Aaeon SBC-456 Manuel utilisateur
SBC-456/456E
Half-size 486 CPU Card with
Flat Panel/CRT SVGA Interface
FCC STATEMENT
THISDEVICECOMPLIESWITHPART15FCCRULES.OPERA-
TIONISSUBJECTTOTHEFOLLOWINGTWOCONDITIONS:
(1)THISDEVICEMAYNOTCAUSEHARMFULINTERFER-
ENCE.(2)THISDEVICEMUSTACCEPTANYINTERFERENCE
RECEIVEDINCLUDINGINTERFERENCETHATMAYCAUSE
UNDESIREDOPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO
COMPLY WITH THE LIMITS FOR A CLASS"A" DIGITAL
DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE RPEASON-
ABLE PROTECTION AGAINTST HARMFUL INTERFER-
ENCEWHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENER-
ATES,USES, AND CAN RADIATE RADIO FREQUENCY
ENERGYAND, IFNOTINSTATLLEDANDUSED IN ACCOR-
DANCEWITH THE INSTRUCTION MANUAL, MAY CAUSE
HARMFUL INTERFERENCE TO RADIO COMMUNICA-
TIONS. OPERATION OF THIS EQUIPMENT IN A RESIDEN-
TIALAREA IS LIKELY TO CAUSE HARMFUL INTERFER-
ENCE IN WHICH CASE THE USER WILL BE REQUIRED
TOCORRECT THE INTERFERENCE AT HIS OWN EX-
PENSE.
Copyright Notice
This document is copyrighted, 1998, by AAEON Technology Inc.
All rights are reserved. AAEON Technology Inc. reserves the right
to make improvements to the products described in this manual at
any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of AAEON Technology Inc. Information provided in
this manual is intended to be accurate and reliable. However,
AAEON Technology Inc. assumes no responsibility for its use, nor
for any infringements upon the rights of third parties which may
result from its use.
Acknowledgements
ALI is a trademark of Acer Laboratories, Inc.
AMD is a trademark of Advanced Micro Devices, Inc.
AMI is a trademark of American Megatrends, Inc.
AutoCAD and AutoShade are trademarks of Autodesk, Inc.
CHIPS Logotype is a registered trademark; Chips 65550 is a
trademark of Chip and Technologies, Inc.
IBM, PC/AT, PS/2 and VGA are trademarks of International
Business Machines Corporation.
Lotus, 1-2-3, and Symphony are trademarks of Lotus Development
Corp.
Microsoft Windows®and MS-DOS, are registered trademarks of
Microsoft Corp.
SMC is a trademark of Standard Microsystems Corporation.
TurboDLD Classic is a trademark of Panacea Inc.
UMC is a trademark of United Microelectronics Corporation.
WordPerfect is a trademark of WordPerfect Corporation.
VESA®is a registered trademark of Video Electronics Standards
Association.
All other product names or trademarks are properties of their
respective owners.
PartNo.2007456010 SBC-456 A1.1 1st Edition
Printed in Taiwan, July 1998
Packing list
Before you begin installing your card, please make sure that the
following materials have been shipped:
• 1 SBC-456/456ECPUcard
• 1 User Manual (this book)
• 1 Hard disk drive (IDE) interfacecable (40 pin)
• 1 Floppy disk drive interface cable (34 pin)
• 1 6-pin mini-DIN dual outlet adapter for keyboard and PS/2
mouse
• 1 Parallel port adapter (26 pins) and COM 2 adapter (for RS-232/
422/485)kit
• 1RJ-45adapter for 10Base-T Ethernet (SBC-456E only)
• 1Utilitydisk with Ethernet driver (SBC-456E only)
• 4 Utility disks with PCI SVGA utility programs and drivers for
DOS,Win3.1, Win95,WinNT3.51/4.0,and OS/2
• PC/104 Module mounting supports
• 1 bag of screws and miscellaneous parts
If any of these items are missing or damaged, contact your distribu-
tor or sales representative immediately.
Notice
DearCustomer,
Thank you for purchasing the SBC-456/456E board. The user
manual is designed to help you get the most out of the SBC-456/
456E, please read it thoroughly before you install and use the
board. The product that you have purchased comes with a one-
year warranty, but AAEON cannot be responsible for misuse of
the product. Therefore, we strongly urge that the first read the
manual before using the product.
To receive the lastest version of the user manual, please visit our
Web site at: Taiwan: www.aaeon.com.tw
U.S.A : www.aaeon.com
Contents
Chapter 1: General Information ................................... 1
Introduction ........................................................................... 2
Features.................................................................................. 3
Specifications ......................................................................... 4
Board layout........................................................................... 6
Card dimensions.................................................................... 7
Chapter 2: Installation .................................................. 9
Jumpers and connectors .................................................... 10
Locating jumpers and connectors .................................... 11
Setting jumpers ................................................................... 12
Safety precautions ............................................................... 13
Installing DRAM (SIMMs) ............................................... 14
InstallingSIMMs .....................................................................14
Removing SIMMs ...................................................................14
IDE hard drive connections (CN1) .................................. 15
Connecting the hard drive .......................................................15
IDE LED.................................................................................16
Display connector (CN9, CN2) ......................................... 17
Floppy drive connector (CN3) .......................................... 19
Connecting the floppy drive.....................................................19
Parallel (printer) connector (CN4) ................................... 20
Installing the retaining bracket.................................................20
Power connector (CN5)...................................................... 21
Serial port connectors (CN8, CN6) .................................. 22
RS-232 connector....................................................................22
RS-232/422/485 connector (CN6)...........................................23
Ethernet connectors (CN7) ............................................... 24
Keyboard and PS/2 mouse connectors (CN10, CN11).. 24
Ethernet link/active signal LED (J2)(J3)........................ 25
Buzzer or external speaker (J4)....................................... 26
Reserved IR connector (J5) ............................................. 26
Clear CMOS (J6)................................................................ 27
Power LED and keylock (J7) ............................................ 27
Fan power connector (J8) .................................................. 28
LCD SHF/ASHF clock selections (JP1) ......................... 28
LCD panel's voltage setting (JP2) ................................... 29
DOC address setting (JP3) ............................................... 29
Hardware reset (JP4) ......................................................... 30
RS-232/422/485 select (JP5)............................................. 30
DiskOnChip socket (U13)................................................. 31
Chapter 3: AMIBIOS Setup ........................................... 33
General Information............................................................ 34
Starting AMIBIOS setup ........................................................34
AMIBIOS main menu.............................................................34
Using a mouse with AMIBIOS setup .....................................35
Using the keyboard with AMIBIOS setup..............................35
Setup ..................................................................................... 36
Standard setup.........................................................................36
Advanced setup................................................................... 38
Chipset setup....................................................................... 45
Power management setup.................................................. 47
PCI/PnP setup ..................................................................... 49
Peripheral setup .................................................................. 54
Security ................................................................................. 57
Utility..................................................................................... 61
Default................................................................................... 63
Original ....................................................................................63
Optimal ....................................................................................63
Fail-Safe ..................................................................................63
Exiting AMIBIOS............................................................... 63
Chpater 4: Flat Panel/CRT Controller Display Drivers
and Utilities .............................................. 65
Software drivers .................................................................. 66
Hardware configuration ..........................................................66
Necessary prerequisites ..........................................................67
Before you begin .....................................................................67
WindowsÔÔ
ÔÔ
Ô95 ...................................................................... 68
WindowsÔÔ
ÔÔ
Ô3.1..................................................................... 69
Changing color schemes..........................................................70
DOS ....................................................................................... 70
Driver installation - DOS Setup...............................................70
Changing display drivers from DOS........................................71
OS/2....................................................................................... 71
Driverinstallation ....................................................................71
WIN-OS/2...............................................................................72
Driver diskette copy ................................................................73
WindowsÔNT3.51 ............................................................. 74
Driverinstallation ....................................................................74
WindowsÔNT4.0 ............................................................... 75
Driverinstallation ....................................................................75
Software utilities.................................................................. 76
The CHIPSDSP utility program..............................................76
The CHIPSCPL utility program..............................................77
Installing theutility ...................................................................77
How to use the utility ..............................................................77
Chapter 5: Ethernet Software Configuration ............ 81
Ethernet software configuration ....................................... 82
Appendix A: Watchdog Timer Demo Pro
gram .......................................83
Appendix B: Installing PC/104 Modules .....87
Installing PC/104 modules................................................. 88
Chapter 1 General Information 1
CHAPTER
1
General
Information
This chapter provides background
informationfor theSBC-456/456E.
Sections include:
• Card specifications
• Board layout
2SBC-456/456E User Manual
Introduction
TheSBC-456/456E is an all-in-one single board 486 computerwithan
onboardflatpanel/CRTSVGAcontrollerandPCIEthernetinterface
(SBC-456E). It packs all the functions of an industrial computer and
its display capabilities onto a single, half-size card. This means the
SBC-456/456E is your absolute best solution for embedded applica-
tions.
The onboard PCI-bus, flat panel/CRT SVGA controller uses the CHIPS
65550 chipset with up to 2 MB of video memory (onboard 1MB). This
chipset, used with the local PCI-bus, enables 32-bit graphic through-
put at up to 33 MHz. Excellent for display-intensive applications, it
supports various LCD types including TFT, STN, B/W, and EL.
The onboard Ethernet Realtek RTL 8029AS PCI bus Ethernet controller
supports remote boot ROM functions (SBC-456E only).
TheSBC-456/456E supports the M-Systems DiskOnChip 2000(option-
al) which is a new generation of high performance single-chip Flash
Disk. It provides a Flash Disk (as a BIOS expansion) which doesn't
require any bus, slots, or connectors. It is also the optimal solution for
Single Board Computers because of its small size, easy integration,
plug-and-play functionality, and its low power consumption. The
DiskOnChip is available in capacities from 2MB to 72MB and fits in a
standard 32-pin DIP socket.
Another feature of the SBC-456/456E is the inclusion of a high speed,
local bus IDE controller. This controller supports (through ATA PIO)
mode 3 and mode 4 hard disks, enabling data transfer rates in excess of
11 MB/second. Up to four IDE devices can be connected, including
large hard disks, CD-ROM drives, tape backup drives, or other IDE
devices. The built-in, enhanced IDE controller provides a 4-layer, 32-
bit, posted write buffer and a 4-layer, 32-bit read-prefetch buffer to
boost IDE performance.
Autres manuels pour SBC-456
1
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Aaeon Matériel informatique
Aaeon
Aaeon GENE-APL6 Manuel utilisateur
Aaeon
Aaeon PER-C41L Manuel utilisateur
Aaeon
Aaeon UPS-EDGE-EHL01 Manuel utilisateur
Aaeon
Aaeon RICO-3399 Manuel utilisateur
Aaeon
Aaeon AEC-6613 Manuel utilisateur
Aaeon
Aaeon COM-ICDB7 Manuel utilisateur
Aaeon
Aaeon SBC-400 Manuel utilisateur
Aaeon
Aaeon PCM-8200 Manuel utilisateur
Aaeon
Aaeon BOXER-6639 Manuel utilisateur
Aaeon
Aaeon SBC-350A Manuel utilisateur
Aaeon
Aaeon UP Squared Pro Manuel utilisateur
Aaeon
Aaeon RICO-3288 Manuel utilisateur
Aaeon
Aaeon EPIC-BT07-A13 Manuel utilisateur
Aaeon
Aaeon SBC-860 Manuel utilisateur
Aaeon
Aaeon UPN-EDGE-EHL01 Manuel utilisateur
Aaeon
Aaeon SBC-356 Manuel utilisateur
Aaeon
Aaeon UP Squared 6000 Edge Computing Kit Manuel utilisateur
Aaeon
Aaeon FSB-866G Manuel utilisateur
Aaeon
Aaeon ETX-701 Manuel utilisateur
Aaeon
Aaeon SBC-860 Manuel utilisateur
Manuels Matériel informatique populaires d'autres marques
EMC2
EMC2 VNX Series Manuel du propriétaire
Panasonic
Panasonic DV0PM20105 Manuel utilisateur
Mitsubishi Electric
Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur
Gigabyte
Gigabyte B660M DS3H AX DDR4 Manuel utilisateur
Raidon
Raidon iT2300 Manuel utilisateur
National Instruments
National Instruments PXI-8186 Manuel utilisateur
