Ameriwood HOME 1005339COM Manuel utilisateur

1005339COM

TV Stand

- Unit can tip over causing severe injury or death.

- Anchor unit to stud in wall (if instructed to).

- Do Not allow children to climb on unit.

- Put heavy items on lower shelves or drawers.

B341005339COM1

THIS INSTRUCTION BOOKLET CONTAINS

IMPORTANT

SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

WARNING

Date of Purchase ___ / ___ / ___

Lot Number:

Do Not Return This Product!

Contact our customer service team for help first.

Call: 1-800-489-3351 (toll free)

Monday-Friday 9am - 5pm CST

Visit: www.ameriwoodhome.com

Assembly Difficulty Meter

Easy Tough

Helpful Hints

Do NOT return this product!

Contact our friendly customer service team first for help.

Call us!

1-800-489-3351

Monday-Friday

9am - 5pm CST

Visit ameriwoodhome.com to view the

limited warranty valid in the U.S. and Canada.

Assembly Tips

- Open your item in the area you plan to keep it to avoid excessive heavy lifting.

- Identify, sort and count the parts before attempting assembly.

- Compression dowels are lightly tapped in with a hammer.

- Slides are labeled with a

(right) and

(left) for proper placement.

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge.

- Use all the nails provided for the back panel and spread them out equally.

- Back panel must be used to make sure your unit is sturdy.

- Do NOT use harsh chemicals or abrasive cleaners on this item.

- Never push, pull, or drag your furniture.

Tube

You

PEOPLE NEEDED FOR ASSEMBLY: 2

ESTIMATED ASSEMBLY TIME: 2 HOUR

Before You Start

Quick

Tip

Assembly

Cam Lock Fastening System

This Cam Lock Fastening System will be used throughout the assembly process.

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, #2 Phillips Head

Screwdriver and Hammer

Caution: If using a power drill or power screwdriver for screwing,

please be aware to slow down and stop when screw is tight.

Failure to do so may result in stripping the screw.

Board Identification

Not actual size

Left Panel

31005339010 Right Panel

31005339020

Top

31005339050

Bottom

31005339060

TV Rail

31005339070

Left Partition

31005339030 Right Partition

31005339040

Center Shelf

31005339080 Center Shelf Rail

31005339090

ABC D

Board Identification

Not actual size

Back

31005339110

Door

31005339120

Back Panel

K100533910

Adjustable Shelf

31005339100

This part is paperboard

construction. It is not made from

wood, but ais required for the

assembly of your unit.

Part List

Actual Size

(x18)

#A22610

cam bolt

(x18)

#A22620

cam lock

(x12)

#A21670

wood dowel

(x8)

#A23030

confirmat screw

(x20)

#A12110

7/16" round

head screw

(x2)

#A52365

knob

(x2)

#A17400

7/8" bolt

(x18)

#A12420

5/8" round

head screw

123

(x5)

#A21960

hidden fastener

(x12)

#A80250

shelf support

(x40)

#A21110

nail

(x4)

#A71880

upper door guide

(x4)

#A71870

lower door roller

610

Note: Your model may have

extra hardware included.

Part List

Not Actual Size

(x6)

#A44325

foot

(x6)

#A54800

foot bracket

(x1)

#A82835

door track

(x1)

#B64356

TV Warning Label

STEP1

Proper orientation of CAM LOCK

Tip

Assembly

Quick

(x2)

#A22610

12 3

(x3)

#A22620 (x2)

#A21670

STEP2

Proper orientation of CAM LOCK

Tip

Assembly

Quick

12 3

(x2)

#A22610 (x3)

#A22620 (x2)

#A21670
