SOM-ETX CPU Board
Model Number AW-BS610
VIA Eden CPU card with VGA/LCD/LVDS, LAN, TV-Out & Audio
User’s Manual
Version 1.0
We embed your need! ©Copyright 2002
User’s Manual
© Copyright 2002. All Rights Reserved
Manual Edition 1.0, February 2005
This document contains proprietary information protected by copyright. All rights are
reserved, no part of this manual may be reproduced, copied, translated or transmitted in
any form or by any means without prior written permission of the manufacturer.
The content of this manual is intended to be accurate and reliable, the original
manufacturer assumes no responsibility for any inaccuracies that may be contained in this
manual. The original manufacturer reserves the right to make improvements to the
products described in this manual at any time without prior notice.
Trademarks
IBM, EGA, VGA, XT/AT, OS/2 and PS/2 are registered trademarks of International business
Machine Corporation
Award is a trademark of Award Software International, Inc
Intel is a trademark of Intel
RTL is a trademark of Realtek
VIA is a trademark of VIA Technologies, Inc
Microsoft, Windows, Windows NT and MS-DOS are either trademarks or registered
trademarks of Microsoft Corporation
All other product names mentioned herein are used for identification purpose only and may
be trademarks and/or registered trademarks of their respective companies
Limitation of Liability
While reasonable efforts have been made to ensure the accuracy of this manual, the
manufacturer and distributor assume no liability resulting from errors or omissions in this
manual, or from the use of the information contained herein.
©2002 AEWIN Technologies Co., Ltd. All rights reserved. 2Ver 1.0. Feb. 2005
User’s Manual
Table of Contents
HTChapter 1. General Information-------------------------------------------------------------4TH
HT1.1 Introduction-----------------------------------------------------------------------------------4TH
HT1.2 Specification----------------------------------------------------------------------------------TH4
HT1.3 AW-BS610 Package-------------------------------------------------------------------------6TH
HT1.4 Board Layout---------------------------------------------------------------------------------7TH
HT1.5 Board Dimension----------------------------------------------------------------------------7TH
HT -8Chapter 2. BIOS Setup-------------------------------------------------------------------------TH
Chapter 3. BIOS Setup--------------------------------------------------------------------------T
2HT.1 Installing Memory----------------------------------------------------------------------------8TH
HT H11
3HT.1 Quick Setup------------------------------------------------------------------------------------11TH
3HT.2 Entering the CMOS Setup Program----------------------------------------------------12TH
3HT.3 Menu Options----------------------------------------------------------------------------------TH13
HTStandard CMOS Features-----------------------------------------------------------------------14TH
HTAdvanced BIOS Features-----------------------------------------------------------------------16TH
HTAdvanced Chipset Features--------------------------------------------------------------------19TH
HTIntegrated Peripherals----------------------------------------------------------------------------22TH
HTPower Management Setup----------------------------------------------------------------------23TH
HTPNP/PCI Configuration---------------------------------------------------------------------------25TH
HTPC Health Status-----------------------------------------------------------------------------------27TH
HTLoad Fail-Safe Default----------------------------------------------------------------------------28TH
HTLoad Optimized Default--------------------------------------------------------------------------29TH
HTSet Supervisor & User Password-------------------------------------------------------------30TH
HTChapter 4. Drivers and Utility------------------------------------------------------------------32TH
HT4.1 System Driver Installation -----------------------------------------------------------------32TH
HT4.2 VGA Driver Installation----------------------------------------------------------------------35TH
4.3 Ethernet Driver Installation ----------------------------------------------------------------37
4.4 Audio Driver Installation --------------------------------------------------------------------42
HTAppendix A. Optional Cable List---------------------------------------------------------------43TH
©2002 AEWIN Technologies Co., Ltd. All rights reserved. 3Ver 1.0. Feb. 2005
User’s Manual
Chapter 1. General Information
1.1Introduction
The AW-BS610 is a VIA EBGA low power consumption processor System On
Module (SOM). Using a VIA EDEN processor up to 733MHz, the AW-BS610 achieves
good performance on the SOM-ETX CPU module. On-board features include two TTL
(16550 compatible) serial ports, one bi-directional parallel (ECP/EPP/SPP) port, four
USB ports, one FPC type floppy disk connector, SIR IrDA 1.1 compliant and a
keyboard/PS2 mouse interface. The two IDE devices supports Ultra DMA 33/66/100
mode with data transfer rate up to 100MB/sec. In addition, the board’s watchdog timer
can automatically reset the system or generate an interrupt if the system stops due to a
program bug or EMI. The built-in VIA BT82C686B supports temperatures, fan speed
and voltages monitoring function. The small size (94mm x 114mm) and use of four high
capacity connector based on the proven SOM-ETX form factor, allow the SOM-ETX
modules to be easily and securely mounted onto a customized solution board or our
standard AW-BP100 5.25” SOM-ETX base board.
The AW-BS610 is a highly integrated multimedia SOM that combines audio, video
and network functions. It provides CRT/24-bit TTL TFT LCD and LVDS interface,
integrated AGP 4X 2D/3D graphic accelerator with system memory 8/16/32MB. The
AW-BS610 also support TV-Out that supports NTSC/PAL format and audio controller
based on Realtek® ALC650 AC97 codec for multimedia applications.
1.2Specification
General Functions
CPU VIA Eden (EBGA packing) CPU
BIOS Award® 512KB Flash BIOS
Chipset VIA VT8606 + VT82C686B
I/O Chipset VT82C686B built-in
Memory Onboard one 144-pin SO-DIMM socket supports up to 512MB SDRAM
Enhanced IDE Supports up to two IDE devices (Ultra DMA33/66/100)
©2002 AEWIN Technologies Co., Ltd. All rights reserved. 4Ver 1.0. Feb. 2005
User’s Manual
FDD interface Support one FPC type floppy disk connector
Parallel port One bi-directional parallel ports and can be reconfigure to FDD interface;
supports SPP/ECP/EPP modes
Serial port Two TTL (16550 compatible) serial ports
IR interface Supports SIR IrDA1.1 compliant
KB/Mouse connector Support PS/2 keyboard/mouse
USB connectors Support four USB ports
Watchdog Timer Can generate a system reset, supports software selectable timeout interval
System Monitoring Built in VIA VT82C686B supports temp, fan speed and voltages monitoring
Expansion interface Supports ISA& PCI expansion interface
Flat Panel/CRT Interface
Chipset VIA Twister-T chip with integrated Savage4 2D/3D/Video Accelerator
Display memory Share system memory 8/16/32MB
Memory Display memory Share system memory 8/16/32MB
Interface 4X AGP VGA/LCD interface, support for 9,12,15,18,24 bit TFT and optional
16- or 24-bit DSTN panel
Display type Support CRT, 24bit TTL TFT LCD and LVDS interface
Output connector TTL TFT LCD connector on board, CRT & LVDS on base board
Ethernet Interface
Chipset Realtek® RTL8139C 100BASE-Tx Fast Ethernet controller
Output connector RJ-45 connector x 1 on the base board
TV-out Interface
Chipset VIA1621 digital TV encoder
TV format Supports NTSC and PAL signals format
Output connector Provides RCA (Composite) video and S-video connector on base board
Audio Interface
Chipset Realtek®ALC650 AC97 codec
Output connector Audio connectors on base board
©2002 AEWIN Technologies Co., Ltd. All rights reserved. 5Ver 1.0. Feb. 2005
User’s Manual
Form factor ETX form factor
Mechanical and Environmental
Power supply voltage VCC (4.75V to 5.25V)
Max. Power
Requirement 5A @5V
Operating
temperature 32 to 140 (0 to 60 )℉℃
Board size 4.5"(L) x 3.7"(W) (114mm x 94mm)
1.3 Package
Please make sure that the following materials have been packed with the board before
starting install your AW-BS610.
1. AW-BS610 SOM-ETX Board
2. Quick Setup Manual
3. Cable List:
46-ICOM00-00 2.54mm COM Port Cable
46-IUSB08-002.54mm USB Cable
Optional Cable
46-ATA660-00 IDE Cable
4. CD-ROM for Drivers, Utilities
If any of these parts are missing or damaged, please contact your distributor or sales
representatives immediately.
Note: for detailed contents of the AW-BS610, please refer to the attached CD-ROM.
©2002 AEWIN Technologies Co., Ltd. All rights reserved. 6Ver 1.0. Feb. 2005
User’s Manual
1.4 Board Layout
1.5Board Dimension
©2002 AEWIN Technologies Co., Ltd. All rights reserved. 7Ver 1.0. Feb. 2005
User’s Manual
Chapter 2. Installing Process
2.1 Installing Memory:
To insert a SDRAM Memory: The AW-BS610 onboard with one 144-pin DDR DIMM sockets
supports up to 512Mbytes DDR SDRAM.
To Insert a DIMM Memory: Please align the module with the socket key and press down until the
levers at each end of the socket snap close up.
There are two directions for installing a module in the socket. Do not attempt to force the module
into the socket incorrectly.
©2002 AEWIN Technologies Co., Ltd. All rights reserved. 8Ver 1.0. Feb. 2005
User’s Manual
©2002 AEWIN Technologies Co., Ltd. All rights reserved. 9Ver 1.0. Feb. 2005
User’s Manual
To Remove a DIMM Memory: To remove a DIMM, press down on the levers at both end of the
module until the module pops out
There is only one direction for installing a module in the socket. Do not attempt to force the
module into the socket incorrectly.
