AMD A75 Manuel utilisateur

USER'S MANUAL

AMD A75 /A55 Chipset

Based

M/B for Socket FM1 AMD Processor

Trademark:

* Specifications and information contained in this documentation are furnished for information use only, and are

subject to change at any time without notice, and should not be construed as a commitment by manufacturer.

NO. G03-A55M-F

Rev

：

1.0

Released in: October, 2011

Environmental Safety Instruction

zAvoid the dusty, humidity and temperature extremes. Do not place the product in any

area where it may become wet.

z0 to 40 centigrade is the suitable temperature. (Actual figure depends on the request of

the main chipset)

zGenerally speaking, dramatic changes in temperature may lead to contact malfunction

and crackles due to constant thermal expansion and contraction from the welding

spots’ that connect components and PCB. Computer should go through an adaptive

phase before it boots when it is moved from a cold environment to a warmer one to

avoid condensation phenomenon. These water drops attached on PCB or the surface

of the components can bring about phenomena as minor as computer instability

resulted from corrosion and oxidation from components and PCB or as major as short

circuit that can burn the components. Suggest starting the computer until the

temperature goes up.

zThe increasing temperature of the capacitor may decrease the life of computer. Using

the close case may decrease the life of other device because the higher temperature in

the inner of the case.

zAttention to the heat sink when you over-clocking. The higher temperature may

decrease the life of the device and burned the capacitor.

Environmental Protection Announcement

Do not dispose this electronic device into the trash while discarding. To minimize pollution

and ensure environment protection of mother earth, please recycle.

CHAPTER 1 INTRODUCTION OF MOTHERBOARDS

1-1 MOTHERBOARD SPECIFICATION...........................................................................1

1-2 SPECIAL FREATURES ............................................................................................2

1-3 LAYOUT DIAGRAM ..................................................................................................4

CHAPTER 2 HARDWARE INSTALLATION

2-1 HARDWARE INSTALLATION STEPS.......................................................................6

2-2 JUMPER SETTING......................................................................................................6

2-3 CPU INSTALLATION..................................................................................................7

2-3-1 ABOUT AMD FM1 CPU SOCKET................................................................7

2-3-2 CPU INSTALLATION GUIDE .......................................................................7

2-4 MEMORY INSTALLATION.........................................................................................8

2-5 EXPANSION CARD INSTALLATION.........................................................................9

2-5-1 EXPANSION SLOTS.....................................................................................9

2-5-2 PROCEDURE FOR EXPANSION CARD INSTALLATION..........................9

CHAPTER 3 CONNCTORS AND HEADERS

3-1 I/O BACK PANEL CONNECTORS.............................................................................10

3-2 MOTHERBOARD INTERNAL CONNECOTRS..........................................................11

3-3 HEADERS ...................................................................................................................13

CHAPTER 4 USEFUL HELP

4-1 HOW TO UPDATE BIOS ............................................................................................15

4-2 TROUBLE SHOOTING ...............................................................................................15

APPENDIX...................................................................................................................16

TABLE OF CONTENT

Chapter 1

Introduction of Motherboards

1-1 Motherboard Specification

Spec Description

Design zMicro-ATX Form Factor

zSize: 24.5 x 19.0 cm

Chipset zAMD™ A75 FCH (Hudson D3) Chipset (Optional for A75M series)

zAMD™ A55 FCH (Hudson D2) Chipset (Optional for A55M series)

CPU Socket

zAMD™ Socket FM1：

zSupport AMD™ A- & E2- “Lynx” Series APU

* For more detailed CPU support information please visit our website

Memory Slot

z240-pin DDRIII Module slot x 2

zSupport 2pcs of DDRIII 1066/1333/1600/1866 memory modules

expandable to 8GB

zDual channel supported

Expansion

Slot

z1pcs * PCI-Express 2.0 x16 by 16 lane slot

z1pcs * PCI-Express 2.0 x1 slot

z1pcs * 32-bit PCI slot

Storage z4 * SATAIII 6Gb/s connectors (Optional for A75M series)

z4* SATAII 3Gb/s connectors (Optional for A55M series)

LAN Chip

zIntegrated with PCI-E megabit LAN chip providing 10/100Mbps data

transfer rate

zSupport Fast Ethernet LAN function

HD Audio Chip z6-channel HD Audio Audio Codec integrated

zAudio driver and utility included

BIOS z16MB Flash ROM BIOS

Multi I/O

zPS/2 keyboard connector x1

zPS/2 mouse connector x1

zVGA connector x1

zDVI connector x1

zHDMI connector x 1

zUSB 2.0 port x 2 + USB 3.0 port x 2(Optional for A75M series)

zUSB 3.0 header x1 (Optional for A75M series)

zUSB 2.0 port x 4 (Optional for A55M series)

zUSB 2.0 header x 2

zRJ-45 LAN connector x1

zAudio connector x1

zFront panel audio header x1

zHDMI-SPDIF header x1

zSpeaker header x1

zPWR LED header x1

zFront panel header x1

Item Checklist

zMotherboard

zDVD for motherboard utilities

zUser’s Manual

zHard Disk Cable

zBack Shied

1-2 Special Features

APU

Accelerated Processing Unit (APU) is the unique combination of

CPU and GPU computing technology. It is designed to vastly

improve today’s internet, video processing, playback and gaming

experiences.

AMD Radeon™ Dual Graphics

The AMD™ Dual Graphics technology combines APU and GPU

computing power to optimize user’s visual experience.

Microsoft®DirectX®11

DirectX ® 11 is the latest in high speed, high fidelity gaming and

computing. It can enable not just more visually stunning games, but

significant performance improvements in some of your favorite

websites and everyday applications.

AMD Steady Video™

New Video Post Processing Capability: automatic jitter reduction on

home/online video.

AMD Turbo

Core™

AMD Turbo Core™

Dynamic adjustment of CPU and GPU performance, Automatically

detects the load, without any driver support.

AMD Steady Video™

USB 3.0 (Optional for A75M series)

Experience Fastest data transfers at 5Gb/s with USB3.0 the new

latest connectivity standard. Built connect easily with nextgeneration

components and peripherals, USB3.0 transfers data 10x faster and

backward compatible with previous USB2.0 components.

SATA 3.0 (Optional for A75M series)

SATA3.0 6Gb/s provides a higher bandwidth to retrieve and transfer

HD media. With this super speed data transfer, SATA3.0 allows an

incredible data boost which is 2x faster than the SATA 3Gb/s.

CPU Vcore OC-CON Solid Capacitors

This series of boards adopt OC-CON solid capacitors for CPU

Vcore power. OC-CON solid capacitors make it possible for

motherboard to work from 55 degrees Centigrade below zero to 125

degrees centigrade. OC-CON capacitors possess superior physical

characteristics to prolong product life ten times than corresponding

motherboard without capacitors every time working temperature

increases 20 degrees. Life of product of motherboard with solid

capacitors declines only 10% of those without solid capacitors as

well under same conditions.

Other Features

include: CPU Smart Fan—Noise Management System

It’s never been a good idea to gain the performance of your system

by sacrificing its acoustics. CPU Smart Fan Noise Management

System is the answer to control the noise level needed for

now-a-day’s high performance computing system. The system will

automatically increase the fan speed when CPU operating loading is

high, after the CPU is in normal operating condition, the system will

low down the fan speed for the silent operating environment. The

system can provide the much longer life cycle for both CPU and the

system fans for game use and business requirements.

CPU Vcore X-Shift—Shift to Higher Performance

The CPU voltage can be adjusted for the precisely over-clocking of

extra demanding computing performance.

Normal load, APU to keep

low frequency energy

3D games, film and television

production and other heavy loads, APU

automatic over clocking

0 ~ 400MHz

1-3 Layout Diagram

For A75M Series Motherboard:

Megabit LAN Chip

Front Panel Header

AMD FM1

Socket

ATX Power Conn.

PCI Slot

PS2 KB &MS

Ports

RJ-45 over

USB 2.0 Ports

DDRIII Slot x 2

ATX 12V Power Connecto

6-CH

HD Audio Chip Power LED Header

USB 2.0 Headers

Front Panel

Audio Header

CPUFAN Header

SYSFAN1 Header

PCI Express x16 by 16-lane Slot

Speaker Header

USB 3.0 Ports

JBAT

VGA Port

Audio Connector

SATAIII Hard Disk

Ports

(SATA1/2/3/4)

JP2

DVI Port

HDMI Port

USB 3.0 Header

AMD A75 Chipset

HDMI-SPDIF Header

PCI Express x1 Slot

RJ-45 LAN Port

USB 2.0 Ports

PS/2 Keyboard

Port

VGA Port

PS/2 Mouse

Port Line-In

Line-Out

MIC-In

DVI Port HDMI Port

USB 3.0 Ports

For A55M Series Motherboard:

Megabit LAN Chip

Front Panel Header

AMD FM1

Socket

ATX Power Conn.

PCI Slot

PS2 KB &MS

Ports

RJ-45 over

USB 2.0 Ports

DDRIII Slot x 2

ATX 12V Power Connecto

6-CH

HD Audio Chip Power LED Header

USB 2.0 Headers

Front Panel

Audio Header

CPUFAN Header

SYSFAN1 Header

PCI Express x16 by 16-lane Slot

Speaker Header

USB 2.0 Ports

JBAT

VGA Port

Audio Connector

SATAII Hard Disk

Ports

(SATA1/2/3/4)

JP2

DVI Port

HDMI Port

AMD A55 Chi

set

HDMI-SPDIF Header

PCI Express x1 Slot

USB 2.0 Ports

PS/2 Keyboard

Port

VGA Port

PS/2 Mouse

Port Line-In

Line-Out

MIC-In

DVI Port HDMI Port

RJ-45 LAN Port

Chapter 2

Hardware Installation

WARNING! Turn off your power when adding or removing expansion cards or

other system components. Failure to do so may cause severe

damage to both your motherboard and expansion cards.

2-1 Hardware Installation Steps

Before using your computer, you had better complete the following steps:

1. Check motherboard jumper setting

2. Install CPU and Fan

3. Install System Memory (DIMM)

4. Install Expansion cards

5. Connect hard disk and front panel /back panel cable

6. Connect ATX Power cable

7. Power-On and Load Standard Default

8. Reboot

9. Install Operating System

10. Install Driver and Utility

2-2 Jumper Setting

(1) CMOS RAM Clear (3-pin): JBAT

A battery must be used to retain the motherboard configuration in CMOS RAM

short 1-2 pins of JBAT to store the CMOS data.

To clear the CMOS, follow the procedure below:

1. Turn off the system and unplug the AC power.

2. Remove ATX power cable from ATX power connector.

3. Locate JBAT and short pins 2-3 for a few seconds.

4. Return JBAT to its normal setting by shorting pins 1-2.

5. Connect ATX power cable back to ATX power connector.

Note: When should clear CMOS

1. Troubleshooting

2. Forget password

3. After over clocking system boot fail

CMOS RAM Clear Setting

2-3 Closed: Clear CMOS

JBATJBAT

1-2 Closed: Normal

(2) Keyboard/USB function Enabled/Disabled: JP2

Keyboard/ & USB Power On Setting

2-3 Closed: KB/USB Power ON Enabled

JP2

1-2 Closed:KB/USB Power ON Disable (Default)

2-3 CPU Installation

2-3-1 About AMD FM1 CPU Socket

This motherboard provides an AMD FM1 socket.

The CPU that comes with the motherboard should have a cooling FAN attached to

prevent overheating. If this is not the case, then purchase a correct cooling FAN

before you turn on your system.

WARNING! Be sure that there is sufficient air circulation across the processor’s

heatsink and CPU cooling FAN is working correctly, otherwise it may

cause the processor and motherboard overheat and damage, you

may install an auxiliary cooling FAN, if necessary.

To install a CPU, first turn off your system and remove its cover. Then find Pin-1

(small triangle indicator) of the CPU and make sure to install it matched with Pin-1

(small triangle indicator) of the CPU socket. See to it that system is turned off and the

installation direction is correct. If the installation direction is wrong, CPU can not be

installed into the socket. In this case do not try to force it into the socket, but to change

to the correct direction.

2-3-2 CPU Installation Guide

1. Locate APU socket.

2. Find APU socket

Pin-1(with small triangle

indicator).

3. Find APU Pin-1

(with small triangle

indicator).

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels AMD Carte mère

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
