Allen-Bradley DeviceNet 1747-SDN Manuel utilisateur

1747-SDN

DeviceNetScanner

Module

Catalog Number

1747-SDN, Series C

User Manual

Important User Information

Solid state equipment has operational characteristics differing from those of

electromechanical equipment. Safety Guidelines for the Application,

Installation and Maintenance of Solid State Controls (publication SGI-1.1

available from your local Rockwell Automation sales office or online at

http://literature.rockwellautomation.com) describes some important

differences between solid state equipment and hard-wired electromechanical

devices. Because of this difference, and also because of the wide variety of

uses for solid state equipment, all persons responsible for applying this

equipment must satisfy themselves that each intended application of this

equipment is acceptable.

In no event will Rockwell Automation, Inc. be responsible or liable for

indirect or consequential damages resulting from the use or application of

this equipment.

The examples and diagrams in this manual are included solely for illustrative

purposes. Because of the many variables and requirements associated with

any particular installation, Rockwell Automation, Inc. cannot assume

responsibility or liability for actual use based on the examples and diagrams.

No patent liability is assumed by Rockwell Automation, Inc. with respect to

use of information, circuits, equipment, or software described in this manual.

Reproduction of the contents of this manual, in whole or in part, without

written permission of Rockwell Automation, Inc., is prohibited.

Throughout this manual, when necessary, we use notes to make you aware

of safety considerations.

Rockwell Automation, TechConnect, SLC, SLC 500, RSNetWorx for DeviceNet, RediSTATION, Series 9000, DH+, Data Highway

Plus, RSLogix 500, FLEX I/O, ControlFlash, RSView, PLC-5, PanelView, RSLinx Classic, are trademarks of Rockwell Automation,

Inc.

Trademarks not belonging to Rockwell Automation are property of their respective companies.

WARNING Identifies information about practices or circumstances that can cause

an explosion in a hazardous environment, which may lead to personal

injury or death, property damage, or economic loss.

IMPORTANT Identifies information that is critical for successful application and

understanding of the product.

ATTENTION Identifies information about practices or circumstances that can lead

to personal injury or death, property damage, or economic loss.

Attentions help you identify a hazard, avoid a hazard, and recognize

the consequence

SHOCK HAZARD Labels may be on or inside the equipment, for example, a drive or

motor, to alert people that dangerous voltage may be present.

BURN HAZARD Labels may be on or inside the equipment, for example, a drive or

motor, to alert people that surfaces may reach dangerous

temperatures.

3Publication 1747-UM655B-EN-P - June 2007

Summary of Changes

The information below summarizes the changes to this manual since

the last publication.

To help you find new and updated information in this release of the

manual, we have included change bars as shown to the right of this

paragraph.

This manual contains this updated information.

Topic Page

The length of the M0 and M1 files 64

Numeric code 65 for normal operation when

AutoScan is enabled was added 91

DeviceNet explicit messaging chapter was

added Chapter 8

AutoScan function chapter was added Chapter 9

Information about programming the module

by using the SLC M0 and M1 files was

added

123…127

Information on the 1747-SDN module’s

firmware history was added Appendix C

Information about data organization was

added Appendix D

Information about explicit message program

control was added Appendix E

Publication 1747-UM655B-EN-P - June 2007

4Summary of Changes

5Publication 1747-UM655B-EN-P - June 2007

Table of Contents

Preface

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

The Example Application . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Common Techniques Used in This Manual. . . . . . . . . . . . . . 11

Additional Resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Chapter 1

Before You Begin

What This Chapter Contains . . . . . . . . . . . . . . . . . . . . . . . . 13

What You Need to Know . . . . . . . . . . . . . . . . . . . . . . . . . . 13

What Your 1747-SDN Module Does . . . . . . . . . . . . . . . . . . . 14

Communicating with Your Devices . . . . . . . . . . . . . . . . . . . 16

Communicating with Your SLC 500 Processor. . . . . . . . . . . . 18

1747-SDN Module Data Tables . . . . . . . . . . . . . . . . . . . . . . 19

RSNetWorx Software as a Configuration Tool . . . . . . . . . . . . 20

What’s Next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Chapter 2

Planning Your Configuration and

Data Mapping Your Devices

What This Chapter Contains . . . . . . . . . . . . . . . . . . . . . . . . 23

What You Need to Know . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Beginning the Process. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

The Example Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

What’s Next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Chapter 3

Hardware Setup

What This Chapter Contains . . . . . . . . . . . . . . . . . . . . . . . . 31

Installing the 1770-KFD Module. . . . . . . . . . . . . . . . . . . . . . 31

Installing the SLC 500 Processor. . . . . . . . . . . . . . . . . . . . . . 32

Installing the ControlNet RS-232 Interface Module . . . . . . . . 35

Installing the 1747-SDN Module. . . . . . . . . . . . . . . . . . . . . . 40

Installing the RediSTATION Operator Interface. . . . . . . . . . . 43

Installing the Series 9000 Photoeye . . . . . . . . . . . . . . . . . . . 44

How Your Network Will Look . . . . . . . . . . . . . . . . . . . . . . . 45

What’s Next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Chapter 4

Configuring the DeviceNet

Network

What This Chapter Contains . . . . . . . . . . . . . . . . . . . . . . . . 47

Installing the Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Use RSLinx Software to Configure the DeviceNet Driver . . . . 48

Using RSNetWorx for DeviceNet Software to Configure the

1747-SDN Module Scanlist . . . . . . . . . . . . . . . . . . . . . . . . . . 50

What’s Next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Publication 1747-UM655B-EN-P - June 2007

6Table of Contents

Chapter 5

Communicating with the

DeviceNet Network from Another

Network

What This Chapter Contains . . . . . . . . . . . . . . . . . . . . . . . . 63

Additional Resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Communicating with the DeviceNet Network via

an Ethernet Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Communicate with the DeviceNet Network via

a DH+ Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

What’s Next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Chapter 6

Creating and Running the Example

Application Program

What This Chapter Contains . . . . . . . . . . . . . . . . . . . . . . . . 79

Install the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Create the Example Application Program . . . . . . . . . . . . . . . 80

Download and Run the Program . . . . . . . . . . . . . . . . . . . . . 82

What’s Next? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Chapter 7

Troubleshooting

Module Status Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Network Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Numeric Display Code Summary . . . . . . . . . . . . . . . . . . . . . 90

Chapter 8

DeviceNet Explicit Messaging

DeviceNet Explicit Message Instruction Overview. . . . . . . . . 93

DeviceNet Explicit Message (DEM) . . . . . . . . . . . . . . . . . . . 94

Chapter 9

AutoScan

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Implementing AutoScan . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Other Important Information about AutoScan. . . . . . . . . . . 112

Appendix A

Data Map Example

What This Appendix Contains . . . . . . . . . . . . . . . . . . . . . . 115

Example Input Mapping Scheme . . . . . . . . . . . . . . . . . . . . 115

Example Output Mapping Scheme. . . . . . . . . . . . . . . . . . . 118

Appendix B

Configuring the M0/M1 Files by

Using RSLogix 500 Software

RSLogix 500 I/O Configuration . . . . . . . . . . . . . . . . . . . . . 121

Programming the Module by Using the SLC M0

and M1 Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

Publication 1747-UM655B-EN-P - June 2007

Table of Contents 7

Appendix C

1747-SDN Module Firmware

History

Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Revision 8.002. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Revisions 7.005 and 7.006 Known Anomalies . . . . . . . . . . . 129

Revision 6.002. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

Revision 5.001. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

Revision 4.026. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

Appendix D

Data Organization

Understand the Data Organization of the Module . . . . . . . . 133

Upload Input Data from the Module to the SLC Processor. . 134

Download Output Data to the Module. . . . . . . . . . . . . . . . 138

Appendix E

Explicit Message Program Control

Using Explicit Message Program Control . . . . . . . . . . . . . . 143

Glossary

Index

Publication 1747-UM655B-EN-P - June 2007

8Table of Contents

9Publication 1747-UM655B-EN-P - June 2007

Preface

Introduction

This user manual is designed to provide you enough information to

get a small example application up and running. Use this manual if

you are knowledgeable about DeviceNet and SLC 500 products, but

may not have used the products in conjunction. The information

provided is a base; modify or expand the examples to suit your

particular needs.

The manual contains instructions on configuring a DeviceNet network

by using RSLinx and RSNetWorx for DeviceNet software. It also

describes how to use the SLC 500 pass-through feature to

communicate with the DeviceNet network for adjustment and tuning

of network devices via an Ethernet and Data Highway Plus (DH+)

network.

The example application demonstrates how to perform control on a

DeviceNet network by using an SLC 500 processor and the 1747-SDN

module. You use RSLogix 500 programming software to create a

ladder logic program to control a photoeye and a RediSTATION

operator interface.

Audience

This manual is intended for control engineers and technicians who are

installing, programming, and maintaining a control system that

includes an SLC 500 processor communicating on a DeviceNet

network through a 1747-SDN module.

We assume that you:

•are developing a DeviceNet network by using a SLC 500

processor in conjunction with a 1747–SDN module.

•know each of your device’s I/O parameters and requirements.

•understand SLC processor programming and operation.

•are experienced with the Microsoft Windows environment.

•are familiar with RSNetWorx for DeviceNet software.

IMPORTANT This user manual should be used in conjunction with the

1747-SDN DeviceNet Scanner Module Installation Instructions,

publication 1747-IN058. The installation instructions contain

important information on configuring your scanner.

Publication 1747-UM655B-EN-P - June 2007

10 Preface

The Example Application

This manual describes how to set up an example application. The

manual provides examples of each step of the setup, with references

to other manuals for more details.

System Components

We used the following devices and software for the example

application. For your own application, substitute your own devices to

fit your needs. The recommended configurations in this user manual

will help you set up the test system and get it working. Your eventual

configuration will depend on your application.

TIP If you use different software or fimware versions of these

products, some of your dialogs may appear slightly different

from those shown in the example.

Quantity Product Name Catalog Number Series/Revision

Hardware

1 SLC 500 modular chassis 1746-A4, 1746-A7, 1746-A10,

1746-A13 B

1 SLC 500 power supply 1746-P1, 1746-P2, 1746-P3,

1746-P4, 1746-P5, 1746-P6 -

1 SLC 5/04 processor 1747-L541, 1747-L542,

1747-L543 -

1 SLC 5/05 processor (Ethernet

network) 1747-L551, 1747-L552,

1747-L553 -

1 DeviceNet scanner module 1747-SDN/B -

1 ControlNet RS-232 interface

module 1747-KFC15 B

1 DeviceNet quad-tap 1492-DN3TW -

1 RediSTATION operator interface

module 2705-TxDN1x42x-xxxx -

1 Series 9000 photoeye 42GNU-9000 or equivalent -

1 DeviceNet RS-232 interface

module 1770-KFD -

1 RS-232 cables 1787-RSCABL/A (personal

computer to 1770-KFD) -

DeviceNet dropline or trunk

cables, as needed 1787-PCABL, 1787-TCABL,

1787-MCABL -

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Allen-Bradley Unité de contrôle

Allen-Bradley

Allen-Bradley ControlLogix 1756-DMD30 Manuel utilisateur

Allen-Bradley

Allen-Bradley 1756 ControlLogix Manuel utilisateur

Allen-Bradley

Allen-Bradley C Series Manuel utilisateur

Allen-Bradley

Allen-Bradley ProcessLogix B Series Manuel utilisateur

Allen-Bradley

Allen-Bradley 1791-16BC Manuel utilisateur

Allen-Bradley

Allen-Bradley POINT I/O 1734-OB2 Manuel utilisateur

Allen-Bradley

Allen-Bradley 1734-OB2 Manuel utilisateur

Allen-Bradley

Allen-Bradley 1771-PM Manuel utilisateur

Allen-Bradley

Allen-Bradley A Series Manuel utilisateur

Allen-Bradley

Allen-Bradley ArmorBlock 1732E-IT4IM12R Manuel utilisateur

Allen-Bradley

Allen-Bradley FLEX I/O ControlNet 1794-ACN15 Manuel utilisateur

Allen-Bradley

Allen-Bradley ArmorBlock 1732E Manuel utilisateur

Allen-Bradley

Allen-Bradley 160-RS1 Manuel utilisateur

Allen-Bradley

Allen-Bradley ControlNet 1786-RPCD Manuel utilisateur

Allen-Bradley

Allen-Bradley ControlLogix ControlNet Scanner Module Manuel de service

Allen-Bradley

Allen-Bradley 1771-IXHR Manuel utilisateur

Allen-Bradley

Allen-Bradley Kinetix 5700 Manuel utilisateur

Allen-Bradley

Allen-Bradley SLC 500 BASIC Manuel utilisateur

Allen-Bradley

Allen-Bradley ArmorBlock 1732E-16CFGM12M12LDR Mode d’emploi

Allen-Bradley

Allen-Bradley Bulletin 160 DeviceNet Manuel utilisateur

Allen-Bradley

Allen-Bradley POINT I/O 1734-4IOL Manuel utilisateur

Allen-Bradley

Allen-Bradley 1771-OBD Manuel utilisateur

Allen-Bradley

Allen-Bradley MicroLogix 1762-OW Manuel utilisateur

Allen-Bradley

Allen-Bradley ControlNet 1788-CNCR Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
