Albatron PM945GC Manuel utilisateur

PM945GC (V2.0)

All rights are reserved. No part of this publication may be reproduced, transmitted, transcribed, stored

in a retrieval system or translated into any language or computer language, in any form or by any means,

electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written

permission of the company. Brands and product names are trademarks or registered trademarks of their

respective companies.

The vendor makes no representations or warranties with respect to the contents herein and especially

disclaim any implied warranties of merchantability or fitness for any purpose. Further the vendor

reserves the right to revise this publication and to make changes to the contents herein without

obligation to notify any party beforehand. Duplication of this publication, in part or in whole, is not

allowed without first obtaining the vendor’s approval in writing.

Trademark

All the trademarks or brands in this document are registered by their respective owner.

Disclaimer

We make no warranty of any kind with regard to the content of this user’s manual. The content is

subject to change without notice and we will not be responsible for any mistakes found in this user’s

manual. All the brand and product names are trademarks of their respective companies.

FCC Compliance Statement

This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be required to correct the interference at his own

expense. However, there is no guarantee that interference will not occur in a particular installation.

CE Mark

The device is in accordance with 89/336 ECC-ENC Directive.

Ver: EG100

PM945GC (V2.0)

Intel®945GC & ICH7

Support Socket 775 Intel®CoreTM 2 Duo/ Pentium®D/

Pentium®4/ Celeron®D/ Celeron®Processor

(The power consumption for the aforementioned

processors must be rated at 65W or less.)

User Manual

Enabling the Hyper-Threading Technology, your computer system is

required to have components as the following:

CPU: An Intel®Pentium®4 Processor with HT Technology

Chipset: An Intel®Chipset that supports HT Technology

BIOS: A BIOS that supports HT Technology must be enabled

OS: An operating system that supports HT Technology

For more information on Hyper-Threading Technology, go to:

http://www.intel.com/info/hyperthreading

Dimensions (Micro-ATX form-factor):

180mm x 244mm ( W x L )

Operating System:

Windows®Vista/ XP/ 2000

Attention- Im

ortant Information

Follow the procedures below…

Troubleshooting Tips

Refer to other sections in this manual…

Things You Have To Know

0The images and pictures in this manual are for reference only and may vary from the

product you received depending on specific hardware models, third party components

and software versions.

0This mainboard contains very delicate IC chips. Always use a grounded wrist strap

when working with the system.

0Do not touch any IC chip, lead, connector or other components.

0Always unplug the AC power when you install or remove any device on the mainboard

or when confuguring pins and switches.

Packing List

PM945GC(V2.0) Mainboard

IDE Cable

SATA Cable

I/O Bracket

Mainboard Setup Driver & User Manual CD

Mainboard Quick Installation Guide

Symbols

Table of Contents

CHAPTER 1. GETTING STARTED .................................................... 1

INTRODUCTION....................................................................................................... 1

SPECIFICATION ....................................................................................................... 2

CONFIGURATION .................................................................................................... 5

Layout of PM945GC (V2.0)............................................................................ 5

HARDWARE INSTALLATION ................................................................................... 6

CPU Processor Installation.............................................................................. 6

Memory Installation: DIMM1/DIMM2........................................................... 7

Back Panel Configuration................................................................................ 9

Front Panel Headers: JW_FP, PWRLED, SPEAK ........................................ 10

Connectors..................................................................................................... 11

Headers & Jumpers........................................................................................ 12

Audio Configuration...................................................................................... 14

Slots ............................................................................................................... 15

Power Supply Attachments............................................................................ 16

CHAPTER 2. BIOS SETUP ........................................................... 17

INTRODUCTION..................................................................................................... 17

MAIN MENU ......................................................................................................... 18

CHAPTER 3: SOFTWARE SETUP................................................... 20

SOFTWARE LIST ................................................................................................... 20

SOFTWARE INSTALLATION ................................................................................... 20

CHAPTER 4: TROUBLESHOOTING................................................. 24

APPENDIX I: 6/4/2 CHANNEL AUDIO EFFECT SETUP............................................ 27

Mainboard PM945GC(V2.0)

Chapter 1. Getting Started

Introduction

Thanks for choosing PM945GC(V2.0) Mainboard. It is based on Intel®945GC Northbridge

chipset and Intel®ICH7 Southbridge chipset. In addition, it also supports integrated Graphics

Media Accelerator 950 for onboard graphics feature. It supports Intel®CoreTM 2 Duo/

Pentium®D/ Pentium®4/ Celeron®D/ Celeron®Processors (The power consumption for the

aforementioned processors must be rated at 65W or less) with FSB (Front Side Bus) frequencies of

1333 MHz (by overclocking)/ 1066 MHz (by overclocking)/ 800 MHz/ 533 MHz.

The PM945GC(V2.0) provides two DIMM (Dual In-Line Memory Modules) sockets which

allowing you to install 240-pin, unbuffered non-ECC, DDRII 667 (by overclocking)/ DDRII 533

SDRAMs. It also supports Dual Channel Technology and allows you installing a total memory

capacity of 4 GB.

This mainboard provides one PCI-Express interface slot up to x16 mode which is

recommended that insert a graphics card onto the PCI-Espress x16 slot. In addition, two

standard PCI slots for use with standard PCI expansion cards are also allowed.

The PM945GC(V2.0) provides one floppy disk drive connector that can be used with

360KB/720KB/1.2MB/1.44MB/2.88MB drives. It also has one IDE connector for IDE hard drives

supporting Ultra ATA 100/66/33. Moreover, this mainboard comes with Serial ATA II support

with four SATA II connectors which provide up to 3 Gbps data transfer rates.

The onboard High Definition Audio CODEC (ALC662) supports high quality performance

6-channel audio play <See Appendix I>. The mainboard also supports the Sony/Philips

Digital Interfaces (S/PDIF) output function (optional).

The PM945GC(V2.0) also comes with an onboard 10/100 Mbps Ethernet LAN chip. There is a

LAN port on the back panel of your case that you can directly plug into an Internet cable.

There are maximal eight USB2.0/ 1.1 ports which can be set up on this mainboard.

All the information (including hardware installation and software installation) in this manual

are for reference only. The contents in this manual may be updated without notice. The

company will not assume any responsibility for any errors or mistakes within.

Mainboard PM945GC(V2.0)

Specification

CPU:

Support Socket 775

Support Intel®CoreTM 2 Duo/ Pentium®D/ Pentium®4/ Celeron®D/ Celeron®

Processors (The power consumption for the aforementioned processors must be

rated at 65W or less.)

Support Hyper-Threading Technology

Support 1333 MHz (by overclocking)/ 1066 MHz (by overclocking)/ 800 MHz/ 533 MHz

FSB (Front Side Bus) Frequencies

Chipset:

Northbridge Chipset – Intel®945GC

Southbridge Chipset – Intel®ICH7

I/O Controller –Fintek®F71872FG

High Definition Audio Codec – Realtek®ALC662

LAN Controller – Marvell®88E8042

Memory:

Two DIMM sockets

Supports unbuffered & non-ECC DDRII 667 (by overclocking)/ DDRII 533 SDRAM

Supports a total memory capacity of up to 4 GB

Supports Dual Channel data bus

Onboard HD Audio Codec (ALC 662):

High performance Codec with high S/N ratio (>90 db)

Supports 6/4/2 channel playback capability

Supports jack sensing and re-tasking function

Built-in Dolby Digital Live Technology

Supports Sony/ Philips Digital Interfaces (S/PDIF) output function (Optional)

Slots:

One PCI-Express x16 interface slot for graphics card or expansion card

Two standard PCI slots for PCI standard expansion cards

Mainboard PM945GC(V2.0)

FDD Connector:

Supports one FDD connector to set up to two floppy disk drives

Supports 360KB/ 720KB/ 1.2MB/ 1.44MB/ 2.88MB

IDE Connector:

One IDE connector

Supports up to two IDE devices

Supports Ultra ATA 33/66/100

Supports high capacity hard disk drives

Serial ATA II Connector:

Four SATA II connectors

Supports SATA 2.0 specification and with transmit rate up to 3 Gbps

One SATA connector can only support one SATA HDD

Onboard LAN Chip:

10/100 Mbps Ethernet LAN supported

I/O facility Connectors

Supports one PS/2 mouse port and one PS/2 keyboard port

Supports one serial port

Supports one VGA port (=D-Sub)

Supports one parallel port（PARALLEL）header and one HDMI-SPDIF OUT (HDMI-SPDIF)

header with external devices connected

Universal Serial Bus:

Four onboard USB 2.0/ 1.1 ports

Two front USB headers come with this mainboard for additional four USB ports

Support a maximum of eight USB ports to connect USB compliant devices

BIOS:

Phoenix-Award™ BIOS

Support APM1.2

Support ACPI 2.0 power management

Mainboard PM945GC(V2.0)

Green Function:

Supports Phoenix-Award™ BIOS power management function

Supports system-wake-from-power-saving-mode by keyboard or mouse touching

Shadow RAM:

Integrated memory controller provides shadow RAM functionality and supports ROM

BIOS

Flash Memory:

Supports flash memory functionality

Supports ESCD functionality

Hardware Monitor Function:

Monitors CPU/ Chassis Fan Speed

Monitors CPU and system temperature

Monitors system voltages

Mainboard PM945GC(V2.0)

Configuration

Layout of PM945GC (V2.0)

Mainboard PM945GC(V2.0)

Hardware Installation

This section will assist you in quickly installing your system hardware. Wear a wrist ground strap before

handling components. Electrostatic discharge may damage the system’s components.

CPU Processor Installation

This mainboard supports Intel®CoreTM 2 Duo/ Pentium®D/ Pentium®4/ Celeron®D/ Celeron®Processors

using a Socket 775. Before building your system, we suggest you to visit the Intel website and review the

processor installation procedures. http://www.intel.com

CPU Socket 775 Configuration Steps:

1. Locate the CPU socket 775 on your

mainboard and nudge the lever away

from the socket as shown. Then lift the

lever to a 140-degree angle (A). Next,

lift up the iron cover (B).

2. There are 2 distinctive marks located

near the corners of the socket on the

same side as the lever as shown (C).

Match these marks with the marks on the

CPU and carefully lower the CPU down

onto the socket (D).

3. Replace the iron cover and then lower

the lever until it snaps back into position

(E). This will lock down the CPU (F).

4. Smear thermal grease on the top of the CPU. Lower the CPU fan

onto the CPU/CPU socket and secure it using the attachments or

screws provided on the fan. Finally, attach the fan power cord

to the CPUFAN header.

Attention

DO NOT touch the CPU pins in case they are damaged. Also, make sure

that you have completed all installation steps before powered on the

system. Finally, double-check that the cooling fan is properly installed

and the CPU fan power cord is securely attached, in case your CPU and

other sensitive components are damaged because of high temperatures.

Autres manuels pour PM945GC

Table des matières

Autres manuels Albatron Carte mère

Albatron

Albatron NForce 650i Ultra Manuel utilisateur

Albatron

Albatron PX865PE Series Manuel utilisateur

Albatron

Albatron KM333 Series Manuel utilisateur

Albatron

Albatron kx600s Manuel utilisateur

Albatron

Albatron PXP35 Manuel utilisateur

Albatron

Albatron KM400T-8X Pro Manuel utilisateur

Albatron

Albatron KM400T-8X Series Manuel utilisateur

Albatron

Albatron PX845PE Series Manuel utilisateur

Albatron

Albatron KX550 Manuel utilisateur

Albatron

Albatron PX845GEV Series Manuel utilisateur

Albatron

Albatron PX865PEL-800 Manuel utilisateur

Albatron

Albatron K8SLI-AM2 Manuel utilisateur

Albatron

Albatron KM51PV-754 Manuel utilisateur

Albatron

Albatron KX18D PRO II Manuel utilisateur

Albatron

Albatron PX845PEV-800 Instructions d'utilisation

Albatron

Albatron PX875P Manuel utilisateur

Albatron

Albatron K8X250GB PRO Manuel utilisateur

Albatron

Albatron PX915P4 Series Manuel utilisateur

Albatron

Albatron PX865PE PRO II Manuel utilisateur

Albatron

Albatron PX865PE7 Manuel utilisateur

Albatron

Albatron PM945GZ Manuel utilisateur

Albatron

Albatron PM915-478 Manuel utilisateur

Albatron

Albatron PM73V Manuel utilisateur

Albatron

Albatron PX848PV Series Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
