Amprobe AMB-25 Manuel utilisateur

INSULATION TESTER

1. SAFETY INFORMATION

The circuit under test must be de-energized and isolated before

connections are made except for voltage measurement.

Verify operation prior to measuring hazardous voltages (voltage

above 30V AC rms, 42V AC peak and 60V DC).

AMB-25

Do not touch the Circuit connections during a test.

Disconnect the live test lead before disconnecting the neutral

test lead.

INSTRUCTION MANUAL

After insulation tests, to protect electric shock, capacitive circuits

must to be discharged.

READ

MEM

Caution refer to this manual before using the meter.

Dangerous voltages.

Meter is protected throughout by double insulation or

reinforced insulation.

Comply with IEC1010-1

When servicing, use only specified replacement parts.

HOLD

Do not use the meter if the low battery indicator ( BT ) is

showed.

Test leads (including crocodile clips) must be in good order,

clean and no broken or cracked.

Do not use the meter if it looks damaged.

Do not use the meter around explosive gas, vapor or dust.

Do not push test button before all connection and preparation is

done. The instrument must only be used by suitably trained and

competent persons.

Do not use the meter with any parts or cover removed.

Do not use the meter in a wet environment.

U.S. PAT. NO. 478,017

JAPAN PAT. NO. 1180870

CHINA PAT. NO. ZL02367250.1

Warnings and Safety symbols:

www. .com information@itm.com1.800.561.8187

2-2 Electrical Specifications

2. SPECIFICATIONS Accuracies are specified as:

±(...% of reading + ...digits) at 23℃±5℃,below 80% RH.

2-1 General Information

Environment conditions : Insulation Resistance

cInstallation CategoriesⅢ1000V Range Resolution Accuracy Test Voltages

40MΩ/400MΩ250V+20% ~ -0%

400MΩ/1000MΩ

/500V 500V+20% ~ -0%

400MΩ/ 2000MΩ

/1000V

40MΩ: 10 KΩ

400MΩ:100 KΩ

4000MΩ: 10M

3%+5

(<1000M)

5%+5

(>1000M) 1000V+20% ~ -0%

Analog Bar Graph 0 to 4000MΩ

Nominal Current ≧1mA

Pollution Degree 2

eAltitude up to 2000 meters

fIndoor use only

Safety Meets of IEC61010-1 and IEC61557

Display : Dual display, 3-3/4 Digital readout with analog bar

indication.

Sampling Rate : 2.5 sample/sec.

Manual data Memory and Read : Memory capacity 9 set.

Over Range Indicator : “” will be displayed.

Low Battery Indication :

BT Resistance & Continuity (<40Ω)

The ( ) will be displayed when the battery voltage drop

below the operating voltage.

Range Resolution Accuracy Max. open Circuit

Voltage

Overload

Protection

999.9Ω0.1Ω1%+2 3V 1000Vrms

Operating Temperature and Humidity：

0℃to 50℃(32℉to 122℉) below 80% RH (noncondensing).

Temperature Coefficient : 0.10 x (specified accuracy)/ ℃

Storage Temperature and Humidity :

-10℃to 60℃(14℉to 140℉) below 70% RH (noncondensing)

Battery : 6 x 1.5V Size “AA” battery.

Fuse : 6mm x 32mm (0.25 x 1.25 inch), 0.5A 1000V, Fast Acting.

Dimensions : 235 (L) x 116 (W) x 54(H) mm ,

(9.3”L x 4.6”W x 2.1”H)

Weight : Approx. 520g (1.15 LB), include battery

Accessories : Test leads, 6pcs battery, Holster, operation manual.

www. .com information@itm.com1.800.561.8187

cLCD display.

3. PARTS & CONTROLS

COM V

dMEM key : Manual data memory control key.

MEM

READ

eLOCK key : Locks the test Insulation Resistance (MΩ).

a). Press and hold down TEST key, then press LOCK key, the

“ LOCK ” icon appears on the display.

b). In MΩmode continuously applies the test voltage to the circuit to

be tested. The beeper sounds every 2 seconds to remind you

that you are in the LOCK mode.

c). Press Lock or TEST key again to exit the mode.

fREAD key: Manual memory data reading control key.

gkey: In Ωfunction, turns the test lead resistance

compensation ON.

Touch the probe tips together, then press key,

the icon appears on the display and the main

display indicates 0.0Ω.

hTEST key :

a). Used for MΩtest functions.

b). Press and hold TEST key until the main display reading is stable.

ij▼▲ keys : In READ mode, select the memory data location for

direct reading the data from the display.

kRotary switch : To select a measurement function.

lInput terminals.

www. .com information@itm.com1.800.561.8187

Display :

MEM

READ

4. BEFORE OPERATION

Warning

To avoid electrical shock remove test leads before opening case or

battery cover. Do not operate with battery cover open.

To avoid electrical shock when performing resistance tests, remove

all power from the circuit to be measured.

To avoid electrical shock, first connect the test leads to the meter

inputs before you make connection to the circuit under test.

To avoid electrical shock, do not touch test lead tips, test points or

terminals when pressing TEST.

4-1 How to connect test leads.

Connect the red test lead into the “ VΩ” terminal and the black

lead into the “ COM ” terminal.

4-2 Battery Check & Replacement

cManual data memory and read location indicator.

1). If battery power is not sufficient, LCD will display “ BT ”.

Replacement of 6 pcs new batteries, type 1.5V size “AA” is required.

dBeeper symbol shows if beeper turned on in Ωfunction.

eHigh voltage warning symbol flashes, if voltage ≧30V is present on the

probes.

2). Use a screw drive to unscrew the screw secured on battery cover.

Take out the used batteries and replace 6 pcs new batteries.

3). Place back the battery cover and secure the screw.

fResistance reading held from the last measurement in MΩand Ω

function. 4-3 Auto-Power-Off

gZero symbol is on if test leads are zeroed out. 1). The meter automatically turns off after 15 minutes of non-use.

2). To turn the meter back on, turn the rotary switch to OFF, then to

the desired function.

hLock symbol is on if the TEST mode is locked in MΩfunctions.

iLow battery symbol. 4-4 Test Leads Check

jMain display reading for all functions. Set the range select switch to the “Ω” range. Connect the

crocodile clips with the test lead tips, Clip alligator clips with lead

other. The indicator should read <0.5Ω. When the leads are not

connected the display will read infinity indicated by “－－”. This

will ensure that test leads are under working condition.

kAnalog bar graph displays resistance on a logarithmic scale and

voltage on a linear scale. The value always tracks the main display.

www. .com information@itm.com1.800.561.8187

7 8

4-5 Manual Data Memory and Read Mode : 5. ΩRESISTANCE AND CONTINUITY MEASUREMENTS

1). Clear the manual memorized data

1). Set the function switch to Ωposition.

cSet the function switch to OFF position to turn off the meter.

dPress and hold down "MEM" key, and turn on the meter.

When LCD shows "dEL" which means the manual memorized

data is erased.

2). Connect red test lead to “ VΩ” terminal and black test lead to

“ COM ” terminal.

3). Connect the probe to the circuit to be measured. Measure

voltage first to ensure that no haszardous voltage is present, then

switch to ohms.

2). Manual data memory

cPress "MEM" key each time, one set of reading to will be

stored to the memory. At this moment, LCD will show the

"MEM" mark and the memory address number. Total memory

size is 9 sets.

4). Read the resistance value from the display. If the resistance is

approximately 40Ωor less, the meter will beep.

dWhen the memory is full, LCD will show " 9 " memory address

number.

3). Read Manual memory data 6. MΩINSULATION RESISTANCE MEASUREMENTS

cPress "READ" key to enter READ mode, the LCD will show

"READ" mark and the memory address number. 6-1 Measuring Insulation Resistance

dPress " " or " " key to select the desired memory address

number data for display. Measuring insulation resistance requires the application of

potentially dangerous voltage to the circuit. This may include

exposed bonded metal work.

ePress " READ " key again to exit this mode.

Before proceeding, ensure that the installation is correctly wired

and no personnel are endangered by any test.

1). Set the function switch to the desired MΩtest voltage position.

2). Connect red test lead to “ VΩ” terminal and black test lead to

“ COM ” terminal.

3). The display will show “-----“ until the TEST button is pushed.

Press and hold the TEST key. The upper right display shows

the test voltage applied to the circuit under test. The main

display shows the resistance until a stable resistance reading is

displayed on the main display.

www. .com information@itm.com1.800.561.8187

9 10

4). Keeping the probes on the test points when release the TEST key. 7. POWER TOOLS AND SMALL APPLIANCES

The upper right display shows the measured resistance reading

and the circuit now discharges through the meter, while the

main display reading shows the decreasing voltage, keep the

probe touched to test points until the circuit is completely

discharged and the main display shows “-----“.

This test would also apply to other similar equipment that has a line cord.

For double insulated power tools, one leads of megohmmeter to be

connected to the housing. The other leads would be connected to some

metal part of the tool (e.g. chuck, blade).

The upper right display holds the resistance reading until a new

test is started or a different function is selected. Note: The switch of the device must be in the “ON” position and the main

power should be disconnected.

6-2 Using the LOCK Function to Measure Insulation Resistance

The LOCK function holds the test voltage on the probes. Use

LOCK function to make long duration measurements, don’t need to

push and hold the TEST key.

1). Press and hold the TEST key, then press the LOCK key to enter

LOCK mode. In this mode, a potentially dangerous voltage is

continuously applied to the probes.

In this mode, if the probes are disconnected from the circuit, the

meter cannot discharge any potentially dangerous capacitive

voltages left on the circuit.

MOTORS

AC-Disconnect the motor from the line by disconnecting the wires at the

motor terminals or by opening the main switch. If the main switch is

used and the motor also has a starter then the starter must be held, by

some means, in the “ON” position. In the latter case, the measured

resistance will include the resistance of the motor, wire and all other

components between the motor and the main switch. If a weakness is

indicated, the motor and other components should be checked

individually.

Ensure that the circuit is de-energized before connecting the test

probes.

2). Press LOCK or TEST key to disable the Lock function.

If the motor is disconnected at the motor terminals, connect one

megohmmeter lead to the grounded motor housing and the other lead to

one of the motor leads.

Disconnect the motor from the line. To test the brush rigging, field coils

and armature connect one megohmmeter lead to the grounded motor

housing and the other lead to the brush on the commutator.

If the resistance measurement indicates a weakness, raise the brushes

off the commutator and separately test the armature, field coils and

brush rigging by connecting one megohmmeter lead to each of them

www. .com information@itm.com1.800.561.8187

individually, leaving the other connected to the grounded motor housing.

The above also applies to DC Generators.

3). Press TEST key, the display should indicate approximately 0.5Ω, if the

display reads OL, replace the fuse as described next and test again.

8-2 Replace the Fuse

Warning

To avoid electric shock, personal injury or damage to the meter, use

only the specified fuse.

1). Set the function switch to OFF position.

2). Disconnect test leads from any power source.

3). Place the meter face down on a nonabrasive surface and loosen the

four screws.

4). Take off the bottom cover.

5). Remove the fuse, replace with a new fuse.

6). Place the bottom cover on and secure the four screws.

CABLES 7). Test the fuse (refer 8-1 Testing the Fuse).

Disconnect the cable from power. Also disconnect opposite end to avoid

errors of any leakage from other equipment. Check each conductor to

ground and /or lead source by connecting one megohmmeter lead to a

ground and /or lead source and the other megohmmeter lead to each of the

conductors in turn. Check insulation resistance between conductors by

connecting megohmmeter leads to conductors in pairs.

9. BATTERY REPLACEMENT

1). Set the function switch to OFF position.

2). Disconnect test leads from any power source.

3). Place the meter face down on a nonabrasive surface and loosen the

two screws.

4). Take off the battery cover.

5). Remove the battery, replace with six new batteries.

6). Place the battery cover on and secure the two screws.

10. MAINTENANCE & CLEANING

Maintenance & Clearing :

8. FUSE CHECK & REPLACEMENT 1). Repairs or servicing not covered in this manual should only be

performed by qualified personnel.

8-1 Testing the Fuse

2). Periodically wipe the case with a dry cloth.

Do not use abrasives or solvents on this instrument.

1). Set the function switch to LoΩposition.

2). Connect the test leads to the input terminals and short then together.

www. .com information@itm.com1.800.561.8187

WARRANTY

Congratulations! Your new instrument has been quality

crafted according to quality standards and contains quality

components and workmanship. It has been inspected for

proper operation of all of its functions and tested by qualified

factory technicians according to the long-established

standards of our company.

Your instrument has a limited warranty against defective

materials and/or workmanship for one year from the date of

purchase provided that, in the opinion of the factory, the

instrument has not been tampered with or taken apart.

Should your instrument fail due to defective materials,

and/or workmanship during this one-year period, a no

charge repair or replacement will be made to the

original purchaser. Please have your dated bill of sale,

which must identify the instrument model number and

serial number and call the number listed below:

Please obtain an RMA number before returning product

for repair.

Outside the U.S.A. the local representative will assist you.

Above limited warranty covers repair and replacement of

instrument only and no other obligation is stated or implied.

www. .com information@itm.com1.800.561.8187

Table des matières

Autres manuels Amprobe Équipement de test

Amprobe

Amprobe MEGATEST 5000 Manuel utilisateur

Amprobe

Amprobe RS-3 PRO CAT IV Analog Manuel utilisateur

Amprobe

Amprobe AT-2032 Manuel utilisateur

Amprobe

Amprobe A-5000 Manuel utilisateur

Amprobe

Amprobe BAT-500 Manuel utilisateur

Amprobe

Amprobe INSP-3 Manuel utilisateur

Amprobe

Amprobe BAT-250 Manuel utilisateur

Amprobe

Amprobe UAT-505 Manuel utilisateur

Amprobe

Amprobe AMB-45 Manuel utilisateur

Amprobe

Amprobe ROBIN KMP7010 Manuel utilisateur

Amprobe

Amprobe Telaris Series Manuel utilisateur

Amprobe

Amprobe VPC-10 Manuel utilisateur

Amprobe

Amprobe DMIII Manuel utilisateur

Amprobe

Amprobe ACD-14 FX Manuel utilisateur

Amprobe

Amprobe AMB-55 Manuel utilisateur

Amprobe

Amprobe UAT-600-EUR Series Manuel utilisateur

Amprobe

Amprobe PY-1A Manuel utilisateur

Amprobe

Amprobe GROUND PROBE GP-1 Manuel utilisateur

Amprobe

Amprobe CT235A Manuel utilisateur

Amprobe

Amprobe INSP-3 Manuel utilisateur

Amprobe

Amprobe SM-CAL1 Manuel utilisateur

Amprobe

Amprobe LT-10-EUR Manuel utilisateur

Amprobe

Amprobe CT238A Manuel utilisateur

Amprobe

Amprobe BAT-200 Manuel utilisateur

Manuels Équipement de test populaires d'autres marques

SMART

SMART KANAAD SBT XTREME 3G Series Manuel utilisateur

Agilent Technologies

Agilent Technologies BERT Serial Manuel utilisateur

Agilent Technologies

Agilent Technologies N3280A Manuel utilisateur

Vernier

Vernier Go Direct Voltage Manuel utilisateur

Lifeloc

Lifeloc R.A.D.A.R. Manuel utilisateur

Fluke

Fluke T5-600 Instructions d'utilisation et d'installation

Mercury

Mercury TSL01 Manuel utilisateur

MAHA

MAHA MBT Series Manuel utilisateur

Fuji Electric

Fuji Electric P-61 Manuel utilisateur

ETC

ETC SealerAtor Manuel utilisateur

Skyfine

Skyfine ETHYWAY V2 Manuel utilisateur

Appion

Appion G5 Twin Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 8159-0112A Manuel utilisateur

BW Technologies

BW Technologies MicroDock II Manuel utilisateur

Sun Nuclear

Sun Nuclear 1027 Manuel utilisateur

Biomark

Biomark HPR LITE READER Manuel utilisateur

Hioki

Hioki 3169-20 Manuel utilisateur

Ashcroft

Ashcroft ATE-100 Manuel utilisateur
