Advantech LR77 v2 Libratum Manuel utilisateur

LTE Industrial Router

LR77 v2

USER MANUAL

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

LR77 v2

Advantech B+B SmartWorx – Americas

Advantech B+B SmartWorx

707 Dayton Road

Ottawa, IL 61350 USA

Website

www.advantech-bb.com

Advantech B+B SmartWorx – Europe

Advantech B+B SmartWorx s.r.o.

Sokolska 71

562 04, Usti nad Orlici,

Czech Republic

Website

www.advantech-bb.com

2019 Advantech B+B SmartWorx s.r.o. No part of this publication may be reproduced or transmitted in any

form or by any means, electronic or mechanical, including photography, recording, or any information storage and

retrieval system without written consent. Information in this manual is subject to change without notice, and does

not represent a commitment on the part of Advantech B+B SmartWorx.

Advantech B+B SmartWorx s.r.o. shall not be liable for incidental or consequential damages resulting from

the furnishing, performance, or use of this manual.

All brand names used in this manual are the registered trademarks of their respective owners. The use of

trademarks or other designations in this publication is for reference purposes only and does not constitute an

endorsement by the trademark holder.

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

LR77 v2

Used symbols

Danger – Information regarding user safety or potential damage to the router.

Attention – Problems that can arise in speciﬁc situations.

Information, notice – Useful tips or information of special interest.

GPL licence

Source codes under GPL licence are available free of charge by sending an email to:

[email protected].

Please see http://ep.advantech-bb.cz/devzone for more information.

Advantech B+B SmartWorx s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic

Document No. MAN-0014-EN, revision from April 4, 2019. Released in the Czech Republic.

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

LR77 v2

Contents

1 Safety Instructions 2

2 WEEE directive 3

3 Router Description 4

4 Contents of Package 5

5 Router Design 6

5.1 Router versions .................................... 6

5.2 Delivery identiﬁcation ................................ 7

5.3 Order codes ...................................... 8

5.3.1 Order code structure ............................. 8

5.3.2 Order code examples ............................ 10

5.4 Basic dimensions of the router box ......................... 11

5.4.1 Plastic box .................................. 11

5.4.2 Metal box ................................... 11

5.5 Mounting recommendations ............................. 12

5.6 Removal from the DIN rail .............................. 14

5.7 Description of the front panel ............................ 15

5.7.1 Status indication ............................... 16

5.7.2 Power connector PWR ............................ 17

5.7.3 Antenna connector ANT, DIV and GPS (alternatively WIFI or WMBUS) . 18

5.7.4 SIM card reader ............................... 19

5.7.5 Ethernet Port ETH .............................. 20

5.7.6 PORT1 .................................... 21

5.7.7 PORT2 .................................... 21

5.7.8 USB Port ................................... 22

5.7.9 I/O Port .................................... 23

5.7.10 Reset ..................................... 25

6 First Use 26

6.1 Connecting the router before ﬁrst use ....................... 26

6.2 Start .......................................... 27

6.3 Conﬁguration ..................................... 27

6.3.1 Conﬁguration over web browser ....................... 27

6.3.2 Conﬁguration over Telnet .......................... 28

7 Technical Parameters 29

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

LR77 v2

7.1 Basic parameters ................................... 29

7.2 Standards and regulations .............................. 30

7.2.1 Versions LR77 v2B and LR77 v2F ..................... 30

7.2.2 Versions LR77 v2BG and LR77 v2FG ................... 30

7.2.3 Versions LR77 v2B L45 ........................... 30

7.3 Technical parameters of module .......................... 32

7.3.1 Versions LR77 v2B and LR77 v2F ..................... 32

7.3.2 Versions LR77 v2BG and LR77 v2FG ................... 33

7.3.3 LTE module supports 450 MHz ....................... 33

7.4 Technical parameters of GPS ............................ 34

7.5 Other Technical Parameters ............................. 35

7.6 Technical parameters of I/O port .......................... 35

7.7 Technical parameters of expansion port ...................... 35

8 Recommended Literature 36

9 Troubleshooting 37

9.1 FAQ .......................................... 37

10 Customers Support 40

10.1 Customer Support for NAM ............................. 40

10.2 Customer Support for Europe ............................ 40

10.3 Customer Support for Asia ............................. 40

iii

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

LR77 v2

List of Figures

1 Contents of package ................................. 5

2 Front panel LR77 v2B(G) .............................. 6

3 Front panel LR77 v2F(G) .............................. 6

4 Front panel LR77 v2B L45 .............................. 6

5 Front panel LR77 v2B(G) SL ............................ 6

6 Front panel LR77 v2F(G) SL ............................ 6

7 Front panel LR77 v2B L45 SL ............................ 6

8 Label examples .................................... 7

9 Basic dimensions of plastic box (bottom and front view) ............. 11

10 Basic dimensions of metal box (bottom and front view) .............. 11

11 Space around antennas (plastic) .......................... 12

12 Space around antennas (metal) ........................... 12

13 Cable routing (plastic) ................................ 13

14 Cable routing (metal) ................................. 13

15 Space in front of connectors (plastic) ........................ 13

16 Space in front of connectors (metal) ........................ 13

17 Default position of plastic and metal DIN rail clip ................. 14

18 Removal from the DIN rail .............................. 14

19 Front panel LR77 v2F(G) .............................. 15

20 Power connector ................................... 17

21 Connection of power supply ............................. 17

22 Connecting of the antenna .............................. 18

23 Ejected SIM holder .................................. 19

24 Ethernet connector .................................. 20

25 Connection of ethernet cable ............................ 20

26 PORT1 cable connection .............................. 21

27 PORT2 cable connection .............................. 22

28 USB connector .................................... 22

29 I/O connector ..................................... 23

30 Connection of I/O cable ............................... 23

31 Connection of input and output to the router .................... 24

32 Router reset ...................................... 25

33 Router connection .................................. 26

34 Entering the IP address of the router ........................ 27

35 Entering login information .............................. 27

36 Router web interface ................................. 28

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

LR77 v2

List of Tables

1 Router versions .................................... 6

2 Delivery identiﬁcation ................................ 7

3 Type of port #1 .................................... 8

4 Type of port #2 .................................... 9

5 Type of router box .................................. 9

6 Type of power supply ................................. 9

7 Speciﬁc variation ................................... 10

8 Order code examples ................................ 10

9 Front panel description ................................ 15

10 Status indication ................................... 16

11 Connection of power connector ........................... 17

12 Connection of Ethernet connector .......................... 20

13 Connection of USB connector ............................ 22

14 Connection of I/O port ................................ 23

15 Description of reset and restart router ....................... 25

16 Basic parameters ................................... 29

17 Versions LR77 v2B and LR77 v2F ......................... 30

18 Versions LR77 v2BG and LR77 v2FG ....................... 30

19 Versions LR77 v2B L45 ............................... 31

20 Versions LR77 v2B and LR77 v2F ......................... 32

21 Versions LR77 v2BG and LR77 v2FG ....................... 33

22 Technical parameters of LTE module 450 MHz .................. 33

23 Technical parameters of GPS ............................ 34

24 Other technical parameters ............................. 35

25 Technical parameters of I/O port .......................... 35

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

LR77 v2

1. Safety Instructions

Please, observe the following instructions:

•The router must be used in compliance with all applicable international and national laws

and in compliance with any special restrictions regulating the utilization of the router in

prescribed applications and environments.

•To prevent possible injury and damage to appliances and to ensure compliance with

all relevant provisions, use only the original accessories. Unauthorized modiﬁcations or

the use of unapproved accessories may result in damage to the router and / or a breach

of applicable regulations. Unauthorized modiﬁcations or use of unapproved accessories

may void the warranty.

•The router can not be opened.

•Turn off the router and disconnect it from power supply before handling the SIM card.

•Caution! The SIM card could be swallowed by small children.

•Input voltage must not exceed 36 V DC max.

•Do not expose the router to extreme ambient conditions. Protect the router against dust,

moisture and high temperature.

•Only routers with appropriate certiﬁcation and labelling should be used in locations where

ﬂammable and explosive materials are present, including gas stations, chemical plants,

or locations in which explosives are used. We remind users of the duty to observe the

restrictions concerning the utilization of radio devices at such places.

•Switch off the router when traveling by plane. Utilization of the router on a plane may

endanger the operation of the plane or interfere with the mobile telephone network, and

may be unlawful. Failure to observe these instructions may result in the suspension or

cancellation of telephone services for the respective client and / or may result in legal

sanctions.

•When using the router in close proximity to personal medical devices, such as cardiac

pacemakers or hearing aids, you must proceed with heightened caution.

•The router may cause interference when used in close proximity to TV sets, radio re-

ceivers or personal computers.

•It is recommended that you create an appropriate copy or backup of all important settings

that are stored in the memory of the device.

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

LR77 v2

2. Product Disposal Instructions

The WEEE (Waste Electrical and Electronic Equipment: 2012/19/EU) directive was in-

troduced to ensure that electrical/electronic products are recycled using the best available

recovery techniques in order to minimize impact on the environment. This product contains

high quality materials and components which can be recycled. At the end of it’s life this pro-

duct MUST NOT be mixed with other commercial waste for disposal. The device contains the

battery. Remove the battery from the device before disposal. The battery in the device needs

to be disposed apart accordingly. Check the terms and conditions of your supplier for disposal

information.

04-09-19

LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: [email protected] — www.lucom.de

www.lucom.de

LR77 v2

3. Router Description

LTE router LR77 v is used to wirelessly connect various equipments and devices via Eth-

ernet interface 10/100 to the Internet or Intranet. Thanks to high data transfer speed of up to

100 Mbps (download) and upload speed up to 50 Mbps it is an ideal wireless solution for trafﬁc

and security camera systems, individual computers, LAN networks, automatic teller machines

(ATM) and other self-service terminals, etc. Routers LR77 v2B L45 are intended for use in

the 450 MHz band whose main advantage is the long range. The lower frequency, the less

transmitters are needed for covering.

As a standard, this LTE cellular router is equipped with one Ethernet 10/100, one USB

Host port, one binary Input/output (I/O) port and one SIM card. To save and backup commu-

nication data a version with two SIM cards is available. The wide range of interface options

of the router further expands Port1 and Port2 expansion ports, which are selected by the cus-

tomer. For Port1 are available: Ethernet port 10/100, serial interface ports RS232, RS485,

RS422, MBUS or inputs/outputs (I/O – CNT). Port2 may be equipped with serial interfaces

RS232, RS485, RS422, MBUS, wireless interfaces WIFI or WMBUS, SDH expansion port or

inputs/outputs (I/O – CNT). Both of ports can be ﬁtted with internal switch (exp. port SWITCH).

This wireless router is supplied either in a plastic or metal casing, based on the requirements

of the customer.

Conﬁguration is done via web interface protected by password. The router supports cre-

ation of VPN tunnels using technologies IPsec, OpenVPN and L2TP to ensure safe commu-

nication. Web interface provides detail statistics about the router activities, signal strength,

detailed log, etc. Cellular router supports functions: DHCP, NAT, NAT-T, DynDNS, NTP, VRRP,

control by SMS and many other function.

Other diagnostic functions ensuring continuous communication include automatic inspec-

tion of PPP connection offering an automatic restart feature – in case of connection losses,

or hardware watchdog which monitors the status of the router. With the help of a special

window (start up script window) you may insert Linux scripts for various actions. For some ap-

plications the key option to create several different conﬁgurations for one LTE wireless router,

the so-called proﬁles (maximum of 4), and the option to switch between them (for example

via SMS, binary input status, etc.) is essential. Cellular routers LR77 v2 may automatically

upgrade conﬁguration and ﬁrmware from server. This allows mass reconﬁguration of many

routers in one time.

The router also supports additional software like R-SeeNet for permanent trafﬁc monitoring

of routers or communication VPN server Digicluster.

Examples of possible applications

•mobile ofﬁce

•ﬂeet management

•security system

•telematic

•telemetric

•remote monitoring

•vending and dispatcher machines
