Amazon B0787D6SGQ Manuel utilisateur
Quick Start Guide
Guide de Démarrage Rapide
Kurzanleitung
Guida Rapida
Guía de Inicio Rápido
クイックスタートガイド
快速使用指南
Ergonomic Wireless Mouse - DPI Adjustable
Souris Sans Fil Ergonomique - DPI ajustable
Ergonomische, kabellose Maus – DPI einstellbar
Mouse Wireless Ergonomico - DPI Regolabile
Ratón Inalámbrico Ergonómico - DPI Ajustable
ワイヤレスマウス人間工学 – DPIア ジャスタブル
人体工学无线鼠标 – DPI 可调 B0787D6SGQ,
B0787PGF9N, B0787K1MLT, B0787QZ6WD, B0787G1YFF
created by: Impala Services Ltd.Page size: 4.25“ x 3.5“ (~108 x 89 mm)
158200-B0787D6SGQ-Mouse-UM-GLO-V06.indb 1 4/10/18 10:09 AM
2
Parts List
DPI Key
ON/OFF Switch
Scrolling Wheel
Right Button
Left Button
Backward
Nano Receiver
Forward
Battery Cover
Setup
Installing the Battery
AA Battery
158200-B0787D6SGQ-Mouse-UM-GLO-V06.indb 2 4/10/18 10:09 AM
3
Setup
Installing the Battery
• Remove the battery cover.
• Insert the battery correctly with regard to polarity (+ and –) marked on the
battery and the product.
• Place the cover back over the battery compartment.
• Set the ON/OFF switch to ON.
Connecting Mouse and Keyboard to Receiver
• Remove the battery cover, and take the nano receiver out.
• Plug the nano receiver into a USB port of your computer.
158200-B0787D6SGQ-Mouse-UM-GLO-V06.indb 3 4/10/18 10:09 AM
4
Operation
Controls
Forward
• Press this button to view the next page in your Internet browser.
Backward
• Press this button to view the previous page in your Internet browser.
DPI Setting Adjustment
• 5 DPI settings are available.
• The number of times the DPI key blinks indicates the current DPI setting
(Note: the default setting is 1600 DPI).
DPI Number of
Blinks
600 DPI 1
1000 DPI 2
1600 DPI 3
2400 DPI 4
3600 DPI 5
158200-B0787D6SGQ-Mouse-UM-GLO-V06.indb 4 4/10/18 10:09 AM
5
Federal Communication Commission
Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate this
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
158200-B0787D6SGQ-Mouse-UM-GLO-V06.indb 5 4/10/18 10:09 AM
6
Radiation Exposure Statement:
The product complies with the FCC portable RF exposure limit set forth for an
uncontrolled environment and are safe for intended operation as described in
this manual. The further RF exposure reduction can be achieved if the product
can be kept as far as possible from the user body or set the device to lower
output power if such function is available.
IC Caution
This device complies with Industry Canada’s licence-exempt RSSs. Operation is
subject to the following two conditions:
(1) This device may not cause interference; and (2) This device must accept any
interference, including interference that may cause undesired operation of the
device.
Simplied EU Declaration of Conformity
Hereby, Amazon EU S.à.r.l., 5 Rue Plaetis, L-2338 Luxembourg declares
that the radio equipment type (Ergonomic Wireless Mouse - DPI Adjustable,
B0787D6SGQ, B0787PGF9N, B0787K1MLT, B0787QZ6WD, B0787G1YFF) is
in compliance with Directive 2014/53/EU.
Intended Use
This product is a wireless computer peripheral intended for interacting with your
desktop/laptop.
158200-B0787D6SGQ-Mouse-UM-GLO-V06.indb 6 4/10/18 10:09 AM
7
Safety and Compliance
Read this instruction manual carefully before using the product. It contains
important information for your safety as well as operating and maintenance
advice. Observe all safety instructions to avoid damage through improper use!
Follow all warnings on the product. Keep this instruction manual for future use.
Should this product be passed on to a third party, then this instruction manual
must be included.
• Never use this product if damaged.
• Do not insert any foreign objects into the inside of the casing.
• Protect the product from extreme temperatures, hot surfaces, open flames,
direct sunlight, water, high humidity, moisture, strong jolts, flammable gases,
vapours and solvents.
• Keep this product and its packaging out of the reach of children and pets.
• Warning! Do not look directly at the LED light.
Battery Warnings
• Keep batteries out of the reach of children.
• Do not dispose of batteries in fire.
• Store unused batteries in their original packaging away from metal objects. If
already unpacked, do not mix or jumble batteries.
• Remove batteries from product if it is not to be used for an extended period
of time unless it is for emergency purposes. Exhausted batteries should be
immediately removed from product and properly disposed.
• If the battery leaks avoid contact with skin and eyes. Rinse affected areas
immediately with plenty of clean water, then consult a doctor.
158200-B0787D6SGQ-Mouse-UM-GLO-V06.indb 7 4/10/18 10:09 AM
8
Cleaning and Maintenance
• Clean the product with a dry lint-free cloth. Do not allow any water or other
liquids enter the product’s interior.
• Do not use abrasives, harsh cleaning solutions or hard brushes for cleaning.
• Clean the battery contacts and also those of the product prior to battery
installation.
Specications
Power Supply: 1.5 V AA battery
Current consumption: 30 mA
Weight: 67.1 g (0.15 lbs)
Dimensions: 10.50 x 7.45 x 3.77 cm (4.1 x 2.9 x 1.5 in)
Encryption: AES128
OS compatibility: Windows 10 / 8 / 7
Transmission power: 1 mW
Frequency band: 2.4 GHz (2.402 GHz - 2.480 GHz)
158200-B0787D6SGQ-Mouse-UM-GLO-V06.indb 8 4/10/18 10:09 AM
9
Disposal
Regulatory information: Disposal of Waste Electrical and
Electronic Equipment (WEEE) The Waste Electrical and
Electronic Equipment (WEEE) Directive aims to minimize the
impact of electrical and electronic goods on the environment,
by increasing re-use and recycling and by reducing the
amount of WEEE going to landfill. The symbol on this product
or its packaging signifies that this product must be disposed
separately from ordinary household wastes at its end of life. Be
aware that this is your responsibility to dispose of electronic
equipment at recycling centers in order to conserve natural
resources.
Each country should have its collection centers for electrical and electronic
equipment recycling. For information about your recycling drop off area, please
contact your related electrical and electronic equipment waste management
authority, your local city office, or your house hold waste disposal service.
Used batteries must not be disposed of through household
garbage, since they might contain toxic elements and heavy
metals that can be harmful to the environment and human health.
Consumers are therefore obligated to return batteries to retail
or local collection facilities free of charge. Used batteries will
be recycled.
They contain important raw materials such as iron, zinc,
manganese or nickel.
The crossed-out wheelie bin symbol indicates: Batteries
and rechargeable batteries must not be disposed of through
household garbage.
158200-B0787D6SGQ-Mouse-UM-GLO-V06.indb 9 4/10/18 10:09 AM
10
Warranty Information
To obtain a copy of the warranty for this product:
For US - Visit amazon.com/AmazonBasics/Warranty
For UK - Visit amazon.co.uk/basics-warranty
— or —
Contact Customer Service at 1-866-216-1072
Feedback
Love it? Hate it?
Let us know with a customer review.
AmazonBasics is committed to delivering customer-driven products that live
up to your high standards. We encourage you to write a review sharing your
experiences with the product.
Please visit: amazon.com/review/review-your-purchases#
For further services:
Visit amazon.com/gp/help/customer/contact-us
— or —
Contact Customer Service at 1-866-216-1072
158200-B0787D6SGQ-Mouse-UM-GLO-V06.indb 10 4/10/18 10:09 AM
