ADA INSTRUMENTS 6D SERVOLINER Manuel utilisateur
Line Laser
OPERATING MANUAL
6D SERVOLINER /
6D SERVOLINER GREEN
adainstruments.com
2English
12
5
7
6
34
13 2
7
хy
х
y
5
4
6
6
7
4
5
9
3
2 1
8
10
11
12
13
3
THE MANUFACTURE RESERVES THE RIGHT TO MAKE CHANGES (NOT
HAVING AN IMPACT ON THE SPECIFICATIONS) TO THE DESIGN, COMPLETE
SET WITHOUT GIVING PRIOR WARNING.
APPLICATION
Line laser ADA 6D SERVOLINER / ADA 6D SERVOLINER GREEN is designed
to check the horizontal and vertical position of the surfaces of the elements
of building structures and also to transfer the angle of inclination of the
structural part to similar parts during construction and installation works.
SPECIFICATIONS
English
Laser beam
Light sources
Laser safety class
Accuracy
Self-leveling range
Working range (with detector)
Rotation/Fine adjustment
Power supply
Mounting thread
Operating temperature
Weight
Size
Dust / water protection
6D SERVOLINER
6D SERVOLINER GREEN
4 lines (H 360º), 4 lines (V 270º), 1 dot (plumb down)
635nm 520nm
2, <1 mWt
±1mm/10m
±3°
20 (70m) 40 (70m)
360°
Li-battery 12.6V, 2600mAh/8xAA 1,5V/charger
5/8"
-10°C ~ +40°C
1.5 kg
Ø 152x220 mm
IP54
4English
FUNCTIONAL DESCRIPTION
- 4 vertical lines (V), 4 horizontal lines (H) (360º), plumb down;
- The line laser is designed for operation indoor and outdoor.
- Electronic compensator for the faster self-leveling ±3º;
- The line laser begins to blink automatically, if the deviation from horizontal
plane is more than ±3º;
- Fine adjustment mechanism helps to find the object;
- Compensator blocks automatically, when the power is off. It protects the
compensator form vibrations during transportation.
FEATURES
1. Vertical laser window
2. Keypad
3. Horizontal laser window
4. Housing
5. Serial number plate
6. Limb 360º
7. Adjustable legs
8. Down point laser / mounting thread 5/8’’
9. Power indicator
10. Battery clip
11. Li-on battery / battery compartment
12. Fine adjustment switch
13. Connector for power unit
2
1
5English
OPERATION
1. Li-battery or battery adapter AA can be used for operation with line
laser. If using a battery adapter AA, install batteries in it. Open the
battery compartment cover. Insert the batteries into the battery
adapter. Close the battery compartment cover. Install Li-battery /
battery adapter AA (11) on the housing of the line laser. To replace
the Li-battery / battery adapter press clip (10) and release it from the
housing of the line laser.
2. To check the power level of the Li-battery use power indicator (9).
To do this, press the button with the battery icon. The number of
highlighted segments on the indicator shows the power level. It is
possible to use charger to operate with the tool. Use charger for
rechargeable batteries. Connect the charger to the connector for
power switch (13) that is located on the housing of the line laser. Line
laser will be ON and charge rechargeable batteries.
WARNING: Never use charger for ordinary batteries. Do not leave
the line laser unattended while using charger. Parameters of
the charger must correspond to the parameters of domestic
electricity. Output voltage must be no more than 12V.
KEYPAD
1. Horizontal switch (H)
2. P o w e r s w i t c h O n / O ( P o w e r L E D )
3. Vertical switch (V)
4. Detector LED
5. Detector mode
6. Self-leveling mode
7. Self-leveling o LED
3
6English
3. Set up the line laser on the oor or the tripod. When using tripod,
screw the tripod screw into the centering hole. Use screw-adapter
to set a line laser on the mounts with bases. Level the line laser
with the bubble level with the help of adjustable legs (7) or tripod.
Press button (2) to switch on the line laser. Press buttons H (1) and
V (3) to switch and select vertical and horizontal lines. Switch o the
unnecessary lines to save battery power.
Variants of projections:
H button:
- 1 horizontal line (sector 120º)
- 2 horizontal lines (sector 180º)
- 4 horizontal lines (sector 360º)
- all horizontal lines are switched o
V button:
- one vertical line and plumb down
- two vertical lines and plumb down
- 4 vertical lines and plumb down
- all vertical lines are switched o
5. Switch On the line laser. Automatic self leveling begins. LED (7) blinks.
When the self-leveling is nished, LED (7) is OFF. If the LED (7) and
the laser beam begin to blink, the deviation of the line laser from the
horizontal plane is more than ±3º. Laser level can’t be self-leveled.
Adjust the line laser with the help of adjustable legs or tripod.
6. Rotate the housing of the line laser to aim the vertical beams. Use
switch (12) for ne adjustment. Use limb (6) to rotate the housing by
the specic angle:
- aim the vertical beam to the selected point.
- rotate the switch (12) to coincide the mark on the housing witht the
selected rotation angle value on the limb.
7English
MANUAL MODE
1. Switch the line laser ON. Auto leveling function is activated. Press but-
ton (6) to switch on the auto manual mode. LED indicator (7) will be ON
constantly.
2. It is possible to set the inclination of the laser beams along the axis
X and Y in the range of ±3º.
3. Press and hold button H (1) or V(3) to set the tilt angle along the axis X.
4. Press button (3) to set the tilt angle along the axis Y. Press and hold but-
ton H (1) or V (3) to set the tilt angle along the axis Y.
5. Laser lines begin to ash when reaching the full distance position. Press
button (6) to exit from the full tilt distance position or switch o the tilt
mode.
TO CHECK THE ACCURACY OF LINE LASER
(SLOPE PLANE)
Set up the line laser between two walls, the distance is 5 m.Turn
on the Line Laser and mark the point of cross laser line on the wall.
Set up the line laser 0,5-0,7m away from the wall and make, as described
above, the same masrks. If the dierence {a1-b2} and {b1-b2} is less then
the value of “accuracy” (see spesications), there is no need in calibration.
Example: when you check the accuracy of Line Laser the dierence
is {a1-a2}=5 mm and {b1-b2}=7 mm. The instrument’s error: {b1-b2}-
{a1-a2}=7-5=2 mm. Now you can compare this error with standard error.
If the accuracy of Line Laser isn’t corresponding with claimed accuracy,
contact the authorized service center.
5
4
8English
TO CHECK LEVEL
Choose a wall and set laser 5M away from the wall. mark cross point on
the wall. Turn the line laser so that the beam is displaced approximately
2.5m to the left. Horizontal line must be in the “accuracy” range (see specif.)
at the same height with the cross point. Repeat the same steps, moving
the laser level to the right. NOTE: do not displace the rotating axis when
checking.
CHECK PLUMB
Choose a wall and set laser 5m away from the wall. Hang a plumb line 2,5
m long. Turn on the laser and aim the vertical laser line to the plumb. The
accuracy of the line is in the range, if the vertical line doesn’t exceed (up or
down) the half of the value of the accuracy that is shown in the specica-
tions (±3 mm/10 m).
PRODUCT LIFE
Product life of the tool is 7 years. The battery and the tool should never
be placed in municipal waste. Date of production, manufacturer’s contact
information, country of origin are indicated on the product sticker.
CARE AND CLEANING
Please handle line laser with care. Clean with soft cloth only after any use.
If necessary damp cloth with some water. If instrument is wet clean and
dry it carefully. Pack it up only if it is perfectly dry. Transport in original
container/case only.
SPECIFIC REASONS FOR ERRONEOUS MEASURING RESULTS
• Measurements through glass or plastic windows;
• Dirty laser emitting window;
6
9
English
• After line laser has been dropped or hit. Please check the accuracy;
• Large uctuation of temperature: if instrument will beused in cold areas
after it has been stored in warm areas (or the other way round) please wait
some minutes before carrying out measurements.
ELECTROMAGNETIC ACCEPTABILITY (EMC)
• It cannot be completely excluded that this instrument will disturb
other
• instruments (e.g. navigation systems);
• will be disturbed by other instruments (e.g. intensive electromagnet-
ic radiation nearby industrial facilities or radio transmitters).
LASER CLASS 2 WARNING LABELS ON THE LASER INSTRUMENT
LASER CLASSIFICATION
The instrument is a laser class 2 laser product accortding to DIN IEC 60825-
1:2014. It is allowed to use unit without further safety precautions.
SAFETY INSTRUCTIONS
• Please follow up instructions given in operators’ manual.
• Do not stare into beam. Laser beam can lead to eye injury (even from
greater distances).
• Do not aim laser beam at persons or animals. The laser plane should
be set up above eye level of persons. Use the instrument for measuring
jobs only.
• Do not open instrument housing. Repairs should be carried out by au-
thorized workshops only. Please contact your local dealer.
• Do not remove warning labels or safety instructions.
• Keep instrument away from children.
• Do not use instrument in explosive environment.
7
10
WARRANTY
This product is warranted by the manufacturer to the original purchaser to
be free from defects in material and workmanship under normal use for a
period of two (2) years from the date of purchase. During the warranty pe-
riod, and upon proof of purchase, the product will be repaired or replaced
(with the same or similar model at manufactures option), without charge
for either parts of labour.
In case of a defect please contact the dealer where you originally pur-
chased this product. The warranty will not apply to this product if it has
been misused, abused or altered. Without limiting the foregoing, leakage
of the battery, bending or dropping the unit are presumed to be defects
resulting from misuse or abuse.
EXCEPTIONS FROM RESPONSIBILITY
The user of this product is expected to follow the instructions given in op-
erators’ manual. Although all instruments left our warehouse in perfect
condition and adjustment the user is expected to carry out periodic checks
of the product’s accuracy and general performance.
The manufacturer, or its representatives, assumes no responsibility of re-
sults of a faulty or intentional usage or misuse including any direct, indi-
rect, consequential damage, and loss of prots.
The manufacturer, or its representatives, assumes no responsibility for
consequential damage, and loss of prots by any disaster (earthquake,
storm, ood ...), re, accident, or an act of a third party and/or a usage in
other than usual conditions.
The manufacturer, or its representatives, assumes no responsibility for
any damage, and loss of prots due to a change of data, loss of data and
interruption of business etc., caused by using the product or an unusable
product.
English
Autres manuels pour 6D SERVOLINER
1
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels ADA INSTRUMENTS Niveau laser
ADA INSTRUMENTS
ADA INSTRUMENTS CUBE Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS 6D SERVOLINER GREEN Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS Eco 2D Pro Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS ROTARY 400 HV Servo Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS CUBE MINI Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS TOPLiner 3x360 Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS CUBE 2-360 Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS TOPLINER 3-360 GREEN Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS ProDigit 30 Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS 6D SERVOLINER GREEN Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS ECO 2 XL Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS 3D Liner 2V Green Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS ProDigit 30 Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS ROTARY 500 HV SERVO Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS CUBE 360-2V GREEN Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS ARMO 2D Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS 6D MAXLINER Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS TOPLINER 3-360 Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS ROTARY 500 HV SERVO Manuel utilisateur
ADA INSTRUMENTS
ADA INSTRUMENTS ADA BASIS Manuel utilisateur
