Advantech PCIe-1674 Manuel utilisateur

User Manual

4-port GbE, PCIe Card

Industrial GbE Network Card

GbE Port PCIe Card User Manual

The documentation and the software included with this product are copyrighted 2015

by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves theright

to make improvements in the products described in this manual at any time without

notice. No part of this manual may be reproduced, copied, translated or transmitted

in any form or by any means without the prior written permission of Advantech Co.,

Ltd. Information provided in this manual is intended to be accurate and reliable. How-

ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-

ments of the rights of third parties, which may result from itsuse.

Acknowledgements

Award is a trademark of Award Software International, Inc.

VIA is a trademark of VIA Technologies, Inc.

IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines Cor-

poration.

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows® is a registered trademark of Microsoft Corp.

RTL is a trademark of Realtek Semi-Conductor Co., Ltd.

ESS is a trademark of ESS Technology, Inc.

UMC is a trademark of United Microelectronics Corporation.

SMI is a trademark of Silicon Motion, Inc.

Creative is a trademark of Creative Technology LTD.

All other product names or trademarks are properties of their respective owners.

Part No. Edition 1

Printed in China December 2017

iii

GbE Port PCIe Card User

Manual

Product Warranty (5 years)

Advantech warrants to you, the original purchaser, that each of its products will be

free from defects in materials and workmanship for two years from the date of pur-

chase.

This warranty does not apply to any products which have been repaired or alteredby

persons other than repair personnel authorized by Advantech, or which have been

subject to misuse, abuse, accident or improper installation. Advantech assumes no

liability under the terms of this warranty as a consequence of suchevents.

Because of Advantech’s high quality-control standards and rigorous testing, most of

our customers never need to use our repair service. If an Advantech product is defec-

tive, it will be repaired or replaced at no charge during the warranty period. For out-

of-warranty repairs, you will be billed according to the cost of replacement materials,

service time and freight. Please consult your dealer for moredetails.

If you think you have a defective product, follow these steps:

Collect all the information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note

anything abnormal and list any onscreen messages you get when the problem

occurs.

Call your dealer and describe the problem. Please have your manual, product,

and any helpful information readily available.

If your product is diagnosed as defective, obtain an RMA (return merchandize

authorization) number from your dealer. This allows us to process your return

more quickly.

Carefully pack the defective product, a fully-completed Repair and Replacement

Order Card and a photocopy proof of purchase date (such as your sales receipt)

in a shippable container. A product returned without proof of the purchase date

is not eligible for warranty service.

Write the RMA number visibly on the outside of the package and ship it prepaid

to yourdealer.

Declaration of Conformity

This product has passed the CE test for environmental specifications when shielded

cables are used for external wiring. We recommend the use of shielded cables. This

kind of cable is available from Advantech. Please contact your local supplier for

ordering information.

FCC Class A

Note: This equipment has been tested and found to comply with the limits for a Class

A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications.Opera-

tion of this equipment in a residential area is likely to cause harmful interference in

which case the user will be required to correct the interference at his ownexpense.

PCIe-GbE_PoE User Manual

Safety Precaution - Static Electricity

Follow these simple precautions to protect yourself from harm and the products from

damage.



Toavoid electrical shock, always disconnect the power from your PC chassis

before you work on it. Don't touch any components on the CPU card or other

cards while the PC is on.



Disconnect power before making any configuration changes. The sudden rush

of power as you connect a jumper or install a card may damage sensitive elec-

tronic components.

Technical Support and Assistance

Visit the Advantech web site at www.advantech.com/support where you can find

the latest information about the product.

Contact your distributor, sales representative, or Advantech's customer service

center for technical support if you need additional assistance. Please have the

following information ready before you call:

–

Product name and serial number

–

Description of your peripheralattachments

–

Description of your software (operating system, version, application software,

etc.)

–

A complete description of the problem

–

The exact wording of any error messages

Document Feedback

To assist us in making improvements to this manual, we would welcome comments

and constructive criticism. Please send all such - in writing to: support@advan-

tech.com

PCIe-GbE_PoE User Manual

Chapter 1 Introduction.........................................1

1.1

Description................................................................................................. 2

1.2

Features .................................................................................................... 2

1.3

Specifications ............................................................................................ 3

1.4

Ordering Information.................................................................................. 3

1.5

Unpacking Checklist.................................................................................. 3

Chapter 2 Hardware Configuration .....................5

2.1

Initial Inspection......................................................................................... 6

2.2

Hardware View .......................................................................................... 7

Figure 2.1 PCIe-1674 Board Layout............................................ 7

2.3

Card Installation......................................................................................... 8

Chapter 3 Driver Setup and Installation..............9

3.1

Introduction.............................................................................................. 10

3.2

Driver Setup............................................................................................. 10

3.2.1

Steps for Windows XP/Vista/7 Driver Setup............................... 10

3.3

Configuring Devices for Win XP/Vista/7.................................................. 10

3.3.1

Jumbo Frame.............................................................................. 11

3.3.2

Receive Buffer............................................................................. 13

3.3.3

Transmit Buffers.......................................................................... 14

3.4

Remove PCI Express GbE Device and Driver ........................................ 15

PCIe-GbE_PoE User Manual

Chapter 1

Introduction

This chapter provides detailed

specifications for the PCI

Express GbE cards.

Sections include:

Description

Features

Specifications

Ordering Information

Selection Guide

GbE Port PCIe Card User Manual

1.1 Description

Advantech PCIe-1672/PCIe-1674 is a PCI Express by 2 or 4 lane and jumbo frame

support for independent Gigabit Ethernet ports. Advantech GbE card levrages the

"Plug and Play" capability defined in the PCI Express bus specification. The board

requires one PCI Express by 2 or 4 slot within the personal computer and provides

independent Gigabit Ethernet Ports via Intel i350 series Gigabit Ethernet controllers.

Multiple Gigabit Ethernet Vision device connections are supported for standard

Gigabit Ethernet Vision data transfer rates of up to 1000Mb per second.

PCIe-1672 and PCIe-1674 feature jumbo frame package, power isolation and IEEE

1588(precise time protocol) to enable synchronization with multi-camera or PD

acquisition.

Each port of PCIe-1672 and PCIe-1674 can provide 1000 Mb/s bandwidth over a

CAT-5/CAT-6/CAT-7 cable of up to 100 meters. It features 9 kB jumbo frame and link

aggregation, which conduct excep- tional performance for continuously receiving

large amount of imagedata.

1.2 Features



Support for four independent GbE ports



Built-in ESD 8KV and EFT 2KV



IEEE 1588 compliant



PCI Express x4 compliant



Support for Link aggregation



Support for jumbo frames (9014 Bytes)



Inrush current, current limit, and short-circuitprotection

1.3 Specifications



Ethernet Port

–

2 or 4 Gigabit Ethernet Media Access Control (MAC) and physicallayer

(PHY) ports.

–

Standard IEEE 802.3 Ethernet interface provided for 1000BASE-T,

100BASE-TX, and 10BASE-T applications (802.3, 802.3u, and 802.3ab,

802.3x)

–

9014 bytes jumbo frame support



Bus Interface

–

PCIe x4



Power Requirements

–

Input voltage: 12 VDC direct from PCIe slot.



ESD/EFT

–

8KV ESD and 2KV EFT



Physical

–

Dimensions (W x D): 174 x 106.65 mm

–

Operating Temperature: 0°C to 50°C

–

Safety Compliance: CE/FCC

1.4 Ordering Information



PCIe-1672L-AE: 2-port PCI Express Gigabit Card



PCIe-1674L-AE: 4-port PCI Express Gigabit Card

1.5 Unpacking Checklist

Ensure that the following items are included in the package.



PCIe-1672L or PCIe-1674L unit

3 GbE Port PCIe Card User Manual

Chapter

Introduction

GbE Port PCIe Card User

Manual
