ABB SM500F Manuel utilisateur

—

ABB MEASUREMENT & ANALYTICS | INSTRUCTION | IN/RANDC/005-EN REV. A

SM500F

Field mountable paperless recorder

Color display replacement

(instruments manufactured from

July 2016)

Measurement made easy

1 Introduction

This publication details replacing an SM500F

paperless recorder’s color display assembly. The

procedure must be carried out by a trained

technician. The contents of the replacement kit

are shown in Table 1.

Description Part number Qty

Color display B13829 1

Slotted spring (Bissel) pin B11344 2

Screw B12452 2

Flexi-cable B12403 1

This publication IN/RandC/005-EN 1

Table 1 Color display assembly replacement kit

SM500/0735

Tools required

• PH0 screwdriver

• T8 Torx driver

2 For more information

Further information is available from:

www.abb.com/recorders

or by scanning these codes:

Sales Service

3 Safety

IMPORTANT NOTE

This procedure is applicable only to recorders

manufactured after June 2016.

SM500F

field mountable

paperless recorder

2 IN/RandC/005-EN Rev. A | SM500F paperless recorder | Color display replacement (instruments manufactured from July 2016)

4 Display assembly replacement

1. Disconnect the recorder from the power supply.

Referring to Fig. 4.1:

2. Unlock the door with the key A, press release catch B

and open the door.

3. Remove the tamper evident seal if fitted, release captive

screw Csecuring the inner cover plate and remove the

inner cover plate.

4. Remove the 2 Torx screws Dsecuring the cable clamp

and remove the cable clamp.

Referring to Fig. 4.2:

5. Disconnect the processor board flexi-cable Efrom the

motherboard.

Referring to Fig. 4.3:

6. Remove the slotted spring (Bissel) pins F, remove the

door assembly and place it face down on the work surface.

Referring to Fig. 4.4:

7. Remove 6 Torx screws Gsecuring the door assembly

rear cover and remove the rear cover.

Referring to Fig. 4.5:

8. Disconnect the processor board flexi-cable H, display

flexi-cable Iand keypad membrane cable Jfrom

the processor board and lift out the processor board.

CAUTION – Minor injuries

The recorder is vulnerable to electrostatic damage.

Wear an anti-static strap or place the instrument on

an anti-static workbench.

Fig. 4.1 Removing the cable clamp

Fig. 4.2 Disconnecting the processor board flexi-cable

Fig. 4.3 Removing the door hinge pins

Fig. 4.4 Removing the rear cover

Fig. 4.5 Disconnecting the processor board

exi-cable

SM500F paperless recorder | Color display replacement (instruments manufactured from July 2016) | IN/RandC/005-EN Rev. A 3

Referring to Fig. 4.6:

9. Remove 4 Torx screws Ksecuring the display mounting

plate and remove the plate complete with display.

Referring to Fig. 4.7:

10. Remove 2 display securing screws Land lift the display

clear of the mounting plate, ensuring the flexi-cable and

inverter cable clear slots Min the mounting plate.

Referring to Fig. 4.8:

11. Remove flexi-cable Nfrom the display and attach the

flexi-cable to the new display (if not already fitted).

Referring to Fig. 4.7:

12. Carefully route the flexi-cable through its respective slot

Min the mounting plate and position the display on the

mounting plate. Secure the display to the mounting plate

with 2 display securing screws L.

13. Remove the protective film from the front of the display and

clean the display and the inside of the door window

thoroughly.

Referring to Fig. 4.9:

14. Route the keypad membrane cable Othrough the slot in

the display mounting plate and position the mounting plate

in the door assembly.

Referring to Fig. 4.6:

15. Secure the display mounting plate to the door using 4 Torx

screws K.

Referring to Fig. 4.5, page 2:

16. Position the processor board into its housing and

reconnect the keypad membrane cable J, display

flexi-cable Iand processor board flexi-cable H.

Referring to Fig. 4.4, page 2:

17. Refit the door assembly rear cover and secure it using the

6 Torx screws G.

Referring to Fig. 4.3, page 2:

18. Align the hinges on the door assembly with the hinge lugs

on the case and secure using the 2 slotted spring (Bissel)

pins F.

Referring to Fig. 4.2, page 2:

19. Reconnect the processor board flexi-cable Eto the

motherboard.

Referring to Fig. 4.1, page 2:

20. Refit the cable clamp and secure it with 2 Torx screws D.

21. Refit the inner cover plate, ensuring lugs Pare located

correctly in the slots in the case and secure with a captive

screw C. Refit the tamper evident seal (if required).

22. Close and lock the door.

23. Restore the power supply to the recorder.

Fig. 4.6 Removing the display mounting plate

Fig. 4.7 Removing the display

Fig. 4.8 Removing the display

Fig. 4.9 Routing the keypad membrane cable

IN/RandC/005-EN Rev. A 12.2018

—

We reserve the right to make technical changes or modify the contents of this document

without prior notice. With regard to purchase orders, the agreed particulars shall prevail.

ABB does not accept any responsibility whatsoever for potential errors or possible lack of

information in this document.

We reserve all rights in this document and in the subject matter and illustrations contained

therein. Any reproduction, disclosure to third parties or utilization of its contents – in

whole or in parts – is forbidden without prior written consent of ABB.

—

ABB Limited

Measurement & Analytics

Howard Road, St. Neots

Cambridgeshire, PE19 8EU

Tel: +44 (0)0870 600 6122

Fax: +44 (0)1480 213 339

Email: instrumen[email protected]om

ABB Inc.

Measurement & Analytics

125 E. County Line Road

Warminster

PA 18974

USA

Tel: +1 215 674 6000

Fax: +1 215 674 7183

abb.com/measurement
