Allen-Bradley E3 Plus Manuel utilisateur

Installation Instructions

E3 Plus EtherNet/IP Adapter

Catalog Number

2100-ENET

Introduction

The E3 Plus EtherNet/IP adapter is a linking device that lets users connect an E3 or E3 Plus

Solid State Overload or an 825-P Motor Protection System directly to an EtherNet/IP network.

This document explains the basic steps needed to configure the E3 Plus EtherNet/IP adapter.

Topic Page

Introduction 1

Important User Information 2

Adapter Components 3

Status Indicators 4

Set the IP Network Address 4

Install EDS File 7

Logix Controller I/O Messaging 9

Additional Resources 12

2E3 Plus EtherNet/IP Adapter

Rockwell Automation Publication 2100-IN090A-EN-P - February 2012

Important User Information

Solid-state equipment has operational characteristics differing from those of electromechanical equipment. Safety Guidelines for the

Application, Installation and Maintenance of Solid State Controls (Publication SGI-1.1 available from your local Rockwell Automation

sales office or online at http://www.rockwellautomation.com/literature/) describes some important differences between solid-state

equipment and hard-wired electromechanical devices. Because of this difference, and also because of the wide variety of uses for

solid-state equipment, all persons responsible for applying this equipment must satisfy themselves that each intended application of

this equipment is acceptable.

In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or

application of this equipment.

The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many variables and

requirements associated with any particular installation, Rockwell Automation, Inc. cannot assume responsibility or liability for actual

use based on the examples and diagrams.

No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits, equipment, or software

described in this manual.

Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell Automation, Inc., is

prohibited.

Throughout this manual, when necessary, we use notes to make you aware of safety considerations.

WARNING: Identifies information about practices or circumstances that can cause an explosion in a hazardous

environment, which may lead to personal injury or death, property damage, or economic loss.

ATTENTION: Identifies information about practices or circumstances that can lead to personal injury or death,

property damage, or economic loss. Attentions help you identify a hazard, avoid a hazard and recognize the

consequences.

SHOCK HAZARD: Labels may be on or inside the equipment, for example, drive or motor, to alert people that

dangerous voltage may be present.

BURN HAZARD: Labels may be on or inside the equipment, for example, drive or motor, to alert people that

surfaces may reach dangerous temperatures.

IMPORTANT Identifies information that is critical for successful application and understanding of the product.

E3 Plus EtherNet/IP Adapter 3

Rockwell Automation Publication 2100-IN090A-EN-P - February 2012

Adapter Components

The adapter has these components.

The E3+ and 825-P must be set to node 63 and have a communication rate of 500K (or have the

autobaud enabled). This is the default state of each of these devices.

Item Part Description

1 Status Indicators Four status indicators for the DeviceNet, adapter, and network connection.

2 E3 Connector This connector is provided for the connection to the E3 Plus or the 825-P.

3 Ethernet Connector An RJ-45 connector for the Ethernet cable. The connector is CAT-5 compliant to

ensure reliable data transfer on 100Base-TX Ethernet connections.

4E3 Plus EtherNet/IP Adapter

Rockwell Automation Publication 2100-IN090A-EN-P - February 2012

Status Indicators

The adapter uses four status indicators to report its operating status.

Set the IP Network Address

The E3 Plus EtherNet/IP adapter is shipped with Bootstrap Protocol (BOOTP) enabled. You

can set the network Internet Protocol (IP) address by using the BOOTP/DHCP server that is

provided with RSLinx Classic software. This utility recognizes BOOTP-enabled devices and

provides an interface to configure a static IP address for each device.

To assign network parameters via the BOOTP/DHCP utility, perform this procedure.

1. Start the BOOTP/DHCP software.

Item Name Color State Description

1 PORT Green Flashing Normal Operation. The adapter is establishing an I/O connection to the E3 Plus

overload relay. It will turn steady green or red.

2 MOD Steady Normal Operation. The adapter is properly connected and communicating with

the E3 Plus overload relay.

3 NET A Green Flashing Normal Operation. The adapter is operating but is not transferring I/O data to a

controller.

4 NET B Steady Normal Operation. The adapter is operating and transferring I/O data to a

controller.

Status Indicators

E3 Plus EtherNet/IP Adapter 5

Rockwell Automation Publication 2100-IN090A-EN-P - February 2012

2. Select Tool > Network Settings and enter the subnet mask for the network.

If appropriate for the network, enter the gateway address, primary/secondary server

addresses, and domain name.

3. Click OK.

The Request History panel displays the hardware addresses of devices issuing BOOTP

or DHCP requests.

4. Double-click the MAC address of the adapter to be configured.

The MAC address is printed on the side of the E3 Plus EtherNet/IP adapter. The format

of the hardware address resembles 00:00:BC:59:72:5A. The New Entry dialog box

appears with the module's Ethernet Address (MAC).

6E3 Plus EtherNet/IP Adapter

Rockwell Automation Publication 2100-IN090A-EN-P - February 2012

5. Enter the IP address for the adapter and, if appropriate, enter the host name and an

adapter description.

6. Click OK.

Once the IP address you entered shows up in the Request History panel (you may need

to cycle power to the adapter), this configuration can be permanently assigned to the

adapter.

7. To do so, highlight the adapter in the Relation List panel and click Disable

BOOTP/DHCP.

8. Confirm that the Status panel message reads, ‘[Disable BOOTP] Command successful’.

When the adapter power is recycled, it will use the assigned configuration and will not

issue a BOOTP request. If you do not click Disable BOOTP/DHCP, the adapter clears

the current IP configuration after a power cycle and will again begin sending BOOTP

requests.

E3 Plus EtherNet/IP Adapter 7

Rockwell Automation Publication 2100-IN090A-EN-P - February 2012

Install EDS File

Before the E3 Plus EtherNet/IP adapter is configured to communicate on an EtherNet/IP

network, it must be registered to the software that configures the network, for example, RSLinx

Classic software. You can register the adapter by installing an electronic data sheet (EDS file).

For the E3 Plus EtherNet/IP adapter, you will install an EDS file for the device that is connected

to the adapter. Use the following procedure to download and register the EDS file for the E3 Plus

EtherNet/IP adapter.

Download EDS file from the EDS Website

The EDS file for the device connected to the E3 Plus EtherNet/IP adapter can be found at

http://www.rockwellautomation.com/resources/eds/.

1. When the web page for the link above comes up, enter the following information.

2. Select the file that relates to the E3 or 825-P module that is connected to the

2100-ENET unit.

3. In the Details & Download column for the device, select Download.

4. Click Save to save the EDS file to your personal computer.

After the EDS file has been downloaded, you need to register the EDS file with the software that

configures the EtherNet/IP network. Follow these steps to register an EDS file with RSLinx

Classic software.

1. Start the EDS Hardware Installation Tool at Start->Programs->Rockwell

Software->RSLinx->Tools.

2. Click Add to register a new device.

E3 Plus Overload 825-P

Network EtherNet/IP EtherNet/IP

Device Type Motor Protector Motor Protector

Bulletin/Catalog No. 2100-ENET 2100-ENET

Major Revision (Leave Blank) (Leave Blank)

Minor Revision (Leave Blank) (Leave Blank)

Keyword (Leave Blank) (Leave Blank)

8E3 Plus EtherNet/IP Adapter

Rockwell Automation Publication 2100-IN090A-EN-P - February 2012

3. Register a single file, browse to the location of the EDS file, and click Next.

4. Click Next to accept the installation test results.

5. Click Next to accept the graphic image.

E3 Plus EtherNet/IP Adapter 9

Rockwell Automation Publication 2100-IN090A-EN-P - February 2012

6. Click Next to register the device.

7. Click Finish.

Logix Controller I/O Messaging

RSLogix 5000 software is used to configure I/O messaging between a Logix controller and an E3

Plus EtherNet/IP adapter on an EtherNet/IP network. Follow these steps to configure a Logix

controller for I/O messaging.

1. Right-click on the EtherNet/IP scanner in I/O Configuration and select New Module

to open the Select Module Type dialog box.

2. Select Generic Ethernet Module and click OK.

3. Enter a name for the E3 Plus EtherNet/IP adapter.

The name creates a tag in RSLogix 5000 software that can be used to read and write data

from the E3 Plus EtherNet/IP adapter.

10 E3 Plus EtherNet/IP Adapter

Rockwell Automation Publication 2100-IN090A-EN-P - February 2012

4. Select Data-INT for the Comm Format.

The Comm Format tells RSLogix 5000 software the format of the data. The Data-INT

format represents the data from the E3 Plus EtherNet/IP adapter as a field of 16-bit

values.

5. Set the Connection Parameters.

I/O data is accessed using Input Instance 100 and Output Instance 103 (for E3

standard) or 105 (for E3 Plus) by default.

The size of the input connection and the output connection shall correspond to the size

of the chosen instance. For Instance 100, the size is 6. For Instances 103 and 105, the size

is 1. The E3 Plus EtherNet/IP adapter Configuration Assembly Instance is 6. Currently,

the 2100-ENET adapter does not support the configuration assembly.

IMPORTANT

If you have already changed the Input and Output Assemblies, you will need to enter those

values instead of the default values.
