Aewin AW-A696 Manuel utilisateur
We embed your need! ©Copyright 2005
Control Board
Model Number AW-A696
Intel® Pentium® III Embedded SBC with six 10/100LAN & SSD
User’s Manual
Version 1.2
User’s Manual
©2005 AEWIN Technologies Co., Ltd. All rights reserved. 2Ver1.2.Dec.2005
© Copyright 2005. All Rights Reserved
Manual Edition 1.2, Dec 2005
This document contains proprietary information protected by copyright. All rights are
reserved, no part of this manual may be reproduced, copied, translated or transmitted in
any form or by any means without prior written permission of the manufacturer.
The content of this manual is intended to be accurate and reliable, the original
manufacturer assumes no responsibility for any inaccuracies that may be contained in this
manual. The original manufacturer reserves the right to make improvements to the
products described in this manual at any time without prior notice.
Trademarks
IBM, EGA, VGA, XT/AT, OS/2 and PS/2 are registered trademarks of International business
Machine Corporation
Award is a trademark of Award Software International, Inc
Intel is a trademark of Intel
RTL is a trademark of Realtek
VIA is a trademark of VIA Technologies, Inc
Microsoft, Windows, Windows NT and MS-DOS are either trademarks or registered
trademarks of Microsoft Corporation
All other product names mentioned herein are used for identification purpose only and may
be trademarks and/or registered trademarks of their respective companies
Limitation of Liability
While reasonable efforts have been made to ensure the accuracy of this manual, the
manufacturer and distributor assume no liability resulting from errors or omissions in this
manual, or from the use of the information contained herein.
User’s Manual
©2005 AEWIN Technologies Co., Ltd. All rights reserved. 3Ver1.2.Dec.2005
Table of Contents
Chapter 1 General Information........................................................................................................5
1.1 Introduction..........................................................................................................................5
1.2 Specification ........................................................................................................................5
1.3 Package...............................................................................................................................6
1.4 Board Layout.......................................................................................................................7
1.5 Board Dimension................................................................................................................7
Chapter 2 Connectors/Switch Location and Configuration.........................................................8
2.1 Connectors/Jumpers Location and Define .....................................................................8
2.2 Install Processor ...............................................................................................................10
2.2.1 Installing CPU:.......................................................................................................10
2.2.2 Remove CPU.........................................................................................................11
2.3 Installing Memory..............................................................................................................13
2.4 Connector and Jumper Settings.....................................................................................14
Chapter 3. BIOS Setup...................................................................................................................19
3.1 Quick Setup.......................................................................................................................19
3.2 Entering the CMOS Setup Program..............................................................................20
3.3 Menu Options....................................................................................................................21
3.4 Standard CMOS Features Setup ...................................................................................22
3.5 Advanced BIOS Features Setup....................................................................................24
3.6 Advanced Chipset Features Setup................................................................................27
3.7 Integrated Peripherals......................................................................................................30
3.8 Power Management Setup..............................................................................................31
3.9 PNP/PCI Configuration....................................................................................................33
3.10 PC Health Status Configuration Setup........................................................................35
3.11 Frequency/Voltage Control Option...............................................................................35
3.12 Load Fail-Safe Defaults.................................................................................................36
3.13 Load Optimized Defaults...............................................................................................37
3.14 Supervisor/User Password ...........................................................................................37
3.15 Save and Exit Setup ......................................................................................................38
3.16 Exit Without Saving........................................................................................................39
Chapter 4 Driver Utility Installation...............................................................................................40
4.1 System Driver Installation................................................................................................40
4.2 VGA Driver Installation.....................................................................................................44
4.3 Ethernet Driver Installation..............................................................................................45
4.3.1 Realtek 8139C Ethernet Installation...................................................................46
4.3.2 Intel® 82551QM Ethernet Installation................................................................51
Appendix A: Programming the Watchdog Timer ........................................................................57
User’s Manual
©2005 AEWIN Technologies Co., Ltd. All rights reserved. 4Ver1.2.Dec.2005
Appendix B: System Resource .....................................................................................................58
Appendix C: Installing CompactFlash Memory...........................................................................61
Appendix D: Optional Cable List...................................................................................................62
User’s Manual
©2005 AEWIN Technologies Co., Ltd. All rights reserved. 5Ver1.2.Dec.2005
Chapter 1 General Information
1.1 Introduction
The AW-A696 is a full function of 5.25” Embedded format SBC board use VIA VT8606 and
VT82C686B chipset supports Intel®Socket 370 Celeron®/Pentium®III Tualatin processors.
The AW-A696 supports six of Intel 82551QM or Realtek RTL8139C+ Ethernet chipset with
RJ45 jack for 10/100Mbps.
The onboard features include two RS-232 serial ports, and onboard SSD interface supports
CompactFlash™ type II Socket. The AW-A696 supports up to two USB ports. For the
expansion ability, the AW-A696 reserved a mini-PCI slot for flexible expansion capabilities.
1.2 Specification
General Functions
CPU Intel ® socket 370 Celeron™ /Pentium® III, Tualatin & VIAC3 processors
up to 133MHz
BIOS Award® 256KB Flash BIOS supports console redirection function
Chipset VIA VT8606 + 82C686B
I/O Chipset VT82C686B built-in
Memory Two 168-pin DIMM socket, up to 512MB SDRAM
Enhanced IDE Supports up to two IDE devices (Ultra DMA33/66/100)
Serial port Two RS-232 ports, one 9-pin D-Sub connector and one pin header
USB connectors Onboard pin-header for two USB ports
PCI Slot One Mini PCI slot
Watchdog Timer Can generate a system reset, supports software selectable timeout
interval
System Monitoring Supports temp, fan speed and voltages monitoring
CRT Interface
Chipset VIATwister chip with integrated Savage4 2D/3D/Video Accelerator
Display Type Support pin header for CRT Monitor
Memory Display memory Share system memory 8/16/32MB
Ethernet Interface
User’s Manual
©2005 AEWIN Technologies Co., Ltd. All rights reserved. 6Ver1.2.Dec.2005
Chipset Six Intel® 82551QM or Realtek® 8139C+ 100Base-TX Fast Ethernet
control
Ethernet Interface PCI 100/10Mbps Ethernet controller, IEEE 802.3U protocol compatible
Bypass Optional two Ethernet ports bypass
SSD Interface One 50-pin CompactFlash type II socket™
Mechanical and Environmental
Power supply voltage +5V (4.75V to 5.25V) , +12V (11.4V to 12.6V),-12V(-11.4 to –12.6)
Max. Power
Requirement +5V @ 7A, +12V @, 200mA, -12V @ 120mA
Operating
temperature 32 to 140 (0 to 60 )℉℃
Board size 8.9"(L) x 7.5"(W) (226mm x 192mm)
1.3 Package
Please make sure that the following materials have been packed with the board before
starting install your AW-A696.
1. AW-A696 Embedded SBC
2. Quick Setup Manual
3. Cable List:
z46-ICOM00-00 2.54mm COM Port Cable
z46-IVGA01-00 2.00mm VGA Cable
z46-IUSB08-002.54mm USB Cable
Optional Cable
z46-ATA660-00 IDE Cable
z46-IPOW20-00 Power Cable
4. CD-ROM for Drivers, Utilities
If any of these parts are missing or damaged, please contact your distributor or sales
representatives immediately.
Note: for detailed contents of the AW-A696, please refer to the attached CD-ROM.
User’s Manual
©2005 AEWIN Technologies Co., Ltd. All rights reserved. 7Ver1.2.Dec.2005
1.4 Board Layout
1.5 Board Dimension
User’s Manual
©2005 AEWIN Technologies Co., Ltd. All rights reserved. 8Ver1.2.Dec.2005
Chapter 2 Connectors/Switch Location and Configuration
2.1 Connectors/Jumpers Location and Define
User’s Manual
©2005 AEWIN Technologies Co., Ltd. All rights reserved. 9Ver1.2.Dec.2005
Connector Define
CN1 FAN1 Connector
CN2 FAN2 Connector
CN3 FAN3 Connector
CN4 6 Pin Power Connector
CN5 VGA Pin Header (2mm)
CN6 IDE Connector (40pin, 2.54mm)
CN7 Reset
CN8 USB Pin-Header (2.54mm)
CN9 Mini PCI Slot
CN10 COM2 Pin-Header
CN12 GPIO LED Pin –Header
CN13 LAN LED Pin-Header
CN15 LAN6 RJ-45 Connector
CN16 LAN1 RJ-45 Connector
CN17 LAN2 RJ-45 Connector
CN18 LAN3 RJ-45 Connector
CN19 LAN4 RJ-45 Connector
CN20 LAN5 RJ-45 Connector
CN21 COM1 D-Sub Connector
CN22 Parallel Pin-Header
JP1 Clear CMOS
JP2 BypassAlways Enabled Select
JP3 Watch Dog or Bypass Select
User’s Manual
©2005 AEWIN Technologies Co., Ltd. All rights reserved. 10 Ver1.2.Dec.2005
2.2 Install Processor
2.2.1 Installing CPU:
(1) The CPU has marks with a triangle then make sure the triangle has the same
position with CPU socket ; then easily pressing down the processor into the socket.
(2) Then tie the screw of CPU socket beginning from right side; you can refer to below
picture.
(3) Now you can to lay aside CPU processor in socket, please see picture.
