AMD IB550F Manuel utilisateur

IB550F

AMD Geode LX

3.5-inch Disk Size SBC

USER’S MANUAL

Version 1.1

IB550F User’s Manual

Acknowledgments

Award is a registered trademark of Award Software International, Inc.

PS/2 is a trademark of International Business Machines Corporation.

AMD, AMD Geode, and combinations thereof, are trademarks of

Advanced Micro Devices, Inc.

Microsoft Windows is a registered trademark of Microsoft Corporation.

All other product names or trademarks are properties of their respective

owners.

IB550F User’s Manual iii

Table of Contents

Introduction...................................................... 1

Product Description....................................................................1

Checklist ....................................................................................2

Specifications .............................................................................3

Board Dimensions ......................................................................4

Installations...................................................... 5

Installing the Memory.................................................................6

Setting the Jumpers ....................................................................7

Connectors on IB550F..............................................................11

BIOS Setup.......................................................21

Drivers Installation......................................37

Entertainment Encryption/Decryption Controller Driver............38

VGA Drivers Installation..........................................................40

Audio Driver Installation ..........................................................43

Silicon Image Sil3512ECTU Driver Installation ........................46

Appendix...........................................................49

A. I/O Port Address Map..........................................................49

B. Interrupt Request Lines (IRQ)..............................................51

C. Watchdog Timer Configuration............................................52

IB550F User’s Manual

This page is intentionally left blank.

INTRODUCTION

IB550F User’s Manual 1

Introduction

Product Description

The IB550F 3.5-inch disk size SBC incorporates the AMD Geode LX

processor with speeds of 433MHz (LX700) or 500MHz (LX800). It

comes with one DDR SO-DIMM socket that has a capacity of 1GB

system memory. The board supports one 10/100Mbps Ethernet, using a

Realtek RTL8100C controller. A 2D graphics controller comes

integrated on the board that supports CRT and TFT LCD displays. Useful

interface includes four USB 2.0 ports, 4 COM ports, and one PCI-104

expansion slot. IB550F also support 2 SATA ports.

IB550F FEATURES:

-Embedded AMD Geode LX processor, 433MHz (LX700) /

500MHz (LX800)

-DDR SO-DIMM x 1, Max. 1GB

-Realtek RTL8100C 10/100Mbps Ethernet

-Integrated LX800/LX700 2D VGA controller, supports CRT

and TFT LCD display

-4 x USB 2.0, 4 x COM, CF socket, Watchdog timer, Digital I/O

-2 x SATA, PCI-104 expansion

-Dimensions: 145mm x 102mm (5.7” x 4”)

INTRODUCTION

IB550F User’s Manual

Checklist

Your IB550F package should include the items listed below.

•The IB550F AMD Geode LX 3.5-inch Disk Size SBC

•This User’s Manual

•1 CD containing chipset drivers and flash memory utility

•Heatsink for AMD Geode LX processor

•Options:

•IB61 cable kit (SATA, COM, PS/2, LPT, USB, Audio, Power

cable)

INTRODUCTION

IB550F User’s Manual 3

Specifications

[

Product Name

IB550F/ IB550F-24

Form Factor

3.5”

CPU Type

AMD Geode (BGU481)

CPU Speed

AMD LX800 500MHz / 128KB L2 cache/ SC (3.8W)

BIOS

Award BIOS

Chipset

AMD CS5536 I/O companion multi-function chipset

Memory

DDR SO-DIMM x1 (w/o ECC), Max.1GB , Single channel

Graphic

LX800 built-in high performance 2D graphic controller

Supports TFT LCD & CRT display

LVDS

18-bit one channels LVDS interface w/DF13 socket x1 [Default]

24-bit one channel LVDS interface w/DF13 socket x1 [IB550F-24]

LAN

Realtek 8100C-LF 10/100M PCI LAN x1

USB (Universal

Serial Bus)

CS5536 built-in USB2.0 controller, support 4ports

Serial ATA Ports

PCI to SATA controller [SiI3512ECTU], supports 2ports

Parallel IDE

CS5536 built-in one channel UDMA100 IDE

- Compact Flash (type II) connector x1

Audio

Realtek ALC203 AC97 audio codec,

Supports 2-CH Line-Out, Line-In & MIC

LPC I/O

Winbond W83627HF + Fintek 81216AD

COM1 (RS232/422/485), COM2~4(RS232) , KB/Mouse, Parallel,

IrDA, Hardware monitor (3 thermal inputs, 4 voltage monitor inputs,

VID0-4)

Digital IO

4 in & 4 out

Keyboard/Mouse

Connector

Mini DIN connector x1

Expansion Slots

PCI-104 x1

Compact Flash Socket x1

Edge Connector

DB-9 connector x1 for COM1 (RS232/422/485)

6-pins Mini-DIN connector x1 for PS/2 KB & Mouse

Dual USB stack connector x1 for USB 1, 2

DB-15 connector x1 for CRT

RJ-45 connector x1 for LAN

On Board

Header/Connector

2x5 pins header x3 for COM2/3/4 (RS232 only)

2x4 pins header x1 for USB 3,4

2x13 pins header x1 for LPT port

2x6 pins header x1 for Audio

2x22 pins header x1 for TFT LCD panel

4-pin header x1 for IrDA

4-pin power connector x 1 for SATA HDD

Watchdog Timer

Yes (256 segments, 0, 1, 2…255 sec/min)

Power Connector

+12V DC-in

RoHS

Yes

Board Size

102mm x 145mm

INTRODUCTION

IB550F User’s Manual

Board Dimensions

INSTALLATIONS

IB550F User’s Manual 5

Installations

This section provides information on how to use the jumpers and

connectors on the IB550F in order to set up a workable system. The

topics covered are:

Installing the Memory..........................................................................6

Setting the Jumpers..............................................................................7

Connectors on IB550F.......................................................................11

INSTALLATIONS

IB550F User’s Manual

Installing the Memory

The IB550F board supports one SODIMM DDR memory socket for a

maximum total memory. The memory module capacities supported are

128MB, 256MB, 512MB and 1GB.

Installing and Removing Memory Modules

To install the DDR modules, locate the memory slot on the board and

perform the following steps:

1. Hold the DDR module so that the keys of the DDR module align with

those on the memory slot. Insert the module into the socket at a slight

angle (approximately 30 degrees). Note that the socket and module are

both keyed, which means that the module can be installed only in one

direction.

2. To seat the memory module into the socket, apply firm and even

pressure to each end of the module until you feel it slip down into the

socket.

3. With the module properly seated in the socket, rotate the module

downward. Continue pressing downward until the clips at each end

lock into position.

4. To remove the DDR module, press the clips with both hands.
