L-W22

A 22” home entertainment LED

display with Full HD resolution,

ultrahigh 20,000,000:1 contrast ratio

and digital HDMI input for any diverse

environments.

e L-W22 features an LED backlight 22” (21.5” viewable)

widescreen display with a full HD 1920 x 1080 resolution, delivering

brilliant image clarity and colour performance. Outstanding

features including 20,000,000:1 contrast ratio, built-in speakers

and dual PC and HDMI inputs, make it ideal for home and oce

multimedia applications.

> 22” widescreen LED display

> LED backlight for energy saving and environmental consciousness

> 1920 x 1080 Full HD resolution

> Slim housing design and widescreen format

> Excellent clarity with ultrahigh 20,000,000:1 dynamic contrast ratio

> Superior colour performance and colour contrast

> HDMI input for Full HD connectivity with multimedia devices

> Built-in 2W x 2 speakers

> Energy eciency

> VESA mount standard

REACH

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: LW22D0 Version 4.1, 20130701

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Surface Treatments

Viewing Angle (H/V)

Display Colour

Response Time

LED-backlit TFT LCD

21.5” (546 mm)

Full HD 1920 x 1080

0.248 mm

250cd/m2 (Typical)

20,000,000:1 (DCR)

Hard Coating (3H),

Anti-glare treatment

170°/160° (Typical)

16.7M

3ms (GTG)

Frequency (H/V) H: 30kHz – 83kHz

V: 56Hz – 75Hz

Input Analogue

Digital

HDMI

15-Pin D-Sub

24-Pin DVI-D

HDMI

Audio Audio In

Speaker

3.5mm Audio Line-in

2W x 2

Power Power Supply

Power Requirements

Consumption

Internal

AC 100 – 240 V, 50-60 Hz

< 33W (On)

< 0.5W (Stand-by)

< 0.5W (Off)

Plug & Play VESA DCC 2B

Operating

Conditions

Temperature

Humidity

0 °C ~ 40 °C

10% ~ 85%

Storage

Conditions

Temperature

Humidity

-25 °C ~ 55 °C

10% ~ 85%

Mounting VESA FPMPMI Yes (100 x 100mm)

Tilt Tilt -4° ~ +18°

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

506 x 366 x 180 mm

(19.9” x 14.4” x 7.1”)

558 x 374 x 124 mm

(22.0” x 14.7” x 4.9”)

Weight Product Weight

Packaged Product Weight

3.5 kg (7.7 lbs)

4.9 kg (10.1 lbs)

Regulation

Approval

Certications &

Compliance

FCC, CB, CE, BSMI, GOST-R,

WEEE, RoHS, REACH

Accessories Supplied CD ROM (user manual), 15-Pin

D-Sub cable, audio cable, AC

power cord

L-W22

e slim and glossy frame represents a

stylish design and also saves desktop space

Built-in HDMI input makes the L-W22 easy to

be paired with Full HD multimedia advices

VESA standard wall mount allows for secure

mounting almost anywhere

Specications L-W22
