AEMC 511 Manuel utilisateur



CLAMP-ON METER



511

512

INSTRUMENTS

ENGLISH User Manual

INSTRUMENTS

MODEL 511

CLAMP METER

01020 30 40

MAX MIN

40A

OFF

MAX MIN

∆

REL

RANGE

HOLD

PEAK

1mS

600V CAT III 1000A

KHz

MHz

KΩ

Ω

P+ H

P–

600V

600V CAT II

300V CAT III

600V

1000V

INSTRUMENTS

MODEL 512

TRMS CLAMP METER

01020 30 40

MAX MIN

40A

OFF

MAX MIN

∆

REL

RANGE

HOLD

PEAK

1mS

600V CAT III 1000A

KHz

MHz

KΩ

Ω

P+ H

P–

600V

600V CAT II

300V CAT III

600V

1000V

www.ShopAEMC.com

Shop for AEMC products online at: 1.888.610.7664

Statement of Compliance

Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments

certiﬁes that this instrument has been calibrated

using standards and instruments traceable to

international standards.

We guarantee that at the time of shipping your

instrument has met its published speciﬁcations.

An NIST traceable certiﬁcate may be

requested at the time of purchase, or obtained

by returning the instrument to our repair and

calibration facility, for a nominal charge.

The recommended calibration interval for this

instrument is 12 months and begins on the date

of receipt by the customer.

Serial #: ________________________________

Catalog #: 2117.67 / 2117.68

Model #: 511/ 512

Please ﬁll in the appropriate date as indicated:

Date Received: ___________________________

Date Calibration Due: ______________________

INSTRUMENTS

www.ShopAEMC.com

Shop for AEMC products online at: 1.888.610.7664

Clamp-on Meter Models 511 and 512

Table of Contents

1. INTRODUCTION ....................................3

1.1 International Electrical Symbols...........4

1.2 Receiving Your Shipment.....................4

1.3 Ordering Information ............................4

1.3.1 Replacement Parts....................4

2. PRODUCT FEATURES ...........................5

2.1 Description ...........................................5

2.2 Model 511/512 Control Features..........6

2.3 LCD Display .........................................7

3. SPECIFICATIONS ..................................8

3.1 ElectricalSpecications .......................8

3.2 MechanicalSpecications....................9

3.3 EnvironmentalSpecications.............10

3.4 SafetySpecications..........................10

4. OPERATION ........................................11

4.1 Button Functions ................................11

4.1.1 Data Hold ...............................11

4.1.2 Peak Hold Function ................11

4.1.3 MAX/MIN Function ..................12

4.1.4 REL Function...........................12

4.1.5 Manual Range Mode...............12

4.2 AC Current Measurement ..................13

4.3 AC Volt Measurement ........................14

4.4 DC Volt Measurement........................15

4.5 Resistance Measurement ..................16

ENGLISH ................................................................ 1

ESPAÑOL.............................................................. 25

www.ShopAEMC.com

Shop for AEMC products online at: 1.888.610.7664

Clamp-on Meter Models 511 and 512

4.6 Continuity Measurement ....................17

4.7 Diode Measurement...........................18

4.8 Frequency Measuring - Voltage .........19

4.9 Frequency Measurement - Current....20

5. MAINTENANCE ...................................21

5.1 Warning!.............................................21

5.2 Cleaning.............................................21

5.3 Battery Replacement..........................22

Limited Warranty ................................................24

Warranty Repairs................................................24

www.ShopAEMC.com

Shop for AEMC products online at: 1.888.610.7664

Clamp-on Meter Models 511 and 512

CHAPTER 1

INTRODUCTION

Warning

● Readtheusermanualbeforeoperatingand

follow all safety information.

● Onlyusethemeterasspeciedinthisuser

manual.

● Neverusethismeteronacircuitwithvolt-

ages greater than 600Vrms @ 50/60 Hz,

Cat. III or 750V, Cat. II.

● Nevermeasurecurrentwhilethetestleads

are connected to the input jacks.

● Donotoperatethemeterifthebodyortest

leads look damaged.

● Checktherotaryrangeswitchandmake

sure it is at the correct position before each

measurement.

● Donotperformresistanceandcontinuity

test on a live circuit.

● Useextremecautionwhenmeasuringlive

systems with voltages greater than 60VDC or

30VAC.

● Useextremecarewhenworkingaroundbus

bars and bare conductors.

● Donotusethemeterinoverrange/overload

conditions (OL).

● Foraccuratereadings,changethebattery

when the symbol appears.

www.ShopAEMC.com

Shop for AEMC products online at: 1.888.610.7664

Clamp-on Meter Models 511 and 512

1.1 International Electrical Symbols

This symbol signies that the instrument is pro-

tected by double or reinforced insulation.

This symbol on the instrument indicates a

WARNING and that the operator must refer to the

user manual for instructions before operating the

instrument. In this manual, the symbol preceding

instructions indicates that if the instructions are

not followed, bodily injury, installation/sample and

product damage may result.

Risk of electric shock. The voltage at the parts

marked with this symbol may be dangerous.

1.2 Receiving Your Shipment

Uponreceiving your shipment, makesurethat the con-

tents are consistent with the packing list. Notify your dis-

tributor of any missing items. If the equipment appears to

bedamaged,leaclaimimmediatelywiththecarrierand

notify your distributor at once, giving a detailed descrip-

tion of any damage. Save the damaged packing container

to substantiate your claim.

1.3 Ordering Information

Clamp-on Meter Model 511 .....................Cat. #2117.67

Includes meter, pair of test leads (red/black with probe tips), one

9V battery, soft carrying case and a user manual.

TRMS Clamp-on Meter Model 512..........Cat. #2117.68

Includes meter, pair of test leads (red/black with probe tips), one

9V battery, soft carrying case and a user manual.

1.3.1 Accessories and Replacement Parts

Set of 2, 5 ft color-coded leads..................Cat. #2140.68

Replacement Pouch ..................................Cat. #2118.94

www.ShopAEMC.com

Shop for AEMC products online at: 1.888.610.7664

Clamp-on Meter Models 511 and 512

CHAPTER 2

PRODUCT FEATURES

2.1 Description

The AEMC®Models 511 and 512 are general purpose

professional clamp-on meters that measure up to the

toughest standards. These meters offer a complete set

of measurement ranges (AC Amps, AC Volts, DC Volts,

Ohms, Continuity with beeper, Frequency from V or A,

Diode Test function) and are in compliance with interna-

tional safety and quality standards to ensure professional

and reliable measuring tools. They are Auto-Ranging and

provide the best measurement range and resolution for

troubleshooting. They also have a high resolution 40A

range.

The Models 511 and 512 are sized for comfortable, one-

handed operation. The tapered and hooked jaw design

facilitates maneuvering in crowded wiring and breaker

panels, making it easy to select conductors. The jaw

opening accommodates one 750kcmil cable or two

350kcmil cables. The large and easy-to-read 4000-count

LCD features comprehensive user information symbols,

such as low battery, polarity, overload, and an analog bar-

graph for easy trend readings. Both models are equipped

with a Data Hold function that freezes the measurement

for later viewing, Min/Max, and a fast 1ms Peak Hold

function for capture of signals.

The Model 511 is average sensing and designed for

traditional average responding electrical systems.

The Model 512 is a True RMS clamp-on that provides

RMS measurements for today’s non-linear electrical

environments.

www.ShopAEMC.com

Shop for AEMC products online at: 1.888.610.7664

Clamp-on Meter Models 511 and 512

2.2 Model 511/512 Control Features

1. Jaw Assembly - 1.575" (40 mm)

2. Lever for Jaw Opening/Closing

3. Rotary Range Selector Switch

4. Maximum/MinimumButton

5. LCD Display

6. COM (black) Input

7. Data Hold Button

8. Peak Hold Button

9. Range Button

10. Relative Button

11. Positive (red) Input

www.ShopAEMC.com

Shop for AEMC products online at: 1.888.610.7664

Clamp-on Meter Models 511 and 512

2.3 LCD Display

Low Battery

DC Input

Polarity Indicator

Zero (Relative)

AC Inupt

Auto Power Off Indication

Positive Peak Detect Indication

Continuity Beeper Enabled

Diode Function Indication

Negative Peak Detect Indication

Data Hold

Manual Range

KΩ Resistance Measurement Indicator

VA Voltage/Current Indicator

KHz / MH Frequency Measurement Indicator

Analog Bargraph

www.ShopAEMC.com

Shop for AEMC products online at: 1.888.610.7664

Clamp-on Meter Models 511 and 512

CHAPTER 3

SPECIFICATIONS

3.1 Electrical Speciﬁcations

Reference Conditions: 23°C ±5°C, 45 to 80% RH, True RMS for VAC and

AACaccuracyarespeciedfrom5%to100%ofrange,crestfactor1.4<CF

<3atfullscale&CF<6athalfscale.

AC Amperes (Auto-Ranging)

Range Resolution Accuracy (50/500Hz) Overload

40A 0.01A

1.9% Reading ± 5cts

800 Arms

400A 0.1A 1500Arms

1000A 1A

AC Volts (Auto-Ranging)

Range Resolution Accuracy (50/500Hz) Overload

400V 0.1V 1.2% Reading ± 5cts 1000Vrms

750V 1V

DC Volts (Auto-Ranging)

Range Resolution Accuracy (50/500Hz) Overload

400V 0.1V 0.75% Reading ± 2cts 1200Vrms

1000V 1V

Resistance - Ohms (Ω)

Range Resolution Accuracy (50/500Hz) Overload

400Ω 0.1Ω 1% Reading ± 2cts 600Vrms

4000Ω 1Ω
