AGPtek H01 Manuel utilisateur
User Manual
H01 Music Player
CONTENT
English
Deutsch
Français
Italiano
Español
日本語
01/08
09/17
18/26
27/35
36/44
45/53
..............................
..............................
..............................
..............................
..............................
..............................
>>AGPTEK
1
Operation
•Press the multi-function button(MFB) at the
bottom of the LCD to switch the different
interfaces in turn.
•Press and hold MFB to confirm or enter into the
function you want to access to.
Charge the bracelet
Detach the wristband, and connect the bracelet to
the running computer or 5V/500mA USB charger for
safe charge. When in charging, the bracelet will
automatically power off.
App Download & Supported
•For first use, we recommend you binding App to
synchronize the data. After binding successfully,
the bracelet will automatically synchronize and
update its data.
•Scan the QR code with mobile phone to download
the App "GloryFit, or search "GloryFit" in "App
store"on mobile phone.
•Note: Mobile phone must support iOS8.0 or
above/Android4.4 or above/Bluetooth 4.0.
Bind bracelet to App
Turn on the App and allow App to turn on Bluetooth
of your device. At this moment, App will start to
search for device(iOS/Android). If it is failure, click
2
the search icon in the upper right. Select the device
you want to bind.
•Note:
1. You need to bind your bracelet in this App, not
directly via phone's Bluetooth connection.
2. When pairing successfully, App will automatically
record bracelet's Bluetooth information. Once App
is turned on, App will automatically search and
connect bracelet if your phone's Bluetooth is on.
3. On the Today interface of App, manually pull down
the interface to synchronize and update the data.
The bracelet can store offline data of 7 days. The
more data it stores, the longer the synchronization
time needs, maximum time about 2 minutes.
Introduction of App
•Set your personal information.
Select Me -- Personal -- Set your information
according to your actual information.
The steps, sleep time, heart rate and blood
pressure recorded daily will be displayed on
Today of the App.
•Sleep monitor
Record the sleeping situation from 6:00 pm of the
current day to 12:00 pm of the next day. There
may be a 30 minute error. When you are in sleep,
the bracelet will enter into the sleep monitor
mode to detect your sleep. The monitored
information of bracelet will be synchronized to
the bracelet. Note: Only wear the bracelet, you
will get these above information.
•Smart Alarm clock.
Three Alarm clocks can be set in App. After
3
setting, it will be synchronized to the bracelet.
When the alarm is activated, the bracelet will
vibrate to remind you. It also support the offline
alarm.
•Reminder function.
Binding the bracelet to the App, find App
reminder in Device of App. Manually turn on one
of these Apps (Twitter, Facebook, Messenger,
WhatsApp, QQ, WeChat, Skype, LINE, Hangouts)
that you want to be reminded on the bracelet.
•Call reminder.
When there is an incoming call, the bracelet will
vibrate. And LCD of Bracelet will display name or
number of caller. If you have turned on Reject a
call with a key, hold MFB for 3s to reject the call.
•Sedentary reminder.
The reminder interval is 1 hour by default. Set the
interval according to your needs.
Display & Functions
Home. Display time, battery and heart rate.
Press MFB to cycle through different
functions. Hold MFB for 3s to enter into
the function that you would like to access
to.
Steps. Record every step you take each day.
These steps will also be updated in the App.
When user is walking, the bracelet will
record the number that your arms are
swing as the number of walking steps.
4
Distance. Display the distance you walk in
that day. This value is to calculate
according to walking steps and your
height set in App.
Calories. Display the total calories of that
day you are burned (Based on walking
steps, your setting height and weight in
App).
Heart rate. In the heart rate interface, it
will automatically detect your heart rate.
Blood pressure. In the interface of blood
pressure, it will automatically detect your
blood pressure.
Training. In this interface, hold MFB for 3s
to enter into rope skipping, running, riding.
Press it to switch different sports.
5
Message. Turn on SMS reminder, the
bracelet will save the 8 messages recently
pushed by the App when receiving a new
message. Press MFB to cycle through the
messages; Hold it for 3s to browse it. Hold
it for 3 seconds again to delete the current
message.
Function. Hold MFB for 3s to access to its
submenu.
•Submenu of Function
1. Info. Hold MFB for 3s to check the firmware
version and Bluetooth information.
2. Reset. Hold MFB for 3s, all data of bracelet will be
cleared. The data of the day in App also will be
cleared. (The rest of the historical data continues
to be retained.)
3. Power off. Hold MFB for 3s will power off, and hold
it for 3s again to power on.
4. Find me. Hold MFB for 3s to search your phone.
After a successful search, your phone will respond
to this.
5. Brightness. Hold MFB for 3s until the icon shake.
6
Press MFB to adjust brightness.
Note: The sensor on the back of the bracelet should
be close to your skin during monitoring. In addition,
please ensure that your skin is clean to avoid the
external environment affecting the testing results.
Warnings
•The bracelet is charged by 5V/500mA charger. Do
not charge it with the over-voltage power supply.
•If there's water on the bracelet, dry it in time.
•Working temperature is from 0 to 45 degree.
Prohibit throwing it into the fire to avoid
exploding.
•Please wipe the the sweat on your wrist in time.
Prohibit the wristband be exposed to soap, sweat,
allergen or contaminated ingredients for a long
time to prevent skin irritation.
•Do not touch chemicals such as gasoline, cleaning
solvents, propanol, alcohol or insect repellent to
prevent damage to the bracelet.
•Do not use this product in high pressure and high
magnetic fields.
FQA
•Cannot bind to the bracelet?
Please make sure your phone being power on and
active. And ensure your bracelet have not connected
to other phones. Then keep the bracelet closer to the
phone. The phone and bracelet will automatically
bind. If it still does not bind, please turn off the
phone's Bluetooth, and then restart the phone's
Bluetooth after 20s.
•Cannot bind to Phone's Bluetooth?
1. Make sure that mobile phone supports
iOS8.0/Android4.4 or above/Bluetooth 4.0.
7
2. Due to the signal interference of the Bluetooth
connection, the connection time may vary from
time to time. If it fails to connect for a long time,
please ensure that the operation is free of
magnetic fields or without interference from
multiple Bluetooth devices.
3. Turn off Bluetooth and restart it once again.
4. Turn off all Apps in the background or boot up
your phone once again.
5. Your phone does not bind other Bluetooth devices
at the same time.
6. Whether the App is working normally in the
background, if not, it may not be connected.
•Why can not receive the notification when the
reminder function is turned on?
1. Android device. Make sure your phone has been
connected to the bracelet and you have turned on
the corresponding permission in the phone
settings. Allow App to access calls, text messages,
contacts, and keep the App running in the
background; if the phone is equipped with security
software. Please add "GloryFit"as Trust.
2. iOS. Restart your phone and connect the bracelet
once again. When connecting the bracelet, you
must wait for the phone to pop up Bluetooth
Pairing Request and click "Bind"to have a
reminder.
•Does the Bluetooth connection need to be
turned on all the time? Is there still data after
disconnection?
1. When Bluetooth is not connected, the previous
data will remain on the bracelet (you can keep 7
days of data). When the mobile phone is
connected to the bracelet successfully, the bracelet
8
data will be automatically uploaded to the mobile
phone and start synchronizing data.
2. Note: If you enable the call and SMS alert feature,
you must keep Bluetooth connected.
Specifications
Model
H01
Screen
0.96 TFT Color screen
Wristband material
TPU
Battery
100mAh Li-Polymer
battery
Battery model
351524
Input
DC 5.0V
Charging time
1-1.5H
Working time
Up to 14 days
Waterproof
IP67
Working
temperature
-10~50℃
Net weight
20g
Size
56.5*19.4*12.6mm
Manufacturer: Shenzhen Ballet Digital Technology
Co., Ltd.
Address: 3rd Floor, Building A1, Iron Tower Industrial
Park, Hedi Road, Shang Village, Gongming Town,
Guangming New District, Shenzhen, China.
E-mail: sup[email protected].
If you have any question or any idea about this
product, please feel free to contact us.
