ACME Dotline 360 Manuel utilisateur

- 1 -

CONTENTS

01/ Safety Instructions.................................................................................................. 2

02/ Technical Specifications ........................................................................................ 4

03/ Control Panel........................................................................................................... 5

04/ Fixture Installation.................................................................................................. 7

05/ How To Set The Unit.............................................................................................. 8

5.1 Main Functions................................................................................................ 8

5.2 Home Position Adjustment ......................................................................... 19

06/ Control By Universal DMX Controller.............................................................. 20

6.1 DMX512 Connection................................................................................... 20

6.2 Address Setting.............................................................................................. 21

6.3 DMX512 Configuration............................................................................... 21

07/ Error Information .................................................................................................. 30

08/ Troubleshooting ....................................................................................................32

09/ Fixture Cleaning....................................................................................................32

- 2 -

01/ Safety Instructions

WARNING

Please keep this User Guide for future consultation. If you sell the unit to another user, be

sure that they also receive this instruction manual.

Important:

Damages caused by the disregard of this user manual are not subject to warranty. The dealer

will not accept liability for any resulting defects or problems.

Unpack and check carefully to ensure that there is no transportation damage before

using the unit.

This product is for indoor use only. Use only in a dry location.

DO install and operate by qualified operator.

DO NOT allow children to operate the fixture.

Use safety chain when fixing the unit. Handle the unit by carrying its base instead of

head only.

The unit must be installed in a location with adequate ventilation, at least 50cm from

adjacent surfaces.

Be sure that no ventilation slots is blocked, otherwise the unit will be overheated.

Before operation, ensure that you are connecting this product to the proper voltage in

accordance with the specifications in this manual or on the product’s specification label.

It’s important to ground the yellow/green conductor to earth in order to avoid electric

shock.

Minimum ambient temperature TA: 0℃. Maximum ambient temperature TA: 40℃.Do

not operate this product at a lower or higher temperature.

DO NOT connect the device to any dimmer pack.

Keep flammable materials away from the fixture while operating to avoid fire hazard.

Make sure the power cord is not crimped or damaged; replace it immediately if damaged.

Unit’s surface temperature may reach up to 60 ℃. DO NOT touch the housing

bare-handed during its operation.

Avoid any flammable liquids, water or metal from entering the unit. Once it happens, cut

Please read the instruction carefully which includes important information

about the installation, usage and maintenance.

- 3 -

off the mains power immediately.

DO NOT operate in a dirty or dusty environment. DO clean the fixture regularly.

DO NOT touch any wire during operation as there might be a hazard of electric shock.

Avoid entanglement of the power cord with other wires.

The minimum distance to objects/surface must be more than 0.5 meters.

Disconnect mains power before fuse replacement or servicing.

Replace fuse only with the same type.

In the event of serious operating problem, stop using the unit immediately.

Never turn on and off the unit time after time.

The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly

damaged.

DO NOT open the housing as there are no user serviceable parts inside.

DO NOT attempt to operate this unit if it becomes damaged. DO NOT attempt any

repairs yourself. Repairs carried out by unskilled people can lead to damage or

malfunction. Please contact the nearest authorized technical assistance center if needed.

Disconnect this product from its power source before servicing.

DO use the original packaging if the device is to be transported.

Avoid direct eye exposure to the light source while the product is on.

DO NOT operate this product if you see damage on the housing, shields, or cables. Have

the damaged parts replaced by an authorized technician at once.

- 4 -

02/ Technical Specifications

Power Voltage

100-240V~ 50/60Hz

Power Consumption

440W

Light Source

12x30W RGBW LED

Zoom Range

3.5°-38°

Dimmer/Strobe

0-100% smooth dimming; outstanding strobe effect with variable

speed

Tilt Movement

220°

Control

DMX Channel

57/14/9+ Channels

Control Mode

DMX512

RDM

Art-Net

Firmware Upgrade

Firmware Upgrade via DMX link

Construction

Display

OLED display

Battery backup for user setup without mains connection

Data In/Out

5-pin XLR (3-pin XLR is optional)

RJ45 Connector

Power In/Out

Power Connector in/out

Protection Rating

IP20

Features

Motorized zoom

Outstanding color mixing effect

Dimensions

1000x113x278mm

39.4"x4.4"x10.9"in

Weight

18.5kgs

40.8lbs

- 5 -

Photometric Diagram:

03/ Control Panel

- 6 -

1. Display

To show the various menus and the selected function

2. Buttons

To enter into move backward or leave the menu

UP

To go backward to move up in the menu

DOWN

To go forward to move down in the menu

ENTER

To perform the desired functions

3. OFFLINE SETTING

4. DMX IN

For DMX512 link, use 5-pin XLR cable to link the unit and DMX

controller to input DMX signal (3-pin XLR cable is optional)

5. POWER IN

To connect to supply power

6. ETHERNET

Transfers fixture’s information to a main controller

7. FUSE(T 10A)

Protects the unit from damage of over current or short circuit

8. POWER OUT

To connect to the next fixture

9. DMX OUT

For DMX512 link, use 5-pin XLR cable to link the next units to

output DMX signal (3-pin XLR cable is optional)

10. BUTTON 1

When splicing the fixtures, push it to the "LOCK" position

11. BUTTON 2

Tilt lock. Push it to the "UNLOCK" position before powering up the

fixture

- 7 -

04/ Fixture Installation

DO install and operate by qualified operator. Fixture(s) should be installed in areas

outside walking paths, seating areas, or away from areas were unauthorized personnel

might reach the fixture by hand. NEVER stand directly below the fixture(s) when rigging,

removing or servicing.

Always ensure that the unit is firmly fixed to avoid vibration and slipping off during

operation. Ensure that the trussing or area of installation must be able to hold 10 times

the weight without any deformation. Always attach a safety cable that can hold at least

12 times the weight of the fixture whenever installing this fixture in a suspended

environment to ensure that the fixture will not fall if the clamp fails.

This fixture is fully operational in three different mounting positions: hanging

upside-down, mounted sideways on trussing, or standing on the floor. Always use and

install the supplied safety cable as a safety measure to prevent accidental damage and/or

injury in the event the clamp fails.

Steps for installing the omega brackets to the fixture:

- 8 -

05/ How To Set The Unit

5.1 Main Functions

To access the control menus, press the [MENU] button.

Navigate the menu structure, using the [ENTER], [UP] and [DOWN] buttons.

To select a menu option or to confirm a selection, press the [ENTER] button.

To return to a higher level in the menu structure without making a change, press the

[MENU] button, or wait 30 seconds.

The main functions are shown below:

SUBMENU

OPTIONS

DMX Setting

Art-Net Setup

Ethernet IP Setup

IP Address

Subnet Mask

Art-Net Port Setup

Net

0-127

Subnet

0-15

Universe

0-15

DMX Address

1-456 (57 CH)

(Default=1)

1-499 (14 CH)

1-504 (9+ CH)

Channel Mode

57 CH

14 CH

RDM Device ID

Mode 3 DMX Addr

1-504 (9+ CH)

Mode 3 ART Addr

1-465 (9+ CH)

DMX Last State

Blackout

Hold

Manu

Fixture Setting

Light Mode

Color Calibration

Disable

Enable

Max

White

Balance

Red

125-255

Green

125-255

Blue

125-255

Dimmer Curve

Optically Linear

Square Law

Inverse Square Law

S Curve

- 9 -

SUBMENU

OPTIONS

Dimmer Speed

Smooth

Fast

Invert Tilt

Disable

Enable

Tilt Feedback

Disable

Enable

Bl. O. Tilt Moving

Disable

Enable

Fan Mode

Silent

Auto

Invert Pixel Order

Disable

Enable

Artnet to DMX

Disable

Enable

Auto Test

Manual Mode

Tilt

0-255

Zoom

0-255

Dimmer

0-255

Strobe

0-255

Red

0-255

Green

0-255

Blue

0-255

White

0-255

Display Setting

Inverse

Yes

Temperature Unit

°C

°F

Display Warning

Disable

Enable

Language

English

Chinese

Fixture Information

LED Temperature

Fixture Usage Time

LED Light Time

Fan Speed

Firmware Version
