M-855

Industrial

Motherboard

User’s Manual

Recycled Paper

60070024IHA00

Manual Rev. 1.00: August 16, 2004

The information in this document is subject to change without prior notice in order

to improve reliability, design, and function and does not represent a commitment

on the part of the manufacturer.

In no event will the manufacturer be liable for direct, indirect, special, incidental, or

consequential damages arising out of the use or inability to use the product or

documentation, even if advised of the possibility of such damages.

This document contains proprietary information protected by copyright. All rights

are reserved. No part of this manual may be reproduced by any mechanical,

electronic, or other means in any form without prior written permission of the

manufacturer.

Trademarks

NuDAQ®, NuIPC®, NuDAM®, NuPRO®are registered trademarks of ADLINK

Technology Inc. Other product names mentioned herein are used for identification

purposes only and may be trademarks and/or registered trademarks of their

respective companies.

Getting Service from ADLINK

Customer Satisfaction is top priority for ADLINK Technology Inc. If you need any

help or service, please contact us.

ADLINK TECHNOLOGY INC.

Web Site http://www.adlinktech.com

Sales & Service [email protected]

TEL +886-2-82265877 FAX +886-2-82265717

Address 9F, No. 166, Jian Yi Road, Chungho City, Taipei, 235 Taiwan

Please email or FAX your detailed information for prompt, satisfactory, and

consistent service.

Detailed Company Information

Company/Organization

Contact Person

E-mail Address

Address

Country

TEL FAX

Web Site

Questions

Product Model

Environment

OS:

Computer Brand:

M/B: CPU:

Chipset: BIOS:

Video Card:

NIC:

Other:

Detail Description

Suggestions for ADLINK

Table of Contents •i

Table of Contents

Chapter 1 Introduction.................................................................................1

1.1 Unpacking Checklist.................................................................2

1.2 Features .....................................................................................3

1.3 System Block Diagram.............................................................5

1.4 Specifications.............................................................................6

Chapter 2 Installation ..................................................................................9

2.1 System Installation....................................................................9

2.2 Board Layout ...........................................................................13

2.3 Jumper Settings ......................................................................14

2.4 Connector Descriptions..........................................................16

Chapter 3 Award BIOS Setup.................................................................33

3.1 BIOS Instructions...................................................................33

3.2 Main Menu ...............................................................................33

3.3 Standard CMOS Features.....................................................35

3.4 IDE Adapters ...........................................................................37

3.5 Advanced BIOS Features......................................................39

3.6 Advanced Chipset Features..................................................42

3.7 Integrated Peripherals............................................................45

3.8 Power Management Setup....................................................49

3.9 PnP/PCI Configurations.........................................................52

3.10 PC Health Status.....................................................................53

3.11 Frequency/Voltage Control....................................................54

3.12 Load Fail-Safe Defaults..........................................................54

3.13 Load Optimized Defaults........................................................55

3.14 Supervisor/User Password Setting.......................................55

3.15 Exiting BIOS Setup.................................................................56

Warranty Policy .............................................................................................57

Introduction •1

Introduction

The M-855 series combines the high performance and exceptional value of the Intel®

855GME chipset with a full-featured, next generation, industrial board. The Intel®

855GME advanced chipset supports socket 478-pins Intel®Pentium®M processors

ranging from 1.30GHz to 1.80GHz, and up to 2GB DDR SDRAM memory on its

400/533MHz FSB. It includes an integrated LVDS and VGA, an onboard Intel®82541

Gigabit Ethernet controller (supporting 10/100/1000 Base-TX Ethernet), audio

line-out, four COM ports, two internal USB2.0 ports, 2 SATA ports, and a

CompactFlash™ type II connector. M-855 uses include ATM, CTI, KIOSK, POS, and

other high-end applications.

The 82801DB I/O Controller Hub (ICH4) employs the Intel®Accelerated Hub

Architecture to make a direct connection from the graphics chip and memory to the

integrated Ethernet controller, IDE controllers (ATA/33, ATA/66, or ATA/100), and six

USB ports.

The M-855 industrial board supports Windows®98/NT/2000/XP and Linux®operation

system.

2 •Introduction

1.1 Unpacking Checklist

1. Take out the M-855 series unit from the carton box, check if the unit is properly

secure in its plastic bag.

2. Check the contents of the carton box:

¡Industrial Board ¡Installation Guide

¡ATA-66/100 HDD ribbon cable ¡Floppy ribbon cable

¡S-ATA & Power cable (1 Set) ¡Driver CD

¡COM3 ribbon cable (1 Set) ¡External K/B & M/S cable

(for RS-232/422/485) (6-pin to 6-pin)

Introduction •3

¡Low profile heat sink with fan ¡I/O Shield

Note: M-855 OEM versions with non-standard configurations may vary

in function or contents according to request.

CAUTION: This board must be protected from static discharge and physical

shock. Never remove any of the socketed parts except at a

static-free workstation. Use the anti-static bag shipped with the

product to handle the board. Wear a wrist strap grounded through

one of the system's ESD Ground jacks while servicing system

components.

1.2 Features

•Intel®Pentium®M / Celeron®M processor

•Intel®855GME + ICH4 AGPset

•Support 2GB DDR266/333 SDRAM (max.) memory

•Front Side Bus Frequency: 400/533MHz

•Chipset integrated graphic & LVDS function

•Single 10/100/1000 Mbps Gigabit Ethernet using Intel®82541 chip

•Software programmable watchdog timer

•Hardware Monitoring

•AC97 Audio Lin-out pin-header

Hardware Monitoring

Hardware monitoring allows the user to monitor various aspects of system operations

and status (including the CPU temperature, voltage, and fan RPM).

I/O Shield Connector

The SBC is equipped with an I/O bracket. Please use the appropriate I/O shield.

4 •Introduction

21.6435.97

56.05

21.75

6.50

38.10

11.96 6.22

26.13

16.80

29.50

25.42

Figure 1: I/O back panel layout

M-855 Series Overview

Function M-855

¡Chipset Intel®855GME

¡LVDS 

¡VGA 

¡Gigabit Ethernet 

¡40-pins EIDE interface 2

¡Type II CF socket 1

¡Parallel ports 1

¡Serial ports 4

¡PCI slots 3

¡USB 2.0 ports (two for USB cable) 6

¡Audio Line-out pin-header 1

¡Fan connector 2
