Amprobe INSP-3 Manuel utilisateur
INSP-3
Wiring Inspection Tester
Users Manual
December 2009, Rev.1
©2009 Amprobe Test Tools.
All rights reserved. Printed in China
English
Limited Warranty and Limitation of Liability
Your Amprobe product will be free from defects in material
and workmanship for 1 year from the date of purchase. This
warranty does not cover fuses, disposable batteries or damage
from accident, neglect, misuse, alteration, contamination, or
abnormal conditions of operation or handling. Resellers are
not authorized to extend any other warranty on Amprobe’s
behalf. To obtain service during the warranty period, return the
product with proof of purchase to an authorized Amprobe Test
Tools Service Center or to an Amprobe dealer or distributor.
See Repair Section for details. THIS WARRANTY IS YOUR ONLY
REMEDY. ALL OTHER WARRANTIES - WHETHER EXPRESS,
IMPLIED OR STAUTORY - INCLUDING IMPLIED WARRANTIES OF
FITNESS FOR A PARTICULAR PURPOSE OR MERCHANTABILITY,
ARE HEREBY DISCLAIMED. MANUFACTURER SHALL NOT
BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES OR LOSSES, ARISING FROM ANY
CAUSE OR THEORY. Since some states or countries do not
allow the exclusion or limitation of an implied warranty or of
incidental or consequential damages, this limitation of liability
may not apply to you.
Repair
All test tools returned for warranty or non-warranty repair or
for calibration should be accompanied by the following: your
name, company’s name, address, telephone number, and proof
of purchase. Additionally, please include a brief description of
the problem or the service requested and include the test leads
with the meter. Non-warranty repair or replacement charges
should be remitted in the form of a check, a money order,
credit card with expiration date, or a purchase order made
payable to Amprobe® Test Tools.
In-Warranty Repairs and Replacement – All Countries
Please read the warranty statement and check your battery
before requesting repair. During the warranty period any
defective test tool can be returned to your Amprobe® Test
Tools distributor for an exchange for the same or like product.
States and Canada In-Warranty repair and replacement units
can also be sent to a Amprobe® Test Tools Service Center (see
address below).
Non-Warranty Repairs and Replacement – US and Canada
Non-warranty repairs in the United States and Canada
should be sent to a Amprobe® Test Tools Service Center. Call
Amprobe® Test Tools or inquire at your point of purchase for
current repair and replacement rates.
1
1) Power Cord Receptacle
2) Power/Select Push button
3) GFCI Test Push button
4) AFCI Test Push button
5) Battery Compartment
6) LCD Display
7) 20A load LED indicator
8) 20A load push button
selector
9) 15A load LED indicator
10) 15A load push button
selector
11) 10A load push button
selector
12) 10A load LED indicator
INSP-3 Wiring Inspection Tester
6
1
4
9
2
3
5
7
8
10
11
12
1
CONTENTS
SYMBOLS........................................................................ 2
UNPACKING AND INSPECTION ..................................... 4
INTRODUCTION .............................................................. 4
Features ...................................................................... 4
OPERATION..................................................................... 6
Main Screen (Refer to Fig.2) ..................................... 6
Secondary Screen (Refer to Fig.3) ............................ 7
What the Readings Mean ......................................... 8
SPECIFICATION ............................................................. 11
MAINTENANCE AND REPAIR ....................................... 11
Battery Replacement .............................................. 12
2
3
SYMBOLS
Battery �Refer to the
manual
Double Insulated Dangerous Voltage
Alternating Current Earth Ground
Direct Current Fuse
�
Application around
and removal
from hazardous
live conductors is
permitted
Complies with EU
directives
=
Do not dispose
of this product as
unsorted municipal
waste
Conform to
relevant Australian
standards
Underwriters
Laboratories.[Note:
Canadian and US.]
Audible tone
Safety Information
•The INSP-3 wiring inspection Tester is conformed
to EN61010-1:2001; CAT II 120 V, class II and
pollution deg.2
•Do not exceed the maximum overload limits
(see specifications) nor the limits marked on the
instrument itself. Never apply more than 120
VAC rms between the adaptor prongs of the
wiring inspection tester.
2
3
�WARNING and PRECAUTIONS
•Before and after hazardous voltage
measurements, test the voltage function on a
known source such as line voltage to determine
proper meter functioning.
•Inspect the INSP-3 wiring inspection tester before
every use. Do not use any damaged part.
•Never ground yourself when taking
measurements. Do not touch exposed circuit
elements or test probe tips.
•Do not operate the instrument in an explosive
atmosphere.
•To reduce the risk of fire or electric shock, do not
expose this product to rain or moisture.
•The meter is intended only for indoor use. To
avoid electrical shock hazard, observe the proper
safety precautions when working with voltages
above 60 VDC, 42.4 Vpk, or 30 VAC rms. These
voltage levels pose a potential shock hazard to
the user.
•Before and after hazardous voltage
measurements, test the voltage function on a
known source such as line voltage to determine
proper meter functioning.
•Keep your hands/fingers behind the hand/finger
barriers (of the meter and the power cord) that
indicate the limits of safe access of the hand-held
part during measurement.
4
5
UNPACKING AND INSPECTION
Your shipping carton should include:
1 INSP-3 Wiring Inspection Tester
1 Power Cord
1 9V Alkaline Battery (Installed)
1 Users Manual
1 Carrying Case
If any of the items are damaged or missing, return
the complete package to the place of purchase for an
exchange.
INTRODUCTION
The INSP-3, wiring inspector is a rugged tester
designed to verify building wiring compliance to
electrical code, especially voltage drop under load.
Identify issues with splices, connections and conductor
quality, crucial to safety and performance of the
electrical system.
Features
• Testingefciency-relevanttestdata(voltage,
voltage drop, hot and neutral voltage drop,
voltage with load, ground impedance) is
presented on a single large display to save
operator time - no scrolling or switching screens
needed
• Veriesifwiringistestedforload
carrying ability that meets electrical code
recommendations for voltage drop under load
4
5
• Meterdetectsfaultywiringinneedofrepair
without removing outlets cover plates, or panel
covers:
• Faultysplicesandconnections
• Incorrectwiring
• Undersizedwiring
• FaultyGFCIs,
• FaultyorincorrectlywiredAFCIs
• Incorrectlinevoltage
• Poorgroundquality
• Userselectable10,15and20ampsloadstoverify
performance of the electrical system
• Incorrectwiringorvoltagedroptestfailureis
clearly indicated by flashing screen
• Willnottripcircuitbreakersorblowfuses
during the test
• TestsGFCIandAFCIoperations
• Checkgroundqualityforsafetyandabilityto
support sensitive electronic equipment
• Measurefaultcurrents
• Savemoneyandtimebyeliminatingguesswork.
NOTE: The Inspector™ 3 does not check the
condition of wiring insulation.
