 kHz to 2.99 GHz (BAND 1)

Span accuracy: ±2.5%

Setting range: 300 Hz to 1 MHz (3 dB BW), 1-3 sequence

Accuracy: ±2% (300 Hz to 300 kHz), ±10% (1 MHz)

Selectivity (60 dB: 3 dB): ≤5: 1

3 Hz to 100 kHz (1-3 sequence) and thru

(The resolution bandwidth limits the setting range.)

≤–95 dBc/Hz (frequency 1 GHz, 10 kHz offset)

≤–115 dBc/Hz (frequency 1 GHz, 10 kHz offset)

HPF On/Off (Band 1)

Bandwidth: 1.6 GHz to 3 GHz

Continuous average power: +40 dBm (MAIN connector)

+20 dBm (AUX connector)

DC: 0 V

At 1 kHz resolution bandwidth, 10 Hz video bandwidth

At MAIN connector, input attenuator 20 dB

≤–90 dBm (10 MHz to 2.2 GHz)

≤–85 dBm (>2.2 GHz)

At AUX connector, input attenuator 0 dB

≤–110 dBm (10 MHz to 2.2 GHz)

≤–105 dBm (>2.2 GHz)

≤–70 dBm (MAIN connector, input attenuator 20 dB)

≤–90 dBm (AUX connector, input attenuator 0 dB)

At MAIN connector, reference level +10.1 to +40 dBm, 0 to

–

50 dB of reference level

±1.5 dB

At AUX connector, reference level –9.9 to +20 dB, 0 to –50 dB of reference level

±1.5 dB

Setting range: –60 to +50 dBm (MAIN connector)

–80 to +30 dBm (AUX connector)

Setting resolution: 0.1 dB

Accuracy: When input attenuator, resolution bandwidth, video bandwidth, and

sweep time are set to auto at frequency 100 MHz and span 2 MHz

after calibration

MAIN connector

±0.5 dB (+10.1 to +40 dBm)

±1.0 dB (–60 to +10 dBm)

AUX connector

±0.5 dB (–9.9 to +20 dBm)

±1.0 dB (–80 to –10 dBm)

Resolution bandwidth switching deviation:

±0.1 dB referenced to 3 kHz resolution

bandwidth

0.5 dB at input attenuator 30 dB (AUX: 10 dB), ambient temperature 18 to 28°C,

referenced to 100 MHz

Band 1

Frequency

Amplitude

1-5

1.3 Specifications

Table 1-1 Option 07: Spectrum Analyzer (2/2)

Log linearity

Spurious response

Sweep time setting

range

Trigger switch

Trigger source

Trigger delay

Gate sweep

Marker function

MEASURE function

Number of data points

Detection modes

Display function

Storage function

Frequency 10 MHz to 2.2 GHz, reference level ≥+0 dBm (MAIN connector), ≥–20 dBm (AUX connector)

±0.5 dB (0 to –50 dB, resolution bandwidth ≤1 MHz)

±1.0 dB (0 to –70 dB, resolution bandwidth ≤30 kHz)

±1.0 dB (0 to –80 dB, resolution bandwidth ≤1 kHz)

Second harmonic distortion: Mixer input level –30 dBm

≤–55 dBc (input frequency 10 to 100 MHz)

≤–60 dBc (input frequency 100 to 1500 MHz)

100 ms to 1000 s (frequency domain sweep)

100 ms to 1000 s (time domain sweep, resolution bandwidth ≤1 kHz)

10 ms to 1000 s (time domain sweep, 3 kHz<resolution bandwidth ≤10 kHz)

1 ms to 1000 s (time domain sweep, resolution bandwidth ≤30 kHz)

FREERUN, TRIGGERED

WIDEIFVIDEO : Bandwidth (3 dB): ≥20 MHz

EXT : Trigger level: TTL level

Trigger slope : RISE/FALL

Range: 0 µs to 100 ms, resolution: 2 µs

Displays the spectrum of the signal input in the specified gate zone on the frequency domain display.

Gate delay: Range: 2 µs to 100 ms from trigger point, resolution: 2 µs

Gate width: Range: 2 µs to 100 ms from gate delay point, resolution: 2 µs

Signal search: PEAK→CF, PEAK→REF

Zone marker: NORMAL, DELTA

Marker→function: MARKER→CF, MARKER→REF, ZONE→SPAN

Peak search: PEAK, NEXT PEAK, NEXT RIGHT PEAK, NEXT LEFT PEAK

Noise power: dBm/Hz, dBm/ch

C/N ratio: dBc/Hz, dBc/ch

Occupied frequency bandwidth: N% of POWER method, XdB down method

Adjacent channel leakage power: REF: TOTAL POWER method, REF: REF LEVEL method

Specified channel display (2 channels ×2), graph display

Average power in burst: Average power in specified time range of time domain waveform

501 points

POS PEAK : Displays the highest point among the sample points

NEG PEAK : Displays lowest point among the sample points

SAMPLE : Displays the instantaneous value at the sample point

Trace A : Displays the frequency spectrum.

Trace B : Displays the frequency spectrum.

Trace Time : Displays the time domain waveform at the center frequency.

NORMAL (Update display)

VIEW (Display hold)

MAX HOLD (Maximum envelop display)

MIN HOLD (Minimum envelop display)

AVERAGE (Average value display)

CUMULATIVE (cumulative display)

OVER WRITE (Overwrite display)

Amplitude

SweepFunctions

Section 1 General

1-6.

2-1

Section 2 Panel Layout

The contents of this section are the same as the contents of Option 01 [3.1 Panel

Layout] in this manual. Therefore, refer to Option 01 [3.1 Panel Layout].

Section 2 Panel Layout
