ADA INSTRUMENTS ProDigit 30 Manuel utilisateur

ProDigit 30

Manufacturer: ADAINSTRUMENTS Address: WWW.ADAINSTRUMENTS.COM

Operating manual

Digital level

Model: ProDigit 30

MEASUREMENT FOUNDATION

ProDigit 30

Table of contents

1. Safety symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2. Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

3. Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6



5. Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

6. Measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

7. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

8. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18







12. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

13. Exceptions from responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21





MEASUREMENT FOUNDATION

ProDigit 30

Safety symbols

The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols, and the explanations

with them, deserve your careful attention and understanding. The symbol warnings DO NOT by themselves eliminate any

danger. The instructions and warnings they give are no substitutes for proper accident prevention measures.

WARNING: BE SURE to read and understand all safety instructions in this manual, including all safety alert symbols such





SYMBOL MEANING

-

bols or pictographs.











DAMAGE PREVENTION AND INFORMATION MESSAGES







MEASUREMENT FOUNDATION

ProDigit 30

Safety instructions

WARNING: BE SURE to read and understand all instructions in this manual before using this level. Failure to follow all instruc-



SAFETY PRECAUTIONS FOR LASERS

WARNING: 

hazardous radiation exposure. WARNING: The use of optical instruments such as, but not limited to, telescopes or transits to

view the laser beam will increase eye hazard.

This level has a built-in laser light. The laser is a Class2 and emits output power of a maximum 1 mW and 635-665 nm wave-



blindness. CAUTION: The following label is on your tool. It indicates level emits the laser light.

BE AWARE of the laser light location. ALWAYS MAKE SURE that any bystanders in the vicinity aware of the dangers of look-

ing directly into the laser. WARNING: LASER RADIATION. DO NOT stare into beam. Class2 laser product.

Only turn laser beam on when the level is on the work surface.

DO NOT remove or deface any product labels. Removing product labels increases the risk of exposure to laser radia-

tion.



could result.

DO NOT place the Digital level in a position that may cause anyone to stare into the laser beam intentionally or uninten-



DO NOT use any magnifying optical tools such as, but not limited to, telescopes or transits to view the laser beam. Seri-





ALWAYS turn the Digital level off when not in use. Leaving the tool on increases the risk of someone inadvertently star-

ing into the laser beam.





MEASUREMENT FOUNDATION

ProDigit 30



dangerous.

DO NOT place the Digital level in a position that may cause anyone to stare into the laser beam intentionally or uninten-



DO NOT use any magnifying optical tools such as, but not limited to, telescopes or transits to view the laser beam. Seri-



ALWAYS turn the Digital level off when not in use. Leaving the tool on increases the risk of someone inadvertently star-

ing into the laser beam.

dangerous.

DO NOT attempt to modify the performance of this laser device in any way. This may result in a dangerous exposure to

laser radiation.



-

rectly. Match the polarities, positive (+) to positive and negative (-) to negative, as marked inside battery compartment.

DO NOT short battery terminals.

DO NOT mix old and new batteries. If batteries are weak, replace both of them with two new batteries. These new bat-

teries should match each other in brand and type.

Remove dead batteries immediately and dispose of them according to your local ordinance.



Keep batteries out of reach of children. They are not playthings.

Remove batteries and store separately if level will not be used for several days.







10.

11.

12.

13.

14.

15.

16.

17.

18.



20.

21.

22.

23.

24.

MEASUREMENT FOUNDATION

ProDigit 30



This digital level is a highly versatile leveling tool designed for fast, easy operation.

Heavy-duty, lightweight aluminum construction, with the LCD digital module constructed of unbreakable ABS polymer that’s

sealed against dirt and water, and the toughest acrylic block bubble vials and solid-state laser components all add up to on-



-

age slopes.

Use the laser beam to extend a visual leveling line over distances much greater than a traditional bubble vial beam level.

Use the level manually, hand held, or mounted on a tripod (sold separately).

Use the digital level inside or outside to measure pitch in inches of rise per foot of run.

Measure in degrees with up to 0.05° accuracy.

Measure any slope in percent...measure level and plumb with either the LCD digital display or with the vertical and horizontal

bubble vials.

Features (Fig.1a)

Keyboard

LCD Display - Large, easy-to-read display screen reads right side up even when level is upside down.

Bubble Vials- The level or plumb of a surface can also be accurately measured by positioning the bubble inside the vial



Integrated 57cm Ruler



Endcaps - Ends cushioned to help protect level from damage.

Laser Light Aperture - The laser beam is emitted from this opening, which is on the end cap of the level.

Magnetic Bottom -Four magnets in the working base allow for secure contact to metal, handy when working with steel

studs or metal ductwork.





MEASUREMENT FOUNDATION

ProDigit 30

Fig.1a









Large, Soft-grip Handles - For ease in carrying, holding level in place.

10.

11.

12.

MEASUREMENT FOUNDATION

ProDigit 30

Key function (Fig.1b)

Power button -press the button to turn the LCD display screen on. Long press it to turn off the LCD display.

REF Button

button for about 3 seconds to start the calibration.

Sound On/Off Button - Used to activate the beeper. When button is pushed, beeper sounds at level (0°), 45°,



M Button - Push to save the current reading in its memory. The level will save last nine different consecutive angle read-

ings in its memory.

MR Button



UNIT Button - By pushing this button you can convert angles to different units. Push to change the display units from



indicate that the pitch is slightly more (+) or less (-) than true level.

MEASUREMENT FOUNDATION

ProDigit 30



LCD SCREEN ICONS



either up or down away from the level (0°).

Battery Power Icon - Indicates the amount of battery power in the unit. Replace batteries when the black power bar

dis appears.





measurements.

REF Indicates that the level is working in relative angle mode.

Err Indicates that the level is wrong positioned or wrong operation in calibration.

CAL1 Indicates that the digital level is in calibrating for one direction.

CAL2 Indicates that the digital level is in calibrating for the another direction.



Recommended use Indoors or Outdoors

Laser class Class2, max laser output ≤1mW

Power supply 2x 1.5V AAA battteries

Angle measuring range 0 to 360°

Optimum operation range 0 to 40°

Accuracy of vials ±0.029°

Accuracy of digital display ±0.05°(level or plumb)

±0.1°(other angles)

Estimated Battery life 10 hours with alkaline batteries

MEASUREMENT FOUNDATION

ProDigit 30

Battery installation (Fig. 2)



and the Laser dot.

Fig.2

NOTE

Open the battery cover, located in the middle of the back of the level (Fig.2).



Close the cover securely in place.

Turn on the LCD display



in centigrade for about 2 seconds, to indicate if level is being used in optimum operating temperature range. The current

angle of the level is then displayed, and a picture of that angle is shown either above or below the line for true level.

An arrow on the display indicates if the level has to be moved up or down. True level is reached when the two lines are

together and the angle shows 0.00°. Turn off the LCD display by pressing and holding the button in for about 2 seconds.

If the digital level is not used for 5 minutes the level automatically turns off. The LCD display is large and easy to read.

When the level is turned upside down, the LCD screen senses and changes to read correctly in the inverted position.
