ADJ PIXIE DRIVER 2000 Manuel utilisateur
User Manual
PIXIE DRIVER 2000
US SKU#: PIX142
EU SKU#: 1226200064
UPC#: 818651027860
ITF-14#: 10818651027867
©2020 ADJ Products, LLC all rights reserved. Information, specications, diagrams, images, and
instructions herein are subject to change without notice. ADJ Products, LLC logo and identifying
product names and numbers herein are trademarks of ADJ Products, LLC. Copyright protection
claimed includes all forms and matters of copyrightable materials and information now allowed by
statutory or judicial law or hereinafter granted. Product names used in this document may be
trademarks or registered trademarks of their respective companies and are hereby acknowledged.
All non-ADJ Products, LLC brands and product names are trademarks or registered trademarks of
their respective companies.
ADJ Products, LLC and all aliated companies hereby disclaim any and all liabilities for property,
equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic
loss associated with the use or reliance of any information contained within this document, and/or as
a result of the improper, unsafe, insucient and negligent assembly, installation, rigging, and opera-
tion of this product.
Europe Energy Saving Notice
Energy Saving Matters (EuP 2009/125/EC)
Saving electric energy is a key to help protecting the enviroment. Please turn o all electrical products when
they are not in use. To avoid power consumption in idle mode, disconnect all electrical equipment from power
when not in use. Thank you!
DOCUMENT VERSION
Due to additional product features and/or enhancements, an updated version of
this document may be available online.
Please check www.adj.com for the latest revision/update of this manual
before beginning installation and/or programming.
08/06/20 1.0 draft 1.0 Not Applicable Initial Release
Date Document
Version
Software
Version > DMX Channel Mode Notes
ADJ Products, LLC - www.adj.com - Pixie Driver 2000 User Manual Page 2
ADJ Products, LLC - www.adj.com - Pixie Driver 2000 User Manual Page 3
Pixie Driver 2000 Table of Contents
Introduction 4
Features | Warranty Registration 5
Safety Guidelines 6
Overview 7
Installation 8
Driver Output Limitations 11
RGB Pixel Control 13
System Menu 14
Limited Warranty 21
Dimensional Drawings 22
Specications 23
Accessories 24
ADJ Products, LLC - www.adj.com - Pixie Driver 2000 User Manual Page 4
Introduction: Congratulations on your purchase of the ADJ Pixie Driver 2000! This device has been
designed to provide easy and versatile control options specifically for the ADJ Pixie Strip 30, 60, and
120 series, and to perform reliably for years when the guidelines in this booklet are followed. Please
read and understand the instructions in this manual carefully and thoroughly before attempting to
operate this device. These instructions contain important information regarding safety during use and
maintenance.
These instructions contain important safety information regarding the use and maintenance of this
unit. Please keep this manual with the unit for future reference.
Customer Support: Contact ADJ Service for any product related service and support needs. Also visit
forums.adj.com with questions, comments or suggestions.
Parts: To purchase parts online visit:
http://parts.adj.com (US)
http://www.adjparts.eu (EU)
ADJ SERVICE USA - Monday - Friday 8:00am to 4:30pm PST
ADJ SERVICE EUROPE - Monday - Friday 08:30 to 17:00 CET
ADJ PRODUCTS LLC USA
6122 S. Eastern Ave. Los Angeles, CA. 90040
323-582-2650 | Fax 323-532-2941 | www.adj.com | info@adj.com
ADJ SUPPLY Europe B.V
Junostraat 2 6468 EW Kerkrade, The Netherlands
+31 (0)45 546 85 00 | Fax +31 45 546 85 99
ADJ PRODUCTS GROUP Mexico
AV Santa Ana 30 Parque Industrial Lerma, Lerma, Mexico 52000
+52 (728) 282-7070
WARNING! To prevent or reduce the risk of electrical shock or re, do not expose this unit to rain or
moisture.
CAUTION! There are no user serviceable parts inside this unit. Do not attempt any repairs yourself,
doing so will void your manufacturer’s warranty. In the unlikely event your unit may require service,
please contact ADJ Products, LLC.
Do not discard the shipping cartoon in the trash. Please recycle when ever possible.
Pixie Driver 2000 Introduction
Pixie Driver 2000 Features
• Power & data supply for ADJ Pixie Strip 30, 60, & 120
• Manual RGB mode
• Internal programs
• Manual dimming and strobe control
• Full pixel mapping control
• 2,040 pixels via Kling-Net
• 340 pixels via Art-Net and sACN (streaming ACN)
• OLED screen with 4-button menu
Included Items:
1 x 10-foot (3m) 4-pin power / data cable
Pixie Driver 2000 Warranty Registration
The Pixie Driver 2000 carries a 2 year limited warranty. Please fill out the enclosed warranty card to
validate your purchase. All returned service items,whether under warranty or not, must be freight pre-
paid and accompanied by a return authorization (R.A.) number. The R.A. number must be clearly written
on the outside of the return package. A brief description of the problem as well as the R.A. number
must also be written down on a piece of paper included in the shipping carton. If the unit is under
warranty, you must provide a copy of your proof of purchase invoice. You may obtain a R.A. number
by contacting our customer support team. All packages returned to the service department not dis-
playing a R.A. number on the outside of the package will be returned to the shipper.
ADJ Products, LLC - www.adj.com - Pixie Driver 2000 User Manual Page 5
ADJ Products, LLC - www.adj.com - Pixie Driver 2000 User Manual Page 6
Pixie Driver 2000 Safety Guidelines
For Your Own Personal Safety, Please Read and Understand This Manual Completely Before
You Attempt To Install Or Operate This Unit!
• Be sure to save the packing carton in the unlikely event the device may have to be returned for
service
• Do not spill water or other liquids into or on to the device.
• Be sure that the local power outlet matches the required voltage for the device
• Do not open up the device under any conditions. There are no user serviceable parts inside
• Disconnect the device’s main power when left unused for long periods of time
• Never connect this device to a dimmer pack
• Do not attempt to operate this device if it has been damaged in any way
• Never operate this device with the cover removed
• To reduce the risk of electrical shock or re, do not expose this device to rain or moisture
• Do not attempt to operate this device if the power cord has been frayed or broken. Do not attempt
to remove or break o the ground prong from the electrical cord. This prong is used to reduce the
risk of electrical shock and re in case of an internal short
• Disconnect from main power before making any type of connection
• Never block the ventilation holes. Always be sure to mount this device in an area that will allow
proper ventilation. Allow about 6” (15cm) between this device and a wall
• This unit is intended for indoor use only. Use of this product outdoors voids all warranties
• Always mount this unit in a safe and stable matter
• Please route your power cord out of the way of foot trac. Power cords should be routed so they
are not likely to be walked on, or pinched by items placed upon or against them
• Ambient operating temperature ranges is from -4°F to 113°F (-20°C to 45°C). Do not operate
this device when ambient temperature falls outside of this range!
• Keep ammable materials away from this xture!
• IP20 Rating: Fixture is protected against solids approximately the size of an adult nger, or
larger. FIXTURE IS NOT PROTECTED AGAINST LIQUID INTRUSION OF ANY KIND!
• The device should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen on, or liquid has been spilled into, the device.
C. The device has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a marked change in performance.
ADJ Products, LLC - www.adj.com - Pixie Driver 2000 User Manual Page 7
Pixie Driver 2000 Overview
1. Setup Button
2. Mode Button
3. LCD Screen
4. Up Button
5. Down Button
6. Main Power Switch
7. Mounting Brackets
8. Safety Cable Attachment Point
9. 10A Output Fuses
10. 3A Input Fuse
11. Power In
12. Kling-Net/Art-Net Ports
13. 4-pin Outlet Sockets
ADJ Products, LLC - www.adj.com - Pixie Driver 2000 User Manual Page 8
Pixie Driver 2000 Installation
FLAMMABLE MATERIAL WARNING!
Keep drive a minimum of 5.0 feet (1.5m) away from ammable material and/or pyrotechnics.
ELECTRICAL CONNECTIONS
A qualied electrician should be used for all electrical connections and/or installations.
DO NOT INSTALL THE DEVICE IF YOU ARE NOT QUALIFIED TO DO SO!
The driver MUST be installed following all local, national, and country commercial electrical and con-
struction codes and regulations.
Before installing or mounting any device, a professional equipment installer MUST be consulted to
determine whether the mounting structure or surface is properly certied to safely support the com-
bined weight of the device and any relevant accessories.
Ambient operating temperature range is from -4°F to 113°F (-20°C to 45°C). Do not operate this
device when ambient temperature falls outside this range.
The device should be installed in areas outside walking paths, seating areas, or away from areas
where unauthorized personnel might be able to reach the device by hand.
ADJ Products, LLC - www.adj.com - Pixie Driver 2000 User Manual Page 9
Pixie Driver 2000 Installation
RACK MOUNTING
This device can be mounted in a standard 19-inch rack using the mounting brackets located on
each side of the device. Make sure to use mounting hardware that ts the mounting holes on the
device as well as the rack itself. Use all four (4) points on the mounting brackets to ensure that the
device is mounted securely. Please see the illustration above for reference.
OUTLET SOCKET PIN CONFIGURATION
This device features two (2) output sockets on the back side, which may be used to connect the
device to the desired lighting xtures. The pins for each output socket are congured as shown in
the image below. Please consult a qualied electrician for all electrical connections and/or
installations.
Pin 1: Power (+)
Pin 2: Data
Pin 3: CLK (clock pin)
Pin 4: Power (-)
Pixie Driver 2000 Installation
MULTIPLE DRIVERS
Up to ve (5) Pixie Driver 2000 devices may be daisy-chained directly together and linked to a single
controller. See the image below for reference. Do NOT daisy-chain more than ve (5) devices
directly together.
If more than ve (5) devices are required, a one-gigabit ethernet switch may be used to expand the
size of the network. However, even in this case, no more than ten (10) branches from the ethernet
switch are allowable, with each branch containing up to ve (5) daisy-chained devices. This permits
a maximum of fty (50) devices to be linked to a single controller, as shown in the image below. Do
NOT exceed this number of devices!
ADJ Products, LLC - www.adj.com - Pixie Driver 2000 User Manual Page 10
ALLOWABLE CABLE LENGTHS
12-AWG 4-pin extension cable or 16-AWG 4-pin extension cable may be used to link multiple de-
vices. However, please take note of maximum allowable cable lengths, as listed below:
- Max length of cable connecting a controller and a device: 59 feet (18m)
- Max length of cable connecting two devices: 32 feet (10m)
- Max total cable length in a single chain: 213 feet (65m) for 12-AWG / 98 feet (30m) for 16-AWG
