Abocom UBT1000H Manuel utilisateur

High Power BluetoothTM Wireless

USB Adapter

The UBT1000H is specifically designed to plug into an

available Universal Serial Bus port connecting to a

desktop or laptop PC. It allows you to make short-range

wireless connections between Bluetooth devices such as

cellular phones, personal digital assistants (PDA), and desktop and notebook

computers.

The UBT1000H uses radio transmission; voice and data are transmitted almost

immediately. BluetoothTM transmission ensures both protection from interference and

secure data transfers. It helps people to share and access the information that is

important to them more easily.

Link your notebook with your handheld, mobile phone, printer and other BluetoothTM

devices within your personal area network (PAN) via a secure short-range wireless

radio link. Get rid of all those troublesome cables and automatically share documents,

browse the internet and synchronize calendars, address books and more.

FEATURE

 Complies with Bluetooth 1.1 specification.

 Uses 2.4 GHz ISM frequency band.

 High-speed Wireless Transmissions, up to 723 Kbps Data Throughput.

 Enable wireless connectivity between a notebook computer and a cellular phone.

 Connections within ranges up to 320 feet (100 meters).

 Provides a high degree of security for communications between Bluetooth

devices.

 Connect with Bluetooth devices outside your PAN to quickly and easily share

data, files and information with a friend or co-worker

 Synchronize devices in your Personal Area Network to keep your data consistent.

 Ease of use.

 Plug and play installation in Windows98SE / 2000 / ME / XP

SPECIFICATION

Standard Bluetooth 1.1

Host Interface USB1.1

Antenna Built in the card

LED Indicator Power: Orange LED

Frequency Range 2.4000-2.4835 GHz

Number of Selectable

Channels

79 channels

Data rate Up to 723 Kbps

Typical Range Devices connect for access and data sharing within ranges up to 320 feet

(100 meters)

Security Data encryption up to 128-bits

RF Technology Frequency hopping spread spectrum(FHSS)

Topology 8 devices

point-to-multipoint

Transmitter Power Output power meets Class 1 requirements_15dBm MAX

Physical Specifications Weight: 10 g

Dimension: 69.53 (L) X 26.68 (W) X 9.19 (H) mm

Power Requirement Normal Operation: 5V DC, 200mA (Max)

Environment Specifications Operating Temperature: 0~45℃ambient temperature

Storage Temperature: -20~45℃ambient temperature

Operating humidity:90% maximum(non-condensing)

Storage humidity:90% maximum(non-condensing)

Supported OS Windows98/ME/2000/XP

Sensitivity -77dBm

Distance 100 M

EMC Certification FCC Part 15 in US

EN300328 and EN300826 (EN301489-17) in Europe
