Controller and
Display Panel
Source USB Port
Target USB
Ports (118)
Power Switch
Introduction
Thank you for purchasing this 1:118 USB Copy Tower SA. Please read this
User Guide thoroughly before using this product.
• Page 2 shows the 1:118 USB Copy Tower SA Display Panel.
Product Features
• Stand Alone, no computer required.
• Copy, Compare, or Erase up to 118 drives simultaneously.
• Backlighted LCD display shows function selected and job progress.
• Compatible with popular drive capacities and formats.
• Fast Synchronous and Asynchronous copying.
Key Items – 1:118 USB Copy Tower SA
Note: Choose a Good Location
1. Do not place near heat sources such as radiators or air ducts, or
in a place subject to direct sunlight, excessive dust, mechanical
vibration or shock.
2. Good care will help assure maximum product life. Improper
operating environment and misuse may void the warranty.
www.aleratec.com
2
Introduction
1:118 USB Copy Tower SA Display Panel
1 Display shows all functions and messages
2 OKbutton is used to execute a selected function
3 ESCbutton is used to cancel a selected function
4 UParrow is used to scroll up through functions or menus
5 DOWN arrow is used to scroll down through functions or menus
Note: When the unit is powered-on, the 1:118 USB Copy Tower SA
will preform a self-test sequence.
OK
USB Duplicator
1. Copy ESC
4
1
35
2
www.aleratec.com 3
Precautions
Before installing your 1:118 USB Copy Tower SA, please read the following.
Installation
Avoid placing the 1:118 USB Copy Tower SA in a location subject to:
• High humidity
• High temperature
• Excessive dust
• Mechanical vibration
• Direct sunlight
• Electromagnetic radiation
Power
This product has a manually switchable power supply. Make sure that the
power supply is set to the proper voltage for your region.
Operation
Avoid exposing the duplicator to sudden changes in temperature as
condensation may form on the lens inside the duplicator. Operating the
duplicator immediately after a sudden increase in temperature may result in
a malfunction during playback or writing operations.
Transportation
Keep the original packing materials for future moving or shipping of the
1:118 USB Copy Tower SA.
www.aleratec.com
4
Overview
Main Menu
This section provides a listing of the functions of the 1:118 USB Copy
Tower SA. Detailed descriptions of each function are given in the next
section. The functions are numbered for easy reference; these numbers are
also used in the next section.
USB Duplicator
1. Copy
OK
ESC
USB Duplicator
2. Compare
OK
ESC
USB Duplicator
3. Copy+Compare
OK
ESC
USB Duplicator
5. Information
OK
ESC
USB Duplicator
6. Utility
OK
ESC
USB Duplicator
7. Setup
OK
ESC
USB Duplicator
4. Capacity Check
OK
ESC
