Abocom WUG2200 Manuel utilisateur

802.11g Wireless LAN

USB Adapter

The WUG2200 is an 802.11g USB2.0 wireless LAN adapter. The WUG2200

features the very latest in advanced wireless chip technology, which is designed on

the basis of IEEE 802.11g standard that offers a data rate up to 54Mbps in the 2.4GHz frequency. Plus, the WUG2200 is

backwards compliant with 802.11b wireless equipment, making it the most economic and convenient wireless adapter that

you can ever find for your wireless application. The high-speed wireless network card plugs into your notebook or desktop

PC and accesses to the LAN or peer-to-peer networking easily without wires or cables. Whether you’re at your desk or in

the boardroom, it allows you to share printers, files, and other network resources.

The USB adapter is designed for a USB type A port of a laptop or desktop computer for creating a wireless workstation.

FEATURES

 Compliant with IEEE802.11g standard for 2.4GHz Wireless LAN

 USB 2.0 compliant

 USB Plug & Play

 Interoperable with existing network infrastructure

 Secure information transmission

 Freedom to roam while staying connected

 Compatible with specialty wireless products and services

 Up to 54 Mbps data rate

 Antenna is built in the card with LEDs indication

 Low power consumption

 Easy to install and configure

♦

SPECIFICATIONS

General:

LED Indicators Power : Green

Act: Green

Link: Green

Power Requirement ♦

♦

Operating Voltage: 5V DC

TX consumption: 480 mA (Max)

RX consumption: 460 mA (Max)

Physical specification ♦

♦

Weight: 50 g

Dimension: 107(L) x 64(W) x 21(H) mm

Supported OS ♦

♦

Windows 2000 (SP3 ,4)

Windows XP (SP1)

Windows ME

Windows 98SE

Environment Specification ♦

♦

Operating Temperature: 0 ~ 45℃ambient temperature

Storage Temperature: -20~70℃ambient temperature

Operating humidity: 90% maximum (non-condensing)

Storage humidity: 90% maximum (non-condensing)

EMI Certification ♦

♦

FCC Part 15 in US

EN300328 and EN300826 (EN301489-17) in Europe

DGT and BSMI in Taiwan

Wireless:

Standard ♦ IEEE 802.11g

Host Interface ♦ USB 2.0

Antenna ♦ External Antenna, rotating angle 0°to 90°

Frequency Range ♦ 2.412GHz ~ 2.4835GHz

Number of Selectable Channels

♦

USA, Canada: 11 channels

Japan: 14 channels

Europe: 13 channels

Modulation Technique ♦

♦

Direct Sequence Spread Spectrum (CCK, DQPSK, DBPSK)

Orthogonal frequency division multiplexing (OFDM)

Security ♦

♦

0/64/128 bit WEP

802.11i 128 bit AES

Media Access Protocol ♦ CSMA/CA (Collision Avoidance) with ACK

Output power ♦

♦

11g: 12 dBm

11b: 14 dBm

Data Rate ♦

♦

802.11g (54 Mbps, 48 Mbps, 36 Mbps, 24 Mbps, 18 Mbps, 12 Mbps, 9 Mbps, 6 Mbps)

802.11b (11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps)

Throughput ♦

♦

19.5 Mbps @ 54Mbps

4.7 Mbps @ 11Mbps

Sensitivity ♦

♦

-67dBm @54Mbps

-80dBm @11Mbps

Outdoor Distance ♦

♦

120M @54Mbps(FER<10%)

132M @11Mbps (PER<8%)
