DATA SHEET

Discover™Series

Mini-Domes

Features that make a difference:

High impact vandal resistant housing that retains shape even after

forceful impact

High impact vandal resistant polycarbonate bubbles (clear and tinted)

Snap-on bubble liner for an extra level of covertness

Advanced pivoting axis provides greater viewing flexibility

Three quality auto iris lens options for better image quality and

improved low light performance

Multiple camera options, including WDR model with latest

Pixim technology

Night-Saver mode for extreme low light conditions

Easy installation with eight mounting options (surface, flush, pendant,

wall, wall-pole, wall-exterior corner, inside corner, electrical box)

Discover Drone option

IP66 and NEMA4X-rated for -30° to 50°C (-22° to 122°F)

Optional heater kit for -50°C (-58°F)

The Discover series of Mini-Domes delivers a vandal resistant

camera solution at a non-vandal resistant price. This series of

high performance Mini-Domes includes high impact, vandal

resistant dome housings built to withstand even the harshest

environments. Unlike other dome housings in the industry,

which are made of metal, the Discover series housing is made

with extremely durable composite and polycarbonate materials

that have “shape memory”. The Discover housing comes with

a choice of clear or tinted vandal resistant bubbles and

includes a bubble liner to make it more covert. An advanced

pivoting axis lets you position the camera at exactly the angle

you need, while optimal white balance provides the clearest,

most color-perfect images possible.

With three different types of mini-domes to choose from,

there’s a Discover solution just right for your particular

requirements.

The Discover wide dynamic range (WDR) Mini-Dome uses

over 504 lines of resolution and a pixel-by-pixel shutter speed

that lets you see better in areas where both very bright and

dark areas exist, such as an entranceway. This model also

features up to a 2x digital zoom to get an even closer view of

the action. Night-Saver mode improves performance in

low light situations, automatically switching from color to

monochrome as light dims and reverting back to color once

light is restored. The WDR mini-dome also includes a

DVR-Saver mode which helps conserve valuable hard drive

space, reducing the size of video files by up to 30% when

used with an Intellex

digital video management system.

The Discover high resolution Mini-Dome has 540 TVL

and also includes a user-selectable Night-Saver mode. For

challenging lighting environments, a selectable expanded auto

white balance mode is available. Vivid colors and powerful low

light performance provide some of the best images available

on the market today.

The Discover standard resolution camera offers a cost

effective solution for the value-conscious with 330 TVL. It is

available with a 3.8 – 9.5 mm vari-focal, auto iris lens.

The Discover series includes a drone option—which looks

like a mini-dome from the outside but without a camera

inside—and is perfect for crime deterrence at an even greater

cost savings.

SPECIFICATIONS

Product offerings and specifications are subject to change without notice. Actual products may vary from photos. Not all products include all features.

Availability varies by region; contact your sales representative. certain product names mentioned herein may be trade names and/or registered trademarks

of other companies.

www.americandynamics.net

Model Number Configuration for Discover Mini-Domes

General

Imager Pixim orca sensor 1/3-inch CCD 1/3-inch CCD

Video Output 1.0 Vp-p/75-ohm, BNC 1.0 Vp-p/75-ohm, BNC 1.0 Vp-p/75-ohm, BNC

Horizontal Resolution 504+ TV lines 540 TV lines 330 TV lines

Active Pixel Count (H x V) Universal: 720 x 540 NTSC: 768 x 494 (PAL: 752 x 582) NTSC: 510 x 492 (PAL: 500 x 582)

Minimum Scene Illumination 0.95 lux @ F1.2 0.65 lux @ F1.2 0.7 lux @ F1.2

Digital Slow Shutter (DSS) 2x (default) – 32x N/A N/A

Wide Dynamic Range 120 dB/17-bit N/A N/A

Sync System Line-lock, phase-adjustable or internal Line-lock, adjustable or internal Internal

S/N Ratio >42 dB 50 dB 48 dB

White Balance Automatic white balance (AWB), AWB AWB

One-touch & manual

AWB Ranges—Normal (Extended) 2200 – 7500 K (2000 K-11000 K) 2700 – 11000 K (2000 – 18000 K) 2700 – 11000 K (N/A)

WDR Metering Zone One zone adjustable N/A N/A

Backlight Compensation N/A Center weighted on/off N/A

Flickerless Mode Selectable on/off Selectable on/off N/A

Night-Saver Selectable on/off Selectable on/off N/A

DVR-Saver Mode Selectable on/off N/A N/A

Digital Zoom Scalable, up to 2x N/A N/A

Power Consumption 3 watts 2.8 watts 1.7 watts

Weight 0.9 kg (1.9 lbs) 1.0 kg (2.2 lbs) 0.9 kg (1.9 lbs)

High Resolution

ADCDH Series

Standard Resolution

ADCDS Series

Wide Dynamic Range

ADCDW Series

Common to all Discover Mini-Domes

Physical, Electrical, Environmental & Regulatory

Dimensions (H x W) 92 x 136 mm (3.6 x 5.4 in)

Housing Color White

Environmental Rating IP66

Bubble Diameter 94 mm (3.7 in)

Bubble Thickness 2.5 mm (0.1 in)

Bubble F-Stop F1.0 (tinted); F0 (clear)

Pan & Effective Tilt (at 7 in) Range1360º & 180º (+/-90º)

Power Input212 VDC -10% +20%

24 VAC +/-20%, 50/60 Hz

Power Connection Flying lead or plug

Without Heater -30º to 50ºC (-22º to 122ºF)

With Optional Heater -50º to 50ºC (-58º to 122ºF)

Humidity 90% (noncondensing)

Storage Temperature -20º to 60ºC (-4º to 140ºF)

Emissions FCC part 15 Class B

CE: EN55022

ICES-003

Immunity CE: EN50130-4

Safety UL/cUL; CSA C22.2

Lenses

2.5 – 6 mm auto iris lens

F-Stop F1.3 ~ 360

Field of View (H x V) 108.2º x 80.4º (wide) & 47.6º x 35.6º (tele)

3.8 – 9.5 mm auto iris lens

F-Stop F1.2 ~ 360

Field of View (H x V) 74.2º x 54.0º (wide) & 30.0º x 22.4º (tele)

9 – 22 mm auto iris lens

F-Stop F1.8 ~ 360

Field of View (H x V) 30.7º x 22.7º (wide) & 14.1º x 10.6º (tele)

Accessories

ADCDDRONE Drone, no camera or lens capability

ADCDMWALL Wall mount w/pendant cap

ADCDMCRNRO Outside corner adapter for use with

ADCDMWALL

ADCDMPEND Pendant cap, three-quarter inch thread

ADCDMCRNR Corner mount

ADCDMPOLE Pole mount for use with ADCDMWALL

ADCDMELEC 4S electrical box adapter

ADCDHTR Heater module

ADCDSLC Video service lead cable

(1) Using a 2.5-6 mm lens at wide angle.

(2) NEC Class 2/LPS power supply required.

BRAND FAMILY CAMERA LENS BUBBLE FORMAT

AD CD X XXXX X X

ADCDH AD Camera H = High resolution

2506 = 2.5 – 6 mm C = Clear N = NTSC

Series Discover

3895 = 3.8 – 9.5 mm T = Tinted P = PAL

0922 = 9 – 22 mm

ADCDW W = Wide dynamic range

2506 = 2.5 – 6 mm C = Clear U = Universal

Series

3895 = 3.8 – 9.5 mm T = Tinted

(NTSC/ PAL)

0922 = 9 – 22 mm

ADCDS S = Standard resolution

3895 = 3.8 – 9.5 mm C = Clear N = NTSC

Series

T = Tinted P = PAL
