AEG 835 D Manuel utilisateur

835 D / 8359 D

Dunstabzugshaube

Fume Extractor Hood

Afzuigkap

Montage- und Gebrauchsanweisung

Installation and Operating Instructions

Montage- en gebruiksaanwijzing

Printedonrecycledpaper.

AEG–puttingwordsintoaction.

Contents

Introduction 19

Extractor version 19

Filter version 20

Electrical connections 21

Safety warnings for electrician 21

Technic Details 23

Installation 24

Safety warnings for kitchen unit installer 24

Installation 26

Hood Operation 28

Safety warnings for user 29

Maintenance and care 30

Metal grease filter 30

Open the metal grease filter 30

Carbon filter 31

Changing the light bulb 32

Cleaning 33

Special accessories 33

Technical assistance service 33

Introduction

Extractorversion

●Thehoodissuppliedasanextractorunitandcanalsobeusedwith

afilteringfunctionbyfittingactivatedcarbonfilters(special

accessory).

●YouwillneedoriginalAEGactivatedcarbonfiltersforthisfunction

(seeSpecialAccessories).

●Theairis forcedoutthroughahosefittedtothetopof thehood

A. Fig. 1.

●The outlet hose must have a diameter of 150 mm (special

accessory)forthefilteringversion.

●Fittheconnectionringabovethehoodwithtwoscrewsthenfiran

exhaustingpipelongenoughtoreachtheoutside.Fig.1.

●Ifthecookingvapourispassedthroughanoutsidewall,youwill

need an MKZ telescopic wall pipe (with intake and

ventilation) E-Nr.:942 118 609 (150 mm Ø) from our range of

special accessories.

Fig. 1

Filter version

●The air is filtered through an activated carbon filter and

passed back into the kitchen through the top outlet duct

grids.

●You will need an original AEG KF 825 activated carbon filter

for the filtering function. (See Special Accessories).

●Fix the deflector with two screws Ø3,5x6,5. Fig. 2.

Fig. 2

Electrical connections

Safety warnings for electrician

It must be ensured that the voltage and current indicated on the rating

plate agree with the voltage of the user to electricity supply.

Iftheappliancehasbeenequippedwithamainsleadwithamoulded-on

type plug, the following regulations must be comply with:

The plug moulded on to the lead incorporates a fuse. For replacement,

usea5ampBS1362fuse.OnlyASTAapprovedorcertifiedfusesshould

beused.Ifthefusecover/carrierislost,areplacementcover/carriemust

beobtainedfromanelectricalgoodsretailer.Ifthesocketoutletsarenot

suitable for the plug fitted to the appliance, then the plug must be cut off

and destroyed for safety reasons, and an appropriate plug be fitted.

Whenwiringtheplugensurethatallstrandsofwirearesecurelyretained

ineachterminal.Donotforgettotightenthemainsleadclampontheplug.

Electrical connections

230 V - using fixed power supply line with plug.

Fuse rating 13 amps

(The unit should only be connected up by an authorized electrician).

See rating plate for further information.

It is recommended that the socket for the plug is sited above the cooker

hood or above the overhead cabinet.

This has 2 advantages:

1) The socket is not visible.

2) The appliance can easily be unplugged when necessary.

Ifafixedconnectionisrequiredthecookerhoodshouldbeconnectedby

anelectricalinstallerregisteredwithacompetentelectricitycompany.An

isolating device is to be provided on the fixed wiring side. Switches with

a contact opening of more than 3mm apply as isolating devices.

These include-automatic cut-out switches, fuses and contactors (VDE

0730, s. 7, Part1).

Electrical connection for the UK

Appliances with 2 wires

The appliance must be connected to fixed wiring with a

double pole switched fused spur outlet with or without pilot

lamp.

We strongly recommend the appliance to be connected only

by a qualified electrician who is a member of the NICEIC who

will comply with the IEE and any local regulations.

NOTE:

The terminology “DOUBLE POLE” means that both the live

and the neutral supplies are switched and disconnected at the

same time.

The terminations labelled SUPPLY are for the connection for

the internal house wiring and the terminations labelled LOAD

are for the appliance.

IMPORTANT

The wires of the mains lead supplied with this appliance

are coloured in accordance with the following code:

Blue-Neutral

Brown-Live

As the colours of the flexible cord of this appliance may

not correspond with the coloured markings identifying the

terminals in the plug, proceed as follows: The wire which

iscolouredbrown must be connected to the terminal which

is marked with the letter L or coloured red.

The wire which is coloured blue must be connected to the

terminal which is marked with the letter N or coloured

black.

LOAD

SUPPLY

LOAD

SUPPLY

DP 13A, 250V

BLUE

(NEUTRAL) BROWN

(LIVE)

FUSE ON

Technic Details

Dimensions (835 D):

HeightxWidthxDepht(incm) 84-117 x59,9x51.5

Dimensions (8359 D):

HeightxWidthxDepht(incm) 84-117 x89,9x51.5

Maximum absorbed power: 185W

Motor absorption: 1 x 160 W

Lighting: 2 x 9 W

Length of the cable: 100 cm

Fan powers (speed), speed in compliance with IEC 61591

Extractor version:

1 218 m3/h

2 337 m3/h

3 406 m3/h

i 527 m3/h

Filter version:

1 156 m3/h

2 240 m3/h

3 261 m3/h

i 308 m3/h

Flange: 150 mm Ø

Installation

Safety warnings for kitchen unit installer

●When used as an extractor unit, the hood must be fitted with

a 150mm diameter hose.

●If the fumes must be forced out through the wall, you must

obtain a MKZ sizable wall exhaust pipe (with external

exhaust and air intake), E-Nr.- 942 118 609 (Ø 150 mm)

which is one of our optional parts.

●When installing the hood, make sure you respect the

following minimum distance from the top edge of the

cooking hob/ring surfaces:

electric cookers 600 mm

gas cookers 650 mm

coal and oil cookers 700 mm min.

●The air outlet must not be connected to chimney flues or

combustion gas ducts. The air outlet must under no circum-

stances be connected to ventilation ducts for rooms in which

fuel-burning appliances are installed.

●It is advisable to apply for authorization from the relevant

controlling authority when connecting the outlet to an unused

chimney flue or combustion gas duct.

The air outlet installation must comply with the regulations

laid down by the relevant authorities.

●When the unit is used in its extractor version, a sufficiently

large ventilation hole must be provided, with dimensions that

are approximately the same as the outlet hole.

●National and regional building regulations impose a number

of restrictions on using hoods and fuel-burning appliances

connected to a chimney, such as coal or oil room-heaters

and gas fires, in the same room.

●The national decree on fuel-burning systems specifies a

maximum depression of 0.04 bar in such rooms.

●Hoods can only be used safely with appliances connected to

a chimney if the room and/or flat (air/environment combina-

tion) is ventilated from outside using a suitable ventilation

hole approximately 500-600 cm2 large to avoid the possibility

of a depression being created during operation of the hood.

If you have any doubts, contact the relevant controlling

authority or building inspector’s office.

●Since the rule for rooms with fuel burning appliances is

“outlet hole of the same size as the ventilation hole”, a hole

of 500-600 cm2, which is to say a larger hole, could reduce

the performance of the extractor hood.

●If the hood is used in its filtering function, it will operate

simply and safely in the above conditions without the need

for any of the aforementioned measures.

●When the hood is used in its extractor function, the following

rules must be followed to obtain optimal operation:

— short and straight outlet hose

— keep bends in outlet hose to a minimum

— never install the hoses with an acute angle, they must

always follow a gentle curve only

— keep the hose as large as possible (150 mm Ø min.).

●Failure to observe these basic rules will drastically reduce the

performance and increase the noise levels of the extractor

hood.

Installation - Fig. 3

●●

●Putthetemplateontothewall(1) anddrilltwoØ12mmholes(2).

●●

●Fittwohooks(3) onthedrilledholes.

●●

●Hangthehoodonthehooksandadjustthepositionofthehood

usingthetwoscrewsonthebottomofthehooks(5).

●●

●Removethemetalfilters(4) andmarktwopoints(6).Removethe

hoodanddrilltwoØ8mmholesonthemarkedpoints.

FittwoØ8mmwalldowels(7),Hangagainthehoodandfixthe

hooddefinitively withtwoscrews5X45 (8).

●●

●Fixthechimneysupport (10) with twoscrews5x45mm(9)and

twowalldowels (11) onthewallclosetotheceiling.

●●

●For exhaustingversion: Fittheconnectionring(S) onthetopof

the hood with two screws Ø 3,5 x 6,5 mm (12S) then fit an

exhausting pipe long enough to reach the outside (13S).

For recycling version: Fix definitively the deflector (13K)

on the top of the hood with two screws Ø 3,5 x 6,5 mm

(12K).

●●

●Prepare the electric connection (14) (see relative chapter).

●●

●Fitthechimney(15) andfixiton thechimneysupportwithtwo

screws3,0x9mm (16).

Thelowerpartofthechimneymustbeslideddownandinserted

onthehousingontheupperpartofthehood (18).

●●

●Fitthetwogrids(17) onbothsidesofthechimney.
