AFL FlexScan FS300 Manuel utilisateur

FlexScan®FS300 OTDR

With SmartAuto®and LinkMap®

User’s Guide

www.AFLglobal.com or (800) 321-5298, (603) 528-7780

Test & Inspection

Safety Information................................................6

Apple Inc. Legal Notice ............................................7

Hardware Overview...............................................8

Controls, Display, Interfaces ......................................8

Front Panel Buttons and Indicators .................................10

Battery Charging...............................................11

Understanding Battery Charge Status ...............................11

Configuring FlexScan to Auto-Off ..................................12

User Interface Overview............................................13

Home Screen Features...........................................13

Test Modes and Features Summary .................................13

Utility Modes and Features Summary................................14

General Settings .................................................15

Common Functions in OTDR Test Modes ...............................23

Live Fiber Detection.............................................23

Launch Quality Check ...........................................23

OTDR Test Results Viewers .......................................24

Contents

SmartAuto®OTDR................................................25

SmartAuto OTDR Setup Summary ..................................25

Network Type .................................................25

Test Wavelength ...............................................26

Fiber Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Viewing and Configuring Fiber Type ..............................27

Launch & Tail Cords.............................................29

Pass/Fail Rule .................................................30

Viewing and Configuring Pass/Fail Rule ...........................31

To Start SmartAuto OTDR Test.....................................34

Understanding LinkMap®View Features .............................35

Understanding Event Table View Features ............................37

Understanding Trace View Features ................................38

Trace View – Cursor Control Enabled..............................39

Trace View – Zoom Control Enabled ..............................40

Expert and Real-time OTDR .........................................41

Understanding Expert and Real-time OTDR Settings ....................41

Expert and Real-time OTDR Setup ....................................43

Testing in Expert OTDR Mode .......................................44

Contents

Test Sequence in Expert OTDR Mode ................................44

Testing in Real-time OTDR Mode .....................................45

Test Sequence in Real-time OTDR Mode .............................45

Light Source and Power Meter Operation...............................46

Light Source Settings and Features .................................46

Power Meter Settings and Features .................................47

Inspecting Fibers with FOCIS Series Inspection Probe and FlexScan ...........48

FOCIS Flex Inspection Probe Overview...............................48

Pairing FlexScan with FOCIS Flex Inspection Probe .....................50

Enable Bluetooth on FlexScan .....................................50

Enable Bluetooth on FOCIS Flex....................................51

Configuring Auto-Send ..........................................52

Inspecting Optical Connectors .....................................53

File Manager ....................................................55

Saving Results.................................................56

Saving Results for Bi-directional Reporting ...........................56

Saving to a Newly Created Folder ..................................57

Saving to the Current Folder ......................................57

Viewing Saved Test Results .......................................58

Contents

File Manager ....................................................59

Deleting Projects/Jobs/Fibers......................................59

Transferring Results to a PC via USB ..................................60

Back Up Saved Results to USB Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Printing Results to PDF ............................................62

How to View Device Information .....................................63

General Information ..............................................64

Contacting Customer Service......................................64

Warranty Terms and Conditions....................................64

Safety Information

WARNING! Use of procedures or adjustments other than those specied herein may result in hazardous radiation

exposure.

850/1300 nm MM OTDR/OLS port

1310/1550 nm SM OTDR/OLS port

This is a CLASS I LASER output.

VFL port This is a CLASS IIIa/3R LASER output.

Avoid exposure to the beam!

NOTE! FlexScan OTDRs equipped with Bluetooth/WiFi (option W1) contain the following two Bluetooth / WiFi

Transmitter Modules:

FCC ID: X3ZBTMOD8 FCC ID: Z64-WL18DBMOD

IC: 8828A-MOD8 IC: 451I-WL18DBMOD

WARNING! Use only the specied AC adapter. Use of another type of AC adapter can damage the instrument and

create the danger of re and electrical shock.

WARNING! To avoid the danger of re and electrical shock:

• Never use a voltage that is different from that for which the AC adapter is rated.

• Do not plug the unit into a power outlet that is shared by other devices.

• Never modify the power cord or excessively bend, twist, or pull it.

• Do not allow the power cord to become damaged.

• Do not place heavy objects on the power cord or expose it to heat.

• Never touch the AC adapter while your hands are wet.

• Should the power cord become seriously damaged (internal wiring exposed or shorted), contact the manufacturer

to request servicing.

• CAUTION! Do not run any tests or perform functions that activate a FlexScan laser unless ber is attached to the

corresponding port.

• CAUTION! To avoid serious eye injury, never look directly into the optical outputs of ber optic network

equipment, test equipment, patch cords, or test jumpers. Refer to your company’s safety procedures when

working with optical systems.

• NOTICE: Except user replaceable battery, FlexScan OTDR contains no user-serviceable parts, it must be returned

to AFL or authorized agents for repair and calibration.

• IMPORTANT: Proper care in handling should be taken when using any precision optical test equipment.

Scratched or contaminated optical connectors can impact the performance of the instrument. It is important to

keep the dust caps in place when the unit is not being used.

• IMPORTANT: Always clean OTDR port and any mating connectors using approved cleaning supplies (e.g. One-

click cleaner) before mating the connectors.

• CAUTION! Power levels in excess of +10 dBm may damage OTDR optics. Do not connect OTDR to network

connectors where received power level may exceed +10 dBm. If high power levels are suspected, verify power

level by connecting to OPM and measuring received power level.

Safety Information

Apple Inc. Legal Notice

AirPlay, iPad, iPhone, iPod, iPod classic, iPod nano, iPod touch, and Retina are trademarks of Apple Inc., registered

in the U.S. and other countries. iPad Air, iPad mini, and Lightning are trademarks of Apple Inc.

Controls, Display, Interfaces

Hardware Overview

Ref Feature Description

1Power button Press to power FlexScan OTDR on/off.

2Power port (5 VDC) This is interface for the AC power adapter/charger.

3AC/Charger indicator Illuminates when AC is connected and indicates battery charging status.

• RED light = rechargeable battery is charging.

• GREEN light = rechargeable battery is fully charged.

4 USB host port This USB port may be used to connect USB Flash Drive for data storage, results

backup or to update FlexScan software.

5Micro-USB function

port

With the supplied USB cable, this port may be used to connect OTDR to a USB host

port on a PC to upload stored results, PDF printouts and captured screen images.

Ref Feature Description

6Multimode OTDR/

Source port

This is a CLASS I LASER output. Multimode OTDR/Light Source port.

7Single-mode

OTDR/Source port

This is a CLASS I LASER output. Single-mode OTDR/Light Source port.

8VFL port This is a CLASS IIIa/3R LASER output. Avoid exposure to the beam!

The VFL (visual fault locator) port is a 635 nm (visible red) laser. Used for short-range

fault-location.

9Power meter port Optical Power Meter port. Used for power (dBm, W) or loss (dB) measurements.

10 Touchscreen

display

5” 800 x 480 Color Backlit LCD and Gesture-Recognition Touchscreen.

Hardware Overview

7 986

Front Panel Buttons and Indicators

Ref Feature Description

11 Home button Press to access the Home screen.

12 Test start/stop button Press to start a new test; or, if a test is running, stop the current test.

13 VFL button Use the VFL button to control the VFL laser:

Press and hold ~ 1 sec to enable VFL at ~2 Hz ash rate

Press and hold ~ 2 sec = CW

Press and hold ~ 1 sec to switch off

14 VFL indicator When the VFL port is active this indicator illuminates as follows:

• Flashing RED = VFL ashing at ~2 Hz rate

• Solid RED = VFL on CW

• OFF = VFL is off

Reserved
