Acadian Robotics Pantera Mode d’emploi

MADE IN THE USA

Care and Use Manual

Pantera

Precision Rie Silencer

SECTION 1 - PRECAUTIONS

SECTION 2 – GETTING TO KNOW YOUR SILENCER

Pantera is congured with caliber-specic components sized

to improve bullet ight characteriscs.

CONTACT INFORMATION

Mail Website & Email

Acadian Armament, LLC acadianarmament.com

Administrave Oces info@acadianarmament.com

1005 La Neuville Road

Lafayee, LA 70508

337-991-0940

Model Design Caliber Mount Weight Dim.

Pantera

6mm (243 caliber)

6.5mm (270 caliber)

30 caliber

Direct thread

1/2”-28 tpi

5/8”-24 tpi

13.2

ounces 7.1”L x 1.5”∅

Pantera is a Two-Stage Suppression (TSS™) Silencer.

TSS™ SILENCERS ARE DESIGNED FOR SEMI-AUTOMATIC AND

BOLT ACTION RATES OF FIRE (ROF).

LIMITED LIFETIME WARRANTY

Acadian Armament, LLC warrants to the inial retail purchaser that

products manufactured by, or at the direcon of, Acadian Armament

(Acadian Armament products) and purchased from authorized Acadian

Armament dealers are free from defects in material and workmanship.

This warranty covers, and is limited to, service, repair and/or replace-

ment, at our sole discreon, of Acadian Armament products. This war-

ranty is unlimited in duraon for the inial retail purchaser.

This express limited lifeme warranty is the ONLY warranty and no other

express or implied warranes are otherwise provided. ACADIAN ARMA-

MENT PRODUCTS ARE SOLD “AS IS” AND HAVE NO WARRANTY OF

MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE.

LIMITATIONS:

This warranty does not cover damage to rearms, devices or other prod-

ucts with which Acadian Armament products are used. This warranty

does not cover damage to any Acadian Armament product due to nor-

mal wear and tear; careless, negligent or abusive acts, whether those

acts are deliberate or accidental in nature; user’s failure to follow care,

use and/or safe handling instrucons; unauthorized adjustments or

modicaons, misuse, or any illegal acvity or possession; the use of

reloaded, defecve, inappropriate, hand loaded or non-SAAMI/NATO

specicaon ammunion; and/or the use of any Acadian Armament

product outside of the specied restricons and limitaons for that

product.

MANUFACTURER’S DISCLAIMER:

ACADIAN ARMAMENT ASSUMES NO RESPONSIBILITY, AND SHALL

HAVE NO LIABILITY, FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.

FURTHER, ACADIAN ARMAMENT ASSUMES NO RESPONSIBILITY FOR

PERSONAL INJURY, PROPERTY DAMAGE, OR ECONOMIC LOSS. THIS

DISCLAIMER EXTENDS TO DAMAGES RESULTING FROM ANY AND ALL

ACTS IDENTIFIED IN THE “LIMITATIONS” SECTION ABOVE.

**NOTE** This Limited Lifeme Warranty, including the Limitaons and

Manufacturer’s Disclaimer, is subject to all applicable laws and as such

may grant the purchaser addional rights as well as limit the terms of

this warranty.

WARRANTY REPAIRS:

To iniate a repair order, the owner should rst contact Acadian Arma-

ment by compleng and subming a Repair Order Form (found on our

website www.acadianarmament.com), as many issues can be handled

without having to return a product. Repair Order Forms should be sub-

mied to service@acadianarmament.com.

If it is determined that returning a product to Acadian Armament is

required, a copy of the Repair Order Form must be included with the

product along with a legible copy of the owner’s approved BATFE Form

3, 4 or 5. (It is advised that the owner keep a copy of the Repair Order

Form for his/her records.)

A determinaon as to whether a damaged product is covered by this

warranty, and whether service, repair and/or replacement of a product

is required, is solely at the discreon of Acadian Armament. Shipping

and insurance costs to the manufacturer are the responsibility of the

product owner. Should it be determined that a damaged product is

covered by this warranty Acadian Armament will cover the cost of ser-

vice, repair, and/or replacement as well as any reasonable shipping and

insurance costs to return the product to the owner.

If for any reason a damaged product is not covered by this warranty,

Acadian Armament will service, repair or replace said product for a fair

and reasonable price.

Read and understand all the following precauons

before installing and using this silencer.

WARNING: This silencer is intended for use on devices classied as

rearms or dangerous weapons by the Bureau of Alcohol, Tobacco,

Firearms and Explosives. The use of such weapons is potenally le-

thal!

THE USE OF THIS SILENCER (aka SUPPRESSOR or MUFFLER) MAY GIVE

THE USER OR OBSERVER THE IMPRESSION OF REDUCED DANGER OR

LETHALITY.

THE USE OF THIS SILENCER DOES

NOT REDUCE DANGER OR LETHALITY

CAUTION: Carefully read this Care and Use manual which gives basic

instrucon on the proper installaon, use and maintenance of this

silencer. It is the user’s responsibility to become familiar with the

proper use, handling and funcon of this silencer and the weapon

upon which it is installed PRIOR TO USE.

CONDITION: This silencer was carefully inspected before packaging.

Acadian Armament cannot control handling aer it leaves the factory

so examine the silencer carefully at the me of purchase and before

use. Your dealer will be pleased to assist you in making this examina-

on at the me of purchase.

Once installed, the Pantera becomes a component of the host weap-

on. When the barrel and suppressor are warm, re-torque the sup-

pressor to the muzzle. Check periodically to assure the suppressor

remains ght on the muzzle thread and that the components have not

loosened. Allow to cool before aempng to remove or disassemble.

Pantera with TSS™ Two-Stage Suppression

The Two-Stage Suppression (TSS™) design considers shot consistency

and bullet stability as the primary performance objecves. The TSS™

method separates the tasks of blast suppression and separang muz-

zle gases from the bullet as substanally separate events. The rst

stage of suppression contains the muzzle blast and the second stage

prevents expanding muzzle gases from advancing with the bullet. This

method results in signicant reducons of yaw and drag on the bullet,

improved recoil management and weapon control.

Device Funcon: The unique design of TSS™ silencers provide unsur-

passed ballisc stability and accuracy by managing the forces about

the bullet while suppressing the muzzle blast. The bullet is quickly

isolated from the muzzle blast in the rst stage where solid propellant

is captured and prevented from leaving the suppressor unburned. In

the second stage, muzzle gases expanding from the bullet are pre-

vented from advancing with the bullet as those gases become turbu-

lent. The bullet leaves the device substanally free of muzzle gases.

Cleaning: All silencer/suppressor devices capture solid material from

the muzzle blast. Accumulated deposits within those devices will

aect the harmonics of the assembly and can aect performance,

point of impact, etc.

TSS™ are designed to be completely disassembled for cleaning. Most

deposits can be cleaned using convenonal solvents and detergents.

Cleaning frequency depends on use and condions. Do not use acid-

based cleaners on the aluminum Shell or Scrubber. Prolong soaking in

acid-based cleaners can damage the SBN©-/QPQ© surface treatment

of the steel components.

Figure 2: Pantera Disassembled

SECTION 3 – INSTALLING YOUR SILENCER

Inspect the silencer to ensure there is no obstrucon or de-

bris. If an obstrucon or debris is found, disassemble the

silencer as necessary and clear before proceeding.

Pantera has stainless steel base threads which aach direct-

ly to the rearm muzzle thread. If the muzzle thread is also

stainless steel, apply an-seize compound to prevent metal-

to-metal galling.

Direct Mount silencers are preferred when simplicity and accuracy

are signicant consideraons. Pantera mounts directly to the host

weapon via the thread on the host barrel muzzle and are designed to

be used without the crush washer in place.

STEP 1: Remove the thread protector or ash hider and crush wash-

er from the barrel of the host weapon.

NEVER USE A CRUSH WASHER WITH A PANTERA

Figure 4: Seang the base to the muzzle thread shoulder.

Figure 3: Flash Hider and Crush Washer

STEP 2: Thread the base onto the barrel. Pantera is designed for use

without a crush washer and must be threaded completely to the

shoulder on the muzzle thread.

Tighten to approximately 10-15 -lbs. Ensure there is no gap be-

tween the shoulder and base.

Inspect the silencer seang during use to ensure proper

seang. Repeated ring may cause the connecon to loos-

en.

WARNING: SILENCERS CAN BECOME VERY HOT DURING USE.

SECTION 4 – DISASSEMBLING & ASSEMBLING

Pantera is designed to be completely disassembled for cleaning,

inspecon, maintenance and repair. (Fig 2)

The cap and base of your Pantera can be removed with a 3mm pin

spanner wrench. Holes in the face of the base allow use of the

spanner wrench to remove the silencer from the weapon. An AR

castle-nut wrench will t the notches of the base for installaon,

removal or disassembly.

NOTE: The Base and Cap can become dicult to remove aer

prolonged use. Please consult your Dealer or AcadianArma-

ment.com for service ps.

NEVER ATTEMPT TO INSTALL, REMOVE OR MAINTAIN A

SILENCER ON A LOADED FIREARM. Always ensure the weap-

on is unloaded and safe before proceeding.

Remove the Scrubber using a hex wrench (9mm wrench for 30-cal;

8mm wrench for 6.5mm, 7mm wrench for 6mm) in the hex broach.

Figure 5: Using a hex wrench to remove the Scrubber

To assemble your Pantera, simply reverse the disassembly procedure.

Use approximately 10-15 -lbs of torque when assembling the base

and cap to the shell.

Apply an-seize or a silicon/PTFE compound to threads

before reassembly. When cleaning with water and/or

detergents, allow to dry thoroughly before reassembly.

CAUTION: Ensure the host weapon is unloaded and made safe be-

fore aempng to service, install or remove any silencer.

Figure 1: Pantera Components and Features

WARNING: Firing the weapon with the hex wrench in

place WILL cause a catastrophic and dangerous failure.

It is a BEST PRACTICE to remove the silencer from the host

weapon before removing the scrubber.

It is a BEST PRACTICE to never leave the wrench unaend-

ed in the scrubber for any reason.

Autres manuels Acadian Robotics Imprimante 3D

Acadian Robotics

Acadian Robotics Copperhead Manuel utilisateur

Manuels Imprimante 3D populaires d'autres marques

Ultimaker

Ultimaker S5 Material Station Manuel utilisateur

EcubMaker

EcubMaker TOYDIY Manuel utilisateur

AnyCubic

AnyCubic Kossel Plus Manuel utilisateur

ReDeTec

ReDeTec ProtoCycler Manuel utilisateur

Kywoo3D

Kywoo3D Tycoon IDEX Manuel utilisateur

CraftBot

CraftBot PLUS PRO Manuel utilisateur

3DGence

3DGence INDUSTRY F340 Manuel utilisateur

HP Jet Fusion 4200 Mode d'emploi

Rokit

Rokit AEP Series Manuel utilisateur

AnkerMake

AnkerMake M5 Manuel utilisateur

DIYElectronics

DIYElectronics PRUSA I3 Instructions de montage

Ackuretta

Ackuretta FreeShape 120 Manuel utilisateur

LONGER

LONGER LK5Pro Manuel utilisateur

Stratasys

Stratasys J850 Manuel utilisateur

MakerBot

MakerBot Replicator Manuel utilisateur

Stratasys

Stratasys FDM Vantage Series Manuel utilisateur

ZYYX

ZYYX Pro II Manuel utilisateur

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER Creator Guide de l'utilisateur
