AEG Electrolux BS836600S Manuel utilisateur

BS836600N

BS836600S

EN User Manual

CONTENTS

1. SAFETY INFORMATION.................................................................................................3

2. SAFETY INSTRUCTIONS................................................................................................ 4

3. PRODUCT DESCRIPTION.............................................................................................. 6

4. CONTROL PANEL...........................................................................................................8

5. BEFORE FIRST USE.........................................................................................................9

6. QUICK GUIDE................................................................................................................10

7. DAILY USE......................................................................................................................11

8. ASSISTED COOKING................................................................................................... 20

9. USING THE ACCESSORIES..........................................................................................27

10. ADDITIONAL FUNCTIONS........................................................................................29

11. HINTS AND TIPS.........................................................................................................29

12. CARE AND CLEANING.............................................................................................. 56

13. TROUBLESHOOTING.................................................................................................58

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you impeccable

performance for many years, with innovative technologies that help make life simpler

features you might not find on ordinary appliances. Please spend a few minutes

reading to get the very best from it.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.aeg.com

www.registeraeg.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.aeg.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the following

data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

2 www.aeg.com

1. SAFETY INFORMATION

Before the installation and use of the appliance,

carefully read the supplied instructions. The

manufacturer is not responsible if an incorrect

installation and use causes injuries and damages. Always

keep the instructions with the appliance for future

reference.

1.1 Children and vulnerable people safety

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

•Do not let children play with the appliance.

•Keep all packaging away from children.

•Keep children and pets away from the appliance when

it operates or when it cools down. Accessible parts are

hot.

•If the appliance has a child safety device, we

recommend you activate it.

•Cleaning and user maintenance shall not be made by

children without supervision.

•Children of less than 3 years should be kept away

unless continuously supervised.

1.2 General Safety

•Only a qualified person must install this appliance and

replace the cable.

•Internally the appliance becomes hot when in

operation. Do not touch the heating elements that are

in the appliance. Always use oven gloves to remove or

put in accessories or ovenware.

•Before maintenance cut the power supply.

ENGLISH 3

•Ensure that the appliance is switched off before

replacing the lamp to avoid the possibility of electric

shock.

•Do not use a steam cleaner to clean the appliance.

•Do not use harsh abrasive cleaners or sharp metal

scrapers to clean the glass door since they can scratch

the surface, which may result in shattering of the glass.

•If the supply cord is damaged, it must be replaced by

the manufacturer, its Authorised Service Centre or

similarly qualified persons in order to avoid a hazard.

•To remove the shelf supports first pull the front of the

shelf support and then the rear end away from the

side walls. Install the shelf supports in the opposite

sequence.

•Only use the core temperature sensor recommended

for this appliance.

2. SAFETY INSTRUCTIONS

2.1 Installation

WARNING!

Only a qualified person must

install this appliance.

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Obey the installation instruction

supplied with the appliance.

• Always be careful when you move the

appliance because it is heavy. Always

wear safety gloves.

• Do not pull the appliance by the

handle.

• Keep the minimum distance from the

other appliances and units.

• Make sure that the appliance is

installed below and adjacent safe

structures.

• The sides of the appliance must stay

adjacent to appliances or to units with

the same height.

2.2 Electrical connection

WARNING!

Risk of fire and electrical

shock.

• All electrical connections should be

made by a qualified electrician.

• The appliance must be earthed.

• Make sure that the electrical

information on the rating plate agrees

with the power supply. If not contact

an electrician.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to

the mains plug and to the mains

cable. Should the mains cable need

to be replaced, this must be carried

out by our Authorised Service Centre.

• Do not let mains cables to come in

touch with the appliance door,

specially when the door is hot.

• The shock protection of live and

insulated parts must be fastened in

such a way that it cannot be removed

without tools.

www.aeg.com

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there is

access to the mains plug after the

installation.

• If the mains socket is loose, do not

connect the mains plug.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• Use only correct isolation devices: line

protecting cut-outs, fuses (screw type

fuses removed from the holder), earth

leakage trips and contactors.

• The electrical installation must have

an isolation device which lets you

disconnect the appliance from the

mains at all poles. The isolation

device must have a contact opening

width of minimum 3 mm.

• This appliance complies with the

E.E.C. Directives.

2.3 Use

WARNING!

Risk of injury, burns and

electrical shock or explosion.

• Use this appliance in a household

only.

• Do not change the specification of

this appliance.

• Make sure that the ventilation

openings are not blocked.

• Do not let the appliance stay

unattended during operation.

• Deactivate the appliance after each

use.

• Be careful when you open the

appliance door while the appliance is

in operation. Hot air can release.

• Do not operate the appliance with

wet hands or when it has contact with

water.

• Do not apply pressure on the open

door.

• Do not use the appliance as a work

surface or as a storage surface.

• Open the appliance door carefully.

The use of ingredients with alcohol

can cause a mixture of alcohol and air.

• Do not let sparks or open flames to

come in contact with the appliance

when you open the door.

• Do not put flammable products or

items that are wet with flammable

products in, near or on the appliance.

WARNING!

Risk of damage to the

appliance.

• To prevent damage or discoloration

to the enamel:

– do not put ovenware or other

objects in the appliance directly

on the bottom.

– do not put aluminium foil directly

on the bottom of the appliance.

– do not put water directly into the

hot appliance.

– do not keep moist dishes and

food in the appliance after you

finish the cooking.

– be careful when you remove or

install the accessories.

• Discoloration of the enamel has no

effect on the performance of the

appliance. It is not a defect in the

sense of the warranty law.

• Use a deep pan for moist cakes. Fruit

juices cause stains that can be

permanent.

• This appliance is for cooking

purposes only. It must not be used for

other purposes, for example room

heating.

• Always cook with the oven door

closed.

2.4 Steam Cooking

WARNING!

Risk of burns and damage to

the appliance.

• Do not open the appliance door

during steam cooking. Steam can

release.

2.5 Care and cleaning

WARNING!

Risk of injury, fire, or damage

to the appliance.

• Before maintenance, deactivate the

appliance and disconnect the mains

plug from the mains socket.

ENGLISH 5

• Make sure the appliance is cold.

There is the risk that the glass panels

can break.

• Replace immediately the door glass

panels when they are damaged.

Contact the Service.

• Be careful when you remove the door

from the appliance. The door is

heavy!

• Clean regularly the appliance to

prevent the deterioration of the

surface material.

• Remaining fat or food in the

appliance can cause fire.

• Clean the appliance with a moist soft

cloth. Only use neutral detergents. Do

not use abrasive products, abrasive

cleaning pads, solvents or metal

objects.

• If you use an oven spray, obey the

safety instructions on the packaging.

• Do not clean the catalytic enamel (if

applicable) with any kind of

detergent.

2.6 Internal light

• The type of light bulb or halogen

lamp used for this appliance is only

for household appliances. Do not use

it for house lighting.

WARNING!

Risk of electrical shock.

• Before replacing the lamp, disconnect

the appliance from the power supply.

• Only use lamps with the same

specifications.

2.7 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent

children and pets to get closed in the

appliance.

3. PRODUCT DESCRIPTION

3.1 General overview

1Control panel

2Electronic programmer

3Water drawer

4Socket for the core temperature

sensor

5Heating element

6Lamp

7Fan

8Steam generator with cover

9Shelf support, removable

10 Shelf positions

www.aeg.com

3.2 Accessories

Wire shelf

For cookware, cake tins, roasts.

Baking tray

For cakes and biscuits.

Grill- / Roasting pan

To bake and roast or as a pan to collect

fat.

Patisserie tray

For rolls, brezels and small pastries.

Suitable for steam functions. The

discolouration of the surface has no

effect on the functions.

Core temperature sensor

To measure how far the food is cooked.

Telescopic runners

For shelves and trays.

Steam set

One unperforated and one perforated

food container.

The steam set drains the condensing

water away from the food during steam

cooking. Use it to prepare food that

should not be in the water during the

cooking (e.g. vegetables, pieces of fish,

chicken breast). The set is not suitable for

food that needs to soak in the water (e.g.

rice, polenta, pasta).

Sponge

For absorbing the remaining water from

the steam generator.

ENGLISH 7

4. CONTROL PANEL

4.1 Electronic programmer

1 2 3 4 5

Use the sensor fields to operate the appliance.

Sensor

field

Function Comment

1ON / OFF To activate and deactivate the appliance.

2- Display It shows the current settings of the appliance.

3Favourite Pro-

gramme

It contains a list of favourite cooking programmes

made by the user.

4Minute Minder To set the function: Minute Minder.

5Assisted Cooking Straight access to the Cookbook and Quickstart

when the appliance is active.

The sensor fields for Favourite

Programme, Minute Minder

and Assisted Cooking are

visible only when the

appliance is active.

4.2 Display

After activating, the appliance shows a

basic heating function mode.

www.aeg.com8

11:09

150°

start

A B DC

A) Return to menu

B) Current set heating function

C) Current set temperature

D) Clock

E) Start

Other indicators of the display:

Symbol Function

Change of the text size

More options

Core temperature sensor

5. BEFORE FIRST USE

WARNING!

Refer to Safety chapters.

5.1 Initial Cleaning

Remove all accessories and removable

shelf supports from the appliance.

Refer to "Care and cleaning"

chapter.

1. Clean the appliance before first use.

2. Put the accessories and the

removable shelf supports back to

their initial position.

5.2 Software licence

The software included in this product

contains copyrighted software that is

licensed under the BSD, fontconfig, FTL,

GPL-2.0, LGPL-2.0, LGPL-2.1, libJpeg,

zLib/ libpng, MIT, OpenSSL / SSLEAY

and others.

It is possible to display the complete

copy of the licences in the device on the

TFT screen display by following through

the menu the path: Base Settings /

Service / Licence.

It is possible to download the source

code of the open source software used

in the product by following the hyperlink

present in the web product page.

5.3 First Connection

When you connect the appliance to the

mains you have to set:

• the language

• time

• clock format

• date

• fast heat-up

The chosen name or number can be set

in two ways. Scroll it to the required

position or touch the chosen option. You

can change the settings in the menu:

Base Settings.

ENGLISH 9

6. QUICK GUIDE

6.1 Using the touchscreen

• To scroll the menu use a quick

gesture or drag your finger across the

display.

• The strength of the gesture

determines how fast the screen

moves.

• The scroll movement can stop by

itself or you can stop it immediately if

you touch the display.

• The chosen function activates when

you release the finger from the

display.

• To activate a menu function touch the

display on the selected function.

• You can change any parameter shown

on the display when you touch it.

• To set the required function, time or

temperature you can scroll through

the list or touch the option you want

to choose.

• When you activate a heating function

the Menu does not appear on the

display. Touch the display anywhere

and the Menu appears again.

• When the appliance is active, and

some of the symbols disappear from

the display, touch the display

anywhere. All the symbols come back

on.

• After you set some functions a pop-

up window appears with additional

information.

• The temperature can switch places on

the display with other functions that

are in the bottom right and left

corner.

11:09

150°

20min33min start

6.2 Quick Guide to the menu

Functions Heating Functions

Specials

Cleaning

Favourites

Timers Set Minute Minder

Set Duration

Set End Time

Set Start Time

Elapsed Time

Options Lamp

Child Lock

Screen Lock

Assisted Cooking Cookbook

SousVide Cook-

book

Quickstart

SousVide Quickstart

Last and most used Last used

Most used

Base Settings Fast heat-up

Heat + Hold

Display

Sound

Language

Time and Date

Service

You can add a shortcut to the function,

which you often use. You can find the

added shortcuts in the main menu after

Last and most used.

www.aeg.com

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels AEG Electrolux Four

AEG Electrolux

AEG Electrolux E 59442-6 Manuel utilisateur

AEG Electrolux

AEG Electrolux D98000VF Manuel utilisateur

AEG Electrolux

AEG Electrolux E9871-5 Manuel utilisateur

AEG Electrolux

AEG Electrolux USER MANUAL BUILT-IN ELECTRIC OVEN B5701-5 Manuel utilisateur

AEG Electrolux

AEG Electrolux COMPETENCE E5731-4 Manuel utilisateur

AEG Electrolux

AEG Electrolux B4001-5 Manuel utilisateur

AEG Electrolux

AEG Electrolux E3191-5 Manuel utilisateur

AEG Electrolux

AEG Electrolux U88106 Manuel utilisateur

AEG Electrolux

AEG Electrolux COMPETENCE B3150-4 Manuel d'utilisation

AEG Electrolux

AEG Electrolux KB9820E Manuel utilisateur

AEG Electrolux

AEG Electrolux E43012-5 Manuel utilisateur

AEG Electrolux

AEG Electrolux COMPETENCE D4101-4 Manuel utilisateur

AEG Electrolux

AEG Electrolux COMPETENCE B4301-4 Manuel utilisateur

AEG Electrolux

AEG Electrolux COMPETENCE E2191-4 Manuel d'utilisation

AEG Electrolux

AEG Electrolux B1180-5 Manuel utilisateur

AEG Electrolux

AEG Electrolux E5731-7 Manuel utilisateur

AEG Electrolux

AEG Electrolux COMPETENCE E3741-4 Manuel utilisateur

AEG Electrolux

AEG Electrolux COMPETENCE D4101-5-ME Manuel utilisateur

AEG Electrolux

AEG Electrolux COMPETENCE KB9800E Manuel utilisateur

AEG Electrolux

AEG Electrolux E31540-6 Manuel utilisateur

AEG Electrolux

AEG Electrolux B3781-5 Manuel utilisateur

AEG Electrolux

AEG Electrolux Competence B4100-1-WSA Manuel utilisateur

AEG Electrolux

AEG Electrolux B3101-5 Manuel utilisateur

AEG Electrolux

AEG Electrolux B1100-5 Manuel utilisateur

Manuels Four populaires d'autres marques

Bosch

Bosch HVA531NS0 Manuel utilisateur

Electrolux

Electrolux EOF6P46X Manuel utilisateur

NEFF

NEFF B44S32 5GB Series Manuel utilisateur

Combi

Combi BLODGETT BC142GDS Manuel utilisateur

AEG

AEG COMPETENCE 311704300 Manuel utilisateur

Falcon

Falcon DOMINATOR PLUS G3106 Series Guide de l'utilisateur

Rational

Rational SCC WE 61G Manuel utilisateur

Smeg

Smeg DOSPA38X Manuel d'installation et d'exploitation

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manuel utilisateur

Miele

Miele HR 1954-2 Manuel utilisateur

KHIND

KHIND OT50 Manuel utilisateur

Henny Penny

Henny Penny Smoker Box Manuel utilisateur

Lang

Lang ECOD-AP Manuel utilisateur

AEG

AEG BEK455310M Manuel utilisateur

Frigidaire

Frigidaire FNGE90JGR Manuel utilisateur

Hotpoint

Hotpoint FE9 S831 JSH IX Manuel utilisateur

GE Advantium SCB2000 Manuel utilisateur

AEG

AEG DE401301DM Manuel utilisateur
