ABB B23 Manuel utilisateur
1
EN
B23/B24
INSTALLATION MANUAL
Contents
Disclaimer ......................................................................................... 2
Copyright........................................................................................... 2
Trademark......................................................................................... 2
Introduction ....................................................................................... 3
Product Overview.............................................................................. 3
Installation......................................................................................... 7
Installation Requirements.................................................................. 8
Troubleshooting ................................................................................ 8
Configuration..................................................................................... 9
Service and Maintenance.................................................................. 9
B23_B24_install.book Page 1 Thursday, May 30, 2013 4:01 PM
2
Disclaimer
The information in this document is subject to change without notice
and should not be construed as a commitment by ABB AB. ABB AB as-
sumes no responsibility for any errors that may appear in this docu-
ment.
In no event shall ABB AB be liable for direct, indirect, special, incidental
or consequential damages of any nature or kind arising from the use of
this document, nor shall ABB AB be liable for incidental or consequen-
tial damages arising from use of any software or hardware described in
this document.
Copyright
This document and parts thereof must not be reproduced or copied
without written permission from ABB AB, and the contents thereof must
not be imparted to a third party nor used for any unauthorized purpose.
The software or hardware described in this document is furnished un-
der a license and may be used, copied, or disclosed only in accordance
with the terms of such license.
© Copyright 2013 ABB AB. All rights reserved.
Trademark
ABB AB is a registered trademark of the ABB Group. All other brand or
product names mentioned in this document may be trademarks or reg-
istered trademarks of their respective holders.
B23_B24_install.book Page 2 Thursday, May 30, 2013 4:01 PM
3
EN EN
Introduction
The B23/B24 meters are electricity meters for DIN-rail mounting in dis-
tribution boards or small enclosures. The meters are connected directly
and/or via external current transformers.
Read the information in this manual carefully before you install the
equipment.
Product Overview
Part Description
1 Sealing points
2 Terminal block
2
11
3
4
5
6
178
9
5110
11
12
13
14
14
B23_B24_install.book Page 3 Thursday, May 30, 2013 4:01 PM
4
3 LED, flashes in proportion to the energy measured
4 Product data
5 Sealing points for sealable cover
6 Set button
7 Display
8 OK / Exit button
9 Down / Up button
10 Terminal for communication connection
11 Terminal for input / output connection
12 Optical communication interface
13 Sealing label
14 Sealable terminal cover
Technical Data Direct conn. Indirect conn.
Voltage
Voltage 3 x 220-240/380-415 V (-20% to +15%)
Part Description
B23_B24_install.book Page 4 Thursday, May 30, 2013 4:01 PM
5
EN EN
Terminal wire area
Tightening torque
1 - 25 mm²
2.0 Nm
0.5 - 10 mm²
1.5 Nm
Current
- base
I
b
- rated
I
n
- reference
I
ref
- maximum
I
max
- minimum
I
min
5 A
5 A
65 A
0.25 A
1 A
1 A
6 A
0.01 A
Frequency 50 or 60 Hz ± 5%
Accuracy 1%, 2% 0.5%, 1%
Material Polycarbonate in transparent front glass.
Glass reinforced polycarbonate in bottom
case and upper case. Polycarbonate in ter-
minal cover.
Weight
Operating temp. -40 °C to +70 °C
Storage temp. -40 °C to +85 °C
Humidity 75% yearly average, 95% on 30 days/year
Resistance to heat Terminal 960°C, cover 650°C (IEC 60695-
2-1)
Outputs
Technical Data Direct conn. Indirect conn.
B23_B24_install.book Page 5 Thursday, May 30, 2013 4:01 PM
6
Current 2 - 100 mA
Voltage 24 VAC - 240 VAC, 24 VDC - 240 VDC. For
meters with only 1 output 5 - 40VDC.
Pulse frequency 1-999999 pulse(s) per kWh or MWh
Pulse length 10 - 990 ms
Terminal wire area 0.5 - 1 mm²
Tightening torque 0.25 Nm
Comm. terminal
Terminal wire area 0.5 - 1 mm²
Tightening torque 0.25 Nm
Transformer ratios
Config. current ratio 1 - 9999 / 1 - 9
Pulse indicator
Pulse frequency 1000 imp/kWh 5000 imp/kWh
Pulse width 40 ms
EMC
Impulse voltage test 6 kV 1.2/50μs (IEC 60060-1)
Surge voltage test 4 kV 1.2/50μs (IEC 61000-4-5)
Technical Data Direct conn. Indirect conn.
B23_B24_install.book Page 6 Thursday, May 30, 2013 4:01 PM
7
EN EN
Installation
For information about how to mount and install the equipment, follow
the instructions in the Installation Guide at the end of this manual.
E Warning – Working with high voltage is potentially lethal. Per-
sons subjected to high voltage may suffer cardiac arrest, burn
injuries, or other severe injuries. To avoid such injuries, make
sure to disconnect the power supply before you start the instal-
lation.
Fast trans. burn test 4 kV ( IEC 61000-4-4 )
Immunity HF-fields 80 MHz - 2 GHz at 10 V/m (IEC61000-4-3)
Immunity conducted 2 kHz - 150 kHz
150 kHz – 80 MHz ( IEC 61000-4-6 )
RF Emission EN 55022, class B (CISPR22)
ESD 15 kV ( IEC 61000-4-2 )
Standards IEC 62052-11, IEC 62053-21,
IEC 62053-22, IEC 62053-23, GB/T
17215.211-2006, GB/T 17215.321-
2008,GB/T 17215.322-2008, GB 4208-
2008, EN 50470-1, EN 50470-3 category
A,B & C
Accuracy class Class 1 & class 2 Class 0,5 S &
class 2
Technical Data Direct conn. Indirect conn.
B23_B24_install.book Page 7 Thursday, May 30, 2013 4:01 PM
8
Electrical equipment should only be installed, accessed, ser-
viced and maintained by qualified electrical personnel.
E Warning – For safety reasons it is recommended that the
equipment is installed in a way that makes it impossible to
reach or touch the terminal blocks by accident.
The best way to make a safe installation is to install the unit in
an enclosure. Further, access to the equipment should be lim-
ited through use of lock and key, controlled by qualified electri-
cal personnel.
W Warning – The meters must always be protected by fuses on
the incoming side.
In order to allow for maintenance of transformer rated meters,
it is recommended that there should be a short circuiting device
installed near the meter.
Do not operate the equipment outside the specified technical
data.
Installation Requirements
To comply with the protection requirements the meter must be
mounted in protection class IP 51 enclosures, or better, according to
IEC 60259.
Meters with wireless communication should not be installed closer
than 20 cm from people.
Troubleshooting
If any of the following icons W VCappear in the display after the
installation has been completed and power has been connected to the
meter, refer to the B23/B24 User Manual for detailed information.
B23_B24_install.book Page 8 Thursday, May 30, 2013 4:01 PM
9
EN EN
Configuration
To configure the meter and change the default settings, follow the in-
structions in the Configuration Guide at the end of this manual.
Default Settings
The following table lists the default settings of the meter that normally
needs to be changed. Check the settings to see if any of them needs to
be changed.
N Note – For all other settings, including communication default
settings, refer to the B23/B24 User Manual.
Service and Maintenance
The meter contains no parts that can be repaired or exchanged. A bro-
ken meter must be replaced.
If the meter needs to be cleaned, use a lightly moistened cloth and a
mild detergent to wipe it.
C Caution – Be careful that no liquid gets into the meter since it
may damage the equipment.
Parameter Direct connected Transformer conn.
Ratios CT ---- 1
Pulse frequency 100 imp/kWh 10 imp/kWh
Pulse length 100 ms 100 ms
No. of wires 4 4
B23_B24_install.book Page 9 Thursday, May 30, 2013 4:01 PM
10
B23_B24_install.book Page 10 Thursday, May 30, 2013 4:01 PM
