Advantech PCL-730 Manuel utilisateur
PCL-730
32-channel Isolated
Digital I/O Card
Copyright
This documentation is copyrighted 1996 by Advantech Co., Ltd. All
rights are reserved. Advantech Co., Ltd. reserves the right to make
improvements in the products described in this manual at any time
without notice.
No part of this manual may be reproduced, copied, translated or
transmitted in any form or by any means without the prior written
permission of Advantech Co., Ltd. Information provided in this
manual is intended to be accurate and reliable. However, Advantech
Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties which may result from its use.
Acknowledgments
PC-LabCard is a trademark of Advantech Co., Ltd. IBM and PC are
trademarks of International Business Machines Corporation. MS-
DOS, Microsoft C and Quick BASIC are trademarks of Microsoft
Corporation. BASIC is a trademark of Dartmouth College. Intel is a
trademark of Intel Corporation. TURBO C is a trademark of Borland
International.
CE notification
The PCL-730, developed by ADVANTECH CO., LTD., has passed
the CE test for environmental specifications when shielded cables are
used for external wiring. We recommend the use of shielded cables.
This kind of cable is available from Advantech. Please contact your
local supplier for ordering information.
Part No. 2003730001 5th Edition
Printed in Taiwan June 1998
Contents
Chapter 1 General Information ................................... 1
Introduction .....................................................................................2
Features............................................................................................2
Applications .....................................................................................2
Specifications ...................................................................................3
Digital input ...................................................................................3
Digital output .................................................................................3
Interrupt source ..............................................................................3
Register format ...............................................................................4
Dimensions .....................................................................................4
Connectors......................................................................................4
Powerconsumption ........................................................................4
Daughterboards...............................................................................5
Chapter 2 Installation ................................................... 7
InitialInspection..............................................................................8
SwitchandJumper Settings ...........................................................9
Base address selection (SW1) ......................................................10
Interrupt level (JP1)......................................................................11
Interrupt triggering (JP2)..............................................................11
Interrupt source (JP3)...................................................................12
Version control (JP4) ....................................................................12
HardwareInstallation...................................................................13
Chapter 3 Signal Connections .................................... 15
ConnectorPinAssignments..........................................................16
TTL-level I/O ................................................................................19
IsolatedInput ................................................................................20
IsolatedOutput .............................................................................20
Appendix A Register Format ........................................ 21
Appendix B PC I/O Port Address Map ........................... 23
Chapter 1 General Information 1
1
General Information
CHAPTER
2PCL-730 User's Manual
Introduction
The PCL-730 offers 32 isolated digital I/O channels (16 DI and 16
DO) and 32 TTL digital I/O channels (16 DI and 16 DO) on a PC add-
on card. Providing 1000 V isolation, each I/O channel corresponds to
a bit in a PC I/O port, making the PCL-730 very easy to program. The
PCL-730 offers one PC interrupt with jumper-selectable IRQ.
Features
• 32 isolated DIO channels (16 inputs and 16 outputs)
• 32 TTL-level DIO channels (16 inputs and 16 outputs)
• High output driving capacity
• High-voltage isolation on isolated I/O channels (1000 VDC)
• Interrupt capacity
• Two separate 20-pin connectors for isolated input channels and
output channels
• D-type connectors for isolated input channels and output channels
• High sink current on isolated output channels (200 mA/channel)
Applications
• Industrial ON/OFF control
• Contact closure monitoring
• Switch status sensing
• BCD interfacing
• Digital I/O control
• Industrial and lab automation
Chapter 1 General Information 3
Specifications
Digital input
16 optically-isolated inputs
• Input voltage: 5 to 24 VDC
• Input resistance: 1.2 KW@ 0.5 W
• Isolation voltage: 2,500 VDC
• Maximum speed: 10 KHz
16 TTL-level inputs
• Input voltage:
Low: 0.8 V max.
High: 2.0 V min.
• Input load:
Low: 0.4 mA max at 0.5 V
High: 0.05 mA max at 2.7 V
Digital output
16 optically-isolated outputs
• Output voltage: Open collector 5 to 40 VDC
• Sink current: 200 mA max.
• Isolation voltage: 1000 VDC
16 TTL-level outputs
• Output voltage:
Low: Sink 8 mA at 0.5 V max.
High: Source -0.4 mA at 2.4 V min.
Interrupt source
Jumper selectable:
Channels 0 and 1 of Isolated DI port or
Channels 0 and 1 of TTL DI port
4PCL-730 User's Manual
Register format
BASE+0 and BASE+1 Isolated DI/O
BASE+2 and BASE+3 TTL DI/O
Dimensions
185 mm x 100 mm
Connectors
DB-37 connector for isolated DIO
Two 20-pin flat-cable connectors for isolated DIO
Two 20-pin flat-cable connectors for TTL DIO
Power consumption
+5 V: 330 mA typical, 500 mA maximum
Chapter 1 General Information 5
Daughterboards
The PCL-730 interfaces with a wide variety of Advantech daughter-
boards, such as the following:
PCLD-786 AC/DC power SSR and relay driver board
This board holds eight optically-isolated solid state relay modules and
provides an additional eight outputs to drive external relays.
PCLD-785B and PCLD-885 relay output boards
These boards let you control relays through the PCL-730's 16-bit TTL
digital output channels. PCLD-785B provides 24 SPDT relays, while
the PCLD-885 provides 16 SPST power relays.
PCLD-782B Isolated D/I Board
This board provides 24 optically-isolated digital input channels and a
cable to connect to the PCL-730's digital input ports.
PCLD-885
The PCLD-885 provides 16 SPST power relay channels with a
maximum contact rating of AC: 250 V, 5 A or DC: 20 V, 5 A. The
PCLD-885 can be driven directly by the digital outputs of PC-
LabCards through 20-pin flat-cable connectors or 50-pin OPTO-22
compatible connectors.
PCLD-780
This wiring terminal board makes analog or digital I/O connections
easy.
PCLD-880
The PCLD-880 is a universal screw terminal board for industrial
wiring. It can be used with the analog or digital ports of various PC-
LabCards via 20-pin flat cables or shielded round cables with DB-37
connectors.
6PCL-730 User's Manual
