Express-HR

User’s Manual

Manual Revision: 2.00

Revision Date: June 11, 2012

Part Number: 50-1J036-1000

Express-HR User’s ManualPage 2

Revision History

Release Date Change

2.00 June 11, 2012 Initial release

Page 3Express-IA533 User’s Manual Page 3Express-IA533 User’s ManualExpress-HR User’s Manual Page 3

Page 3Express-HR User’s Manual

Table of Contents

Preface ............................................................................................................................5

1 Introduction...............................................................................................................7

1.1 Description ...........................................................................................................................7

2 Specifications............................................................................................................8

2.1 General.................................................................................................................................8

2.2 Expansion Busses ...............................................................................................................8

2.3 Video ....................................................................................................................................9

2.4 Audio ....................................................................................................................................9

2.5 LAN.......................................................................................................................................9

2.6 Multi I/O ..............................................................................................................................10

2.7 Super I/O ............................................................................................................................10

2.8 TPM (Trusted Platform Module)........................................................................................10

2.9 Power Specifications .........................................................................................................10

2.10 Power Consumption ..........................................................................................................11

2.11 Operating Systems ............................................................................................................12

2.12 Mechanical and Environmental.........................................................................................12

3 FunctionDiagram ...................................................................................................13

4 MechanicalDimensions..........................................................................................14

5 PinoutandSignalDescriptions..............................................................................15

5.1 COM Express® Type 6 compatible pinout........................................................................15

5.2 Carrier Board Design Guide ..............................................................................................15

5.3 Pin Definitions ....................................................................................................................16

5.4 Signal Descriptions............................................................................................................18

5.5 Onboard Fan Connector....................................................................................................26

6 ModuleConfiguration .............................................................................................27

6.1 Digital Display Interface (DDI) ...........................................................................................27

6.2 PCI Express x16 Configuration..........................................................................................27

Express-HR User’s ManualPage 4

7 EmbeddedFunctions..............................................................................................28

7.1 Watchdog Timer.................................................................................................................28

7.2 GPIO ...................................................................................................................................29

7.3 Hardware Monitoring.........................................................................................................30

8 System Resources..................................................................................................31

8.1 System Memory Map.........................................................................................................31

8.2 Direct Memory Access Channels ......................................................................................32

8.3 Legacy I/O Map..................................................................................................................32

8.4 Interrupt Request (IRQ) Lines ...........................................................................................33

8.5 PCI Configuration Space Map ...........................................................................................35

8.6 PCI Interrupt Routing Map .................................................................................................36

9 BIOSSetupUtility....................................................................................................37

9.1 Starting the BIOS................................................................................................................37

9.2 UEFI BIOS Setup Utility......................................................................................................38

9.3 Main Setup.........................................................................................................................39

9.4 Advanced Setup.................................................................................................................40

9.5 Chipset Configuration........................................................................................................54

9.6 Boot Setup..........................................................................................................................60

9.7 Security Setup....................................................................................................................62

9.8 Save & Exit .........................................................................................................................63

10 BIOSCheckpoints,BeepCodes.............................................................................65

10.1 Status Code Ranges..........................................................................................................66

10.2 Standard Status Codes .....................................................................................................66

10.3 OEM-Reserved Status Code Ranges ...............................................................................72

Important Safety Instructions......................................................................................73

GettingService .............................................................................................................74

Page 5Express-IA533 User’s Manual Page 5Express-IA533 User’s ManualExpress-HR User’s Manual Page 5

Page 5Express-HR User’s Manual

Preface

This document contains proprietary information protected by copyright. All rights are

reserved. No part of this manual may be reproduced by any mechanical, electronic, or other

means in any form without prior written permission of the manufacturer.

Disclaimer

The information in this document is subject to change without prior notice in order to improve

reliability, design, and function and does not represent a commitment on the part of the

manufacturer.

In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential

damages arising out of the use or inability to use the product or documentation, even if advised

of the possibility of such damages.

Environmental Responsibility

ADLINK is committed to fulfill its social responsibility to global environmental preservation

through compliance with the European Union's Restriction of Hazardous Substances (RoHS)

directive and Waste Electrical and Electronic Equipment (WEEE) directive. Environmental

protection is a top priority forADLINK. We have enforced measures to ensure that our products,

manufacturing processes, components, and raw materials have as little impact on the

environment as possible. When products are at their end of life, our customers are encouraged to

dispose of them in accordance with the product disposal and/or recovery programs prescribed by

their nation or company.

Trademarks

AMIBIOS®8 is a registered trademark of American Megatrends, Inc. COM Express®, and

PICMG®are registered trademarks of the PCI Industrial Computer Manufacturers Group.

Product names mentioned herein are used for identification purposes only and may be

trademarks and/or registered trademarks of their respective companies.

Express-HR User’s ManualPage 6

Conventions

Take note of the following conventions used throughout this manual to make sure that users

perform certain tasks and instructions properly.

Additional information, aids, and tips that help users perform tasks.

Information to prevent minor physical injury, component damage, data loss,

and/or program corruption when trying to complete a task.

Information to prevent serious physical injury, component damage, data

loss, and/or program corruption when trying to complete a specific task.

Page 7Express-IA533 User’s Manual Page 7Express-IA533 User’s ManualExpress-HR User’s Manual Page 7

Page 7Express-HR User’s Manual

1Introduction

1.1 Description

The Express-HR is a COM Express® COM.0 R2.0 Type 6 module supporting the 64-bit Intel®

Core™ i7/i5 processor with CPU, memory controller, and graphics processor on the same

chip. Based on the latest Mobile Intel® QM67 Express chipset, the Express-HR is specifically

designed for customers who need high-level processing and graphics performance in a long

product life solution.

The Express-HR features the Intel® Core™ i7/i5 processor supporting Intel® Hyper-threading

Technology (4 cores, 8 threads) and up to 16GB of DDR3 dual-channel memory at

1066/1333 MHz to provide excellent overall performance. Intel® Flexible Display Interface

and Direct Media Interface provide high speed connectivity to the Intel® QM67 Express

chipset.

Integrated HD Graphics 3000 includes features such as OpenGL 3.0, DirectX10.1, Intel®

Clear Video HD Technology, Advanced Scheduler 2.0, 1.0, XPDM support, and DirectX Video

Acceleration (DXVA) support for full AVC/VC1/MPEG2 hardware decode. Graphics outputs

include VGA, LVDS and three DDI ports supporting HDMI / DVT / DisplayPort or SDVO. The

Express-HR is specifically designed for customers with high-performance processing

graphics requirements who want to outsource the custom core logic of their systems for

reduced development time.

The Express-HR has dual stacked SODIMM sockets for up to 16 GB DDR3 memory. The

Intel® Mobile QM67 Express chipset integrates VGA and dual-channel 18/24-bit LVDS

display output. In addition to the onboard integrated graphics, a multiplexed PCI Express®

x16 Graphics bus is available for discrete graphics expansion or general purpose x8 or x4

PCI Express® connectivity.

The Express-HR features a single onboard Gigabit Ethernet port, up to eight USB 2.0 ports,

two SATA 6 Gb/s ports and two SATA 3 Gb/s ports with optional support for RAID 0/1/5/10.

Support is provided for SMBus and I2C. The module is equipped with SPI AMI EFI BIOS with

CMOS backup, supporting embedded features such as remote console, CMOS backup,

hardware monitor, and watchdog timer.

The Express-HR is a RoHS compliant and lead-free product.

Express-HR User’s ManualPage 8

2Specifications

2.1 General

fCPU: Sandy Bridge 32 nm process, BGA type

Intel® Core™ i7-2715QE 2.1 GHz (3.0 GHz Turbo), 6MB L3 cache, 45W

Intel® Core™ i7-2655LE 2.2 GHz (2.9 GHz Turbo), 4MB L3 cache, 25W

Intel® Core™ i7-2610UE 1.5 GHz (2.4 GHz Turbo), 4MB L3 cache, 17W

Intel® Core™ i5-2515E 2.5 GHz (3.2 GHz Turbo), 3MB L3 cache, 35W

fMemory: Dual channel non-ECC 1066/1333 MHz DDR3 memory up to 16 GB in

dual SODIMM socket

fChipset: Mobile Intel® QM67 Express

fL3 Cache: 6MB (i7-2715QE), 4MB (i7-2655LE and i7-2610UE), 3MB (i5-2515E)

fBIOS: AMI EFI with CMOS backup in 16 Mbit SPI BIOS

fDebug Interface: XDP SFF-26 extension for ICE debug

fHardware Monitor: Supply voltages and CPU temperature

fWatchdog Timer: Programmable timer ranges to generate RESET

2.2 Expansion Busses

fOn Processor:

- PCI Express x16 Graphics (Gen2) bus for discrete graphics solution or General

Purpose PCI Express (2 x8 or 1 x8 with 2 x4) - see 6.2 PCI Express x16

Configuration

fOn Chipset:

- 8 PCI Express x1: 0/1/2/3/4/5/6 are free, 7 is occupied by GbE LAN

- LPC bus for optional connections to SIO, UART, etc.

fLPC bus, SMBus (system), I2C(user)

Page 9Express-IA533 User’s Manual Page 9Express-IA533 User’s ManualExpress-HR User’s Manual Page 9

Page 9Express-HR User’s Manual

2.3 Video

fCore:HDGraphics3000 at 650–1300MHz

fIntegratedGraphicsFeatures:

- DirectX 10.1 and OpenGL 3.0

- Intel Clear Video HD Technology

- Advanced Scheduler 2.0, 1.0, XPDM support

- DirectX Video Acceleration (DXVA) support for full AVC/VC1/MPEG2 hardware decode

fVGA Interface: Analog VGA support up to QXGA, 300MHz DAC

fLVDS Interface: Dualchannel 18/24-bit

fDigital Display Interface (DDI): Three DDI ports supporting HDMI / DVI / DisplayPort or

SDVO (see Note below regarding DisplayPort). A maximum of two simultaneous display

outputs are supported. SDVO is available on DDI1 only. See 6.1 Digital Display Interface

for information on configuring the DDI output.

DisplayPort

DisplayPort is a VESA interface standard for digital display. It defines a new license-

free, royalty-free, state-of-the-art digital audio/video interconnect, intended to be

used primarily between a computer and its display monitor, or a computer and a

home theater system. It features 1.62 Gb/s and 2.7 Gb/s transfer rates over 1, 2 or 4

data lanes, 8b 10b coding, Hot-Plug detect support and HDCP support. Embedded

DisplayPort (eDP) does not offer all features of standard DisplayPort because

embedded applications do not require features such as link training, hot plug

detection or logo testing. The eDP standard supports one data pair supporting XGA

(1024x768) over two wires. Optionally 4 wires can be used for two data pairs to

support 1280x1024.

2.4 Audio

fChipset: Integrated in Intel® PCH QM67

fAudio Codec: on Express-BASE6 (ALC888)

2.5 LAN

fChipset: Intel® Gigabit LAN PHY WG82579LM

fInterface: 10/100/1000 Mbps Ethernet

Express-HR User’s ManualPage 10

2.6 Multi I/O

fSATA: Supports two SATA ports at 6 Gb/s and two ports at 3 Gb/s with support for

RAID0,1,5,10

fUSB: Supports up to eight ports USB 2.0

fSSD: Optional SATA based Solid State Disk, 8/16/32 GB

2.7 Super I/O

fConnected to LPC bus on carrier if needed

2.8 TPM (Trusted Platform Module)

fChipset:InfineonSLB9635TT1.2

fType: TPM1.2

2.9 Power Specifications

fInput Power: AT mode (12 V +/- 5%) andATX mode (12 V and 5 Vsb +/- 5%)

fPower States: supporting S0, S1, S3, S4, S5

fSmart Battery Support: yes

Table des matières

Autres manuels ADLINK Technology Unité de contrôle

ADLINK Technology

ADLINK Technology USB-1210 Manuel utilisateur

ADLINK Technology

ADLINK Technology NuDAM-6017 Manuel utilisateur

ADLINK Technology

ADLINK Technology HSL-DI32-UD Manuel utilisateur

ADLINK Technology

ADLINK Technology COM Express Express-CFR Manuel utilisateur

ADLINK Technology

ADLINK Technology COM Express nanoX-BASE Manuel utilisateur

ADLINK Technology

ADLINK Technology cPCI-R6500 Series Manuel utilisateur

ADLINK Technology

ADLINK Technology USB-1210 Manuel utilisateur

ADLINK Technology

ADLINK Technology NuDAM-6063 Manuel utilisateur

ADLINK Technology

ADLINK Technology cPCI-6830 Series Manuel utilisateur

ADLINK Technology

ADLINK Technology USB-7230 Manuel utilisateur

ADLINK Technology

ADLINK Technology NuDAM-6018 Manuel utilisateur

ADLINK Technology

ADLINK Technology MPC-8164 Manuel utilisateur

ADLINK Technology

ADLINK Technology USB-2405 Manuel utilisateur

ADLINK Technology

ADLINK Technology AVA-5500 Series Manuel utilisateur

ADLINK Technology

ADLINK Technology ND-6021 Manuel utilisateur

ADLINK Technology

ADLINK Technology cPCI-3534 Manuel utilisateur

ADLINK Technology

ADLINK Technology PXI-7901 Manuel utilisateur

ADLINK Technology

ADLINK Technology NuIPC cPCI-6760D Series Manuel utilisateur

ADLINK Technology

ADLINK Technology cPCI-3840 Series Manuel utilisateur

ADLINK Technology

ADLINK Technology cPCI-R6100 Manuel utilisateur

ADLINK Technology

ADLINK Technology SMARC LEC-PX30 Manuel utilisateur

ADLINK Technology

ADLINK Technology cExpress-HL Manuel utilisateur

ADLINK Technology

ADLINK Technology USB-1901 Manuel utilisateur

ADLINK Technology

ADLINK Technology EGX-MXM-P2000 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
