(Cat. No. 1794-ASB Series B)
&(,
), *&(-%
'#,(*+
(&&-'#,#('* + ,)-+"-,,('
++((*,(+/#," +'
/#," +' "#' ++((*
&(, % ('' ,(*
('' ,#('+
(&&('('' ,#('+
% 0-+('' ,(*
Installation Instructions
FLEX I/O Remote I/O Adapter2
If this product has the CE mark it is approved for installation within the
European Union and EEA regions. It has been designed and tested to meet
the following directives.
This product is tested to meet Council Directive 89/336/EEC
Electromagnetic Compatibility (EMC) and the following standards, in
whole or in part, documented in a technical construction file:
•EN 50081-2EMC – Generic Emission Standard, Part 2 – Industrial
Environment
•EN 50082-2EMC – Generic Immunity Standard, Part 2 – Industrial
Environment
This product is intended for use in an industrial environment.
This product is tested to meet Council Directive 73/23/EEC Low Voltage,
by applying the safety requirements of EN 61131–2 Programmable
Controllers, Part 2 – Equipment Requirements and Tests.
For specific information required by EN 61131-2, see the appropriate
sections in this publication, as well as the following Allen-Bradley
publications:
•Industrial Automation Wiring and Grounding Guidelines For Noise
Immunity, publication 1770-4.1
•Guidelines for Handling Lithium Batteries, publication AG-5.4
•Automation Systems Catalog, publication B111
FLEX I/O Remote I/O Adapter 3
1. Position the remote I/O adapter module A on a 35 x 7.5mm DIN rail
B(A-B pt. no. 199-DR1; 46277-3; EN 50022) at a slight angle.
2. Hook the lip on the rear of the adapter (A) onto the top of the DIN rail
(B), and rotate the adapter module onto the rail.
3. Press the adapter module down onto the DIN rail until flush. Locking
tab (C) will snap into position and lock the adapter module to the DIN
rail.
4. If the adapter module does not lock in place, use a screwdriver or
similar device to move the locking tab down while pressing the
adapter module flush onto the DIN rail and release the locking tab to
lock the adapter module in place. If necessary, push up on the locking
tab to lock.
5. Connect the adapter wiring as shown under “Wiring” later in this
document.
NOTE: For Panel/Wall mounting, refer to publication 1794-5.13, “Panel
Mounting Kit, Cat. No. 1794-NM1.”
FLEX I/O Remote I/O Adapter4
-!'&" ,&*)/*.$(!$+
1. Connect the remote I/O cable to the removable remote I/O connector.
'-$
&+$
%&$'#&+$
'$ +&+$
2. Connect +24V dc input to the left side of the lower connector,
terminal E.
3. Connect 24V common to the left side of the upper connector,
terminal D.
4. Connections Gand Fare used to pass 24V dc power (G) and 24V
common (F) to the next module in the series (if required).
FLEX I/O Remote I/O Adapter 5
The adapter switches are located under a flip-open cover on the front of
the adapter. Set the switches as shown below.
87654321
87654321
FLEX I/O Remote I/O Adapter6
.&$-$)(1)/ ' +
87654321
87654321
S1 S2
$+,-
+).*
%
.' +
)&,---
+) ,,)+ ,-+-)%).-
)''.($-$)(-
*&0 &0
,-*- +
)&(*.-,
, +/
First I/O Group I/O Rack Number
S1-8 S1-7 Module roup
S1-6 thru S1-1
,-
! +-)-# -& )(
(
! +
-)
-#
-&
)(
*"
+
-#
S2-8 S2-7 Hold Inputs S2-6
Last Adapter
S2-5
Reply Delay
, +/ )&
(*.-,
)-&,-
!!
, -(*.-,
,- (
Communication
Rate
Processor Restart
Lockout
Hold Last State
S2-4 S2-3 Bits/s S2-2 Processor: S2-1
Processor will:
% ,-+- , -
.-*.-,
%
)% .-
)&&,-,--
%
%
FLEX I/O Remote I/O Adapter 7
!
Rack Number S1 S itch Position
1747ĆSN PLC-2 &
1771ĆSN PLC-5 PLC-5/250 PLC-3 6 5 4 3 2 1
FLEX I/O Remote I/O Adapter8
'&"!)"( $
S1 S itch PositionRack Number
123456
PLC-3PLC-5/250PLC-5
PLC-2 &
1771ĆSN
1747ĆSN
"&
$%%%!"!'$&"!
)
#$"%%"$%!%!$
)!)#$"%%"$%!%!$%
)!)#$"%%"$%!%!$%
)!)#$"%%"$%!%!$%
)!)#$"%%"$%!%!$%
)#$"%%"$%!%!$%
)#$"%%"$%!%!$%
FLEX I/O Remote I/O Adapter 9
ublication 1794Ć5.11 - November 1996
1794ĆASB
Specifications
I/O Capacity
8 modules
ower Supply
Note:
In order to comply with CE Low V
oltage
Directives, you must use a Safety Extra Low
V
oltage (SEL
V) or a rotected Extra Low
V
oltage ( EL
V) power supply to power this
adapter.
Input V
oltage Rating
24V dc nominal
Input V
oltage Range
19.2V to 31.2V dc (includes 5% ac ripple)
Communication Rate
57.6k bps
1
15.2k bps
230.4k bps
Indicators
Adapter Active - green
Adapter fault - red
Local fault - red
Flexbus Output Current
640mA maximum
Isolation Voltage
100% tested at 850V dc for 1s between user
power and flexbus
ower Consumption
450mA maximum from external 24V supply
ower Dissipation
4.6W maximum @ 31.2V dc
Thermal Dissipation
15.7 BTU/hr @ 31.2V dc
Environmental Conditions
Operational Temperature
Storage Temperature
Relative Humidity
Shock Operating
NonĆoperating
Vibration
0 to 55
o
C (32 to 131
oF)
-40 to 85
o
C (-40 to 185
oF)
5 to 95% noncondensing
30 g peak acceleration, 1
1(+1)ms pulse width
50 g peak acceleration, 1
1(+1)ms pulse width
T
ested 5 g @ 10-500Hz per IEC 68Ć2Ć6
Remote I/O Cable
Belden 9463 or equivalent as specified in
publication ICCGĆ2.2
ower Conductors
Wire Size
Category
12 gauge (4mm
2
) stranded maximum
3/64 inch (1.2mm) insulation max.
21
Specifications continued on next page
FLEX I/O Remote I/O Adapter10
Pu lication 1794Ć5.11 - Novem er 1996
Agency Certification
(when product or packaging is
marked)
•CSA certified
•CSA Class I, Division 2
Groups A, B, C, D certified
•
UL listed
•CE marked for all applica le directives
User Manual
Pu lication 1794Ć6.5.3
1 Use
this conductor category information for planning conductor routing. Refer to pu lication
1770Ć4.1, Industrial Automation Wiring and Grounding Guidelines."
