Advantech MIC-3359 Manuel utilisateur

C-

-3

USER’

’

’S

Manual

Advantech CompactPCI®

Modular Industrial Compute

MIC-3359

6U CompactPCI® Intel®

Desktop Pentium® 4

Mobile Pentium® 4-M

Processor Board with VGA

on Board

MIC-3359 User Manual --- Page I

This document is copyrighted, 2005. All rights are reserved. The original

manufacturer reserves the right to make improvements to the products described in

this manual at any time without notice. No part of this manual may be reproduced,

copied, translated or transmitted in any form or by any means without the prior

written permission of the original manufacturer. Information provided in this manual

is intended to be accurate and reliable. However, the original manufacturer assumes

no responsibility for its use, nor for any infringements upon the rights of third parties

which may result from its use.

Acknowledgements

PICMG™, CompactPCI®and the PICMG™, CompactPCI®logos are trademarks of the

PCI Industrial Computers Manufacturers Group. All other product names or

trademarks are properties of their respective owners.

CE Notification

The MIC-3359, developed by Advantech Co., Ltd., has passed the CE test for

environment specifications when shielded cables are used for external wiring. We

recommend the use of shielded cables.

FCC

This device complies with the requirements in part 15 of the FCC rule: Operation is

subject to be following two conditions：

(1) This device may not cause harmful interference.

(2) This device must accept any interference received, including interference that may

cause undesired operation.

CAUTION!!

Danger of explosion if battery in correctly replaced. The battery need not to be

charged. Replace only with Advantech-specified batteries.

MIC-3359 User Manual --- Page II

Product warranty

Advantech warrants to you, the original purchaser, that each of its products will be

free from defects in materials and workmanship for one year from the date of

purchase.

This warranty does not apply to any products which have been repaired or altered by

persons other than repair personnel authorized by Advantech, or which have been

subject to misuse, abuse, accident or improper installation. Advantech assumes no

liability under the terms of this warranty as a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous testing, most of

our customers never need to use our repair service. If an Advantech product is

defective, it will be repaired or replaced at no charge during the warranty period. For

out-of-warranty repairs, you will be billed according to the cost of replacement

materials, service time and freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1、Collect all the information about the problem encountered. For example, CPU

speed, Advantech products used, other hardware and software used, etc. Note

anything abnormal and list any on-screen messages you get when the problem

occurs.

2、Call your dealer and describe the problem. Please have your manual, product,

and any helpful information readily available.

3、If your product is diagnosed as defective, obtain an RMA (return merchandise

authorization) number from your dealer. This allows us to process your return

more quickly.

4、Carefully pack the defective product, a fully-completed Repair and Replacement

Order Board and a photocopy proof of purchase date (such as your sales receipt)

in a shippable container. A product returned without proof of the purchase date

is not eligible for warranty service.

5、Write the RMA number visibly on the outside of the package and ship it prepaid

to your dealer.

MIC-3359 User Manual --- Page III

Packing List

Before installation, ensure that the following materials have been received:

• 1 MIC-3359 all-in-one single board computer

• 1 Utility and user manual (PDF file) CD-ROM disc

• 1 CPU Heat sink (Assembled)

• 1 Thermal pad for Pentium 4-M CPU

• 1 Solder-side cover (Assembled)

• Several screws

• 1 warranty certificate document

If any of these items are missing or damaged, contact your distributor or sales

representative immediately.

Technical Support and Sales Assistance

If you have any technical questions about the MIC-3359 or any other Advantech

products, please visit our support website at:

! http://www.advantech.com.tw/support

For more information about Advantech's products and sales information, please visit:

! http://www.advantech.com

Contents

Contents................................................................................ IV

Tables ................................................................................... VI

Figures .................................................................................VII

1. Hardware Configuration ......................................................2

1.1 Introduction ..................................................................... 2

Single P2P Bridge....................................................................3

1.2 Specifications ................................................................... 4

1.3 Jumpers and Switches ....................................................... 7

1.3.1 Jumper Setting ............................................................ 7

1.3.2 Clear CMOS (JP4)......................................................... 9

1.3.3 Switch Setting ............................................................10

1.4 Connector Setting ............................................................12

1.5 Safety Precautions ...........................................................12

1.6 Installing the CPU and Heatsink..........................................13

1.7 Software Support .............................................................14

2. AWARD BIOS Setup ........................................................... 16

2.1 Entering Setup.................................................................16

2.1.1 Standard CMOS Setup .................................................17

2.1.2 Advanced BIOS Features Setup .....................................17

2.1.3 Advanced Chipset Features Setup..................................21

2.1.4 Integrated Peripherals .................................................24

MIC-3359 User Manual --- Page IV

2.1.5 Power Management Setup ............................................27

2.1.6 PNP/PCI Configuration Setup ........................................27

2.1.7 PC Health Status.........................................................29

2.1.8 Load Optimized Defaults ..............................................30

2.1.9 Set Password..............................................................30

2.1.10 Save and Exit Setup ..................................................30

2.1.11 Exit Without Saving ...................................................30

Appendix A Pin Assignments ...............................................32

A.1 J1 Connector ...................................................................32

A.2 J2 Connector ...................................................................33

A.3 J3 Connector ...................................................................34

A.4 J5 Connector ...................................................................35

A.5~A.7 On board jumpers and connectors ...............................36

A.8~A11 On board jumpers and connectors ..............................34

A.12~A16 On board jumper and connectors ..............................35

MIC-3359 User Manual --- Page V

Tables

Table 1-1 MIC-3359 jumper descriptions..................................... 7

Table 1-2 MIC-3359 switch descriptions...................................... 7

Table 1-3 JP2 jumper definition ................................................. 7

Table 1-4 JP3 jumper definition ................................................. 8

Table 1-5 JP5 jumper definition ................................................. 8

Table 1-6 JP7 jumper definition ................................................. 8

Table 1-7 JP8 jumper definition ................................................. 9

Table 1-8 JP4 definition ............................................................ 9

Table 1-9 SW1 & SW3 definition ...............................................10

Table 1-10 SW2 definition........................................................10

Table 1-11 MIC-3359 connector descriptions ..............................12

Table A . 1 J1 connector ...........................................................32

Table A . 2 J2 connector ...........................................................33

Table A . 3 J3 connector ...........................................................34

Table A . 4 J5 connector ...........................................................35

Tables A. 5 ~ A. 7 On board jumpers and connectors ..................36

Tables A. 8 ~ A.11 On board jumpers and connectors .................37

Tables A.12 ~ A.16 On board jumpers and connectors.................38

MIC-3359 User Manual --- Page VI

Figures

Figure 1-1 MIC-3359 functional block diagram............................. 6

Figure 1-2 MIC-3359 jumper, switch and connector locations........11

Figure 1-3 Complete assembly CPU and heatsink........................14

Figure 2-1 Setup program initial screen.....................................16

Figure 2-2 Standard CMOS setup screen....................................17

Figure 2-3 Advanced BIOS features setup screen........................18

Figure 2-4 Advanced Chipset features setup screen.....................21

Figure 2-5 Integrated Peripherals setup screen...........................24

Figure 2-6 Power management setup screen ..............................27

Figure 2-7 PNP/PCI configuration screen....................................28

Figure 2-8 PC Health setup screen ............................................29

MIC-3359 User Manual --- Page VII

MIC-3359 User Manual --- Page 1

Chapter

Hardware Configuration

1. Hardware Configuration

1.1 Introduction

The MIC-3359 is a 6U 8HP CompactPCI®SBC ideal for mission critical, demanding

industrial or military applications which require high performance as well as

endurance in harsh operating environments.

The MIC-3359 CompactPCI®CPU board is optimized for Intel®845GV chipset. It

supports both the Intel Desktop Celeron®and Pentium®4 processor up to 2.8 GHz,

and the mobile Pentium® 4 -M processor. The VGA is integrated in the Intel®845GV

chipset, and there are two DDR DIMM slots which can support system memory up to

2GB. The MIC-3359 uses the Intel 82562ET for 10/100 Mb Fast Ethernet, with an

option for the Intel®82551ER for 10/100 Mb Fast Ethernet which is pin-to-pin

compatible with the Intel®82540EM for Giga Ethernet. The Pericom PI7C8150MA MHz

PCI-to-PCI Bridge is designed for bus expansions, programmable data transfer rate

control, and frequency conversions.

To achieve the most cost effective combination for entry-level CT applications or entry

to mid-level industrial applications, you can use a MIC-3041L enclosure with a

MIC-3359 6U CPCI board and Intel Pentium IV processor without a rear I/O transition

board. This gives the best performance-price balance and produces the most

cost-effective solution.

High Performance Intel®Pentium®4 Processor-M, Intel®Desktop Pentium®

4 Processor, and Celeron® Processor

The MIC-3359 supports the Intel®Pentium® 4 processor-M 1.7 GHz and 2.2 GHz, the

Desktop Pentium®4 Processor, and the Celeron® Processor with either u-FCPGA

package or u-FCBGA package. Both Intel®Pentium® processor-M and Intel®Pentium®

processor have on-chip 512 KB L2 cache providing high performance. The Intel®

Celeron® processor has an on-chip 256KB L2 cache providing high performance. With

the support of a 400 MHz and 533 MHz front-side bus, the MIC-3359 can fulfill

customer’s expectations of price-performance computing capability.

MIC-3359 User Manual --- Page 2

Table des matières

Autres manuels Advantech Carte mère

Advantech

Advantech PCA-6751 Series Manuel d'installation et d'exploitation

Advantech

Advantech Mini-ITX AIMB-250 Series Manuel utilisateur

Advantech

Advantech PCM-9579 Manuel d'installation et d'exploitation

Advantech

Advantech ACP-2010 Manuel utilisateur

Advantech

Advantech AIMB-705 Manuel d'installation et d'exploitation

Advantech

Advantech PCM-9374 Manuel d'installation et d'exploitation

Advantech

Advantech AIMB-706 Manuel utilisateur

Advantech

Advantech AIMB-214 Manuel utilisateur

Advantech

Advantech PCM-5824 Manuel d'installation et d'exploitation

Advantech

Advantech PCM-4386 Manuel utilisateur

Advantech

Advantech AIMB-218 Series Manuel d'installation et d'exploitation

Advantech

Advantech HPC-2820-ISSE Manuel utilisateur

Advantech

Advantech AIMB-213 Manuel d'installation et d'exploitation

Advantech

Advantech PCM-9590 Manuel utilisateur

Advantech

Advantech ASMB-585 Manuel utilisateur

Advantech

Advantech AIMB-766 Manuel utilisateur

Advantech

Advantech ASMB-782 Manuel d'installation et d'exploitation

Advantech

Advantech AIMB-223G2-S2A2E Manuel utilisateur

Advantech

Advantech SOM-DB2500 Manuel utilisateur

Advantech

Advantech SIMB-982 Manuel utilisateur

Advantech

Advantech ASMB-913I Manuel d'installation et d'exploitation

Advantech

Advantech MIC-3369C Manuel utilisateur

Advantech

Advantech PCI-7030 Manuel d'installation et d'exploitation

Advantech

Advantech MIO-2262 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
